TOUCHLITE
W/8" WIRE
INSTALLATION INSTRUCTIONS
TOUCHLITE
by Intellitec
00-00098-100
Intellitec's TouchLite is a sensor pad activated control for outdoor lighting. When wired into an
existing 12 Volt outdoor porch light, it provides 30 seconds of light to allow the user to find the door key
and unlock the door in a darkened area. This particular model with the 8" pigtail wire was created to
allow for an extended limit for installation.
1485 Jacobs Rd.
Intellitec
Deland, FL 32724
386.738.7307
www.intellitec.com
P/N 53-00098-100 Rev. B 032119
Advertisement
Related Manuals for Intellitec TOUCHLITE
Summary of Contents for Intellitec TOUCHLITE
- Page 1 Intellitec 00-00098-100 Intellitec's TouchLite is a sensor pad activated control for outdoor lighting. When wired into an existing 12 Volt outdoor porch light, it provides 30 seconds of light to allow the user to find the door key and unlock the door in a darkened area. This particular model with the 8" pigtail wire was created to allow for an extended limit for installation.
- Page 2 2. Spread a layer of silicone sealer on the back of the TouchLite Button plate. Be careful not to get any sealer in the peg. The TouchLite Button has an 8" pigtail assembly attached. Push the faston end of the pigtail assembly into the hole on the front of the TouchLite.
