Chapter 2 General Information

MAIN COMPONENTS

See Figure 1. The radiographic table contains:
1 Tabletop
2 Emergency Shut-off Switch (Model QT-750 only)
3 Foot Pedal/FLOAT Push Button Inhibit Switch
4 Base
5 Foot Pedal(s) - Float (Model QT-740)
6 Float Push Button Switch
7 Patient Handgrips
8 Image Receptor Lock Release Switch
1
2
3
4
10
Float, Up and Down (Model QT-750)
Figure 1. Radiographic Table Main Components
8
Models QT-740 & QT-750 - Operator's Manual
7
6
5
