MONOPLEX SLIDE OUT CONTROLLER
The MONOPLEX SLIDE OUT CONTROLLER is a power switching controller used to operate a slide out room
in an RV. Power from the battery of the vehicle is fed to this control. Inadvertent shorts at this box could result in
damage and/or injury.
All servicing of this box should be done only by a qualified Service Technician.
Tools required: Low current test light, DC voltmeter
Intellitec
www.intellitec.com
SERVICE MANUAL
SERVICE MANUAL
SLIDE OUT
ROOM
CONTROLLER
by Intellitec
Made in the USA
P/N 00-00193-000
P/N 00-00193-100
P/N 00-00193-300
CAUTION:
1485 Jacobs Rd.
Deland, FL. 32724
P/N 53-00193-100 Rev. E 032119
386.738.7307
Advertisement
Related Manuals for Intellitec MONOPLEX
Summary of Contents for Intellitec MONOPLEX
- Page 1 CAUTION: The MONOPLEX SLIDE OUT CONTROLLER is a power switching controller used to operate a slide out room in an RV. Power from the battery of the vehicle is fed to this control. Inadvertent shorts at this box could result in damage and/or injury.
- Page 2 PRODUCT DESCRIPTION The MONOPLEX Slide Out Room controller is designed to control the operation of a slide out room electrical mechanism. It automatically stops the slide out when it reaches its inner or outer limit, by sensing the current drawn by the motor.
- Page 3 MONOPLEX SLIDE OUT CONTROLLER SERVICE MANUAL SERVICE MANUAL SERVICE MANUAL TROUBLE SHOOTING POSSIBLE CAUSE/SOLUTION PROBLEM +12 volts not available. Check for +12 volts at Room won't slide out, indicator not on. controller. If the voltage is not present, check fuse/breaker feeding controller.
- Page 4 MONOPLEX SLIDE OUT CONTROLLER SERVICE MANUAL SERVICE MANUAL TYPICAL INSTALLATION Figure 1 1485 Jacobs Rd. Intellitec Deland, FL. 32724 386.738.7307 www.intellitec.com P/N 53-00193-100 Rev. E 032119...
