  • Page 1 DIAMANT M RUBINO PLUS Monosplit DC inverter in pompa di calore Monosplit DC inverter in heat pump Monosplit DC-inverter in warmtepomp MANUALE INSTALLAZIONE E MANUTENZIONE USE AND MAINTENANCE MANUAL INSTALLATIE- EN ONDERHOUDSHANDLEIDING Cod. 3QE46190 - Rev. 01 - 10/2020...

  • Page 2: Table Of Contents

    RUBINO PLUS 1. GENERAL SPECIFICATIONS ..................17 1.1 CONSIGNMENT OF THE MACHINE ..................17 1.2 FOREWORD ........................17 1.3 PRESENTATION OF THE UNIT..................17 1.4 DECLARATION OF CONFORMITY ..................17 1.5 TECHNICAL DATA ......................18 1.6 OVERALL DIMENSIONS ....................18 1.7 UNITDESCRIPTION ......................19 1.8 SAFETY REGULATIONS ....................20 2.

  • Page 3: General Specifications

    RUBINO PLUS 1. GENERAL SPECIFICATIONS 1.1 CONSIGNMENT OF THE MACHINE As soon as the machine is consigned, it is essential for the user to make sure that he has received all the items indicated on the consignment note and that the machine has not been damaged during transport. If damage is discovered, allow the forwarding agent to ascertain its entity and also inform our seller.

  • Page 4: Technical Data

    RUBINO PLUS 1.5 TECHNICAL DATA MODEL Power Supply 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50 V-F-Hz Cooling Capacity* 2050 2640 3520 5275 7035 Heating Capacity * 2350 2930 3810 5570 7330 Outdoor unit air flow 460/330/260 460/330/260 530/400/350 800/600/500 1090/770/610 (Max-med-min) Sound pressure level outdoor unit ** 37/32/22 37/32/22 37/32/22...

  • Page 5: Unitdescription

    RUBINO PLUS 1.7 UNITDESCRIPTION 1 - "fig. 2 -". CABINET FOR THE WALL INDOOR UNIT The cabinet housing the wall indoor unit is entirely made of ABS and also acts as a bearing structure. 2 - "fig. 2 -". VENTILATING UNIT The ventilating unit of the wall unit consists of a tangential fan.

  • Page 6: Safety Regulations

    RUBINO PLUS 1.8 SAFETY REGULATIONS Strictly comply with the following regulations to prevent injury to the operator or damage to the machine. • The unit installation must be done according to the installation rules valid in your country. • This installer's handbook, the user manual and the wiring diagrams are integral part of the machine.They must be kept with care and be ready to hand should the operators require them for consultation.

  • Page 7: Installation

    RUBINO PLUS 2. INSTALLATION 2.1 PACKING AND STORING All machines are packed in cardboard boxes specific for each unit. The indications required to correctly handle the appliance while storing and installing it are written on the packing. The storage temperature must be between -25°C and 55°C. Note: Do not throw the packing away exteriors to avoid envi- ronmental pollution.
  • Page 8 RUBINO PLUS Outdoor unit positioned on top and indoor unit on the bottom ("fig. 5 -"). In this case, in particular on mono split units, the suction line must have traps as indicated in the diagram in the installation manual of the outdoor units.The connection piping must be insulated.
  • Page 9 RUBINO PLUS The installation is summarised in the following figures "fig. 6 -": fig. 6 - 1: select installation location 2-3: attach mounting plate 4: drill wall hole 5: connect piping 6: connect wiring 7: prepare drain hose 8: wrap piping and cable 9: mount indoor unit Cod.

  • Page 10: Installing The Indoor Unit

    RUBINO PLUS 2.3 INSTALLING THE INDOOR UNIT Choice of place of installation. In compliance with the conditions indicated in the "Installation Diagrams" section, reported in the ma- nual of the outdoor units. position the unit as low as possible, leaving 15 cm of free space over the unit. It is recommended to observe the spaces indicated in the figure "fig.
  • Page 11 RUBINO PLUS Mod. 18 Shape internal unit fig. 10 - Mod. 24 Shape internal unit fig. 11 - Proceed as follows: Position the plate on the wall at a suitable height and fix it in place keeping it as level as possible (use a spirit level). Mark the position of the securing holes.

  • Page 12: Installation Option

    RUBINO PLUS 2.4 INSTALLATION OPTION The indoor unit may also be installed in the following positions: 1. With side outlet to the right. 2. With outlet facing downwards 3. With side outlet to the left. To install the unit with rear outlet to the left, proceed as indicated below: 1.

  • Page 13: Refrigerant Connections

    RUBINO PLUS 2.6 REFRIGERANT CONNECTIONS To connect the refrigerant lines, proceed as follows ("fig. 18 -"): • Match the ends of the previously flared pipe with those of the connections on the indoor units • Screw the union by hand and then tighten it with a suitable wrench (to avoid tension on the pipes it is advisable to also use a second wrench).

  • Page 14: Pipe Insulation

    RUBINO PLUS 2.8 PIPE INSULATION In order to ensure the system efficiency and its correct operation, it is necessary to use pre-insulated cooling connection lines easily available on the market.Pay also attention to the connection points according to what described. •...

  • Page 15: Setting And Work

    RUBINO PLUS 3. SETTING AND WORK 3.1 STARTING UP FOR THE FIRST TIME Before starting the unit for the first time, before starting the system for seasonal work or after a long period at a standstill, carry out the following preliminary inspections with regard to the electrical and cooling parts. 3.2 PRELIMINARY CHECKS ON THE ELECTRICAL PART Note: Before inspecting any electrical part, disconnect the power supply from the machine by unplugging it from the mains socket.
  • Page 16 RUBINO PLUS 2.6 COLLEGAMENTI FRIGORIFERI Per collegare le linee frigorifere procedere come indicato di seguito ("fig. 18 -"): • Far combaciare le estremità del tubo cartellato precedentemente con quelle degli attacchi posti sulle unità interne • Avvitare a mano il bocchettone e quindi serrarlo con l’ausilio di un chiave adeguata (per evitare tensioni sulle tubazioni è consigliabile agire con una controchiave).
  • Page 17 RUBINO PLUS 2.8 ISOLAMENTO TUBAZIONI E’ opportuno per garantire l’efficienza del sistema ed il suo corretto funzionamento che vengano utilizzate linee di collegamento fri- gorifero pre-isolate, comunemente reperibili in commercio. Si raccomanda inoltre di fare attenzione ai punti di collegamento secondo quanto descritto.
  • Page 18 RUBINO PLUS 3. MESSA IN FUNZIONE 3.1 PRIMO AVVIAMENTO Prima di eseguire il primo avviamento, prima di avviare l'impianto per il lavoro stagionale o dopo una lunga sosta è necessario ese- guire i seguenti controlli preliminari che riguardano la parte elettrica e la parte frigorifera. 3.2 CONTROLLO PRELIMINARE PARTE ELETTRICA N.B.: Prima di eseguire un qualsiasi controllo elettrico togliere l'alimentazione dalla macchina staccando la spina dalla presa di rete.
  • Page 19 RUBINO PLUS 1. GENERAL SPECIFICATIONS ..................17 1.1 CONSIGNMENT OF THE MACHINE ..................17 1.2 FOREWORD ........................17 1.3 PRESENTATION OF THE UNIT..................17 1.4 DECLARATION OF CONFORMITY ..................17 1.5 TECHNICAL DATA ......................18 1.6 OVERALL DIMENSIONS ....................18 1.7 UNITDESCRIPTION ......................19 1.8 SAFETY REGULATIONS ....................20 2.

  • Page 20: General Specifications

    RUBINO PLUS 1. GENERAL SPECIFICATIONS 1.1 CONSIGNMENT OF THE MACHINE As soon as the machine is consigned, it is essential for the user to make sure that he has received all the items indicated on the consignment note and that the machine has not been damaged during transport. If damage is discovered, allow the forwarding agent to ascertain its entity and also inform our seller.

  • Page 21: Technical Data

    RUBINO PLUS 1.5 TECHNICAL DATA MODEL Power Supply 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50 V-F-Hz Cooling Capacity* 2050 2640 3520 5275 7035 Heating Capacity * 2350 2930 3810 5570 7330 Outdoor unit air flow 460/330/260 460/330/260 530/400/350 800/600/500 1090/770/610 (Max-med-min) Sound pressure level outdoor unit ** 37/32/22 37/32/22 37/32/22...

  • Page 22: Unitdescription

    RUBINO PLUS 1.7 UNITDESCRIPTION 1 - "fig. 2 -". CABINET FOR THE WALL INDOOR UNIT The cabinet housing the wall indoor unit is entirely made of ABS and also acts as a bearing structure. 2 - "fig. 2 -". VENTILATING UNIT The ventilating unit of the wall unit consists of a tangential fan.

  • Page 23: Safety Regulations

    RUBINO PLUS 1.8 SAFETY REGULATIONS Strictly comply with the following regulations to prevent injury to the operator or damage to the machine. • The unit installation must be done according to the installation rules valid in your country. • This installer's handbook, the user manual and the wiring diagrams are integral part of the machine.They must be kept with care and be ready to hand should the operators require them for consultation.

  • Page 24: Installation

    RUBINO PLUS 2. INSTALLATION 2.1 PACKING AND STORING All machines are packed in cardboard boxes specific for each unit. The indications required to correctly handle the appliance while storing and installing it are written on the packing. The storage temperature must be between -25°C and 55°C. Note: Do not throw the packing away exteriors to avoid envi- ronmental pollution.
  • Page 25 RUBINO PLUS Outdoor unit positioned on top and indoor unit on the bottom ("fig. 5 -"). In this case, in particular on mono split units, the suction line must have traps as indicated in the diagram in the installation manual of the outdoor units.The connection piping must be insulated.
  • Page 26 RUBINO PLUS The installation is summarised in the following figures "fig. 6 -": fig. 6 - 1: select installation location 2-3: attach mounting plate 4: drill wall hole 5: connect piping 6: connect wiring 7: prepare drain hose 8: wrap piping and cable 9: mount indoor unit Cod.

  • Page 27: Installing The Indoor Unit

    RUBINO PLUS 2.3 INSTALLING THE INDOOR UNIT Choice of place of installation. In compliance with the conditions indicated in the "Installation Diagrams" section, reported in the ma- nual of the outdoor units. position the unit as low as possible, leaving 15 cm of free space over the unit. It is recommended to observe the spaces indicated in the figure "fig.
  • Page 28 RUBINO PLUS Mod. 18 Shape internal unit fig. 10 - Mod. 24 Shape internal unit fig. 11 - Proceed as follows: Position the plate on the wall at a suitable height and fix it in place keeping it as level as possible (use a spirit level). Mark the position of the securing holes.

  • Page 29: Installation Option

    RUBINO PLUS 2.4 INSTALLATION OPTION The indoor unit may also be installed in the following positions: 1. With side outlet to the right. 2. With outlet facing downwards 3. With side outlet to the left. To install the unit with rear outlet to the left, proceed as indicated below: 1.

  • Page 30: Refrigerant Connections

    RUBINO PLUS 2.6 REFRIGERANT CONNECTIONS To connect the refrigerant lines, proceed as follows ("fig. 18 -"): • Match the ends of the previously flared pipe with those of the connections on the indoor units • Screw the union by hand and then tighten it with a suitable wrench (to avoid tension on the pipes it is advisable to also use a second wrench).

  • Page 31: Pipe Insulation

    RUBINO PLUS 2.8 PIPE INSULATION In order to ensure the system efficiency and its correct operation, it is necessary to use pre-insulated cooling connection lines easily available on the market.Pay also attention to the connection points according to what described. •...

  • Page 32: Setting And Work

    RUBINO PLUS 3. SETTING AND WORK 3.1 STARTING UP FOR THE FIRST TIME Before starting the unit for the first time, before starting the system for seasonal work or after a long period at a standstill, carry out the following preliminary inspections with regard to the electrical and cooling parts. 3.2 PRELIMINARY CHECKS ON THE ELECTRICAL PART Note: Before inspecting any electrical part, disconnect the power supply from the machine by unplugging it from the mains socket.
  • Page 33 RUBINO PLUS 1. ALGEMENE KENMERKEN ..................... 31 1.1 INONTVANGSTNEMING VAN DE MACHINE ..............31 1.2 PRESENTATIE ........................31 1.3 PRESENTATIE VAN DE UNIT ....................31 1.4 VERKLARING VAN OVEREENSTEMMING ...............31 1.5 TECHNISCHE GEGEVENS ....................32 1.6 BUITENAFMETINGEN ......................32 1.7 COMPONENTEN BINNENUNIT ..................33 1.8 VEILIGHEIDSVOORSCHRIFTEN ..................34 2.

  • Page 34: Algemene Kenmerken

    RUBINO PLUS 1. ALGEMENE KENMERKEN 1.1 INONTVANGSTNEMING VAN DE MACHINE Controleer bij de inontvangstneming van de unit of u alle materialen die in het bijgaande document zijn vermeld hebt ontvangen en of de unit geen schade heeft geleden tijdens het transport. Indien dit wel het geval is, laat de transporteur dan de omvang van de geleden schade vaststellen en waarschuw ondertussen onze klantenbeheerafdeling.

  • Page 35: Technische Gegevens

    RUBINO PLUS 1.5 TECHNISCHE GEGEVENS MODEL Stroomvoorziening 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50 V-F-Hz Koelcapaciteit * 2050 2640 3520 5275 7035 Verwarmingscapaciteit * 2350 2930 3810 5570 7330 Luchtstroom 460/330/260 460/330/260 530/400/350 800/600/500 1090/770/610 (Max-med-min) Geluidsdrukniveaut ** 37/32/22 37/32/22 37/32/22 41/37/31 46/37/34,5 dB(A) (Max-med-min)

  • Page 36: Componenten Binnenunit

    RUBINO PLUS 1.7 COMPONENTEN BINNENUNIT 1- "Fig. 2 -". AFDEKKAST De afdekkast bestaat volledig uit ABS en fungeert ook als dra- agconstructie. 2- "Fig. 2 -". VENTILATIEGROEP De ventilatiegroep wordt gevormd door een dwarsstroomventila- tor. Dit maakt een zeer stille werking mogelijk. De motor is een borstelloze gelijkstroommotor 3- "Fig.

  • Page 37: Veiligheidsvoorschriften

    RUBINO PLUS 1.8 VEILIGHEIDSVOORSCHRIFTEN Onderstaande voorschriften moeten aandachtig worden opgevolgd om letsel en schade te voorkomen. • De installatie van de machine moet volgens de nationale installatienormen worden verricht • Deze handleiding van de installateur, de gebruikershandleiding en de schakelschema's zijn een essentieel onderdeel van de machine.

  • Page 38: Installatie

    RUBINO PLUS 2. INSTALLATIE 2.1 VERPAKKING EN OPSLAG Alle modellen zijn verpakt in voor elke unit specifiek karton. Op de verpakkingen zijn aanwijzingen aangebracht voor een correcte hantering tijdens de opslag en de inwerkingstelling. De op- slagtemperatuur moet tussen -25°C en 55°C liggen. NB: Laat het verpakkingsmateriaal niet in het milieu achter.
  • Page 39 RUBINO PLUS Buitenunit hoog en binnenunit laag geplaatst ("Fig. 5 -"). In dit geval moeten er met name op de mono split-units sifons op de zuigleiding worden aangebracht volgens de aanwijzingen in het schema in de installatiehandleiding van de buitenunits. Deze sifons zijn bedoeld om terugloop van olie naar de compressor mogelijk te maken.
  • Page 40 RUBINO PLUS De installatieprocedure van de binnenunit is grafisch samengevat in de volgende afbeelding "Fig. 6 -": Fig. 6 - 1: keuze van de plaats van installatie 2-3: bevestiging van de steunplaat 4: constructie van het doorvoergat door de muur 5: leidingaansluiting 6: elektrische verbindingen 7: voorbereiding van de condensafvoerleiding...

  • Page 41: Installatie Van De Binnenunit

    RUBINO PLUS 2.3 INSTALLATIE VAN DE BINNENUNIT Keuze van de installatieplaats. Met inachtneming van de omstandigheden beschreven in het deel "Installatieschema’s", te vinden in de handleiding van de buitenunits. Plaats de unit zo laag mogelijk, in ieder geval met 15 cm vrije ruimte boven de unit. Geadviseerd wordt om de aangegeven ruimten aan te houden ("Fig.
  • Page 42 RUBINO PLUS Mod. 18 Sagoma unità interna Fig. 10 - Mod. 24 Sagoma unità interna Fig. 11 - Ga als volgt te werk: Zet de plaat op de juiste hoogte tegen de wand en bevestig hem door hem zo horizontaal mogelijk te houden (gebruik een waterpas). Markeer de positie van de bevestigingsgaten.

  • Page 43: Installatie-Opties

    RUBINO PLUS 2.4 INSTALLATIE-OPTIES De binnenunit kan ook in de volgende posities worden geïnstalleerd: 1. Met de uitlaat aan de rechterzijde. 2. Met de uitlaat aan de achterzijde. 3. Met de uitlaat aan de linkerzijde. Ga als volgt te werk om de installaties uit te voeren met de uitlaat links achter: 1.

  • Page 44: Koelaansluitingen

    RUBINO PLUS 2.6 KOELAANSLUITINGEN Ga als volgt te werk om de koelleidingen aan te sluiten: • Laat de uiteinden van de eerder opgetrompte leiding ("Fig. 18 -") samenvallen met de aansluitingen op de binnenunits. • Draai met de hand de koppelmof vast en haal hem vervolgens aan met een geschikte sleutel (om spanningen op de leidingen te vermijden, is het raadzaam om een contrasleutel te gebruiken).

  • Page 45: Pijpisolatie

    RUBINO PLUS 2.8 PIJPISOLATIE Om de efficiëntie van het systeem en de juiste werking ervan te waarborgen, is het raadzaam om vooraf geïsoleerde koelkastaanslu- Het wordt ook aanbevolen om aandacht te besteden aan itleidingen te gebruiken, die gewoonlijk op de markt verkrijgbaar zijn. de verbindingspunten zoals beschreven.

  • Page 46: Inwerkingstelling

    RUBINO PLUS 3. INWERKINGSTELLING 3.1 EERSTE START Voor de eerste start of na een lange periode van stilstand moeten eerst de volgende controles worden uitgevoerd op het elektrische deel en het koelgedeelte, alvorens de installatie voor het seizoen te starten. 3.2 VOORAFGAANDE CONTROLE ELEKTRISCHE GEDEELTE NB: Sluit de voedingsspanning van de machine af door de stekker uit het stopcontact te halen alvorens elektrische controles uit te voeren.
  • Page 47 LAMBORGHINI Caloreclima è un marchio del gruppo FERROLI Spa 37047 San Bonifacio (Verona) Italy ¬ Via Ritonda 78/A ¬ tel. +39.045.6139411 ¬ fax +39.045.6100933 www.ferroli.com Made in China Cod. 3QEXXXX - Rev. 00 -...
