Operating Manual
Software Options:
GSM400/850/900/1800/1900-MS
for CMU-B21
R&S CMU-K20/-K21/-K22/-K23/-K24
1115.5900.02/6007.02/6107.02/6207.02/6307.02
Including the following extensions:
GPRS/EGPRS Software Extension
for all GSM Software Packages
R&S CMU-K42/-K43
1115.4691.02/1115.6907.02
AMR GSM for CMU 200
R&S CMU-K45
1150.3100.02
Printed in the Federal
Republic of Germany
1115.6088.12-12-
Test and Measurement
Division
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GSM400-MS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rohde & Schwarz GSM400-MS

Summary of Contents for Rohde & Schwarz GSM400-MS

  • Page 1 Test and Measurement Division Operating Manual Software Options: GSM400/850/900/1800/1900-MS for CMU-B21 R&S CMU-K20/-K21/-K22/-K23/-K24 1115.5900.02/6007.02/6107.02/6207.02/6307.02 Including the following extensions: GPRS/EGPRS Software Extension for all GSM Software Packages R&S CMU-K42/-K43 1115.4691.02/1115.6907.02 AMR GSM for CMU 200 R&S CMU-K45 1150.3100.02 Printed in the Federal Republic of Germany 1115.6088.12-12-...
  • Page 2 Dear Customer, throughout this manual, CMU-K20 to CMU-K24 and CMU-K42/-43/-K45 is generally used as an abbreviation for software options R&S CMU-K20 to R&S CMU-K24 and R&S CMU-K42/-K43/-K45. The Universal Radio Communication Tester R&S CMU 200 is abbreviated as CMU200.
  • Page 3 CMU-K20/-K21/-K22/-K23/-K24 Contents Tabbed Divider Overview Safety Instructions Certificate of Quality List of R&S Representatives Contents of Manuals for Universal Radio Communication Tester CMU Tabbed Divider Chapter 1: Installation Chapter 2: Getting Started Chapter 3: Manual Operation Chapter 4: Functions and their Application Chapter 5: Remote Control –...

  • Page 5: Table Of Contents

    CMU-K20/-K21/-K22/-K23/-K24 List of Figures List of Figures Fig. 4-1 Measurement menu Analyzer/Generator (example: P/t Norm. GMSK).........4.3 Fig. 4-2 Measurement menu Power – P/t Norm. GMSK..............4.9 Fig. 4-3 Trigger slot offset and slot count (for Trig. Slot Offset = 3)..........4.18 Fig.
  • Page 6 List of Figures CMU-K20/-K21/-K22/-K23/-K24 Fig. 4-48 Display of results (Power – P/t Multislot) ................4.107 Fig. 4-49 Display of measurement results (P/PCL menu)..............4.108 Fig. 4-50 Display of measurement results (P/t Access Burst menu) ..........4.109 Fig. 4-51 Power Configuration – Limits .................... 4.113 Fig.
  • Page 7 CMU-K20/-K21/-K22/-K23/-K24 List of Tables List of Tables Table 3-1 Measurement groups in Signalling and Non Signalling mode..........3.4 Table 4-1 GSM tolerances for spectrum due to modulation ............. 4.62 Table 4-2 GSM tolerances for spectrum due to modulation (absolute) ..........4.63 Table 4-3 GSM tolerances for spectrum due to switching plus modulation effects:......
  • Page 9 Certified Quality System Certified Environmental System ISO 9001 ISO 14001 DQS REG. NO 1954 QM DQS REG. NO 1954 UM Qualitätszertifikat Certificate of quality Certificat de qualité Sehr geehrter Kunde, Dear Customer, Cher client, Sie haben sich für den Kauf eines Rohde & You have decided to buy a Rohde &...
  • Page 11 Support Center Telefon / Telephone: +49 (0)180 512 42 42 Fax: +49 89 41 29 137 77 E-mail: CustomerSupport@rohde-schwarz.com Für technische Fragen zu diesem Rohde & Schwarz-Gerät steht Ihnen die Hotline der Rohde & Schwarz Vertriebs-GmbH, Support Center, zur Verfügung. Unser Team bespricht mit Ihnen Ihre Fragen und sucht Lösungen für Ihre Probleme.
  • Page 13 Adressen/Addresses FIRMENSITZ/HEADQUARTERS Phone Zweigniederlassung Süd, Geschäftsstelle +49 (89) 41 86 95-0 München +49 (89) 40 47 64 E-mail Mühldorfstraße 15 · D-81671 München Postfach 80 14 69 · D-81614 München Rohde & Schwarz GmbH & Co. KG +49 (89) 41 29-0 Mühldorfstraße 15 ·...
  • Page 14 Adressen/Addresses Canada ROHDE & SCHWARZ CANADA Inc. +1 (613) 592 80 00 Denmark ROHDE & SCHWARZ DANMARK A/S +45 (43) 43 66 99 555 March Rd. +1 (613) 592 80 09 Ejby Industrivej 40 +45 (43) 43 77 44 Kanata, Ontario K2K 2M5 cgirwarnauth@rscanada.ca 2600 Glostrup Canada...
  • Page 15 Adressen/Addresses India ROHDE & SCHWARZ India Pvt. Ltd. +91 (80) 535 23 62 Kenya Excel Enterprises Ltd +254 (2) 55 80 88 Bangalore Office +91 (80) 535 03 61 Dunga Road +254 (2) 54 46 79 No. 24, Service Road, Domlur rsindiab@rsnl.net P.O.Box 42 788 2nd Stage Extension...
  • Page 16 Adressen/Addresses Norway ROHDE & SCHWARZ NORGE AS +47 (23) 38 66 00 Sri Lanka LANKA AVIONICS +94 (1) 95 66 78 Enebakkveien 302 B +47 (23) 38 66 01 658/1/1, Negombo Road +94 (1) 95 83 11 1188 Oslo Mattumagala lankavio@sltnet.lk Ragama Oman...
  • Page 17 Adressen/Addresses United Arab ROHDE & SCHWARZ Emirates L.L.C. +971 (2) 631 20 40 Emirates P.O.Box 31156 +971 (2) 631 30 40 Abu Dhabi rsuaeam@emirates.net.ae United ROHDE & SCHWARZ UK Ltd. +44 (1252) 81 88 88 (sales) Kingdom Ancells Business Park +44 (1252) 81 88 18 (service) Fleet +44 (1252) 81 14 47...
  • Page 19 CMU-K20/-K21/-K22/-K23/-K24 Manuals Contents of Manuals for Universal Radio Communication Tester CMU The user documentation for the R&S CMU 200/300 is divided in an operating manual for the basic in- strument (including options CMU-B41, CMU-B17) and separate manuals for individual software and hardware options.
  • Page 20 Manuals CMU-K20/-K21/-K22/-K23/-K24 Service Manual Instrument The service manual instrument informs on how to check compliance with rated specifications, on in- strument function, repair, troubleshooting and fault elimination. It contains all information required for the maintenance of CMU by exchanging modules. Service Manual Modules The service manual modules is not delivered with the instrument but may be obtained from your R&S service department using the order number 1100.4903.91.
  • Page 21 CMU-K20/-K21/-K22/-K23/-K24 Manuals What's new in this Revision... This operating manual describes version V3.40 of the GSM-MS firmware package. Compared to previ- ous versions, this new firmware provides numerous extensions and improvements. The new features described in this manual are listed below. New Features Description Refer to...
  • Page 22 Manuals CMU-K20/-K21/-K22/-K23/-K24 Frequently Used Abbreviations Access Burst Abs. Absolute Acknowledged mode Automatic Gain Control Adaptive Multi-Rate (codec) Advice of Charge Atten. Attenuation Aux Tx Additional RF generator (signal) BCCH Allocation Bandw. Bandwidth Base Transceiver Station Color Code BCCH Broadcast Control Channel BCCH Broadcast Control Channel Bit Error Rate...
  • Page 23 CMU-K20/-K21/-K22/-K23/-K24 Manuals Trg. Trigger Training Sequence (Code) Update State Flag Vect. Vector 1115.6088.12 E-12...
  • Page 25 CMU-K20/-K21/-K22/-K23/-K24 Contents of Chapter 1 Contents 1 Installation and First Steps.................. Software Installation or Update...................... Creating a new Software Configuration ..................Enabling Software Options......................1115.6088.12 I-1.1...
  • Page 27 CMU-K20/-K21/-K22/-K23/-K24 Software Installation or Update 1 Installation and First Steps This chapter describes how to install, update or enable software options GSM400/850/900/1800/1900- MS for the Universal Radio Communication Tester CMU200. Before proceeding to perform any of the steps described in this manual, please make sure that the in- strument is properly connected and put into operation according to the instructions given in chapter 1 of the CMU200 manual.
  • Page 28 Software Installation or Update CMU-K20/-K21/-K22/-K23/-K24 Softkey no. 5 on the left softkey bar, Install software..., is used to install new software from an external storage medium. The CMU automatically recognizes the storage medium and indicates the corre- sponding slot number: Slot 0 or 1 denotes the left or right slot of the PCMCIA interface. If a floppy disk is used the menu option reads Install software version <version>...
  • Page 29 CMU-K20/-K21/-K22/-K23/-K24 Software Installation or Update The upgrade selection dialog displays a list of base software versions that can be combined with the new GSM MS software. Select the appropriate base version and press Upgrade. The new GSM MS option is added to the configuration or updates the previous GSM MS version of the configuration.
  • Page 30 Creating a new Software Configuration CMU-K20/-K21/-K22/-K23/-K24 The VersionManager is closed and the CMU is rebooted. The new firmware options are now operational and listed in the Menu Select menu together with their version number. Besides, the last software con- figuration installed is automatically taken as the active one in the next measurement session. Creating a new Software Configuration The CMU handles base software versions and network options on a separate basis.
  • Page 31 CMU-K20/-K21/-K22/-K23/-K24 Creating a new Software Configuration Note: This dialog is skipped if the new base software version is not compatible with any of the existing configurations. An incompatible new base software must be in- stalled as a new base software. If you wish to add a new configuration to your hard disk, press Install as new base.
  • Page 32 Enabling Software Options CMU-K20/-K21/-K22/-K23/-K24 Enabling Software Options A new CMU software option purchased is ready to operate after it is enabled by means of a key code supplied with the option. This key code is to be entered into the Option Enable popup window which in turn can be opened via from the Setup –...
  • Page 33 CMU-K20/-K21/-K22/-K23/-K24 Contents of Chapter 2 Contents 2 Getting Started ..................... Connecting the GSM Mobile Phone to the CMU ................2.2 Non Signalling Mode........................2.6 Signalling Mode ..........................2.14 Call Setup and Signalling Parameters .................. 2.14 Receiver Reports and Power Measurements ............... 2.20 Sensitivity Measurements .....................

  • Page 35: Getting Started

    CMU-K20/-K21/-K22/-K23/-K24 Preparing a GSM Mobile Phone Test 2 Getting Started The following chapter presents a sample GSM mobile test with the universal radio communication tester CMU. intended provide quick overview function groups GSM400/850/900/1800/1900-MS Non Signalling and GSM400/850/900/1800/1900-MS Signalling and their functionality and to lead through some basic tests that are commonly performed on GSM mobile phones.
  • Page 36 Preparing a GSM Mobile Phone Test CMU-K20/-K21/-K22/-K23/-K24 Preparing a GSM Mobile Phone Test This chapter describes how to use the CMU for GSM mobile phone tests. As a prerequisite for starting the session, the instrument must be correctly set up and connected to the AC power supply as de- scribed in chapter 1 of the operating manual for the CMU basic unit.
  • Page 37 CMU-K20/-K21/-K22/-K23/-K24 Preparing a GSM Mobile Phone Test Additional Information... Alternative Settings and Measurements ... on Step 1 " Mains switch on the rear panel chapter 1 of CMU manual When the mains switch at the rear is set to the OFF position, the complete instrument is disconnected from the power sup- ply.
  • Page 38 Preparing a GSM Mobile Phone Test CMU-K20/-K21/-K22/-K23/-K24 Step 4 MENU SELECT ! Press the Menu Select key to open the " Menu Select menu. ⇓ The Menu Select menu indicates the func- tion groups available. If a function group is selected the corresponding modes and measurement menus are indicated.
  • Page 39 CMU-K20/-K21/-K22/-K23/-K24 Preparing a GSM Mobile Phone Test Additional Information... Alternative Settings and Measurements ... on Step 4 " Menu Select menu chapter 3 The Menu Select menu shows all function groups installed on chapter 4 your CMU. All function groups GSMxxx-MS are subdivided in Frequently used measurement the two measurement modes Non Signalling and Signalling, menus can be stored together...

  • Page 40: Non Signalling Mode

    Non Signalling Mode CMU-K20/-K21/-K22/-K23/-K24 Non Signalling Mode In the Non Signalling mode, a GSM-specific RF signal can be generated and a RF signal with GSM characteristics can be analyzed. Compared to the Signalling mode test times may be reduced consid- erably.
  • Page 41 CMU-K20/-K21/-K22/-K23/-K24 Non Signalling Mode Additional Information... Alternative Settings and Measurements ... on Step 1 Analyzer/Generator menu chapter 4, p. 4.2 ff. The Analyzer/Generator menu contains three with associated The Analyzer/Generator settings hotkeys used to are also provided in the Analyzer •...
  • Page 42 Non Signalling Mode CMU-K20/-K21/-K22/-K23/-K24 Step 2 ! Press selected Power/t Norm. GMSK softkey again to call up the Power Configuration menu. ⇓ In the Control tab, the Power Configuration menu defines the scope of the Power measurement. The settings offered in this menu are discussed in section General Settings in chapter 3.
  • Page 43 CMU-K20/-K21/-K22/-K23/-K24 Non Signalling Mode Additional Information... Alternative Settings and Measurements ... on Step 2 " Power Configuration menu chapter 3. The Power Configuration menu contains three tabs defining Settings made in the Power Con- • Measurement control and statistical settings (Control), figuration menu apply to power •...
  • Page 44 Non Signalling Mode CMU-K20/-K21/-K22/-K23/-K24 ⇓ Step 4 Press the Marker/Display softkey twice to change the hotkeys displayed below " the diagram. ! Press the Display Area hotkey to open a ⇓ window offering a list of different zoom areas. If you select Left Upper Corner the CMU zooms in on the left upper corner of the burst.
  • Page 45 CMU-K20/-K21/-K22/-K23/-K24 Non Signalling Mode Additional Information... Alternative Settings and Measurements ... on Step 4 " Softkeys and hotkeys chapter 4, p. 4.9 ff. To enlarge the diagram area of the graphical measurement The Analyzer Level softkey con- menus the left softkey column is suppressed. The functional- figures the input level and exter- ity of each softkey on the right side is extended by hotkeys nal attenuation as well as the...
  • Page 46 Non Signalling Mode CMU-K20/-K21/-K22/-K23/-K24 ⇓ Step 6 ! Press the ESCAPE key to close the ESCAPE Power Configuration menu and return to the main menu. ⇓ The trace is now continuously measured and updated in the display. With the dis- play mode Maximum, which is indicated in the upper right corner of the diagram, trace values will be replaced only if a current...
  • Page 47 CMU-K20/-K21/-K22/-K23/-K24 Non Signalling Mode Additional Information... Alternative Settings and Measurements ... on Step 7 " Phase and frequency errors chapter 4, p. 4.38 ff. GSM equipment can use different modulation schemes; the The measurement principle for basic scheme is GMSK modulation, which is a constant- phase and frequency errors is envelope, binary, differential phase-shift keying scheme.

  • Page 48: Signalling Mode

    Signalling Mode CMU-K20/-K21/-K22/-K23/-K24 Signalling Mode In the Signalling mode the CMU first transmits a control channel signal to which the mobile is able to synchronize. A call can then be established from either the CMU or the mobile. The measurement must be synchronized to the signal transmitted by the mobile;...
  • Page 49 CMU-K20/-K21/-K22/-K23/-K24 Signalling Mode Additional Information... Alternative Settings and Measurements ... on Step 1 " BS Signal chapter 4, p. 4.161 ff. The CMU is able to generate two different RF carrier signals The control and traffic channels (traffic channel and BCCH control channel) which can be are configured in the BS Signal configured separately.
  • Page 50 Signalling Mode CMU-K20/-K21/-K22/-K23/-K24 ⇓ Step 3 ! Press the Network hotkey. The Network tab is displayed. The Network tab defines a variety of pa- rameters concerning the network and the operating mode of the mobile station. The purpose of these settings is to simu- late the operating conditions of a mobile station in the GSM network as realistically as possible.
  • Page 51 CMU-K20/-K21/-K22/-K23/-K24 Signalling Mode Additional Information... Alternative Settings and Measurements ... on Step 3 Network parameters chapter 4, p. 4.169 ff. The purpose of network parameter settings in the mobile test can be rather different from the original purpose (in the real GSM network).
  • Page 52 Signalling Mode CMU-K20/-K21/-K22/-K23/-K24 Step 5 ! Accept the call at your phone. ! Press Connect. Control to reopen the Connection Control menu. ⇓ The Connection (Call Established) pre- sents a comprehensive list of the signalling parameters for the current connection (see MS Capabilities on page 2.17).
  • Page 53 CMU-K20/-K21/-K22/-K23/-K24 Signalling Mode Additional Information... Alternative Settings and Measurements ... on Step 5 " Power control level (PCL) chapter 4, p. 4.112 ff. Dynamic power control is used in GSM networks to reduce PCL levels and power classes are the output power of the mobile station as far as possible. In listed in section Limits for the practice the base station sets the mobile power on a dimen- Average Burst Power in chap-...

  • Page 54: Receiver Reports And Power Measurements

    Signalling Mode CMU-K20/-K21/-K22/-K23/-K24 Receiver Reports and Power Measurements Besides the signalling parameters discussed above the receiver reports of the mobile station are transmitted to the CMU. Power and modulation measurements can be performed as in the Non Signal- ling mode. Step 1 The Overview menu indicates the most important settings in the function group...
  • Page 55 CMU-K20/-K21/-K22/-K23/-K24 Signalling Mode Additional Information... Alternative Settings and Measurements ... on Step 1 " MS Receiver Reports chapter 4, p. 4.135 ff. GSM mobile phones continuously measure the signal The exact definition of RX Level strength and quality of several nearby base stations. The and RX Quality is given in section measured values for the active base station (serving cell Panel MS Rcv.
  • Page 56 Signalling Mode CMU-K20/-K21/-K22/-K23/-K24 Receiver Quality Measurements Receiver Quality measurements evaluate parameters which characterize the quality of transmission on the complete signal path between CMU and mobile station. To this purpose the bits sent to the mobile station are looped back and retransmitted. The CMU compares the bits received with those sent and can thus calculate the percentage of faulty bits.
  • Page 57 CMU-K20/-K21/-K22/-K23/-K24 Signalling Mode Additional Information... Alternative Settings and Measurements ... on Step 1 Applications chapter 4, p. 4.125 ff. Within the Receiver Quality measurement group, the repeti- general discussion tion modes BER (single shot bit error rate tests) and BER Av- measurement control and appli- erage (continuous bit error rate tests) are treated as different cations see chapters 3 and 5.
  • Page 59 CMU-K20/-K21/-K22/-K23/-K24 Contents of Chapter 3 Contents 3 Manual Control ..................... Menu Structure..........................Test Modes ..........................Configurations.......................... Measurement Groups......................General Settings ..........................Menu Overview ..........................GSM-MS Non Signalling – General Configurations..............GSM-MS Non Signalling – Power and Modulation ..............GSM-MS Non Signalling – Spectrum ..................3.10 GSM-MS Signalling –...

  • Page 61: Manual Control

    The menus used to control GSM measurements can be arranged in different ways. From the functional point of view, they form the following groups: • The function groups GSM400-MS, GSM850-MS, GSM900-MS, GSM1800-MS and GSM1900-MS • The two test modes Signalling and Non Signalling •...

  • Page 62: Configurations

    Menu Structure CMU-K20/-K21/-K22/-K23/-K24 erably. The test signal may be inside or outside the designated GSM channel range. Normal burst signals are generated and analyzed. Various transmitter quality measurements (burst power versus time in one or several timeslots, average burst power in subsequent timeslots or frames, phase and frequency errors, error vector magnitude, I/Q imbalance and origin offset in the constellation dia- gram, adjacent channel power due to switching and due to modulation) can be performed.

  • Page 63: Measurement Groups

    CMU-K20/-K21/-K22/-K23/-K24 Menu Structure The Connect. Control softkey is located on the right side of the title bar of each Connection main and graphical measurement menu. It opens a popup menu with several Control tabs controlling • The signal generators and analyzers of the instrument (Analyzer and Gen- erator in Non Signalling, MS Signal and BS Signal in Signalling mode) •...
  • Page 64 Menu Structure CMU-K20/-K21/-K22/-K23/-K24 Table 3-1 Measurement Groups in the Signalling and Non Signalling Mode Non Signalling Signalling (GMSK and 8PSK-modulated signals supported) (GMSK-modulated signals supported) Analyzer/Generator Overview Shows the settings for the signals generated and analyzed Shows the settings for attempting a connection to the mobile by the instrument and presents an overview of the basic and presents an overview of the basic scalar power and scalar power and modulation results.

  • Page 65: General Settings

    CMU-K20/-K21/-K22/-K23/-K24 General Settings Non Signalling Signalling (GMSK and 8PSK-modulated signals supported) (GMSK-modulated signals supported) lation parameters. tion parameters. Application Phase Error 8PSK: Application Phase Error 8PSK: Diagram showing the phase error within the burst as a func- Diagram showing the phase error within the burst as a func- tion of time plus a statistical evaluation of 8PSK modulation tion of time plus a statistical evaluation of 8PSK modulation parameters.
  • Page 66 General Settings CMU-K20/-K21/-K22/-K23/-K24 user; the results are periodically updated A third repetition mode is available in remote control: Counting Repeated single shot measurement with a fixed number of sta- tistics cycles The repetition mode is set in the Control tab of the configuration popup-menus assigned to the three measurement groups Power, Modulation, and Spectrum.
  • Page 67 CMU-K20/-K21/-K22/-K23/-K24 General Settings mum and Max./Min. on the other hand, if the measurement extends over more than one statistic count (repetition mode Continuous, measurement time longer than one statistic count). After evaluation of the different traces, the burst power is logarithmized and plotted in a semi-logarithmic diagram.

  • Page 68: Menu Overview

    Menu Overview CMU-K20/-K21/-K22/-K23/-K24 Menu Overview GSM-MS Non Signalling – General Configurations 1115.6088.12 E-10...

  • Page 69: Gsm-Ms Non Signalling - Power And Modulation

    CMU-K20/-K21/-K22/-K23/-K24 Menu Overview GSM-MS Non Signalling – Power and Modulation 1115.6088.12 E-10...

  • Page 70: Gsm-Ms Non Signalling - Spectrum

    Menu Overview CMU-K20/-K21/-K22/-K23/-K24 GSM-MS Non Signalling – Spectrum 1115.6088.12 3.10 E-10...

  • Page 71: Gsm-Ms Signalling - General Configurations I

    CMU-K20/-K21/-K22/-K23/-K24 Menu Overview GSM-MS Signalling – General Configurations I 1115.6088.12 3.11 E-10...

  • Page 72: Gsm-Ms Signalling - General Configurations Ii

    Menu Overview CMU-K20/-K21/-K22/-K23/-K24 GSM-MS Signalling – General Configurations II 1115.6088.12 3.12 E-10...

  • Page 73: Gsm-Ms Signalling - Power And Modulation

    CMU-K20/-K21/-K22/-K23/-K24 Menu Overview GSM-MS Signalling – Power and Modulation 1115.6088.12 3.13 E-10...

  • Page 74: Gsm-Ms Signalling - Spectrum And Receiver Quality

    Menu Overview CMU-K20/-K21/-K22/-K23/-K24 GSM-MS Signalling – Spectrum and Receiver Quality 1115.6088.12 3.14 E-10...
  • Page 75 Contents of Chapter CMU-K20/K21/K22/K23/K24 Contents 4 Functions and their Application ................ 4.1 GSM Module Tests (Non Signalling) ....................4.2 Analyzer/Generator Menu......................4.2 Test Settings ........................4.3 Measurement Control ..................4.4 Selecting the Application...................4.5 Application-Specific Settings................4.5 Measurement Results....................4.6 Power Measurements ......................4.8 Measurement Menu (Power) ..................4.9 Test Settings .....................4.9 a) Measurement Control ................
  • Page 76 Contents of Chapter CMU-K20/K21/K22/K23/K24 a) Spectrum due to Modulation............... 4.62 b) Spectrum due to Switching..............4.65 Selection of Measurement Points (Spectrum Configuration – Meas X) ..4.67 Audio Measurements ......................4.68 Connection Control ....................... 4.69 RF Analyzer Settings (Connection Control – Analyzer) ..........4.69 Softkey-Oriented Version................
  • Page 77 Contents of Chapter CMU-K20/K21/K22/K23/K24 Frame Structure for Speech and Data Channels ............. 4.123 Statistical BER Tests ....................4.125 Measurement Menu (Receiver Quality)..............4.129 Test Settings ....................4.129 Measurement Results .................. 4.132 a) BER and BER Average..............4.132 b) BLER....................4.135 MS Rcv.

  • Page 79: Functions And Their Application

    Non Signalling: Analyzer/Generator Menu CMU-K20/K21/K22/K23/K24 4 Functions and their Application This chapter explains in detail all functions for the measurement of mobile stations supporting the GSM standard. The chapter is divided in two sections corresponding to the two function groups for module tests (GSM400/850/900/1800/1900-MS Non Signalling) mobile tests...

  • Page 80: Gsm Module Tests (Non Signalling)

    Non Signalling: Analyzer/Generator Menu CMU-K20/K21/K22/K23/K24 GSM Module Tests (Non Signalling) The structure of this section is based on the configuration and measurement groups in function group GSM400/850/900/1800/1900-MS Non Signalling, i.e. the menus of the graphical user interface. The menus are described in the following order: Overview of fundamental test settings and measurement results (Analyzer/Generator menu) Measurement menus Power, Modulation, and Spectrum: Purpose of the measurements and relation to the test specifications and conformance requirements, description of measurement...

  • Page 81: Fig. 4-1 Measurement Menu Analyzer/Generator (Example: P/T Norm. Gmsk)

    Non Signalling: Analyzer/Generator Menu CMU-K20/K21/K22/K23/K24 Measurement The output fields in the left half of the Analyzer/Generator menu show the current results measurement results. The results depend on the selected application. They are described in detail in section Measurement Results on p. The results displayed in the Analyzer/Generator menu represent only a small fraction of the power and modulation results that the CMU is able to acquire.

  • Page 82: Measurement Control

    Non Signalling: Analyzer/Generator Menu CMU-K20/K21/K22/K23/K24 The Frequency hotkey opens the input window Frequency. Frequency Input windows indicate the current parameter value (in this case: the current RF input frequency) or a list of the possible settings. Parameters are changed by •...

  • Page 83: Selecting The Application

    Non Signalling: Analyzer/Generator Menu CMU-K20/K21/K22/K23/K24 Selecting the Application The Application softkey selects the measurement application. The measurement Appli- control softkey (second softkey below Connect. Control) indicates the current cation application. Some of the hotkeys associated to the different softkeys, the Setup table, and the results in the Analyzer/Generator menu also vary as a function of the application.

  • Page 84: Measurement Results

    Non Signalling: Analyzer/Generator Menu CMU-K20/K21/K22/K23/K24 Measurement Results The results displayed in the Analyzer/Generator menu depend on the selected application: The results for the P/t Norm. GMSK and Ext. Phase Error GMSK applications are displayed simultaneously because both applications can be run in parallel. The results appear in two output fields, each containing three entries.
  • Page 85 Non Signalling: Analyzer/Generator Menu CMU-K20/K21/K22/K23/K24 The results for the Overview 8PSK application appear in two output fields with two and three rows, respectively. A header line indicates the name of the application and its measurement status. All results refer to the current burst. No comparison is made between different bursts, so the result does not depend on the statistical settings (e.g.

  • Page 86: Power Measurements

    Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 Power Measurements The menu group Power is designed to measure the RF output power of the MS transmitter. The power can be analyzed as a function of time in a single timeslot or in up to 4 consecutive timeslots. Furthermore, the CMU evaluates the average power and its evolution over several consecutive slots or frames.

  • Page 87: Fig. 4-2 Measurement Menu Power - P/T Norm. Gmsk

    Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 Measurement Menu (Power) The graphical measurement menu Power shows the results of the burst analysis (power measurement). • The measurement control softkey P/t Norm. GMSK, which changes to P/t Norm. 8PSK, P/Frame etc., depending on the power measurement application and on the modulation scheme selected) controls the power measurement, indicates its status (RUN | HLT | OFF) and opens the configuration menu Power Configuration.

  • Page 88: A) Measurement Control

    Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 a) Measurement Control Each Power application is controlled by means of the measurement control softkey below the Connect. Control softkey and the associated hotkeys. The P/t Norm. GMSK measurement control softkey (which changes to P/t Norm. P/t Norm.

  • Page 89: C) P/T Normal Gmsk

    Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 The P/t Normal 8PSK hotkey selects the power versus time measurement for P/t Normal 8PSK modulated normal burst signals (see explanation of GSM burst structure at 8PSK the beginning of section Limit lines (Power Configuration – Limit Lines) on page 4.32).
  • Page 90 Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 The hotkey Repetition determines the repetition mode of the measurement (Single Repetition Shot or Continuous measurement). Remote control CONFigure:POWer[:NORMal][:GMSK]:CONTrol:REPetition <Repetition>,<StopCond>,<Stepmode> The Stop Condition hotkey sets a stop condition for the measurement (None or On Stop Limit Failure).
  • Page 91 Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 Remote control [SENSE:]LEVel:MODE MANual | AUTomatic The RF Attenuation hotkey selects a strategy for tuning the RF analyzer. Attenuation Normal Input signal is kept unchanged Low Noise Enhanced mixer level. This setting ensures the full dynamic range of the CMU and is therefore recommended for Power and Spectrum measurements.
  • Page 92 Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 The following analyzer settings are described in more detail in section RF Analyzer Settings (Connection Control – Analyzer) on p. 4.69. The Frequency hotkey defines the frequency of the analyzed signal in MHz. Frequency Remote control [SENSe:]RFANalyzer:CHANnel <Number>...
  • Page 93 Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 Remote control CONFigure:RFGenerator:MODulation:TSEQuence:SELection <TSC> The Bit Modulation hotkey selects a bit sequence to be modulated onto the generator signal. Modulation Remote control CONFigure:RFGenerator:MODulation:BIT:SELection <Sequence> The Transmission hotkey determines the shape of the generator signal (burst Trans- signal or continuous wave with constant level).
  • Page 94 Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 Remote control No command, screen configuration only. The Rel. 2 hotkey switches the delta marker 2 on or off (use the ON/OFF key). Functions and remote control are analogous to delta marker 1. The D-Line hotkey switches the D-line in the test diagram on or off. D-Line The D-line is a horizontal, colored auxiliary line in the test diagram and is used for marking a level value and for measuring level differences.

  • Page 95: D) P/T Normal 8Psk

    Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 The Menus softkey displays the hotkey bar for changing to the other measurement Menus groups. The main measurement menu within each group is directly opened by pressing the associated hotkey. d) P/t Normal 8PSK The P/t Normal 8PSK test settings differ from the P/t Normal GMSK settings (see p.

  • Page 96: Fig. 4-3 Trigger Slot Offset And Slot Count (For Trig. Slot Offset = 3)

    Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 The hotkey Slot Count defines an integer number of timeslots to be measured. The Slot actual measured time range is larger than the integer number of slots because it Count comprises an additional display margin; for details see remote control command description.
  • Page 97 Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 The hotkey Info Box switches the info boxes for all displayed timeslots on or off. Info For a description of the info boxes see section P/t Multislot on p. 4.23 Remote control No command, display configuration only The Timing Offset hotkey shifts the burst by the entered number of symbol periods, Timing e.g.

  • Page 98: Fig. 4-4 Display Of Results (Power - P/T Norm. Gmsk)

    Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 f) P/Frame, P/Slot Graph, P/Slot Table The P/Frame, P/Slot Graph, and P/Slot Table test settings differ from the P/t Normal GMSK settings (see p. 4.11 ff.) in several respects: • The measurement statistics is simplified; only the repetition mode can be set. •...
  • Page 99 Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 the Connection Control menu (see section Table-Oriented Version on p. 4.73 ff.) Attenuation Setting for the attenuation of the input level (Normal, Low Noise, Low Distortion) as set in the Analyzer tab of the Connection Control menu (see section Table-Oriented Version on p.

  • Page 100: Fig. 4-5 Display Of Results (Power - P/T Norm. 8Psk)

    Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 The measurement result is displayed as a continuous measurement curve in the Measurement test diagram together with the limit lines, markers and the D-line, if defined. The curves (arrays) curve is derived from 668 equidistant measurement points with a ¼ symbol spacing covering a time range between –10 symbols and 156 ¾...

  • Page 101: Fig. 4-6 Display Of Results (Power - P/T Multislot)

    Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 c) P/t Multislot As shown in Fig. 4-6 below, the P/t Multislot measurement results are similar to the P/t Normal GMSK results. The following differences occur: • The first parameter line shows the selected Trig. Slot Offset, see p.

  • Page 102: D) P/Frame

    Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 The measurement result is displayed together with the limit lines, markers and the Measurement D-line (if defined) as a continuous measurement curve in the test diagram. The curves (arrays) curve is derived from equidistant measurement points with a ¼ symbol spacing the number of which depends on the number of timeslots measured (see Slot Count hotkey on p.

  • Page 103: Fig. 4-7 Display Of Results (Power - P/Frame)

    Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 Parameter line Frame table Fig. 4-7 Display of results (Power – P/Frame) Settings The essential settings are indicated in a parameter line above the test diagram. The line is identical to the first parameter line of the test diagram in the P/t Normal GMSK application.

  • Page 104: Fig. 4-8 Display Of Results (Power - P/Slot Menu)

    Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 e) P/Slot Graph The results displayed in the measurement menu Power, application P/Slot Graph, can be divided into two groups: • Settings • Measurement results, i.e. the average burst power in all eight slots of a TDMA frame The measurement results are indicated in a parameter line, the test diagram and a table: Parameter line Test diagram...

  • Page 105: Fig. 4-9 Display Of Results (Power - P/Slot Table)

    Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 f) P/Slot Table The results displayed in the measurement menu Power, application P/Slot Table, can be divided into two groups: • Settings • Measurement results, i.e. the average burst power in up to 512 consecutive TDMA timeslots. The measurement results are indicated in a parameter line, the test diagram and a table: Parameter line Slot table...

  • Page 106: Fig. 4-10 Power Configuration - Control

    Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 Measurement Configurations (Power Configuration) The popup menu Power Configuration contains three tabs to determine the parameters controlling the power measurement including the error tolerances. The popup menu Power Configuration is activated by pressing the measurement control softkey at the top right in the graphical measurement menu Power twice.
  • Page 107 Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 Remote control CONFigure:POWer[:NORMal][:GMSK]:CONTrol:DEFault ON | OFF etc. The Repetition parameter defines how often the measurement is repeated: Repetition Single Shot Single-shot measurement: the measurement is stopped after a statistics cycle (or after a stop condition is met, see below). A stopped measurement is indicated by the status display HLT in the Power softkey.
  • Page 108 Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 Continuous Display of minimum and maximum from all bursts already measured. The average value, however, is calculated according to the rule in Chapter 3, section General Settings. Remote control no display mode set explicitly, the four measurement curves are accessible via FETCh:ARRAy:POWer[:NORMal][:GMSK][:CURRent]? FETCh:ARRAy:POWer[:NORMal][:GMSK]:MINimum? FETCh:ARRAy:POWer[:NORMal][:GMSK]:MAXimum?
  • Page 109 Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 Average power denotes the RF carrier power averaged over the useful part of the measured burst (application P/t Normal 8PSK) or of the measured timeslot (application P/t Multislot with 8PSK modulation, see Slot Count softkey on p. 4.57). Owing to the characteristics of 8PSK modulation, the amplitude of the RF signal varies with the transmitted data.

  • Page 110: Limit Lines (Power Configuration - Limit Lines)

    Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 The Info Box parameter switches the info boxes for all displayed timeslots on or off. P/t Multislot – Info Box Remote control No command, display configuration only P/Slot Table – The input field Slot Count defines the total number of slots measured in the P/Slot Slot Count Table application.

  • Page 111: Fig. 4-11 Gsm Power/Time Template For Normal And Access Bursts With Gmsk Modulation

    Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 carrier power over the useful part of the burstduration of the burst as received by the CMU. The burst is fitted into the tolerance template such that the transition between bit 13/14 of the training sequence corresponds to the center of the useful part of the burst. This timing reference can be modified via the Time softkey, see section Test Settings on page 4.9.

  • Page 112: Fig. 4-12 Gsm Power/Time Template For Normal Bursts With 8Psk Modulation

    Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 P / dB +2.4 Normal burst: 147 symbols (**) µs 7056/13 (542.8) (***) t / µs Fig. 4-12 GSM power/time template for normal bursts with 8PSK modulation (according to GSM05.05 version 8.5.0; see explanation after previous figure) The limit lines for multislot configurations are based on the single-slot limit lines: Multislot According to GSM 11.10, the power/time template for multislot configurations coincides with...

  • Page 113: Fig. 4-14 Power Configuration - Limit Lines

    Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 Note: The CMU treats the areas where the lower limit lines are switched on as the useful part of the burst; the remaining areas form the guard period. The tester calculates the multislot tolerance template from the single-slot limit lines and the Multislot Guard level (see below) and normalizes it to the average RF carrier power in the useful part of the Meas.
  • Page 114 Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 Remote control CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE:UPPer:ALL:DYNamic:ENABle CONFigure:POWer[:NORMal]:EPSK:LIMit:LINE:UPPer:ALL:DYNamic:ENABle Static limit lines The Static limit lines are defined as follows: Area 1 to 16 Area number Enable Enabled (switch on) or disabled (and invisible) limit line. A disabled limit line implies that the limit check for the area is switched off as well.

  • Page 115: Limit Values For Average Burst Power (Power Configuration - Limits)

    Non Signalling: Power Measurements CMU-K20/K21/K22/K23/K24 Lower Limit Line The table Lower Limit Line defines the lower limit lines for normal bursts. All settings are analogous to the upper limit lines. Remote control CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE:LOWer<nr> [:STATic]:ENABle ON | OFF CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE:LOWer<nr>[:STATic] <StartTime>,<EndTime>,<StartRelLevel>,<EndRelLevel>, <StartAbsLevel>,<EndAbsLevel>,<Visibility> The Multislot Guard parameter defines the level in dB by which the upper limit line P/t Multislot –...

  • Page 116: Modulation Measurements

    Non Signalling: Modulation Measurements CMU-K20/K21/K22/K23/K24 Modulation Measurements The menu group Modulation comprises the functions for measurement of the modulation parameters of the RF signal transmitted by the mobile phone. The measurement results are displayed in the graphical measurement menu Modulation, the popup menu Modulation Configuration is used for configuration of the measurements.

  • Page 117: Fig. 4-15 Measurement Menu Modulation - Ext. Phase Err. Gmsk

    Non Signalling: Modulation Measurements CMU-K20/K21/K22/K23/K24 Menu Select Menu Select Fig. 4-15 Measurement menu Modulation – Ext. Phase Err. GMSK Test Settings The Analyzer Level, Analyzer Settings, Generator, and Menus test settings are identical with those in the Power menu (see section Test Settings on page 4.9).
  • Page 118 Non Signalling: Modulation Measurements CMU-K20/K21/K22/K23/K24 Pressing the Ext. Phase Err. GMSK softkey twice opens the popup menu Measurement Modulation Configuration (see page 4.50 ff.). Besides, the hotkeys Repetition, Stop configuration Condition, and Statistic Count defining the scope of the measurement and the Trig. Slot Offset hotkey are associated to the Ext.

  • Page 119: Fig. 4-16 Display Of Results (Modulation - Ext. Phase Err. Gmsk)

    Non Signalling: Modulation Measurements CMU-K20/K21/K22/K23/K24 Measurement Results The values shown in the measurement menu Modulation can be divided into three groups: • Setting values • Scalar measurement results (single values) • Arrays (the measurement curve plotted as a function of time) The values are indicated in a parameter line, the test diagram and a tabular overview below: Parameter line 1,2 Test diagram...
  • Page 120 Non Signalling: Modulation Measurements CMU-K20/K21/K22/K23/K24 Output fields and The output fields display the following scalar values: table TSC detected Detected training sequence of the current burst received from the mobile station (GSM 0 to 7 or Dummy or "---"), see Analyzer tab, section Table-Oriented Version on p.

  • Page 121: Measurement Menu (Modulation - 8Psk)

    Non Signalling: Modulation Measurements CMU-K20/K21/K22/K23/K24 Measurement Menu (Modulation – 8PSK) If the 8PSK modulation scheme is selected (see Application softkey in section Test Settings on page 4.39 ff.), the graphical measurement menu Modulation displays quantities characterizing the 8PSK modulation accuracy. •...

  • Page 122: Fig. 4-17 Modulation Errors In The I/Q Vector Diagram

    Non Signalling: Modulation Measurements CMU-K20/K21/K22/K23/K24 Error vector, The I/Q vector diagram shows the following Er = Re - Id quantities measured in the Modulation menu: | Er | = | Re – Id | Error vector magnitude (EVM) ∆ϕ Phase error Ideal modulation | Re | - | Id | Magnitude error...

  • Page 123: Fig. 4-19 Measurement Menu Modulation - Overview 8Psk

    Non Signalling: Modulation Measurements CMU-K20/K21/K22/K23/K24 The I/Q imbalance is measured for GMSK-modulated signals only. Fig. 4-19 Measurement menu Modulation – Overview 8PSK Test Settings The Analyzer Level, Analyzer Settings, Generator, and Menus test settings are identical with those in the Power menu (see section Test settings on page 4.9) . The Overview 8PSK measurement control softkey (which changes to EVM 8PSK, Magn.

  • Page 124: Measurement Results

    Non Signalling: Modulation Measurements CMU-K20/K21/K22/K23/K24 The Phase Error 8PSK hotkey selects the phase error of the modulation vector to Phase Err. be displayed. 8PSK The phase error is the difference in phase between the measured signal from the mobile station and an ideal signal waveform at the symbol points, see explanation in section Measurement Menu (Modulation –...

  • Page 125: Fig. 4-20 Display Of Results (Modulation - Overview)

    Non Signalling: Modulation Measurements CMU-K20/K21/K22/K23/K24 a) Scalar Results (Overview) The measurement menu for the application Overview 8PSK shows all scalar results. Most of the values are indicated in tabular form: Parameter line Output fields Output table and additional fields Fig. 4-20 Display of results (Modulation – Overview) Parameter line The parameter line contains the following settings: Max.

  • Page 126: Fig. 4-21 Display Of Results (Modulation - Evm / Phase Error / Magn. Error)

    Non Signalling: Modulation Measurements CMU-K20/K21/K22/K23/K24 Error Vect. Magn. Peak and effective (RMS averaged) value of the relative error vector magnitude Magn. Error Peak and RMS (relative) magnitude error Phase Error Peak and RMS phase error Origin Offset Origin offset in the I/Q constellation diagram Frequency Error Difference between measured and expected signal frequency Additional fields Three output fields to the right of output table indicate the following results and settings:...
  • Page 127 Non Signalling: Modulation Measurements CMU-K20/K21/K22/K23/K24 Parameter line The first parameter line contains the following settings: Max. Level Maximum input level set as in the Analyzer tab of the Connection Control menu (see section Table-Oriented Version on p. 4.73 ff.) Attenuation Setting for the external attenuation of the input level (Normal, Low Noise, Low Distortion) Freq.

  • Page 128: Measurement Configurations (Modulation Configuration)

    Non Signalling: Modulation Measurements CMU-K20/K21/K22/K23/K24 Remote control etc. READ[:SCALar]:MODulation:EVMagnitude:EPSK CALCulate[:SCALar]:MODulation:EVMagnitude:EPSK :LIMit:MATChing? Traces (arrays) The continuous trace in the test diagram shows the measured quantity as a function of time (in symbols). The display mode (Current, Max./Min., Average) for the trace is indicated in the upper right corner of the diagram. The measurement curve comprises the whole useful part of the normal burst (symbol 0 to 146 ¾).

  • Page 129: Fig. 4-22 Modulation Configuration - Control

    Non Signalling: Modulation Measurements CMU-K20/K21/K22/K23/K24 Fig. 4-22 Modulation Configuration – Control The settings can be defined separately for the different applications of the Modulation measurement group. Most functions are analogous to those of the menu Control in the menu group Power (see page 4.28).

  • Page 130: Fig. 4-23 Modulation Configuration - Limits

    Non Signalling: Modulation Measurements CMU-K20/K21/K22/K23/K24 [:CURRent]? FETCh:ARRAy:MODulation:XPERror[:GMSK][:BURSt]:MMAX? FETCh:ARRAy:MODulation:XPERror[:GMSK][:BURSt] :AVERage? etc. The Decode hotkey defines whether or not guard or tail bits are decoded (for Decode GMSK modulation only). Guard and tail bits are located at the beginning and the end of a normal burst (see Fig.
  • Page 131 Non Signalling: Modulation Measurements CMU-K20/K21/K22/K23/K24 The Ovw., EVM, ME, PE 8PSK table section defines all limits for 8PSK-modulated Ovw., EVM, ME, signals. The limits are set independently for the display modes Current and PE 8PSK Max./Min. on one hand, Average on the other hand; see section Measurement Control (Modulation Configuration –...
  • Page 132 Non Signalling: Modulation Measurements CMU-K20/K21/K22/K23/K24 quantities must fall below the specified positive limit). In contrast to the Power measurement where individual limit lines can be switched off, the Modulation limit check is always active. Remote control CONFigure:MODulation:XPERror[:GMSK]:LIMit[:CURRent] <PhaseErrorPeak>,<PhaseErrorRMS>,<FrequencyError> 1115.6088.12 4.54 E-11...

  • Page 133: Spectrum Measurements

    Non Signalling: Spectrum Measurements CMU-K20/K21/K22/K23/K24 Spectrum Measurements The menu group Spectrum comprises the functions for measurement of the off-carrier power originating from the modulation process (spectrum due to modulation) and from the bursty nature of the RF signal, i.e. the power ramping up and down (spectrum due to switching) . The two spectra are treated as two different applications;...

  • Page 134: Fig. 4-24 Measurement Menu Spectrum Due To Modulation

    Non Signalling: Spectrum Measurements CMU-K20/K21/K22/K23/K24 Menu Select Menu Select Fig. 4-24 Measurement menu Spectrum due to Modulation Test Settings The Analyzer Level, Analyzer Settings, Generator, Marker, and Menus test settings are identical with those in the Power menu (see section Test settings on page 4.9) . The following softkeys and hotkeys differ from the Power measurement: The Modulation GMSK softkey controls the measurement and indicates its status Modulation...
  • Page 135 Non Signalling: Spectrum Measurements CMU-K20/K21/K22/K23/K24 The following parameter is specific to the Spectrum due to Switching measurement and provided for both GSMK and 8PSK modulation: Slot Count defines whether a single timeslot or all timeslots are considered for the Slot Spectrum due to Switching measurement: Count Single...

  • Page 136: Fig. 4-25 Display Of Results (Spectrum Due To Modulation)

    Non Signalling: Spectrum Measurements CMU-K20/K21/K22/K23/K24 The Switching GMSK hotkey selects the spectrum due to switching for GMSK Switching modulated signals to be displayed. In this mode, the power at the nominal GMSK frequency and the relative power at up to 4 neighboring frequencies is displayed in a single graph, see p.
  • Page 137 Non Signalling: Spectrum Measurements CMU-K20/K21/K22/K23/K24 Attenuation Setting for the external attenuation of the input level (Normal, Low Noise, Low Distortion) Freq. Offset Frequency offset compared to the nominal channel frequency Chan./Trig. Slot Offs. RF channel and trigger slot offset (see Trig. Slot Offset hotkey on p.

  • Page 138: Fig. 4-26 Display Of Results (Spectrum Due To Switching)

    Non Signalling: Spectrum Measurements CMU-K20/K21/K22/K23/K24 b) Spectrum due to Switching In the Spectrum due to Switching measurement, the maximum level measured at a series of fixed frequency points around the selected RF frequency is displayed. The results and the corresponding settings are indicated in two parameter lines, the test diagram (bar graph), and an info box: Parameter lines Bar graph and...

  • Page 139: Fig. 4-27 Spectrum Configuration - Control

    Non Signalling: Spectrum Measurements CMU-K20/K21/K22/K23/K24 Measurement Configurations (Spectrum) The popup menu Spectrum Configuration contains three tabs to define the parameters of the spectrum measurement including the error tolerances. The popup menu Spectrum Configuration is called up by pressing the measurement control softkey in the top right of the graphical measurement menu Spectrum twice (this softkey reads due to Modulation or due to Switching , depending on the selected application).

  • Page 140: Table 4-1 Gsm Tolerances For Spectrum Due To Modulation

    Non Signalling: Spectrum Measurements CMU-K20/K21/K22/K23/K24 Cont. Stat. Mode The Cont. Stat. Mode parameter defines the analyzer settings for the Spectrum due to Switching measurement: Peak Hold The switching transients are equal to the maximum MS level measured, only updated after a new measurement is started Statistic Count The switching transients are equal to the peak value over one measurement cycle (statistic count), updated after each cycle.

  • Page 141: Fig. 4-28 Spectral Mask As Specified For Gsm Mobile Stations

    Non Signalling: Spectrum Measurements CMU-K20/K21/K22/K23/K24 In the frequency range above 400 kHz from the carrier and for output powers between 33 dBm and 39 dBm (GSM400/850/900), the limit depends linearly on the output power. The resulting spectral mask for GMSK modulation is shown below ( Fig.

  • Page 142: Fig. 4-29 Spectrum Configuration - Limit Lines

    Non Signalling: Spectrum Measurements CMU-K20/K21/K22/K23/K24 Fig. 4-29 Spectrum Configuration – Limit Lines The Default All Settings switch assigns default values to all settings in the Limits tab Default Settings (the default values are quoted in the command description in chapter 6 of this manual).

  • Page 143: Table 4-3 Gsm Tolerances For Spectrum Due To Switching Plus Modulation Effects

    Non Signalling: Spectrum Measurements CMU-K20/K21/K22/K23/K24 b) Spectrum due to Switching The limit lines for the spectrum due to switching as specified in GSM 05.05 and GSM 11.10 cover offset frequencies between 0.4 and 1.8 MHz. They are equal for all three GSM bands but depend on the output power of the mobile station.

  • Page 144: Fig. 4-30 Spectrum Configuration - Limits

    Non Signalling: Spectrum Measurements CMU-K20/K21/K22/K23/K24 Fig. 4-30 Spectrum Configuration – Limits The Default All Settings switch assigns default values to all settings in the Limits tab Default Settings (the default values are quoted in the command description in chapter 6 of this manual).

  • Page 145: Selection Of Measurement Points (Spectrum Configuration - Meas X)

    Non Signalling: Spectrum Measurements CMU-K20/K21/K22/K23/K24 Selection of Measurement Points (Spectrum Configuration – Meas X) The tab Meas X defines at which frequencies a Spectrum measurement is performed. Fig. 4-31 Spectrum Configuration – Meas X All settings can be defined separately for the two applications due to Modulation and due to Switching . Default Settings The Default All Settings switch assigns default values to all settings in the Meas X tab (the default values are quoted in the command description in chapter 6 of this...

  • Page 146: Audio Measurements

    Non Signalling: Audio Measurements CMU-K20/K21/K22/K23/K24 Audio Measurements The menu group Audio comprises the functions for generating and measuring single or multitone audio signals. The menu group is available with option CMU-B41, Audio Generator and Analyzer . All Audio menus and remote-control commands are described in the CMU 200/300 operating manual. The Audio option supports two independent test circuits.

  • Page 147: Fig. 4-32 Connection Control - Analyzer (Softkey)

    Non Signalling: Connection Control CMU-K20/K21/K22/K23/K24 Connection Control The popup menu Connection Control contains several tabs to configure the inputs and outputs of the CMU and the respective signals in the function group GSM400/850/900/1800/1900-MS Non Signalling and the trigger settings . The menu group is activated via the softkey Connect.

  • Page 148: Table 4-4 Gsm Channels In Uplink Direction

    Non Signalling: Connection Control CMU-K20/K21/K22/K23/K24 The Max. Level softkey sets the maximum expected input level (overload level). Max. This level corresponds to the maximum peak envelope power (PEP) of the GSM Level signal that the CMU is able to measure. For GSM signals, the PEP is very close to the average burst power (low crest factor), however, it is appropriate to allow for a display margin of a few dB.
  • Page 149 Non Signalling: Connection Control CMU-K20/K21/K22/K23/K24 Frequency Channel GSM1800 Frequency Channel GSM1900 / [MHz] Band / [MHz] Band – – ↓ ↓ ↓ ↓ 1710 1850 1710.2 1850.2 ↓ ↓ ↓ ↓ GSM 1800 band GSM 1900 band 1784.8 1909.8 1785 1910 –...

  • Page 150: Fig. 4-33 Bit Structure Of A Gsm Normal Burst

    Non Signalling: Connection Control CMU-K20/K21/K22/K23/K24 The training sequence is located in the middle of the symmetrical normal burst and is used for synchronization and to assess the transmission conditions in the RF channel. Useful Information Useful Information Training sequence Tail bits (end or start bit) Bits 0 to 2, 145 to 147 Useful information Bits 3 to 59, 88 to 144...

  • Page 151: Fig. 4-34 Connection Control - Analyzer (Table)

    Non Signalling: Connection Control CMU-K20/K21/K22/K23/K24 The Wideband Power softkey controls the wideband power measurement and Wideband indicates its status (RUN | HLT | OFF) . The status can be changed after softkey Power selection (pressing once) by means of the ON/OFF key or the CONT/HALT key. The measurement result is in units of dBm.
  • Page 152 Non Signalling: Connection Control CMU-K20/K21/K22/K23/K24 The following settings are not provided in the table-oriented version of the Analyzer tab: Default Settings The Default All Settings switch assigns default values to all settings in the Analyzer tab (the default values are quoted in the command description in chapter 6 of this manual).

  • Page 153: Generator Settings (Connection Control - Generator)

    Non Signalling: Connection Control CMU-K20/K21/K22/K23/K24 The RF Attenuation parameter defines how the RF analyzer of the CMU is tuned to Analyzer Level – meet the requirements of the current measurement type. In general, a compromise RF Attenuation between the acceptable noise level in the displayed result and the contribution of internally generated distortion must be reached.

  • Page 154: Fig. 4-35 Connection Control - Generator (Softkey)

    Non Signalling: Connection Control CMU-K20/K21/K22/K23/K24 • The generator frequency (RF Channel, Frequency Offset) • A Training Sequence and a Bit Modulation sequence to be modulated onto the generated RF signal • The Transmission mode (continuous or burst signal) Fig. 4-35 Connection Control –...

  • Page 155: Table 4-5 Gsm Channels In Downlink Direction

    Non Signalling: Connection Control CMU-K20/K21/K22/K23/K24 compensating for the external attenuation or gain. Otherwise it is adapted to the level closest to the shifted default value. Error messages If the level defined for RF Level is too high or too low, a window will appear with the error message "<RF_Level>...
  • Page 156 Non Signalling: Connection Control CMU-K20/K21/K22/K23/K24 Frequency Channel GSM1800 Frequency Channel GSM1900 / [MHz] Band / [MHz] Band – – ↓ ↓ ↓ ↓ 1805 1930 1805.2 1930.2 ↓ ↓ ↓ ↓ GSM 1800 band GSM 1900 band 1879.8 1989.8 – –...

  • Page 157: Fig. 4-36 Connection Control - Generator (Table)

    Non Signalling: Connection Control CMU-K20/K21/K22/K23/K24 The Bit Modulation softkey defines a bit sequence that is modulated onto the RF carrier signal. The following types of modulation sequence can be selected: Modulation No signal superimposed, "empty" carrier All 0 Modulation sequence consisting of zeros PRBS Pseudo random bit sequence Dummy Bursts...

  • Page 158: Fig. 4-37 Connection Control - Af/Rf Connectors

    Non Signalling: Connection Control CMU-K20/K21/K22/K23/K24 The Default All Settings switch assigns default values to all settings in the Analyzer Default Settings tab (the default values are quoted in the command description in chapter 6 of this manual). Remote control – AF/RF Connectors (Connection Control –...
  • Page 159 Non Signalling: Connection Control CMU-K20/K21/K22/K23/K24 The RF Output softkey defines which of the three connectors RF 1, RF 2 and RF 3 OUT is to be used as RF output connector. A symbol indicates the selected RF Output output. Note: It is possible to combine any pair of input and output connectors.

  • Page 160: Fig. 4-38 Connection Control - Synchronization

    Non Signalling: Connection Control CMU-K20/K21/K22/K23/K24 UNIVERSAL RADIO COMMUNICATION TESTER CMU 200 11 00.00 08.02 FUNCTION SYSTEM MENU DATA CTRL SELECT HELP SETUP PRINT DATA VARIATION DATA 1 M/µ µV DATA 2 dBµV - x) dBm Ext. Att. Input (set): x dB Attenuator AUX 3 _ µ...
  • Page 161 Non Signalling: Connection Control CMU-K20/K21/K22/K23/K24 The associated field allows to select between two alternatives: Int. (10 MHz) Internal synchronization by means of a 10 MHz reference frequency (TCXO or OCXO, CMU-B11/-B12). Ext. (at REF IN) Synchronization to external reference signal to be fed in via input REF IN.

  • Page 162: Trigger (Connection Control - Trigger)

    Non Signalling: Connection Control CMU-K20/K21/K22/K23/K24 The softkey REF OUT 2 configures a network-specific system clock REF OUT 2 to be fed to the output REF OUT 2 at the rear of the instrument. OUT 2 The associated field permits to select between two alternatives: OFF (other network) The clock frequency of the current function group is not fed to the output REF OUT 2 .

  • Page 163: Fig. 4-39 Connection Control - Trigger

    Non Signalling: Connection Control CMU-K20/K21/K22/K23/K24 Fig. 4-39 Connection Control – Trigger The Default Settings checkbox assigns the default setting to all functions in the Default Settings Trigger tab (the default values are quoted in the command description in chapter 6 of this manual).
  • Page 164 Non Signalling: Connection Control CMU-K20/K21/K22/K23/K24 The Value parameters define the trigger thresholds if the measurement is triggered RF Power / by the RF Power or IF Power (see Source function above) respectively. Both IF Power thresholds are defined relative to the maximum input level set in the Analyzer tab (see Max.

  • Page 165: Fig. 4-40 Connection Control - I/Q-If

    Non Signalling: Connection Control CMU-K20/K21/K22/K23/K24 I/Q-IF Interface (Connection Control – I/Q-IF) The I/Q-IF tab is part of the second group of tabs in the Connection Control menu. It is accessible after pressing the 1 / 2 toggle hotkey once. Pressing 1 / 2 again switches back to the first group of tabs described above.

  • Page 166: Table 4-6 I/Q-If Scenarios And Path Settings

    Non Signalling: Connection Control CMU-K20/K21/K22/K23/K24 Selects the TX signal path, leaving the RX Path unchanged but adapting the I/Q-IF RX Path test scenario to the new RX/TX path combination: If the combination corresponds to a predefined scenario, then I/Q-IF is set to the predefined scenario; otherwise it is set to User-defined .

  • Page 167: Gsm Mobile Tests (Signalling)

    CMU-K20/K21/K22/K23/K24 Signalling: Setting up a Connection GSM Mobile Tests (Signalling) The structure of this section is based on the configuration and measurement groups defined in function group GSM400/850/900/1800/1900-MS Signalling. The menus are described in the following order: 1. Call setup to the mobile station (Connection Control – Connection) 2.

  • Page 168: Fig. 4-41 Signalling States Of The Cmu (Circuit Switched Mode)

    CMU-K20/K21/K22/K23/K24 Signalling: Setting up a Connection Send SMS Signal On Signal Off Signal On Signal Off Signal Call to MS / MS Power Down Signal Off MS Synchronization / MS Power Down Call to MS Synchronized Alerting Call Release (also: Alert Timeout, MS Call Release) Signal MS Synchronization / Send...

  • Page 169: Fig. 4-42 Connection Control - Connection (Signal Off)

    CMU-K20/K21/K22/K23/K24 Signalling: Setting up a Connection CMU in the state Signal On (BS Signal) • The Network code • Selected AF and RF connectors and external attenuation (AF/RF • Status and result of wideband peak power measurement (Wideband Power) Besides, it contains softkeys which lead to other operating modes or signalling states: •...

  • Page 170: Connection Control With Signal (State Signal On)

    CMU-K20/K21/K22/K23/K24 Signalling: Setting up a Connection The Main Service softkey selects Circuit Switched or Packet Data (GPRS or Main EGPRS) operation of the MS under test. This softkey is disabled (grayed) if the Service Network Support is set to GSM. See also section on p.

  • Page 171: Fig. 4-43 Connection Control - Connection (Signal On)

    CMU-K20/K21/K22/K23/K24 Signalling: Setting up a Connection • Switch off the control channel signal for synchronization (Signal Off –> state Signal Off) • Set up a call to the mobile station (Connect Mobile –> state Alerting) • Short message service (Send SMS –> return to state Signal On) The popup menu Connection (Signal On) is opened after the control channel signal of the CMU is switched on (Softkey Signal On in the popup menu Connection (Signal On)).
  • Page 172 CMU-K20/K21/K22/K23/K24 Signalling: Setting up a Connection Remote control PROCedure:SIGNalling[:CSWitched]:ACTion MTC The Send SMS softkey activates the short message service. It opens the Short Send Message Service popup menu: A text with a maximum of 160 alphanumeric characters can be entered in the input field.

  • Page 173: Fig. 4-44 Overview Of Settings And Measurements

    CMU-K20/K21/K22/K23/K24 Signalling: Overview Menu Overview Menu The Overview menu displays the essential results of the P/t Norm. GMSK, the Ext. Phase Err. GMSK, and the Overview 8PSK applications and provides access to the most important measurement settings. In particular, it configures the GSM downlink signal that the CMU transmits in order to set up and control a connection (BS Signal) and defines the properties of the uplink signal expected from the device under test (MS Signal).

  • Page 174: Test Settings

    CMU-K20/K21/K22/K23/K24 Signalling: Overview Menu Test Settings The settings for the Overview menu are accessible via softkey/hotkey combinations. The function of the measurement control softkeys P/t Norm. GMSK, Ext. Phase Err. GMSK, and Overview 8PSK is analogous to the measurement control softkeys in the Analyzer/Generator menu; see section Measurement Control on p.

  • Page 175: Power Measurements

    CMU-K20/K21/K22/K23/K24 Signalling: Power Measurements Power Measurements The menu group Power is designed to measure the RF output power of the MS transmitter. The power of a normal burst in a single timeslot or in up to 4 consecutive timeslots, the power of an access burst, the averaged power and its evolution over several slots or frames can be analyzed.

  • Page 176: Fig. 4-45 Measurement Menu Power - P/T Normal Gmsk

    CMU-K20/K21/K22/K23/K24 Signalling: Power Measurements • The other softkeys to the right of the test diagram are combined with various hotkeys (e.g. the hotkeys PCL, Channel, Timeslot, and Timing Advance are associated with the softkey MS Signal). If a softkey is selected and an associated hotkey is pressed, a popup window will appear which indicates the current setting and enables an entry.
  • Page 177 CMU-K20/K21/K22/K23/K24 Signalling: Power Measurements The P/t Normal GMSK hotkey selects the power versus time measurement for P/t Normal GMSK modulated normal burst signals (see explanation of GSM burst structure at GMSK the beginning of section Limit lines (Power Configuration – Limit Lines) on page 4.32).

  • Page 178: A) P/T Normal Gmsk, P/T Normal 8Psk, P/T Access Burst

    CMU-K20/K21/K22/K23/K24 Signalling: Power Measurements POWer commands, e.g. CONFigure:POWer:PCL... The P/t Access Burst hotkey selects the power versus time measurement of the P/t Access access burst. Burst Note: There is no mode where the mobile transmits access bursts in consecutive TDMA frames. As a consequence, in the P/t Access GMSK application, only one access burst can be measured when the mobile attempts a location update (activate the application before performing a location update).
  • Page 179 CMU-K20/K21/K22/K23/K24 Signalling: Power Measurements The Slot Config. hotkey opens the Slot Configuration Editor window to determine Slot the levels in all uplink and downlink timeslots. The Slot Configuration Editor is Config. described in section on p. 4.157 Softkey-oriented Version: MS Multislot Mode Slot Config.

  • Page 180: B) P/T Multislot

    CMU-K20/K21/K22/K23/K24 Signalling: Power Measurements CONFigure:BSSignal[:CSWitched][:TCH][:SSLot]:TIMeslot PROCedure:SIGNalling[:CSWitched][:TCH][:SSLot]:TIMeslot The Slot Config. hotkey opens the Slot Configuration Editor window to determine Slot the levels in all uplink and downlink timeslots. The Slot Configuration Editor is Config. described in section on p. 4.157 Softkey-oriented Version: MS Multislot Mode Slot Config.

  • Page 181: C) P/Frame, P/Slot Graph, P/Slot Table

    CMU-K20/K21/K22/K23/K24 Signalling: Power Measurements The hotkey Slot Count defines an integer number of timeslots to be measured. The Slot actual measured time range is larger than the integer number of slots because it Count comprises an additional display margin; for details see remote control command description.

  • Page 182: Measurement Results

    CMU-K20/K21/K22/K23/K24 Signalling: Power Measurements The 1 Chan hotkey defines the first GSM channel to be measured. For a list of Chan GSM channels refer to the tables in section Control of Input and Output Signals (p. ff; the analyzed channels are uplink channels). 4.69 Remote control CONFigure:POWer:PCL:CHANnel <Channel1>,...,<Channeln>...

  • Page 183: Fig. 4-46 Display Of Measurement Results (P/T Normal Gmsk Menu)

    CMU-K20/K21/K22/K23/K24 Signalling: Power Measurements Parameter line 1 / 2 Test diagram Info box Fig. 4-46 Display of measurement results (P/t Normal GMSK menu) Scalar measurement results and settings are indicated in the two parameter lines Settings/ above the test diagram and in the info box, a popup window in the middle of the scalar results graphical screen Power.
  • Page 184 CMU-K20/K21/K22/K23/K24 Signalling: Power Measurements Training sequence of the measured RF signal. TSC detected Relative number of measured bursts that are out of the Out of Limit tolerances defined by the limit lines. Error message if the displayed curve is out of tolerance. Burst Matching Remote control Settings are read out using the query corresponding to the setting command...

  • Page 185: Fig. 4-47 Display Of Results (Power - P/T Norm. 8Psk)

    CMU-K20/K21/K22/K23/K24 Signalling: Power Measurements b) P/t Normal 8PSK As shown in below, the P/t Normal 8PSK measurement results are similar to the P/t Normal Fig. 4-47 GMSK results. The x-axis scale of both diagrams is equal because 8PSK and GMSK symbol periods are of equal length.

  • Page 186: Fig. 4-49 Display Of Measurement Results (P/Pcl Menu)

    CMU-K20/K21/K22/K23/K24 Signalling: Power Measurements d) P/Frame, P/Slot Graph, P/Slot Table The results displayed in the measurement menu Power, applications P/Frame, P/Slot Graph, and P/Slot Table are analogous to the corresponding Non Signalling mode results; see section Measurement Results on page ff.

  • Page 187: Fig. 4-50 Display Of Measurement Results (P/T Access Burst Menu)

    CMU-K20/K21/K22/K23/K24 Signalling: Power Measurements f) P/t Access Burst The results displayed in the measurement menu Power, application P/t Access Burst, can be divided into three groups: • Settings • Scalar measurement results (single values) • Arrays (the measurement curve plotted as a function of time) The measurement results are indicated in two parameter lines, the test diagram and an info box: Parameter line 1 / 2 Test diagram...

  • Page 188: Measurement Configurations (Power Configuration)

    CMU-K20/K21/K22/K23/K24 Signalling: Power Measurements The info box indicates the results for the scalar measured values: Avg. Burst Power Average burst power, depending on the display mode set (see upper right corner of the diagram). Time offset (in symbol periods) between the expected and the Time of Arrival measured timing of the current burst from the mobile.

  • Page 189: Measurement Control (Power Configuration - Control)

    CMU-K20/K21/K22/K23/K24 Signalling: Power Measurements Measurement Control (Power Configuration – Control) The Control tab controls the power measurement by determining • The Repetition mode • The Stop Condition for the measurement (for burst power vs. time measurements only) • The type of measurement curve displayed (Display Mode, for burst power vs. time measurements only) •...

  • Page 190: Table 4-7 Gsm Power Classes

    CMU-K20/K21/K22/K23/K24 Signalling: Power Measurements Limit Values for Average Burst Power (Power Configuration – Limits) The Limits tab defines tolerance limits for the average burst power depending on the power control level of the mobile phone (PCL). The limits apply to all applications of the Power menu providing a limit check (not to P/Frame, P/Slot Graph and P/Slot Table).

  • Page 191: Fig. 4-51 Power Configuration - Limits

    CMU-K20/K21/K22/K23/K24 Signalling: Power Measurements Fig. 4-51 Power Configuration – Limits The Default Settings switch overwrites all settings of the Limits tab with default Default Settings values. The table Average Burst Power defines a tolerance band for the average burst Average Burst power.

  • Page 192: Fig. 4-52 Measurement Menu Modulation

    CMU-K20/K21/K22/K23/K24 Signalling: Modulation Measurements Modulation Measurements The menu group Modulation contains the functions for measurement of the modulation parameters of the RF signal transmitted by the mobile phone. The popup menu Modulation Configuration is used for configuration of the measurements; the measurement results are displayed in the graphical measurement menu Modulation.

  • Page 193: Fig. 4-53 Display Of Results (Modulation Menu)

    CMU-K20/K21/K22/K23/K24 Signalling: Modulation Measurements Measurement Results The values shown in the measurement menu Modulation can be divided into three groups: • Setting values • Scalar measurement results (single values) • Arrays (the measurement curve plotted as a function of time) The values are indicated in two parameter lines, the test diagram and a tabular overview below: Parameter line 1 | 2 Test diagram...

  • Page 194: Fig. 4-54 Measurement Menu Spectrum (Application Modulation Gmsk)

    CMU-K20/K21/K22/K23/K24 Signalling: Spectrum Measurements Spectrum Measurements The menu group Spectrum contains the functions for measurement of the off-carrier power, which is due to the modulation and the bursty nature of the RF signal. The popup menu Spectrum Configuration is used for configuration of the measurements; the measurement results are displayed in the graphical measurement menus Spectrum.

  • Page 195: Measurement Results

    CMU-K20/K21/K22/K23/K24 Signalling: Spectrum Measurements Measurement Results The Spectrum measurement menu and the results depend on the type of spectrum (application Modulation GMSK or Switching GMSK) selected. In contrast to the Non Signalling mode (see p. ff.) the first parameter line also contains the PCL of 4.41 the mobile.

  • Page 196: Receiver Quality Measurements

    CMU-K20/K21/K22/K23/K24 Signalling: Receiver Quality Measurements Receiver Quality Measurements The menu group Receiver Quality tests the transmission performance on the complete signal path from the CMU to the device under test (mobile station) and back. To this end the mobile is set to test loop operation where it returns the received data back to the tester.
  • Page 197 CMU-K20/K21/K22/K23/K24 Signalling: Receiver Quality Measurements RBER Ib = Erroneous class Ib bits (RF) / total number of class Ib bits (RF) * 100% The Block Error Ratio (BLER) is the ratio of blocks that the MS receives in error to the total number of received blocks, where a block is defined as received in error if the error detection functions in the receiver indicate an error as a the result of the Block Check Sequence (BCS, see GSM 11.10):...

  • Page 198: Fig. 4-55 Signal Paths For Ber Measurements

    CMU-K20/K21/K22/K23/K24 Signalling: Receiver Quality Measurements RLC Layer Ack/Nack Channel Channel (no loopback of data) Encoder Coder (Data) RBER RBER BLER DBLER Channel Test of Channel Evaluate Block Decoder Decoder Check (Data) Sequence RF IN Channel Modulator Modulator Modulator Analyzer Decoder Modulator modulator Channel...

  • Page 199: Table 4-9 Bler And Dbler Measurement Settings

    CMU-K20/K21/K22/K23/K24 Signalling: Receiver Quality Measurements The number of timeslots that can be evaluated simultaneously is limited by the Optimizing the multislot capabilities of the DUT but also depends on some CMU settings. To BLER obtain maximum flexibility in the BLER measurement, check the following settings: measurement ! To ensure that the CMU can send RLC blocks in several (up to 4) timeslots set (see p.

  • Page 200: Fig. 4-56 52-Multiframe For Pdch

    CMU-K20/K21/K22/K23/K24 Signalling: Receiver Quality Measurements Main Service Traffic Mode / CMU Signalling Signalling Channel / Receiver Quality Results Coding Scheme State Service Selection Meas. Mode / available Application Packet Data CS1 to CS4 TBF Established BLER BLER BLER (Option CMU- K42, GPRS) Packet Data MCS1 to MCS9...

  • Page 201: Fig. 4-57 Comparison Between Bler And Dbler: Cs4 (Left Diagram) And Cs1

    CMU-K20/K21/K22/K23/K24 Signalling: Receiver Quality Measurements determined by the difference of the data field size compared to the complete RLC block size. For other coding schemes, there are additional effects originating from the different channel coding of the header and data fields and from differences in the bit error rate of header and data bits after the channel decoder.

  • Page 202: Table 4-11 Frame Structure For Main Service: Packet Data, Service Selection: Red. Sig.- Egprs Sym

    CMU-K20/K21/K22/K23/K24 Signalling: Receiver Quality Measurements Frame type Channel coder Bits per frame CS2 Test Mode CS3 Test Mode CS4 Test Mode MCS1 Test Mode MCS2 Test Mode MCS3 Test Mode MCS4 Test Mode MCS5 Test Mode MCS6 Test Mode MCS7 Test Mode MCS8 Test Mode MCS9 Test Mode Table 4-11 Frame structure for Main Service: Packet Data, Service Selection: Red.

  • Page 203: Statistical Ber Tests

    CMU-K20/K21/K22/K23/K24 Signalling: Receiver Quality Measurements Frame type Channel coder Bits per frame MCS7 MCS8 MCS9 Statistical BER Tests In a normal bit error rate test, a fixed number of bits is transmitted, leading to a fixed test time for each BER result.
  • Page 204 CMU-K20/K21/K22/K23/K24 Signalling: Receiver Quality Measurements In the figure below the lower confidence level is the sum of all probabilities p(n ) up to the measured number of bit errors. The upper confidence level is the sum of all probabilities p(n , BER ) above the measured number of bit errors.
  • Page 205 CMU-K20/K21/K22/K23/K24 Signalling: Receiver Quality Measurements The probability distribution gets relatively narrower as the measurement goes on Evolution in and n increase. For infinitely long measurement times, the and the numbers n time, early fail limit tends towards the specified limit, the early pass limit tends towards Target Test Time the specified limit times M.

  • Page 206: Fig. 4-59 Dual-Limit Confidence Ber

    CMU-K20/K21/K22/K23/K24 Signalling: Receiver Quality Measurements The single-limit BER test described above can be extended to restrict the BER to a Dual-Limit Test band between two limits. For practical reasons, the lower band limit is calculated as <BER Limit> (1 – n %), the upper band limit is calculated as <BER Limit> (1 + n %). Factors of 10 %, 20 % and 30 % are provided;...

  • Page 207: Fig. 4-60 Receiver Quality (Ber)

    CMU-K20/K21/K22/K23/K24 Signalling: Receiver Quality Measurements Measurement Menu (Receiver Quality) The Receiver Quality menu shows the results and the most important parameters of the Receiver Quality measurement. • The measurement control softkey BER (which changes to BER Average, Neighbor Cell or BLER if one of these applications is selected) controls the Receiver Quality measurement, indicates its status (RUN, HLT, OFF) and opens the configuration menu Receiver Quality Configuration.
  • Page 208 CMU-K20/K21/K22/K23/K24 Signalling: Receiver Quality Measurements ABORt:RXQuality:BER STOP:RXQuality:BER CONTinue:RXQuality:BER Pressing the measurement control softkey twice opens the popup menu Receiver Measurement Quality Configuration (see section Measurement Configurations (Receiver Quality configuration on page 4.138 ff.). Besides, a number of hotkeys defining the scope Configuration) of the measurement are associated to the measurement control softkey.
  • Page 209 CMU-K20/K21/K22/K23/K24 Signalling: Receiver Quality Measurements Remote control No explicit switchover command. All single shot measurements are identified by the level keywords ...RXQuality:BLER... The BS Signal softkey determines the level and the data transmitted on the CMU's traffic channel. The following settings are specific to the Receiver Quality Signal measurement: The TCH Level BER hotkey sets the level of the CMU's traffic channel signal (for...

  • Page 210: Fig. 4-61 Display Of Test Settings And Measurement Results (Ber)

    CMU-K20/K21/K22/K23/K24 Signalling: Receiver Quality Measurements Measurement Results The measurement results depend on the application selected. a) BER and BER Average The test settings of the current Receiver Quality measurement and the results are displayed in the tables in the center of the menu. Fig.
  • Page 211 CMU-K20/K21/K22/K23/K24 Signalling: Receiver Quality Measurements In a Burst by Burst measurement (Fast BER, Measurement Mode = Burst by Burst by Burst Burst), the following is displayed: Bit error rate for all bits (unprotected bits, no other bits are transmitted) Result of cyclic redundancy check: number of frames erased on CRC Error the signal path from the to the CMU...
  • Page 212 CMU-K20/K21/K22/K23/K24 Signalling: Receiver Quality Measurements If a confidence BER test is performed (i.e. if the stop condition Confidence Level is Confidence set), an additional output field displays one of the following measurement results: BER results Measurement still running, no early fail or early pass decision Running made.

  • Page 213: Fig. 4-62 Display Of Test Settings And Measurement Results (Bler)

    CMU-K20/K21/K22/K23/K24 Signalling: Receiver Quality Measurements b) BLER The results of the current Receiver Quality measurement are displayed in the tables in the center of the menu. Fig. 4-62 Display of test settings and measurement results (BLER) The measurement results are defined at the beginning of section Receiver Quality Measurements page 4.118.

  • Page 214: Ms Rcv. Reports - Received Results Of The Mobile Phone

    CMU-K20/K21/K22/K23/K24 Signalling: Receiver Quality Measurements All results are updated every 2 seconds. BLER/RLC blocks on one hand and RLC Measurement data rate on the other hand are calculated with a different statistics: Statistics • The sum for the RLC blocks and the BLER runs over all blocks received since the beginning of the measurement.

  • Page 215: Table 4-8 Definition Of Rx Level

    CMU-K20/K21/K22/K23/K24 Signalling: Receiver Quality Measurements Table 4-8 Definition of RX Level Value of RX Level Corresponding signal strength > –48 dBm –49 dBm to –48 dBm –50 dBm to –49 dBm –109 dBm to –108 dBm –110 dBm to –109 dBm <...

  • Page 216: Fig. 4-63 Receiver Quality - Control

    CMU-K20/K21/K22/K23/K24 Signalling: Receiver Quality Measurements Measurement Configurations (Receiver Quality Configuration) The popup menu Receiver Quality Configuration contains two tabs to define the parameters for the bit error rate measurement. The popup menu Receiver Quality Configuration is opened by pressing the measurement control softkey BER/ BER Average/Neighbor Cell/BLER at the top right in the Receiver Quality menu twice.
  • Page 217 CMU-K20/K21/K22/K23/K24 Signalling: Receiver Quality Measurements (automatic gain control). The AGC Holdoff Time is also applied if the RF level changes during the Receiver Quality measurement. Sync Holdoff Time Delay time after which the signalling unit of the CMU starts synchronizing to the bit stream. This holdoff time is not applied in the case of RF level changes during the Receiver Quality measurement.
  • Page 218 CMU-K20/K21/K22/K23/K24 Signalling: Receiver Quality Measurements Remote control CONFigure:RXQuality:BER:CONTrol:CONFidence:FAIL CONFigure:RXQuality:BER:CONTrol:CONFidence:PASS CONFigure:RXQuality:BER:CONTrol:CONFidence:RWINdow CONFigure:RXQuality:BER:CONTrol:CONFidence:MTTIme BER Test Setups The BER table section defines up to 10 user-specific configuration files for single shot Receiver Quality measurements (application BER). The test setups are numbered from 1 to 10 and can be called up via the Test Setup hotkey associated to the BER softkey.
  • Page 219 CMU-K20/K21/K22/K23/K24 Signalling: Receiver Quality Measurements The Meas. Mode parameter hotkey selects the quantities to be measured. For a list Meas. Mode of measurement modes and corresponding measurement results see also section on page 4.132 Measurement Results Bit error rate (separately for class II and class Ib bits) Residual bit error rate (separately for class II and class Ib bits) RBER / FER and frame erasure rate...
  • Page 220 CMU-K20/K21/K22/K23/K24 Signalling: Receiver Quality Measurements The following level settings for the BS traffic channel are valid during the Receiver Quality measurement only; they don't supersede the downlink levels defined in the Slot Configuration Editor described in section on p. 4.157 Softkey-oriented Version: MS Multislot Mode In circuit switched mode, two alternative ways of defining the TCH levels are provided: Depending on the Level Mode setting in the Slot Configuration Editor, either the TCH Level BER or the Individual...

  • Page 221: Fig. 4-64 Receiver Quality Configuration - Limits

    CMU-K20/K21/K22/K23/K24 Signalling: Receiver Quality Measurements Upper Limits for Bit Error Rate (Receiver Quality Configuration – Limits) The Limits tab defines the upper limits for the individual measured quantities in the Receiver Quality menu. All settings can be defined separately for the two applications BER (with up to ten different test setups) and BER Average.
  • Page 222 CMU-K20/K21/K22/K23/K24 Signalling: Receiver Quality Measurements Remote control CONFigure:RXQuality:BER<nr>|BAVerage:LIMit:FERRors <Frame_Errors> Upper limit of the Data Block Error Rate in the value range 0% to 100% (only DBLER measured in measurement mode BER/DBLER). Remote control CONFigure:RXQuality:BER:LIMit:DBLer Upper limit of the USF Block Error Rate in the value range 0% to 100%. Only USF BLER measured in measurement mode BER/DBLER and on packet switched data channels (GPRS, option CMU-K42).

  • Page 223: Connection Control

    CMU-K20/K21/K22/K23/K24 Signalling: Connection Control Connection Control The menu group Connection Control controls the signalling procedures (call setup and release, services, signalling parameters) and determines the inputs and outputs with the external attenuation values and the reference frequency. The purpose of the Signalling test mode is to perform transmitter and receiver tests with an existing call (or data transfer) connection between the CMU and the mobile.

  • Page 224: Fig. 4-65 Connection Control - Connection (Synchronized)

    CMU-K20/K21/K22/K23/K24 Signalling: Connection Control Fig. 4-65 Connection Control – Connection (Synchronized) The function of the Power softkey is described in the section Signalling Control without Signal (State on page 4.90, the softkeys Signal Off and Send SMS in the section Signal Off) Connection Control with on page 4.92.

  • Page 225: Fig. 4-66 Connection Control - Connection (Alerting)

    CMU-K20/K21/K22/K23/K24 Signalling: Connection Control • Deactivation of the control channel signal for synchronization and call release (Signal Off) • Disconnect Mobile while keeping the control channel signal switched on (-> state Synchronized) The popup menu Connection (Alerting) is opened while the mobile phone is ringing during a call setup (Connect Mobile softkey in the Signal On or in the Synchronized state).

  • Page 226: Connection Control With Call Established

    CMU-K20/K21/K22/K23/K24 Signalling: Connection Control Connection Control with Call Established (State Call Established) In addition to the parameter overview described in section Connection Control with Call Established 4.148 ff., the Network Support and Main Service softkeys, and the wideband power measurement described in section on p.
  • Page 227 CMU-K20/K21/K22/K23/K24 Signalling: Connection Control Signalling States The Signalling States section indicates the current signalling states of the CMU in GSM (Circuit Switched, see on p. 4.90) and GPRS (Packet Data) mode. Fig. 4-41 GSM and GPRS states are independent from each other. The GPRS signalling scheme is described in section on p.
  • Page 228 CMU-K20/K21/K22/K23/K24 Signalling: Connection Control Multislot class Maximum number of slots Downlink (MS RX) Uplink (MS TX) not applicable not applicable not applicable not applicable not applicable not applicable not applicable not applicable RX describes the maximum number of receive timeslots that the MS can use per TDMA frame.

  • Page 229: Handover To Another Network (Connection Control - Handover)

    CMU-K20/K21/K22/K23/K24 Signalling: Connection Control The BS Signal section indicates important parameters describing the signals that BS Signal the CMU transmits in the state Signal On. These parameters can be set in the BS Signal tab and are explained there in more detail (see section RF Signals of the on page 4.161...

  • Page 230: Fig. 4-68 Connection Control - Handover (Destination Selection)

    CMU-K20/K21/K22/K23/K24 Signalling: Connection Control Fig. 4-68 Connection Control – Handover (destination selection) The softkey Destination Selection selects the target network for handover. Destination Dual-band handover between all enabled GSM bands is supported. Once the Selection selection is confirmed via Enter, the CMU changes to the Call Pending signalling state.

  • Page 231: Fig. 4-69 Connection Control - Handover (Call Pending)

    CMU-K20/K21/K22/K23/K24 Signalling: Connection Control Fig. 4-69 Connection Control – Handover (Call Pending) The Destination Parameter softkey sets important target network parameters that Destination come into effect as soon as the call is handed over. Parameter Sets all Destination Parameters to default values. Default All Sett.

  • Page 232: Rf Signals Of The Ms (Connection Control - Ms Signal)

    CMU-K20/K21/K22/K23/K24 Signalling: Connection Control CONFigure:BSSignal[:CSWitched][:TCH]:CHANnel <TCH> The Handover softkey initiates a handover to the target network. Handover Note: After a handover the BS Signal tab no longer shows the current control channel settings (in particular, the BCCH Mode, BCCH Level and BCCH Channel) but displays "from other network", indicating that the values of the origin network have been left unchanged.

  • Page 233: Fig. 4-70 Connection Control - Ms Signal (Panel, Single Slot)

    CMU-K20/K21/K22/K23/K24 Signalling: Connection Control Fig. 4-70 Connection Control – MS Signal (panel, single slot) The Slot Mode softkey set the mobile station under test to either Single Slot or Slot Multislot operation. As soon as a call is established the slot mode can no longer be Mode changed and the softkey is disabled (grayed).
  • Page 234 CMU-K20/K21/K22/K23/K24 Signalling: Connection Control Remote control CONFigure:MSSignal[:CSWitched][:TCH][:SSLot]:MS:PCL PROCedure:SIGNalling[:CSWitched][:TCH][:SSLot]:MS:PCL The Timing Advance softkey sets a (positive) delay time (in symbol periods) Timing correcting the timing of the mobile. In the network, timing advance is to compensate Advance for the propagation time of the signal from the BTS to the mobile and back. Remote control PROCedure:SIGNalling[:CSWitched][:TCH]:TADVance CONFigure:MSSignal[:CSWitched][:TCH]:TADVance...

  • Page 235: Fig. 4-71 Connection Control - Ms Signal (Panel, Multislot)

    CMU-K20/K21/K22/K23/K24 Signalling: Connection Control Softkey-oriented Version: MS Multislot Mode The Slot Mode of the mobile can be set by means of the softkey (see p. 4.155) before a call Slot Mode is established. While Multislot mode is selected, the softkey-oriented version of the MS Signal tab determines •...
  • Page 236 CMU-K20/K21/K22/K23/K24 Signalling: Connection Control The Slot Config. softkey sets the output power of the mobile station transmitter and Slot the main timeslot number (see below). The output power can be selected in PCL Config. (Power Control Level) units or as a corresponding absolute power value (in dBm with a 2 dBm spacing);...
  • Page 237 CMU-K20/K21/K22/K23/K24 Signalling: Connection Control The Multi Slot section determines the main timeslot and the way the levels are Multi Slot defined. Individual levels in all downlink channels or distinction between Level Mode Used/Unused timeslots. If Used/Unused is selected the Used Timeslot Level and the Unused Timeslot Level can be defined in the Traffic Channel section.

  • Page 238: Fig. 4-72 Connection Control - Ms Signal (Table)

    CMU-K20/K21/K22/K23/K24 Signalling: Connection Control The Loop softkey sets the test loop at the MS. Receiver Quality measurements use Loop their own test loops so the loop defined here is valid as long as no Receiver Quality measurement is active. All test loops are defined in standard 3GPP TS 04.14. The following loops are available in multislot mode: No test loop set Multi-slot TCH burst-by-burst loop...

  • Page 239: Rf Signals Of The Cmu (Connection Control - Bs Signal)

    CMU-K20/K21/K22/K23/K24 Signalling: Connection Control The Default All Settings switch assigns default values to all settings in the MS Default Settings Signal tab (the default values are quoted in the command description in chapter 6 of this manual). Remote control – The PMAX parameter sets the maximum MS transmitter output power allowed in PMAX the cell.

  • Page 240: Fig. 4-73 Connection Control - Bs Signal (Panel, Single Slot)

    CMU-K20/K21/K22/K23/K24 Signalling: Connection Control The present chapter describes the parameters related to circuit switched operation of the mobile phone. Tests in Packet Data (GPRS) mode require option CMU-K42. They are described in section on p. 4.195 Signals of the CMU (Connection Control – BS Signal) The CMU provides a softkey-oriented version of the BS Signal tab and a table-oriented version with extended functionality.
  • Page 241 CMU-K20/K21/K22/K23/K24 Signalling: Connection Control Remote control CONFigure:BSSignal:FM:DEViation <Frequency> The Mode softkey defines the BS Signal configuration after a connection has been Mode set up: Switch off BCCH after the connection has been established. This BCCH or TCH means that in the Call Established and TBF Established states, all timeslots are available for the TCH.
  • Page 242 CMU-K20/K21/K22/K23/K24 Signalling: Connection Control Remote control No separate switchover command. The slot modes are selected implicitly by the keywords [:SSLot] or :MSLot in the command header. The TCH Level softkey sets the absolute level (in dBm) in the used timeslot and the relative level in all unused timeslots of the BS signal.

  • Page 243: Fig. 4-74 Connection Control - Bs Signal (Panel, Multislot)

    CMU-K20/K21/K22/K23/K24 Signalling: Connection Control The Timeslot softkey determines the traffic channel timeslot number for the single Timeslot slot circuit switched connection. Remote control PROCedure:SIGNalling[:CSWitched][:TCH][:SSLot]:TIMeslot CONFigure:BSSignal[:CSWitched][:TCH][:SSLot]:TIMeslot Softkey-oriented Version: Multislot Mode The Slot Mode of the mobile can be set by means of the Slot Mode softkey before a call is established. While Multislot mode is selected, frequency Hopping is set to Off and the softkey-oriented version of the BS Signal tab determines •...
  • Page 244 CMU-K20/K21/K22/K23/K24 Signalling: Connection Control The Level Mode softkey determines how the downlink TCH levels are defined if the Level mobile is in Multislot mode: Mode All active (used) timeslots are at the same level and all inactive Used/Unused (unused) timeslots are at the same level. The Used Timeslot Level and the Unused Timeslot Level can be defined by means of the Slot Config.

  • Page 245: Fig. 4-75 Connection Control - Bs Signal (Table)

    CMU-K20/K21/K22/K23/K24 Signalling: Connection Control Table-oriented Version The table-oriented version of the BS Signal tab contains all BS signal settings of the softkey-oriented version (see sections on p. 4.162 Softkey-oriented Version: Single Slot Mode Softkey-oriented on p. 4.165). Besides it defines: Version: Multislot Mode •...
  • Page 246 CMU-K20/K21/K22/K23/K24 Signalling: Connection Control service) or TEST (packet data main service) signalling states. It is automatically reset (switched off) each time that the connection is released. A test case using the random frequency offset for determining the EGPRS usable receiver input level range is described in standard 3GPP TS 51.010-1. Remote control PROCedure:BSSignal:FM:DEViation:RANDom:ENABle ON | OFF If option CMU-B95, Additional RF Generator, is fitted, the CMU provides a second...

  • Page 247: Network Parameters (Connection Control - Network)

    CMU-K20/K21/K22/K23/K24 Signalling: Connection Control on page 4.162). oriented Version: Single Slot Mode In GSM networks, frequency hopping is primarily used for error protection in the radio transmission path. It consists of periodically switching over the transmission channels (except BCCH) to other carrier frequencies. The frequency changes after each radio frame so that the dwell time on each carrier frequency is 4.615 ms ("slow"...

  • Page 248: Fig. 4-76 Connection Control - Network Parameters (Panel)

    CMU-K20/K21/K22/K23/K24 Signalling: Connection Control Fig. 4-76 Connection Control – Network parameters (panel) The Traffic Mode softkey determines the speech or data channel coding and the Traffic transmission rate in the traffic channels: Mode Use of standard full-rate speech coding Full Rate Version 1 Full Rate Version 2 Enhanced full rate speech coding Half-rate speech coding...
  • Page 249 CMU-K20/K21/K22/K23/K24 Signalling: Connection Control Modulation and coding scheme 9 (MCS9) specified for MCS9 Test Mode EGPRS. The four coding schemes CS1 to CS4 are defined for the GPRS packet-data traffic channels (PDTCH). For most packet control channels, coding scheme CS1 is used. All coding schemes CS1 to CS4 are mandatory for MSs supporting GPRS.
  • Page 250 CMU-K20/K21/K22/K23/K24 Signalling: Connection Control digital/analog conversion directly to the analog output. This signal is used for external calibration of the analog input paths. The CMU sends and receives speech frames that are routed to the Codec Cal internal speech codec (option CMU-B52). Analog signals are provided via the SPEECH connector at the front panel of the instrument.

  • Page 251: Fig. 4-77 Connection Control - Network Parameters (Table)

    CMU-K20/K21/K22/K23/K24 Signalling: Connection Control Table-oriented Version The table-oriented version of the Network tab contains all Network settings of the softkey-oriented version (see section on p. 4.169). Besides it defines: Softkey-oriented Version • The Network Support of the CMU simulating a BS station and the Main Service. These network parameters can also be defined in the Connection tab;...
  • Page 252 CMU-K20/K21/K22/K23/K24 Signalling: Connection Control B52 Mode qualifies whether the speech codec (option CMU-B52) is reserved for B52 Mode audio measurements or for the BLER measurement: The speech codec is reserved for audio measurements (see Speech Coder also section AF/RF Connectors (Connection Control – AF/RF) on p.
  • Page 253 CMU-K20/K21/K22/K23/K24 Signalling: Connection Control Remote control CONFigure:NETWork[:CSWitched]:SMODe:STIMe <Frames> Location Update Location Update determines in which cases the mobile performs a location update: • each time the mobile station is switched on Always • only if required Auto A location update is normally used to signal to the base stations that the mobile station has changed its position.
  • Page 254 CMU-K20/K21/K22/K23/K24 Signalling: Connection Control Signalling Channel determines which channel is used for signalling: Signalling Channel Signalling via stand-alone dedicated channel: Call setup to traffic SDCCH channel with an extra signalling channel (normal mode in the network), duration 4 s to 6 s Signalling via fast associated control channel: Fast call setup FACCH with signalling on traffic channel, duration 1 s to 2 s...
  • Page 255 CMU-K20/K21/K22/K23/K24 Signalling: Connection Control The IMSI request can be switched off if the IMSI of the mobile phone is known and reported to the tester as Default IMSI (see above). This speeds up the call setup procedure. Remote control CONFigure:NETWork[:CSWitched]:REQuest:IMSI ON | OFF CONFigure:NETWork[:CSWitched]:REQuest:IMEI ON | OFF...
  • Page 256 CMU-K20/K21/K22/K23/K24 Signalling: Connection Control Formulas for calculation of the advice of charge according to E1 ... E7 GSM specification. Numerical input in the value range 0 to 8191. Remote control CONFigure:NETWork[:CSWitched]:AOCharge:ENABle ON | OFF CONFigure:NETWork[:CSWitched]:AOCharge <Value1>, .. ,<Value7> Slot Offset defines the DL timeslot that the mobile is to loopback to the uplink main Slot Offset timeslot.

  • Page 257: Fig. 4-78 Connection Control - Af/Rf Connectors

    CMU-K20/K21/K22/K23/K24 Signalling: Connection Control The BA List function configures the list of used channels in the neighbor cells (BA BA List list, BCCH allocation list). The BA list is of significance for selecting the radio cells of the mobile station. Up to 16 entries are possible in the list ( 16 used channels i.e.

  • Page 258: Reference Frequency (Connection Control - Sync.)

    CMU-K20/K21/K22/K23/K24 Signalling: Connection Control The Speech Encoder softkey selects the input source for the CMU speech encoder Speech (option CMU-B52). The following two input sources are available: Encoder Generator Use the audio generator signal which is also fed to the AF OUT connector on the CMU front panel Use the signal of the 9-pole SPEECH (handset) connector on the CMU Handset...

  • Page 259: Trigger (Group Configuration - Trigger)

    CMU-K20/K21/K22/K23/K24 Signalling: Connection Control Trigger (Group Configuration – Trigger) The Trigger tab is part of the second group of tabs in the Connection Control menu. It is accessible after pressing the 1 / 2 toggle hotkey once. Pressing 1 / 2 again switches back to the first group of tabs described above.
  • Page 260 CMU-K20/K21/K22/K23/K24 Signalling: Connection Control The uplink frame trigger signal is also fed to pin 2 of the AUX 3 connector at the front of the instrument where is can be tapped off to synchronize external devices; see Output Trigger below. It consists of a high-pulse TTL signal with its rising edge at the beginning of timeslot 0 of each MS TDMA frame except the idle frames and with a length of exactly 1 timeslot (577 µs).

  • Page 261: I/Q-If Interface (Connection Control - I/Q-If)

    CMU-K20/K21/K22/K23/K24 Signalling: Connection Control Slope qualifies whether the trigger event occurs on the Rising Edge or on the Slope Falling Edge of the trigger signal. The setting has no influence on Free Run measurements. Due to the polarity and the length of the uplink frame trigger signal (see Source = Signalling above), changing the slope from Rising Edge to Falling Edge corresponds to the introduction of a 1-slot delay of the measurements.

  • Page 262: Fig. 4-80 Group Configuration - Input Level

    CMU-K20/K21/K22/K23/K24 Signalling: Connection Control Input Path (Connection Control – Analyzer) The Analyzer tab is part of the second group of tabs in the Connection Control menu. It is accessible after pressing the 1 / 2 toggle hotkey once. Pressing 1 / 2 again switches back to the first group of tabs described above.
  • Page 263 CMU-K20/K21/K22/K23/K24 Signalling: Connection Control Remote control [SENSe:]LEVel:MODE MANual | PCL | AUTOmatic The Multi Slot – Meas. Slot parameter defines in which GSM timeslots MS tests are Multi Slot performed. The Meas. Slot setting only affects the measurements performed on the Meas.

  • Page 264: Display Control (Connection Control - Misc.)

    CMU-K20/K21/K22/K23/K24 Signalling: Connection Control Display Control (Connection Control – Misc.) The Misc. tab is part of the second group of tabs in the Connection Control menu. It is accessible after pressing the 1 / 2 toggle hotkey once. Pressing 1 / 2 again switches back to the first group of tabs described above.

  • Page 265: Options And Extensions

    CMU-K20/K21/K22/K23/K24 GPRS Signalling and EGPRS Options and Extensions The features described in this section require the installation of additional software options; for a complete list of deliverable options refer to the data sheet. GPRS Signalling and EGPRS (Options CMU-K42/K43) General Packet Radio Service (GPRS) is one of the extensions of GSM Phase 2+ that are aimed to increase the obtainable data transfer rate.

  • Page 266: Setup Of A Connection

    CMU-K20/K21/K22/K23/K24 GPRS Signalling and EGPRS Setup of a Connection (Popup Menu Connection Control – Connection) The menu group Connection Control controls signalling (setup and release of a connection, services, signalling parameters) and configures the inputs and outputs with the external attenuation values and the reference frequency.
  • Page 267 CMU-K20/K21/K22/K23/K24 GPRS Signalling and EGPRS MS under test attempts a GPRS attach. The Connection tab contains an additional softkey labeled Service Selection. 4. Press Service Selection and select the GPRS test mode appropriate for your test case. 5. To establish a TBF connection proceed as outlined in Fig. 4-83 below and in the following sections.

  • Page 268: Connection Control - Signal Off

    CMU-K20/K21/K22/K23/K24 GPRS Signalling and EGPRS GPRS mobile tests are to be performed in TBF Established mode. This is why the GPRS test mode menus for connection setup (Connection Control – Connection) appear immediately after the function group and mode GSM400/850/900/1800/1900-MS Signalling is activated.

  • Page 269: Fig. 4-84 Connection Control - Connection (Signal Off)

    CMU-K20/K21/K22/K23/K24 GPRS Signalling and EGPRS Fig. 4-84 Connection Control – Connection (Signal Off) The function of the softkeys Main Service, Network Support, and Wideband Power is described in section on page 4.90. The parameter overview in Signalling Control without Signal (State Signal Off) the left half of the menu is also indicated in the other Connection tabs and is described in section on p.
  • Page 270 CMU-K20/K21/K22/K23/K24 GPRS Signalling and EGPRS The Service Selection softkey selects the GPRS test mode. The EGPRS test Service modes require option CMU-K43. All other test modes require option CMU-K42. Selection Test Mode A The mobile can be commanded to test mode A specified for MS transmitter RF tests;...

  • Page 271: Fig. 4-85 Connection Control - Connection (Idle)

    CMU-K20/K21/K22/K23/K24 GPRS Signalling and EGPRS In test mode A, the MS is commanded to continuously transmit RLC data blocks containing a pseudo random data sequence. In test mode B, the CMU transmits RLC blocks on the downlink containing a pseudo random data sequence; the MS loops back the data received. The test mode is terminated when the CMU initiates the TBF release (Disconnect Mobile) or if the CMU's control channel is switched off (Signal Off).

  • Page 272: Connection Control - Attached

    CMU-K20/K21/K22/K23/K24 GPRS Signalling and EGPRS Connection Control – Attached In addition to the parameter overview, the Service Selection softkey and the wideband power measurement described in section on page 4.90 Signalling Control without Signal (State Signal Off) the Connection (Attached) tab contains the following softkeys which lead to other services or signalling states: •...

  • Page 273: Fig. 4-87 Connection Control - Connection (Tbf Established)

    CMU-K20/K21/K22/K23/K24 GPRS Signalling and EGPRS Fig. 4-87 Connection Control – Connection (TBF Established) RF Signals of the MS (Connection Control – MS Signal) The MS Signal tab configures the operating mode and the RF traffic channel signal of the MS under test.

  • Page 274: Fig. 4-88 Connection Control - Ms Signal (Table)

    CMU-K20/K21/K22/K23/K24 GPRS Signalling and EGPRS The CMU provides a softkey-oriented version of the MS Signal tab and a table-oriented version with extended functionality. The MS Signal hotkey toggles between the two versions if it is pressed repeatedly. For packet data mode, the two tabs provide the same settings. Fig.

  • Page 275: Fig. 4-89 Connection Control - Bs Signal (Table)

    CMU-K20/K21/K22/K23/K24 GPRS Signalling and EGPRS Note: The number of downlink and uplink channels must be compatible with on p. 4.149. the multislot class of the MS under test; see Table 4-10 Remote control CONFigure:MSSignal:PDATa[:TCH]:MSLot:SCONfig CONFigure:BSSignal:PDATa[:TCH]:MSLot:SCONfig PROCedure:SIGNalling:PDATa[:TCH]:MSLot:SCONfig RF Signals of the CMU (Connection Control – BS Signal) The BS Signal tab configures the RF signals of the CMU (which simulates a base station transmitting a GSM control and traffic channel signal), selects a frequency offset, the frequency hopping scheme and the traffic channel data.

  • Page 276: Network Parameters (Connection Control - Network)

    CMU-K20/K21/K22/K23/K24 GPRS Signalling and EGPRS The Packet Data – Traffic Channel section defines the power control parameter P0 Packet Data – and the traffic channel that the CMU will use for data transfer: Traffic Channel Downlink power control parameter P0; see background information at the beginning of this section GSM channel that the CMU will use for packet data transfer RF Channel...

  • Page 277: Fig. 4-90 Connection Control - Network

    CMU-K20/K21/K22/K23/K24 GPRS Signalling and EGPRS Fig. 4-90 Connection Control – Network The Network Support parameter is to report to the MS under test whether or not the Network CMU currently supports GPRS or EGPRS; see softkey on p. 4.92. Support Network Support Remote control CONFigure:NETWork:NSUPport GSM | GGPR...
  • Page 278 CMU-K20/K21/K22/K23/K24 GPRS Signalling and EGPRS and coding schemes MCS1 to MCS9. Puncturing means that bits in the radio blocks are removed after channel coding in order to reduce the amount of transferred data and enhance the useful data rate. The puncturing schemes are selectable so that it is possible to test their influence on measured quantities, e.g.
  • Page 279 CMU-K20/K21/K22/K23/K24 GPRS Signalling and EGPRS Timeslot (no. 0 to 7) that is to be taken as the first downlink Slot Offset timeslot when the MS is in multislot operation (downlink timeslot offset parameter in the GPRS_TEST_MODE_CMD). Testmode with Enable or disable the operating mode where the mobile periodically transmits PACKET_UPLINK_ACK_NACK...
  • Page 280 CMU-K20/K21/K22/K23/K24 GPRS Signalling and EGPRS In incremental redundancy mode, the CMU starts transferring the output data block with the selected initial puncturing scheme. If decoding fails, the second data block is transmitted in addition and decoded together with the fist block. For modulation and coding schemes MCS3, MCS4 and MCS7 to MCS9, a third stage with a third puncturing scheme is available.

  • Page 281: Adaptive Multi-Rate (Amr) Speech Codec

    CMU-K20/K21/K22/K23/K24 Adaptive Multi-Rate (AMR) Speech Codec Adaptive Multi-Rate (AMR) Speech Codec (Option R&S CMU-K45) If an AMR speech codec test is selected (see softkey on p. 4.170) the Network tab Traffic Mode displays additional softkeys to configure the AMR codec and test the uplink and downlink codec adaptation (inband signalling).

  • Page 282: Fig. 4-91 Connection Control - Network Parameters (Amr)

    CMU-K20/K21/K22/K23/K24 Adaptive Multi-Rate (AMR) Speech Codec To prepare an 4. Press Connect. Control to open the Connection Control menu and access the AMR test… Connection tab. 5. If necessary, disconnect the MS under test and ensure that the CMU is in the Signal Off, Signal On, or Synchronized signaling states.
  • Page 283 CMU-K20/K21/K22/K23/K24 Adaptive Multi-Rate (AMR) Speech Codec The AMR Rate Set softkey opens a popup menu to select four codec modes and define the decision thresholds for changing the codec mode. Rate Set AMR Full Rate The first line of the AMR Rate Set Editor indicates the AMR codec type (Full Rate or Half Rate) selected by means of the Traffic Mode softkey.
  • Page 284 CMU-K20/K21/K22/K23/K24 Adaptive Multi-Rate (AMR) Speech Codec Defining and The standard places the following restrictions to the threshold values: testing threshold • The hysteresis must be positive or zero: values Up (j) ≥ Down (j + 1) for j= 1 to 3 •...
  • Page 285 CMU-K20/K21/K22/K23/K24 Adaptive Multi-Rate (AMR) Speech Codec The TCH Level softkey defines the downlink (BS Signal) TCH level in the used and unused timeslots (used/unused level mode) or the reference level (individual level Level mode). The level can be changed to check whether the MS requests the correct DL codec mode according to the AMR Rate Set settings (see above).
  • Page 287 CMU-K20/-K21/-K22/-K23/-K24 Contents of Chapter 5 Contents 5 Remote Control – Basics..................Structure of the GSM Function Groups ..................5.1 Measurement Control ........................5.2 Measurement Groups ......................5.2 Measurement Statistics......................5.5 Specifying Limits ........................5.6 Status Reporting System.........................5.6 Special Terms and Notation ......................5.8 1115.6088.12 I-5.1 E-10...

  • Page 289: Remote Control - Basics

    Chapter 6 of this manual gives a description of all GSM remote control commands, including their pa- rameters, as well as the default values and ranges of all numerical parameters. Function group The commands for the function groups GSM400-MS, GSM850-MS, GSM900- and mode MS, GSM1800-MS and GSM1900-MS are largely identical, however, the ranges of numerical values and some default settings may not coincide.

  • Page 290: Measurement Control

    Measurement Control CMU-K20/-K21/-K22/-K23/-K24 • Measurement groups (Non Signalling mode): POWer[:NORMal]..., POWer:MPR • Common command and measurement groups (identical in Non Signalling and Signalling mode (OPTion, RESet, STATus:OPERation, IQIF, WPOWer, NPOWer, POWer:SLOT, POWer:XSLot, POWer:FRAMe, POWer:MSLot, MODulation..., SPECtrum...) • Measurement groups (Signalling mode): POWer[:NORMal]..., POWer:ABURst..., POWer:PCL, POWer:MPR, RXQuality...

  • Page 291: Table 5-1 Measurement Objects In Signalling And Non Signalling Mode

    CMU-K20/-K21/-K22/-K23/-K24 Measurement Control Table 5-1 Measurement objects in Signalling and Non Signalling mode Non Signalling Signalling Meas. Object Measurement group / Meas. Object Measurement group / Application Application WPOWer Wideband Power softkey WPOWer Wideband Power softkey (wide-band peak power (wide-band peak power meas- measurement).
  • Page 292 Measurement Control CMU-K20/-K21/-K22/-K23/-K24 Non Signalling Signalling Meas. Object Measurement group / Meas. Object Measurement group / Application Application MODulation[:PERRor] No equivalent in manual con- MODulation[:PERRor] No equivalent in manual con- [:GMSK] [:GMSK] trol trol Fast phase and frequency Fast phase and frequency error measurement excluding error measurement excluding the I/Q imbalance and origin...

  • Page 293: Table 5-2 Repetition Mode In Remote Control

    CMU-K20/-K21/-K22/-K23/-K24 Measurement Control Measurement Statistics The repetition mode defines how many evaluation periods are measured if the measurement is not stopped explicitly (measurement control commands STOP..., ABORT...) or by a limit failure. With remote control the three repetition modes Single Shot, Continuous and Counting are available (Count- ing is not available in manual control, see chapter 3).

  • Page 294: Table 5-3 Limits And Limit Check

    Status Reporting System CMU-K20/-K21/-K22/-K23/-K24 Specifying Limits The following table gives an overview of the types of limits and possible results of the limit check. Table 5-3 Limits and limit check Type Description Command Scalar limits Limit values for a single (scalar) measured quan- CONFigure:<meas_obj>:LIMit:<Spec.>...

  • Page 295: Table 5-4 Meaning Of The Bits Used In The Status:operation:cmu:sum1|2:Cmu Sub-Registers Assigned To Gsmxxx-Ms Non Signalling

    CMU-K20/-K21/-K22/-K23/-K24 Status Reporting System GSM mobile tests comprise the two signalling modes Non Signalling and Signalling for each of the function groups GSM400/850/900/1800/1900-MS so that a total of 10 secondary addresses can be used. In the status registers for the Non Signalling mode the following bits are assigned: Table 5-4 Meaning of the bits used in the STATus:OPERation:CMU:SUM1|2:CMU<nr>...

  • Page 296: Special Terms And Notation

    Special Terms and Notation CMU-K20/-K21/-K22/-K23/-K24 Bit-No. Meaning Symbol in STATus:OPERation:SYMBolic... RF Input Underdriven RFIU This bit is set while the RF input level at connector RF1, RF2 or RF 4 IN falls below the measurement range controlled by the specified RF Max.
  • Page 297 CMU-K20/-K21/-K22/-K23/-K24 Special Terms and Notation range (see commands READ:SUBarrays...; the subarrays are defined via CONFigure:SUBarrays...). Parameters Setting commands are usually supplemented by a parameter or a list of several parameters. Parameters either provide alternative options (setting a or setting b or setting c ..., see special character "|"), or they form a comma-separated list (setting x,y).
  • Page 298 Special Terms and Notation CMU-K20/-K21/-K22/-K23/-K24 Remarks: The Remarks column gives additional information about the commands which − Have no query form (no query) − Have only a query form (query only) − Can be used both as setting commands and as queries (with query, this applies to all commands belonging to none of the two preceding catego- ries) Alphabetical...
  • Page 299 CMU-K20/K21/K22/K23/K24 Contents of Chapter 6 Contents 6 Remote Control – Commands................6.1 Connection Control (Non Signalling only)..................6.1 Subsystem LEVel (Input Level)....................6.1 Subsystem RFANalyzer (Analyzed Input Signals)..............6.2 Generator Object "RFGenerator" – Generator control.............6.4 Generator Level – Subsystem RFGenerator:LEVel ............6.4 RF Generator Frequency – Subsystem RFGenerator:FREQuency ......6.5 Subsystem RFGenerator:MODulation ................6.6 Subsystem for Input and Output (Connectors, External Attenuation)........6.7 Subsystem DM:CLOCk (Synchronization)................6.8...
  • Page 300 Contents of Chapter 6 CMU-K20/K21/K22/K23/K24 Subsystem POWer:SLOT................... 1.43 POWer:XSLot........................1.45 Subsystem POWer:XSLot:CONTrol ................1.46 Subsystem POWer:XSLot:SCOunt................1.46 Subsystem SUBarrays:POWer:XSLot ................ 1.48 Subsystem POWer:XSLot? ..................1.48 POWer:FRAMe ........................1.50 Subsystem POWer:FRAMe:CONTrol................. 1.51 Subsystem SUBarrays:POWer:FRAMe..............1.52 Subsystem POWer:FRAMe ..................1.52 POWer:MSLot ........................1.54 Control of Measurement –...
  • Page 301 CMU-K20/K21/K22/K23/K24 Contents of Chapter 6 Measured Values – Subsystem MODulation[:PERRor]:EPSK ........1.95 MODulation:MERRor ......................1.97 Control of Measurement – Subsystem MODulation:MERRor ........1.97 Test Configuration....................... 1.98 Subsystem MODulation:MERRor:EPSK:CONTrol ........1.98 Tolerance values – Subsystem MODulation:OEMP:EPSK:LIMit ....1.99 Subsystem SUBarrays:MODulation............. 1.100 Measured Values –...
  • Page 302 Contents of Chapter 6 CMU-K20/K21/K22/K23/K24 Measured Values – Subsystem POWer:MPR ............6.149 Receiver Quality........................6.152 General Settings – Subsystem RXQuality..............6.152 Confidence BER – Subsystem RXQuality:CONTrol:CONFidence......6.153 Receiver Quality – Single Shot ................. 6.154 Control of Measurement – Subsystem RXQuality:BER....... 6.154 Subsystem RXQuality:BER:CONTrol..........
  • Page 303 CMU-K20/K21/K22/K23/K24 Contents of Chapter 6 Subsystem NETWork....................6.218 Subsystem NETWork:IDENtity ..............6.219 Subsystem NETWork:PDATa ..............6.219 MSSinfo ........................6.222 Adaptive Multi-Rate (AMR) Speech Codec................. 6.223 Subsystem NETWork[:CSWitched]:AMR (AMR Codec Test) ........6.223 MSSinfo (AMR Codec Modes).................. 6.227 6 Remote Control - Commands................6.229 List of Commands ........................

  • Page 305: Remote Control - Commands

    Connection Control (Non Signalling only) CMU-K20/K21/K22/K23/K24 6 Remote Control – Commands In the following, all remote-control commands for the function groups GSM400/850/900/1800/1900-MS will be presented in tabular form with their parameters and the ranges of values. The chapter is organ- ized in analogy to the reference part for manual operation (chapter 4).

  • Page 306: Subsystem Rfanalyzer (Analyzed Input Signals)

    Connection Control (Non Signalling only) CMU-K20/K21/K22/K23/K24 [SENSe:]LEVel:MAXimum <Level> Max. Level <Level> Description of parameters Def. value Def. unit FW vers. –40 dBm to +53 dBm Maximum input level for RF 1 +30.0 V1.20 –54 dBm to +39 dBm Maximum input level for RF 2 +30.0 –77 dBm to 0 dBm Maximum input level for RF 4 IN...
  • Page 307 Connection Control (Non Signalling only) CMU-K20/K21/K22/K23/K24 [SENSe:]RFANalyzer:CHANnel <Number> RF Channel <Number> Description of parameters Def. value Def. unit FW vers. 0.2 MHz to 2700 MHz Input frequency 455 (GSM400) V2.00 (see also data sheet) 837 (GSM850) 903 (GSM900) 1750 (GSM1800) 1880 (GSM1900) Description of command This command defines the frequency of the RF signal analyzed.

  • Page 308: Generator Object "Rfgenerator" - Generator Control

    Connection Control (Non Signalling only) CMU-K20/K21/K22/K23/K24 CONFigure:RFANalyzer:MCONtrol:TSOFfset <Slots> Trig. Slot Offset <Slots> Description of parameters Def. value Def. unit FW vers. 0 to 7 Trigger slot offset, no. of slots – V3.05 Description of command This command defines a delay time between the trigger time and the measured timeslot. RFANalyzer:DEFault <Enable>...

  • Page 309: Rf Generator Frequency - Subsystem Rfgenerator:frequency

    Connection Control (Non Signalling only) CMU-K20/K21/K22/K23/K24 SOURce:RFGenerator:LEVel:UTIMeslot <Level> RF Level used <Level> Description of parameters Def. value Def. unit FW vers. –137 dBm to –27 dBm RF1 level in used timeslot –27 V1.15 –137 dBm to –10 dBm RF2 level in used timeslot –27 –90 dBm to +13 dBm RF 3 OUT level in used timeslot...

  • Page 310: Subsystem Rfgenerator:modulation

    Connection Control (Non Signalling only) CMU-K20/K21/K22/K23/K24 SOURce:RFGenerator:FREQuency[:CHANnel] <Number> RF Channel <Number> Description of parameters Def. value Def. unit FW vers. 0.2 MHz to 2700 MHz Input frequency 465 (GSM400) V1.15 (see also data sheet) 882 (GSM850) 948 (GSM900) 1845 (GSM1800) 1960 (GSM1900) Description of command This command defines the frequency of the RF signal generated.

  • Page 311: Subsystem For Input And Output (Connectors, External Attenuation)

    Connection Control (Non Signalling only) CMU-K20/K21/K22/K23/K24 Subsystem for Input and Output (Connectors, External Attenuation) The subsystem for input and output configures the input and output connectors. The subsystem corre- sponds to the tab RF in the popup menu Connect. Control. INPut[:STATe] <State>...

  • Page 312: Subsystem Dm:clock (Synchronization)

    Connection Control (Non Signalling only) CMU-K20/K21/K22/K23/K24 Subsystem DM:CLOCk (Synchronization) The subsystem DM:CLOCk sets a system clock specific to the network. This frequency is set in the tab Sync. in the popup menu Connect. Control. SOURce:DM:CLOCk:STATe <Mode> REF OUT 2 on/off <Mode>...
  • Page 313 Connection Control (Non Signalling only) CMU-K20/K21/K22/K23/K24 TRIGger[:SEQuence]:THReshold:RFPower <Threshold> Level – RF Power <Threshold> Parameter description Def. value Default unit FW vers. LOW | Low trigger threshold (RF Max. Level – 26 dB) MEDium – V3.10 MEDium | Medium trigger threshold (RF Max. Level – 16 dB) HIGH High trigger threshold (RF Max.

  • Page 314: Config. File Management - System Mmemory

    Config. File Management – System MMEMory CMU-K20/K21/K22/K23/K24 Config. File Management – System MMEMory The MMEMory system provides mass storage capabilities for the CMU. The functionality of this system is included in the Data menu; see CMU200/300 operating manual. The mass storage of the CMU may be internal or external. The internal mass storage device is a sec- tion on the internal hard disk that is reserved for mass storage (directory c:\temp).

  • Page 315: Measurement Groups (Non Signalling Only)

    Measurement Groups (Non Signalling only) CMU-K20/K21/K22/K23/K24 Measurement Groups (Non Signalling only) The measurement groups in this section are either provided in Non Signalling mode only or imple- mented with major differences in the two test modes. POWer[:NORMal] The subsystem POWer[:NORMal] measures the MS transmitter output power versus time. The subsys- tem corresponds to the measurement menu Power and the associated popup menu Power Configura- tion.

  • Page 316: Test Configuration

    Measurement Groups (Non Signalling only) CMU-K20/K21/K22/K23/K24 FETCh:POWer[:NORMal][:GMSK]:STATus? Measurement Status FETCh:POWer[:NORMal]:EPSK:STATus? Return Description of parameters Def. value Def. unit FW vers. OFF | Measurement in the OFF state (*RST or ABORt) – V1.15 RUN | Running (after INITiate, CONTinue or READ) STOP | Stopped (STOP) ERR |...
  • Page 317 Measurement Groups (Non Signalling only) CMU-K20/K21/K22/K23/K24 CONFigure:POWer[:NORMal][:GMSK]:CONTrol <Mode>, <Statistics> Scope of Measurement CONFigure:POWer[:NORMal]:EPSK:CONTrol <Mode>, <Statistics> <Mode> Desciption of parameters Def. value Def. unit SCALar | Scalar values only (incl. ramp matching) ARRay – ARRay Scalar measured values and arrays <Statistics> Description of parameters Def.

  • Page 318: Subsystem Power:limit:line

    Measurement Groups (Non Signalling only) CMU-K20/K21/K22/K23/K24 CONFigure:POWer[:NORMal]:EPSK:CONTrol:RPMode <Mode> Ref. Power Mode <Mode> Description of parameters Def. value Def. unit FW vers. CURRent | Ref. Power calculated from current burst CURR – V2.15 AVERage | Ref. Power calculated from average curve DCOMpens Data compensated/corrected reference power Description of command...
  • Page 319 Measurement Groups (Non Signalling only) CMU-K20/K21/K22/K23/K24 For GMSK modulation (keyword [:GMSK]), 8 areas are defined in the default setting, another 8 areas can be activated if required. The default settings are given in the table below: for Enable forTable Start Stop Start Stop...
  • Page 320 Measurement Groups (Non Signalling only) CMU-K20/K21/K22/K23/K24 CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE:LOWer<nr>[:STATic]:ENABle <Enable> CONFigure:POWer[:NORMal]:EPSK:LIMit:LINE:LOWer<nr>[:STATic]:ENABle <Enable> CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE:LOWer<nr>[:STATic] CONFigure:POWer[:NORMal]:EPSK:LIMit:LINE:LOWer<nr>[:STATic] Lower Limit Line Parameters for query: <StartTime>, <EndTime>, <StartRelLevel>, <EndRelLevel>, <StartAbsLevel>, <EndAbsLevel>, <StartVisibility>, <EndVisibility> for setting: <StartTime>, <EndTime>, <StartRelLevel>, <EndRelLevel>, <StartAbsLevel>, <EndAbsLevel>, <Visibility> Parameters Value range Description of parameters Def.
  • Page 321 Measurement Groups (Non Signalling only) CMU-K20/K21/K22/K23/K24 CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE:UPPer<AreaNr>:DYNamic<RangeNr>:ENABle CONFigure:POWer[:NORMal]:EPSK:LIMit:LINE:UPPer<AreaNr>:DYNamic<RangeNr>:ENABle <Enable> CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE:UPPer<AreaNr>:DYNamic<RangeNr> CONFigure:POWer[:NORMal]:EPSK:LIMit:LINE:UPPer<AreaNr>:DYNamic<RangeNr> <fromTPCL>, <toTPCL>, <Correction>, <Enable> Dynamic Correction <fromTPCL> Description of parameters Def. value Def. unit 0 to 31 | First template PCL for which area <AreaNr> is See table below –...
  • Page 322 Measurement Groups (Non Signalling only) CMU-K20/K21/K22/K23/K24 CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE:UPPer:ALL:DYNamic:ENABle <Enable> CONFigure:POWer[:NORMal]:EPSK:LIMit:LINE:UPPer:ALL:DYNamic:ENABle <Enable> Dynamic Correction on/off <Enable> Description of parameters Def. value Def. unit FW vers. ON | OFF Switch dynamic correction for the whole template on or off – V2.00 Description of command This command switches the dynamic correction of the upper limit line in all areas and for all TPCL ranges on or off.
  • Page 323 Measurement Groups (Non Signalling only) CMU-K20/K21/K22/K23/K24 CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE:LOWer:ALL:DYNamic:ENABle <Enable> CONFigure:POWer[:NORMal]:EPSK:LIMit:LINE:LOWer:ALL:DYNamic:ENABle <Enable> Dynamic Correction on/off <Enable> Description of parameters Def. value Def. unit FW vers. ON | OFF Switch dynamic correction for the whole template on or off – V2.00 Description of command This command switches the dynamic correction of the lower limit line in all areas and for all template PCL ranges on or off.

  • Page 324: Subsystem Power:limit:abpower

    Measurement Groups (Non Signalling only) CMU-K20/K21/K22/K23/K24 Subsystem POWer:LIMIt:ABPower The subsystem POWer:LIMit:ABPower defines the limit values for the average burst power. The sub- system corresponds to the tab Limits in the popup menu Power Configuration. CONFigure:POWer[:NORMal][:GMSK]:LIMit:ABPower<nr> Average Burst Power <StartPCL>, <StopPCL>, <LowerLimit>, <UpperLimit> CONFigure:POWer[:NORMal][:GMSK]:LIMit:ABPower<nr>:ENABle <Enable>...

  • Page 325: Subsystem Subarrays:power

    Measurement Groups (Non Signalling only) CMU-K20/K21/K22/K23/K24 Subsystem SUBarrays:POWer The subsystem SUBarrays:POWer defines the measurement range and the type of output values. CONFigure:SUBarrays:POWer[:NORMal][:GMSK] Definition of Subarrays CONFigure:SUBarrays:POWer[:NORMal]:EPSK <Mode>,<Start>,<Samples>{,<Start>,<Samples>} <Mode> Description of parameters Def. value Def. unit ALL | Return all measurement values –...
  • Page 326 Measurement Groups (Non Signalling only) CMU-K20/K21/K22/K23/K24 Returned values Value range Def. value Def. unit FW vers. AvgBurstPwCurr, –137 dBm to +53 dBm V1.15 PeakBurstPwCurr, –137 dBm to +53 dBm BurstsOutOfTol, 0.0 % to 100.0 % BurstMatching INV | MATC | NMAT | OUT | NTR | NRAM | –...
  • Page 327 Measurement Groups (Non Signalling only) CMU-K20/K21/K22/K23/K24 READ:ARRay:POWer[:NORMal][:GMSK][:CURRent]? Burst Power READ:ARRay:POWer[:NORMal]:EPSK[:CURRent]? READ:ARRay:POWer[:NORMal][:GMSK]:AVERage? READ:ARRay:POWer[:NORMal]:EPSK:AVERage? READ:ARRay:POWer[:NORMal][:GMSK]:MAXimum? READ:ARRay:POWer[:NORMal]:EPSK:MAXimum? READ:ARRay:POWer[:NORMal][:GMSK]:MINimum? READ:ARRay:POWer[:NORMal]:EPSK:MINimum? ⇒ RUN Start single shot measurement and return results FETCh:ARRay:POWer[:NORMal][:GMSK][:CURRent]? FETCh:ARRay:POWer[:NORMal]:EPSK[:CURRent]? FETCh:ARRay:POWer[:NORMal][:GMSK]:AVERage? FETCh:ARRay:POWer[:NORMal]:EPSK:AVERage? FETCh:ARRay:POWer[:NORMal][:GMSK]:MAXimum? FETCh:ARRay:POWer[:NORMal]:EPSK:MAXimum? FETCh:ARRay:POWer[:NORMal][:GMSK]:MINimum? FETCh:ARRay:POWer[:NORMal]:EPSK:MINimum? ⇒ RUN Read meas. results (unsynchronized) SAMPle:ARRay:POWer[:NORMal][:GMSK][:CURRent]? SAMPle:ARRay:POWer[:NORMal]:EPSK[:CURRent]? SAM- Ple:ARRay:POWer[:NORMal][:GMSK]:AVERage?
  • Page 328 Measurement Groups (Non Signalling only) CMU-K20/K21/K22/K23/K24 READ:SUBarrays:POWer[:NORMal][:GMSK][:CURRent]? Subarray Results READ:SUBarrays:POWer[:NORMal]:EPSK[:CURRent]? READ:SUBarrays:POWer[:NORMal][:GMSK]:AVERage? READ:SUBarrays:POWer[:NORMal]:EPSK:AVERage? READ:SUBarrays:POWer[:NORMal][:GMSK]:MAXimum? READ:SUBarrays:POWer[:NORMal]:EPSK:MAXimum? READ:SUBarrays:POWer[:NORMal][:GMSK]:MINimum? READ:SUBarrays:POWer[:NORMal]:EPSK:MINimum? ⇒ RUN Start single shot measurement and return results FETCh:SUBarrays:POWer[:NORMal][:GMSK][:CURRent]? FETCh:SUBarrays:POWer[:NORMal]:EPSK[:CURRent]? FETCh:SUBarrays:POWer[:NORMal][:GMSK]:AVERage? FETCh:SUBarrays:POWer[:NORMal]:EPSK:AVERage? FETCh:SUBarrays:POWer[:NORMal][:GMSK]:MAXimum? FETCh:SUBarrays:POWer[:NORMal]:EPSK:MAXimum? FETCh:SUBarrays:POWer[:NORMal][:GMSK]:MINimum? FETCh:SUBarrays:POWer[:NORMal]:EPSK:MINimum? ⇒ RUN Read meas. results (unsynchronized) SAMPle:SUBarrays:POWer[:NORMal][:GMSK][:CURRent]? SAMPle:SUBarrays:POWer[:NORMal]:EPSK[:CURRent]? SAM- Ple:SUBarrays:POWer[:NORMal][:GMSK]:AVERage? SAMPle:SUBarrays:POWer[:NORMal]:EPSK:AVERage?
  • Page 329 Measurement Groups (Non Signalling only) CMU-K20/K21/K22/K23/K24 CALCulate:ARRay:POWer[:NORMal][:GMSK]:LIMit:MATChing[:CURRent]? CALCulate:ARRay:POWer[:NORMal]:EPSK:LIMit:MATChing[:CURRent]? CALCulate:ARRay:POWer[:NORMal][:GMSK]:LIMit:MATChing:AVERage? CALCulate:ARRay:POWer[:NORMal]:EPSK:LIMit:MATChing:AVERage? CALCulate:ARRay:POWer[:NORMal][:GMSK]:LIMit:MATChing:MAXimum? CALCulate:ARRay:POWer[:NORMal]:EPSK:LIMit:MATChing:MAXimum? CALCulate:ARRay:POWer[:NORMal][:GMSK]:LIMit:MATChing:MINimum? CALCulate:ARRay:POWer[:NORMal]:EPSK:LIMit:MATChing:MINimum? Burst Matching Returned values Value range Def. value Def. unit FW vers. <Matching> MATC | NMAT | INV | NTSC | OUT – V1.15 Description of command This command is always a query.

  • Page 330: Power:mpr

    Measurement Groups (Non Signalling only) CMU-K20/K21/K22/K23/K24 POWer:MPR The subsystem POWer:MPR combines the POWer and MODulation systems, i.e. it measures the sig- nal power vs. time and the scalar modulation parameters simultaneously. The subsystem contains all commands for measurement control and for the output of measurement results; configurations such as limit lines must be defined separately in the POWer and MODulation systems.

  • Page 331: Subsystem Power:mpr:control

    Measurement Groups (Non Signalling only) CMU-K20/K21/K22/K23/K24 Subsystem POWer:MPR:CONTrol The subsystem POWer:MPR:CONTrol defines the repetition mode, statistic count, and stop condition of the measurement. CONFigure:POWer[:NORMal][:GMSK]:MPR:CONTrol <Mode>, <Statistics> Scope of Measurement <Mode> Desciption of parameters Def. value Def. unit SCALar | Scalar values only (incl. ramp matching) ARRay –...

  • Page 332: Subsystem Subarrays:power:mpr

    Measurement Groups (Non Signalling only) CMU-K20/K21/K22/K23/K24 Subsystem SUBarrays:POWer:MPR The subsystem SUBarrays:POWer:MPR defines the measurement range and the type of output values. CONFigure:SUBarrays:POWer[:NORMal][:GMSK]:MPR <Mode>,<Start>,<Samples>{,<Start>,<Samples>} Definition of Subarrays <Mode> Description of parameters Def. value Def. unit ALL | Return all measurement values –...

  • Page 333: Measured Values - Subsystem Power:mpr

    Measurement Groups (Non Signalling only) CMU-K20/K21/K22/K23/K24 Measured Values – Subsystem POWer:MPR The subsystem POWer:MPR determines and returns the results of the combined power and modulation measurement. READ[:SCALar]:POWer[:NORMal][:GMSK]:MPR? Scalar Results: Start single shot measurement and return results FETCh[:SCALar]:POWer[:NORMal][:GMSK]:MPR? Read out measurement results (unsynchronized) SAMPle[:SCALar]:POWer[:NORMal][:GMSK]:MPR? Read out measurement results (synchronized) Returned values...
  • Page 334 Measurement Groups (Non Signalling only) CMU-K20/K21/K22/K23/K24 Returned values Description of parameters Def. value Def. unit FW vers. –100.0 dB... + 20.0 dB BurstPower[1], 1 value for burst power V2.00 –100.0 dB... + 20.0 dB BurstPower[x], xth value for burst power Description of comm These commands are always queries.
  • Page 335 Measurement Groups (Non Signalling only) CMU-K20/K21/K22/K23/K24 CALCulate[:SCALar]POWer[:NORMal][:GMSK]:MPR:LIMit:MATChing? Tolerance Error Returned values Value range Def. value Def. unit FW vers. AvgBurstPwCurr, NMAU | NMAL | INV | OK – V2.00 PeakBurstPwCurr, NMAU | NMAL | INV | OK – BurstMatching, INV | MATC | NMAT | OUT | NTR | NRAM | –...

  • Page 336: Common Measurements And Command Groups

    Common: Option Query CMU-K20/21/22/23/24 Common Measurements and Command Groups The commands for the measurement groups in this section are identical or almost identical in both test modes. Minor differences between Non Signalling and Signalling commands are possible; they will be pointed out throughout the section.

  • Page 337: Partial Reset

    CMU-K20/21/22/23/24 Common: Partial Reset Partial Reset The RESet subsystem restores the (factory) default values for the current function group and test mode. It is similar to the Reset menu opened via the RESET key on the front panel. SYSTem:RESet:CURRent Partial Reset Command description FW vers.

  • Page 338: Symbolic Status Event Register Evaluation

    Common: Symbolic Status Event Register Evaluation CMU-K20/21/22/23/24 CONFigure:IQIF:RXPath <Path> RX Path <Path> Description of parameters Def. value Def. unit FW vers. Bypass – V3.10 BYIQ Bypass w. I/Q-IF OUT XOIO I/Q IN/OUT IOIO IF IN_I/Q IN/OUT IOXO IF IN/OUT Description of command This command selects the RX signal path, leaving the TX path (see command CONFigure:IQIF:TXPath below) unchanged but adapting the I/Q-IF test scenario to the new RX/TX path combination: If the combination corresponds to a predefined scenario, then CONFigure:IQIF:RXTXcombined is set to the predefined...

  • Page 339: Wpower

    CMU-K20/21/22/23/24 Common: WPOWer STATus:OPERation:SYMBolic:ENABle <Event>{,<Event>} Symbolic status evaluation Parameter list Parameter description Default Unit FW vers. Def. Value <Event>{,<Event>} | List of symbols for events to be reported NONE – V3.05 NONE No event reported Command description This command enables event reporting for one or several events in the current GSMxxx-MS Non Signalling function group, i.e.
  • Page 340 Common: WPOWer CMU-K20/21/22/23/24 CONFigure:WPOWer:EREPorting <Mode> Event Reporting <Mode> Description of parameters Def. value Def. unit FW vers. SRQ | Service request – 1.17 SOPC | Single operation complete SRSQ | SRQ and SOPC No reporting Description of command This command defines the events generated when the measurement is terminated or stopped (event reporting, see chapter 5 of CMU200 operating manual).

  • Page 341: Measured Values - Subsystem Wpower

    CMU-K20/21/22/23/24 Common: WPOWer Measured Values – Subsystem WPOWer? The subsystem WPOWer? retrieves the results of the wideband power measurement. READ[:SCALar]:WPOWer? Start single shot measurement and return results FETCh[:SCALar]:WPOWer? Read out measurement results (unsynchronized) SAMPle[:SCALar]:WPOWer? Read out measurement results (synchronized) Return Description of parameters Def.

  • Page 342: Npower

    Common: NPOWer CMU-K20/21/22/23/24 NPOWer The subsystem NPOWer measures the power of the signal transmitted by the mobile phone using the RF analyzer configuration of the POWer measurement. Compared to WPOWer, the NPOWer measurement uses a narrow-band (500 kHz Gauss) filter. The narrow-band NPOWer measurement yields the average, maximum and minimum burst power of the current burst.

  • Page 343: Subsystem Npower:control

    CMU-K20/21/22/23/24 Common: NPOWer Subsystem NPOWer:CONTrol The subsystem NPOWer:CONTrol defines the repetition mode, statistic count, stop condition, and stepping mode of the NPOWer measurement. CONFigure:NPOWer:CONTrol <Statistics>, <Repetition>,<StopCond>,<Stepmode>Scope of Measurement <Statistics> Description of parameters Def. value Def. unit 1 to 1000 | No.

  • Page 344: Measured Values - Subsystem Npower

    Common: NPOWer CMU-K20/21/22/23/24 CONFigure:NPOWer:CONTrol:REPetition <Repetition>,<StopCond>,<Stepmode> Test cycles <Repetition> Description of parameters Def. value Def. unit CONTinuous | Continuous measurement (until STOP or ABORT) SING – SINGleshot | Single shot measurement (until Status = RDY) 1 ... 10000 Multiple measurement (counting, until Status = STEP | RDY) <StopCond>...

  • Page 345: Power:slot

    CMU-K20/21/22/23/24 Common: POWer:SLOT POWer:SLOT The subsystem POWer:SLOT controls the Power vs. Slot measurement. It corresponds to the measurement menu Power with the applications P/Slot Graph. Note: The POWer:SLOT measurement can not be carried out with a Free Run trigger (TRIG- ger[:SEQuence]:SOURce FRUN).

  • Page 346: Power:slot:control

    Common: POWer:SLOT CMU-K20/21/22/23/24 POWer:SLOT:CONTrol CONFigure:POWer:SLOT:CONTrol:REPetition <Repetition>,<StopCondition>,<Stepmode> Test Cycles <Repetition> Description of parameters Def. value Def. unit CONTinuous | Continuous measurement SING – (continuous, until STOP or ABORT) SINGleshot | Single measurement (single shot, until Status = RDY) 1 to 10000 Multiple measurement (counting, until Status = STEP | RDY) <StopCond>...

  • Page 347: Subsystem Subarrays:power:slot

    CMU-K20/21/22/23/24 Common: POWer:SLOT Subsystem SUBarrays:POWer:SLOT The subsystem SUBarrays:POWer:SLOT defines the measurement range and the type of output values. CONFigure:SUBarrays:POWer:SLOT <Mode>,<Start>,<Samples>{,<Start>,<Samples>} Definition of Subarrays <Mode> Description of parameters Def. value Def. unit ALL | Return all measurement values – ARIThmetical | Return arithm.
  • Page 348 Common: POWer:SLOT CMU-K20/21/22/23/24 READ[:SCALar]:POWer:SLOT:SPOWer<nr>? Single Result Start single shot measurement and return results FETCh[:SCALar]:POWer:SLOT:SPOWer<nr>? Read out measurement results (unsynchronized) SAMPle[:SCALar]:POWer:SLOT:SPOWer<nr>? Read out measurement results (synchronized) Returned Values Description of parameters Def. value Def. unit FW vers. –100 dBm to 100 dBm Avg.

  • Page 349: Power:xslot

    CMU-K20/21/22/23/24 Common: POWer:XSLot POWer:XSLot The subsystem POWer:XSLot controls the Power vs. Slot measurement. It corresponds to the measurement menu Power with the applications P/Slot Table. Note: The POWer:XSLot measurement can not be carried out with a Free Run trigger (TRIG- ger[:SEQuence]:SOURce FRUN).

  • Page 350: Subsystem Power:xslot:control

    Common: POWer:XSLot CMU-K20/21/22/23/24 Subsystem POWer:XSLot:CONTrol CONFigure:POWer:XSLot:CONTrol:REPetition <Repetition>,<StopCondition>,<Stepmode> Test Cycles <Repetition> Description of parameters Def. value Def. unit CONTinuous | Continuous measurement SING – (continuous, until STOP or ABORT) SINGleshot | Single measurement (single shot, until Status = RDY) 1 to 10000 Multiple measurement (counting, until Status = STEP | RDY) <StopCond>...
  • Page 351 CMU-K20/21/22/23/24 Common: POWer:XSLot CONFigure:POWer:XSLot:SCOunt <Group>[,<Number>] Slot Count <Group> Description of parameters Def. value Def. unit S128 | S256 | S384 | S512 Number of slots measured, if an integer S128 – multiple of 128 <Number> Description of parameters Def. value Def.

  • Page 352: Subsystem Subarrays:power:xslot

    Common: POWer:XSLot CMU-K20/21/22/23/24 Subsystem SUBarrays:POWer:XSLot The subsystem SUBarrays:POWer:XSLot defines the measurement range and the type of output val- ues. CONFigure:SUBarrays:POWer:XSLot <Mode>,<Start>,<Samples>{,<Start>,<Samples>} Definition of Subarrays <Mode> Description of parameters Def. value Def. unit ALL | Return all measurement values – ARIThmetical | Return arithm.
  • Page 353 CMU-K20/21/22/23/24 Common: POWer:XSLot Single Result READ[:SCALar]:POWer:XSLot:SPOWer<nr>? Start single shot measurement and return results FETCh[:SCALar]:POWer:XSLot:SPOWer<nr>? Read out measurement results (unsynchronized) SAMPle[:SCALar]:POWer:XSLot:SPOWer<nr>? Read out measurement results (synchronized) Returned Values Description of parameters Def. value Def. unit FW vers. –100 dBm to 100 dBm Avg.

  • Page 354: Power:frame

    Common: POWer:FRAMe CMU-K20/21/22/23/24 POWer:FRAMe The subsystem POWer:FRAMe controls the Power vs. Frame measurement. It corresponds to the measurement menu Power with the applications P/Frame. Note: The POWer:FRAMe measurement can not be carried out with a Free Run trigger (TRIG- ger[:SEQuence]:SOURce FRUN). ⇒...

  • Page 355: Subsystem Power:frame:control

    CMU-K20/21/22/23/24 Common: POWer:FRAMe Subsystem POWer:FRAMe:CONTrol CONFigure:POWer:FRAMe:CONTrol:REPetition <Repetition>,<StopCondition>,<Stepmode> Test Cycles <Repetition> Description of parameters Def. value Def. unit CONTinuous | Continuous measurement SING – (continuous, until STOP or ABORT) SINGleshot | Single measurement (single shot, until Status = RDY) 1 to 10000 Multiple measurement (counting, until Status = STEP | RDY) <StopCond>...

  • Page 356: Subsystem Subarrays:power:frame

    Common: POWer:FRAMe CMU-K20/21/22/23/24 Subsystem SUBarrays:POWer:FRAMe The subsystem SUBarrays:POWer:FRAMe defines the measurement range and the type of return values. CONFigure:SUBarrays:POWer:FRAMe <Mode>,<Start>,<Samples>{,<Start>,<Samples>} Definition of Subarrays <Mode> Description of parameters Def. value Def. unit ALL | Return all measurement values – ARIThmetical | Return arithm.
  • Page 357 CMU-K20/21/22/23/24 Common: POWer:FRAMe Single Result READ[:SCALar]:POWer:FRAMe:FPOWer<nr>? Start single shot measurement and return results FETCh[:SCALar]:POWer:FRAMe:FPOWer<nr>? Read out measurement results (unsynchronized) SAMPle[:SCALar]:POWer:FRAMe:FPOWer<nr>? Read out measurement results (synchronized) Returned Values Description of parameters Def. value Def. unit FW vers. –100 dBm to 100 dBm Avg.

  • Page 358: Power:mslot

    Common: POWer:MSLot CMU-K20/21/22/23/24 POWer:MSLot The subsystem POWer:MSLot measures the MS output carrier power versus time in up to 4 consecutive timeslots. The subsystem corresponds to the measurement menu Power, application P/t Multislot, and the associated popup menu Power Configuration. Note: The POWer:MSLot measurement can not be carried out with a Free Run trigger (TRIG- ger[:SEQuence]:SOURce FRUN).

  • Page 359: Subsystem Power:mslot:control

    CMU-K20/21/22/23/24 Common: POWer:MSLot Subsystem POWer:MSLot:CONTrol The subsystem POWer:MSLot:CONTrol defines the repetition mode, statistic count, and stop condition of the measurement. These settings are provided in the Control tab of the popup menu Power Configuration. CONFigure:POWer:MSLot:CONTrol <Mode>,<Statistics> Scope of Measurement <Mode> Description of parameters Def.

  • Page 360: Test Configuration

    Common: POWer:MSLot CMU-K20/21/22/23/24 CONFigure:POWer:MSLot:CONTrol:DEFault <Enable> Default Settings <Enable> Description of parameters Def. value Def. unit FW vers. ON | The parameters are set to their default values – V3.05 Some or all parameters are not set to default Description of command If used as a setting command with the parameter ON this command sets all parameters of the subsystem to their default values (the setting OFF causes an error message).
  • Page 361 CMU-K20/21/22/23/24 Common: POWer:MSLot CONFigure:POWer:MSLot:FILTer <Filter> Filter <Mode> Description of parameters Def. value Def. unit FW vers. G500 | 500 kHz Gaussian filter G500 – V3.05 B600 600 kHz bandpass filter Description of command This command selects the measurement filter for the measurement. CONFigure:POWer:MSLot:LIMit:LINE:GLEVel <Level>...

  • Page 362: Subsystem Subarrays:power:mslot

    Common: POWer:MSLot CMU-K20/21/22/23/24 Subsystem SUBarrays:POWer:MSLot The subsystem SUBarrays:POWer:MSLot defines the measurement range and the type of output values. CONFigure:SUBarrays:POWer:MSLot Definition of Subarrays <Mode>,<Start>,<Samples>{,<Start>,<Samples>} <Mode> Description of parameters Def. value Def. unit ALL | Return all measurement values – ARIThmetical | Return arithm.
  • Page 363 CMU-K20/21/22/23/24 Common: POWer:MSLot Scalar results READ[:SCALar]:POWer:MSLot? Start single shot measurement and return results FETCh[:SCALar]:POWer:MSLot? Read out measurement results (unsynchronized) SAMPle[:SCALar]:POWer:MSLot? Read out measurement results (synchronized) Returned values per timeslot Value range Def. value Def. unit FW vers. BurstsOutOfTolerance, 0.0 % to 100.0 % V3.05 AvgBurstPowerCurrent, –137 dBm to +53 dBm...
  • Page 364 Common: POWer:MSLot CMU-K20/21/22/23/24 READ:ARRay:POWer:MSLot[:CURRent]? Burst Power READ:ARRay:POWer:MSLot:AVERage? READ:ARRay:POWer:MSLot:MAXimum? READ:ARRay:POWer:MSLot:MINimum? Start single shot measurement and return results FETCh:ARRay:POWer:MSLot[:CURRent]? FETCh:ARRay:POWer:MSLot:AVERage? FETCh:ARRay:POWer:MSLot:MAXimum? FETCh:ARRay:POWer:MSLot:MINimum? Read measurement results (unsynchronized) SAMPle:ARRay:POWer:MSLot[:CURRent]? SAMPle:ARRay:POWer:MSLot:AVERage? SAMPle:ARRay:POWer:MSLot:MAXimum? SAMPle:ARRay:POWer:MSLot:MINimum? Read results (synchronized) Returned values Description of parameters Def. value Def. unit FW vers.
  • Page 365 CMU-K20/21/22/23/24 Common: POWer:MSLot READ:SUBarrays:POWer:MSLot[:CURRent]? Subarray Results READ:SUBarrays:POWer:MSLot:AVERage? READ:SUBarrays:POWer:MSLot:MAXimum? READ:SUBarrays:POWer:MSLot:MINimum? ⇒ RUN Start single shot measurement and return results FETCh:SUBarrays:POWer:MSLot[:CURRent]? FETCh:SUBarrays:POWer:MSLot:AVERage? FETCh:SUBarrays:POWer:MSLot:MAXimum? FETCh:SUBarrays:POWer:MSLot:MINimum? ⇒ RUN Read meas. results (unsynchronized) SAMPle:SUBarrays:POWer:MSLot[:CURRent]? SAMPle:SUBarrays:POWer:MSLot:AVERage? SAMPle:SUBarrays:POWer:MSLot:MAXimum? SAMPle:SUBarrays:POWer:MSLot:MINimum? ⇒ RUN Read results (synchronized) Ret. values per subrange Description of parameters Def.

  • Page 366: Tolerance Template

    Common: POWer:MSLot CMU-K20/21/22/23/24 Tolerance Template The subsystem POWer:MSLot:AREA:LIMit... contains the commands to return the current position of the multislot tolerance template and the curve. The subsystem has no equivalent in manual control, however, the current template is indicated in the graphical P/t Multislot digaram. [SENSe:]ARRay:POWer:MSLot:AREA:LIMit:UPPer:TIME? Time of all Areas [SENSe:]ARRay:POWer:MSLot:AREA:LIMit:LOWer:TIME?
  • Page 367 CMU-K20/21/22/23/24 Common: POWer:MSLot [SENSe:]ARRay:POWer:MSLot:AREA:LIMit:INFO:STIMe? Timeslot of all Areas Returned value Value range Def. value Def. unit FW vers. –180 symb. to +520 symb. Start time of measurement curve symb. V3.10 Description of command This commands returns the start time of the measurement curve relative to the beginning of the measured timeslot (Meas.

  • Page 368: Modulation[:Perror]

    Common: MODulation[:PERRor] CMU-K20/21/22/23/24 MODulation[:PERRor] The subsystem MODulation[:PERRor][:GMSK] measures the modulation parameters (frequency and phase errors) in GMSK modulation. The subsystem corresponds to the measurement menu Modulation, application Ext. Phase Err. GMSK, and the associated popup menu Modulation Config, however, it does not provide the I/Q Imbalance and the Origin Offset in the I/Q constellation diagram.

  • Page 369: Subsystem Modulation[:Perror][:Gmsk]:Control

    CMU-K20/21/22/23/24 Common: MODulation[:PERRor] FETCh:MODulation[:PERRor][:GMSK]:STATus? Measurement Status Ret. values Description of parameters Def. value Def. unit FW vers. OFF | Measurement in the OFF state (*RST or ABORt) – V1.15 RUN | Running (after INITiate, CONTinue or READ) STOP | Stopped (STOP) ERR | OFF (could not be started) STEP |...

  • Page 370: Tolerance Values - Subsystem Modulation[:Perror][:Gmsk]:Limit

    Common: MODulation[:PERRor] CMU-K20/21/22/23/24 CONFigure:MODulation[:PERRor][:GMSK]:CONTrol:REPetition Test Cycles <Repetition> ,<StopCond>,<Stepmode> <Repetition> Description of parameters Def. value Def. unit CONTinuous | Continuous measurement (until STOP or ABORT) SING – SINGleshot | Single shot measurement (until Status = RDY) 1 to 10000 Multiple measurement (counting, until Status = STEP | RDY) <StopCond>...
  • Page 371 CMU-K20/21/22/23/24 Common: MODulation[:PERRor] CONFigure:MODulation[:PERRor][:GMSK]:LIMit:UPPer:MODE <Mode> Upper Limit Check on/off <Mode> Description of parameters Def. value Def. unit FW vers. ON | Upper limit check on – V2.00 Upper limit check off Description of command This command switches on or off the tolerance check with respect to the upper limit lines (current and average). CONFigure:MODulation[:PERRor][:GMSK]:LIMit:LOWer:MODE <Mode>...

  • Page 372: Subsystem Modulation

    Common: MODulation[:PERRor] CMU-K20/21/22/23/24 Subsystem MODulation...:TIME The subsystem MODulation...:TIME defines the decoding for the Modulation measurement. The subsystem corresponds to the Decode hotkey in the graphical measurement menu Modulation. CONFigure:MODulation[:PERRor][:GMSK]:TIME:DECode <Mode> Decode <Mode> Description of parameters Def. value Def. unit FW vers. STANdard | The standard bit range is decoded GTBits...

  • Page 373: Measured Values - Subsystem Modulation[:Perror][:Gmsk]

    CMU-K20/21/22/23/24 Common: MODulation[:PERRor] Measured Values – Subsystem MODulation[:PERRor][:GMSK]? The subsystem MODulation[:PERRor][:GMSK] measures and returns the modulation results and compares them with the tolerance values. The subsystem corresponds to the various output elements in the graphical measurement menu MODulation[:PERRor][:GMSK]. Scalar Results: READ[:SCALar]:MODulation[:PERRor][:GMSK]? Start single shot meas.
  • Page 374 Common: MODulation[:PERRor] CMU-K20/21/22/23/24 CALCulate:MODulation[:PERRor][:GMSK]:LIMit:MATChing? Bursts out of Tolerance Returned values Value range Def. value Def. unit FW vers. PhErrPeakCurrent, – V1.15 PhErrPeakAverage, – – PhErrPeakMaxMin, For all measured values: PhErrRMSCurrent, – PhErrRMSAverage, – PhErrRMSMaxMin, NMAU | NMAL | INV | OK –...
  • Page 375 CMU-K20/21/22/23/24 Common: MODulation[:PERRor] READ:SUBarrays:MODulation[:PERRor][:GMSK][:CURRent]? Subarray Results READ:SUBarrays:MODulation[:PERRor][:GMSK]:AVERage? READ:SUBarrays:MODulation[:PERRor][:GMSK]:MMAXimum? ⇒ RUN Start single shot measurement and return results FETCh:SUBarrays:MODulation[:PERRor][:GMSK][:CURRent]? FETCh:SUBarrays:MODulation[:PERRor][:GMSK]:AVERage? FETCh:SUBarrays:MODulation[:PERRor][:GMSK]:MMAXimum? ⇒ RUN Read meas. results (unsynchronized) SAMPle:SUBarrays:MODulation[:PERRor][:GMSK][:CURRent]? SAMPle:SUBarrays:MODulation[:PERRor][:GMSK]:AVERage? SAMPle:SUBarrays:MODulation[:PERRor][:GMSK]:MMAXimum? ⇒ RUN Read results (synchronized) Ret. values per subrange Description of parameters Def.

  • Page 376: Modulation:xperror

    Common: MODulation:XPERror CMU-K20/21/22/23/24 MODulation:XPERror The subsystem MODulation:XPERror[:GMSK] measures the modulation parameters (frequency and phase errors) in GMSK modulation including the I/Q Imbalance and the Origin Offset in the I/Q constellation diagram. The subsystem corresponds to the measurement menu Modulation, application Ext.

  • Page 377: Subsystem Modulation:xperror[:Gmsk]:Control

    CMU-K20/21/22/23/24 Common: MODulation:XPERror CONFigure:MODulation:XPERror[:GMSK]:TIME:DECode <Mode> Decode <Mode> Description of parameters Def. value Def. unit FW vers. STANdard The standard bit range is decoded GTBits – V2.15 GTBits The guard and tail bits are also decoded Description of command This command selects the type of decoding applied for the determination of phase and frequency errors. CONFigure:MODulation:XPERror[:GMSK]:FILTer <Filter>...

  • Page 378: Tolerance Values - Subsystem Modulation:xperror[:Gmsk]:Limit

    Common: MODulation:XPERror CMU-K20/21/22/23/24 CONFigure:MODulation:XPERror[:GMSK]:CONTrol:REPetition Test Cycles <Repetition> ,<StopCond>,<Stepmode> <Repetition> Description of parameters Def. value Def. unit SING – CONTinuous | Continuous measurement (until STOP or ABORT) SINGleshot | Single shot measurement (until Status = RDY) 1 to 10000, Multiple measurement (counting, until Status = STEP | RDY) <StopCond>...
  • Page 379 CMU-K20/21/22/23/24 Common: MODulation:XPERror CONFigure:MODulation:XPERror[:GMSK]:LIMit:AVERage Average Errors <PhaseErrorPeak>,<PhaseErrorRMS>,<OrigOffs>,<IQImb>,<FrequencyError> Parameter Description of parameters Def. value Def. unit FW vers. 0.0 deg to +50.0 deg Phase Error Peak +20.0 V2.15 0.0 deg to +50.0 deg Phase Error RMS +5.0 –100.0 dB to 0 dB Origin Offset –20 –100.0 dB to 0 dB...

  • Page 380: Subsystem Subarrays:modulation:xperror[:Gmsk]

    Common: MODulation:XPERror CMU-K20/21/22/23/24 Subsystem SUBarrays:MODulation:XPERror[:GMSK] The subsystem SUBarrays:MODulation:XPERror[:GMSK] defines the measurement range and the type of output values. CONFigure:SUBarrays:MODulation:XPERror[:GMSK] Definition of Subarrays <Mode>,<Start>,<Samples>{,<Start>,<Samples>} <Mode> Description of parameters Def. value Def. unit ALL | Return all measurement values – ARIThmetical | Return arithm.

  • Page 381: Measured Values - Subsystem Modulation:xperror[:Gmsk]

    CMU-K20/21/22/23/24 Common: MODulation:XPERror Measured Values – Subsystem MODulation:XPERror[:GMSK] The subsystem MODulation:XPERror[:GMSK] measures and returns the modulation results and compares them with the tolerance values. The subsystem corresponds to the various output elements in the graphical measurement menu MODulation:XPERror[:GMSK]. Scalar Results: READ[:SCALar]:MODulation:XPERror[:GMSK]? Start single shot meas.
  • Page 382 Common: MODulation:XPERror CMU-K20/21/22/23/24 CALCulate:MODulation:XPERror[:GMSK]:LIMit:MATChing? Bursts out of Tolerance Returned values Value range Def. value Def. unit FW vers. Phase Err. Peak Current, – V2.15 Phase Err. Peak Average, – Phase Err. Peak MaxMin, For all measured values: – Phase Err. RMS (x3), –...
  • Page 383 CMU-K20/21/22/23/24 Common: MODulation:XPERror READ:SUBarrays:MODulation:XPERror[:GMSK][:CURRent]? Subarray Results READ:SUBarrays:MODulation:XPERror[:GMSK]:AVERage? READ:SUBarrays:MODulation:XPERror[:GMSK]:MMAXimum? ⇒ RUN Start single shot measurement and return results FETCh:SUBarrays:MODulation:XPERror[:GMSK][:CURRent]? FETCh:SUBarrays:MODulation:XPERror[:GMSK]:AVERage? FETCh:SUBarrays:MODulation:XPERror[:GMSK]:MMAXimum? ⇒ RUN Read meas. results (unsynchronized) SAMPle:SUBarrays:MODulation:XPERror[:GMSK][:CURRent]? SAMPle:SUBarrays:MODulation:XPERror[:GMSK]:AVERage? SAMPle:SUBarrays:MODulation:XPERror[:GMSK]:MMAXimum? ⇒ RUN Read results (synchronized) Ret. values per subrange Description of parameters Def.

  • Page 384: Modulation[:Overview]

    Common: MODulation[:OVERview] CMU-K20/21/22/23/24 MODulation[:OVERview] The subsystem MODulation[:OVERview]:EPSK measures general scalar modulation parameters in 8PSK modulation. The subsystem corresponds to the measurement menu Modulation, application Overview 8PSK, and the associated popup menu Modulation Configuration. Control of Measurement – Subsystem MODulation:OVERview:EPSK The subsystem MODulation:OVERview:EPSK controls the modulation measurement. It corresponds to the softkey Overview 8PSK in the measurement menu Modulation.

  • Page 385: Test Configuration

    CMU-K20/21/22/23/24 Common: MODulation[:OVERview] Test Configuration The commands of the following subsystems configure the Modulation measurement. They correspond to the sections in the Modulation Configuration menu that are related to the Overview application. Subsystem MODulation:OVERview:EPSK:CONTrol The subsystem MODulation:OVERview:EPSK:CONTrol configures the modulation measurement. It corresponds to theControl tab in the popup menu Modulation Configuration.

  • Page 386: Tolerance Values - Subsystem Modulation:oemp:epsk:limit

    Common: MODulation[:OVERview] CMU-K20/21/22/23/24 CONFigure:MODulation:OVERview:EPSK:CONTrol:DEFault <Enable> Default Settings <Enable> Description of parameters Def. value Def. unit FW vers. ON | The parameters are set to their default values – V2.15 Some or all parameters differ from the default values Description of command If used as a setting command with the parameter ON this command sets all parameters of the subsystem to their default values (the setting OFF causes an error message).

  • Page 387: Measured Values - Subsystem Modulation:overview:epsk

    CMU-K20/21/22/23/24 Common: MODulation[:OVERview] CONFigure:MODulation:OEMP:EPSK:LIMit:P95Th Percentile <EVM95%>, <MError95%>, <PError95%> Parameter Description of parameters Def. value Def. unit FW vers. 0% to 50.0%, percentile EVM +5.0 V2.15 0% to 50.0%, percentile modulation error +5.0 0° to +180° percentile phase error +5.0 Description of command This command defines upper limits for the 95 percentile of the three quantities error vector magnitude, modula- tion error, and phase error.
  • Page 388 Common: MODulation[:OVERview] CMU-K20/21/22/23/24 Description of command These commands are always queries. They start a modulation measurement and output all scalar measurement results (see chapter 4). The calculation of results in an average or peak measurement is described in chapter 3 (see calculation of statistical quantities).

  • Page 389: Modulation:evmagnitude

    CMU-K20/21/22/23/24 Common: MODulation:EVMagnitude MODulation:EVMagnitude The subsystem MODulation:EVMagnitude measures the error vector magnitude as well as general scalar modulation parameters. The subsystem corresponds to the measurement menu Modulation, application EVM 8PSK, and the associated popup menu Modulation Configuration. Control of Measurement – Subsystem MODulation:EVMagnitude The subsystem MODulation:EVMagnitude controls the modulation measurement.

  • Page 390: Test Configuration

    Common: MODulation:EVMagnitude CMU-K20/21/22/23/24 Test Configuration The commands of the following subsystems configure the Modulation measurement. They correspond to the sections in the Modulation Configuration menu that are related to the Error Vector Magnitude application. Subsystem MODulation:EVMagnitude:EPSK:CONTrol The subsystem MODulation:EVMagnitude:EPSK:CONTrol configures the modulation measurement. It corresponds to the Control tab in the popup menu Modulation Configuration.

  • Page 391: Tolerance Values - Subsystem Modulation:oemp:epsk:limit

    CMU-K20/21/22/23/24 Common: MODulation:EVMagnitude CONFigure:MODulation:EVMagnitude:EPSK:CONTrol:DEFault <Enable> Default Settings <Enable> Description of parameters Def. value Def. unit FW vers. ON | The parameters are set to their default values – V2.15 Some or all parameters differ from the default values Description of command If used as a setting command with the parameter ON this command sets all parameters of the subsystem to their default values (the setting OFF causes an error message).

  • Page 392: Subsystem Subarrays:modulation

    Common: MODulation:EVMagnitude CMU-K20/21/22/23/24 Subsystem SUBarrays:MODulation The subsystem SUBarrays:MODulation defines the measurement range and the type of output values. CONFigure:SUBarrays:MODulation:EVMagnitude:EPSK <Mode>,<Start>,<Samples>{,<Start>,<Samples>} Definition of Subarrays <Mode> Description of parameters Def. value Def. unit ALL | Return all measurement values – ARIThmetical | Return arithm.

  • Page 393: Measured Values - Subsystem Modulation:evmagnitude:epsk

    CMU-K20/21/22/23/24 Common: MODulation:EVMagnitude Measured Values – Subsystem MODulation:EVMagnitude:EPSK The subsystem MODulation:EVMagnitude:EPSK measures and returns the modulation parameters and compares them with the tolerance values. The subsystem corresponds to the various output elements in the measurement menu MODulation, application EVM 8PSK. Scalar Results: READ[:SCALar]:MODulation:EVMagnitude:EPSK? Start single shot meas.
  • Page 394 Common: MODulation:EVMagnitude CMU-K20/21/22/23/24 READ:ARRay:MODulation:EVMagnitude:EPSK[:CURRent]? Phase Error in Burst READ:ARRay:MODulation:EVMagnitude:EPSK:AVERage? READ:ARRay:MODulation:EVMagnitude:EPSK:MMAXimum? ⇒ RUN Start single shot measurement and return results FETCh:ARRay:MODulation:EVMagnitude:EPSK[:CURRent]? FETCh:ARRay:MODulation:EVMagnitude:EPSK:AVERage? FETCh:ARRay:MODulation:EVMagnitude:EPSK:MMAXimum? ⇒ RUN Read measurement results (unsynchronized) SAMPle:ARRay:MODulation:EVMagnitude:EPSK[:CURRent]? SAMPle:ARRay:MODulation:EVMagnitude:EPSK:AVERage? SAMPle:ARRay:MODulation:EVMagnitude:EPSK:MMAXimum? ⇒ RUN Read measurement results (synchronized) Returned values Description of parameters Def.

  • Page 395: Modulation:perror

    CMU-K20/21/22/23/24 Common: MODulation:PERRor MODulation:PERRor The subsystem MODulation:PERRor measures the phase error as well as general scalar modulation parameters. The subsystem corresponds to the measurement menu Modulation, application Phase Error 8PSK, and the associated popup menu Modulation Configuration. Control of Measurement – Subsystem MODulation:PERRor The subsystem MODulation:PERRor controls the modulation measurement.

  • Page 396: Test Configuration

    Common: MODulation:PERRor CMU-K20/21/22/23/24 Test Configuration The commands of the following subsystems configure the Modulation measurement. They correspond to the sections in the Modulation Configuration menu that are related to the Phase Error application. Subsystem MODulation[:PERRor]:EPSK:CONTrol The subsystem MODulation[:PERRor]:EPSK:CONTrol configures the modulation measurement. It cor- responds to the Control tab in the popup menu Modulation Configuration.

  • Page 397: Tolerance Values - Subsystem Modulation:oemp:epsk:limit

    CMU-K20/21/22/23/24 Common: MODulation:PERRor CONFigure:MODulation[:PERRor]:EPSK:CONTrol:DEFault <Enable> Default Settings <Enable> Description of parameters Def. value Def. unit FW vers. ON | The parameters are set to their default values – V2.15 Some or all parameters differ from the default values Description of command If used as a setting command with the parameter ON this command sets all parameters of the subsystem to their default values (the setting OFF causes an error message).

  • Page 398: Subsystem Subarrays:modulation[:Perror]:Epsk

    Common: MODulation:PERRor CMU-K20/21/22/23/24 Subsystem SUBarrays:MODulation[:PERRor]:EPSK The subsystem SUBarrays:MODulation defines the measurement range and the type of output values. CONFigure:SUBarrays:MODulation[:PERRor]:EPSK <Mode>,<Start>,<Samples>{,<Start>,<Samples>} Definition of Subarrays <Mode> Description of parameters Def. value Def. unit ALL | Return all measurement values – ARIThmetical | Return arithm.

  • Page 399: Measured Values - Subsystem Modulation[:Perror]:Epsk

    CMU-K20/21/22/23/24 Common: MODulation:PERRor Measured Values – Subsystem MODulation[:PERRor]:EPSK The subsystem MODulation[:PERRor]:EPSK measures and returns the modulation parameters and compares them with the tolerance values. The subsystem corresponds to the various output elements in the measurement menu MODulation, application Phase Error 8PSK. Scalar Results: READ[:SCALar]:MODulation[:PERRor]:EPSK? Start single shot meas.
  • Page 400 Common: MODulation:PERRor CMU-K20/21/22/23/24 READ:ARRay:MODulation[:PERRor]:EPSK[:CURRent]? Phase Error in Burst READ:ARRay:MODulation[:PERRor]:EPSK:AVERage? READ:ARRay:MODulation[:PERRor]:EPSK:MMAXimum? ⇒ RUN Start single shot measurement and return results FETCh:ARRay:MODulation[:PERRor]:EPSK[:CURRent]? FETCh:ARRay:MODulation[:PERRor]:EPSK:AVERage? FETCh:ARRay:MODulation[:PERRor]:EPSK:MMAXimum? ⇒ RUN Read measurement results (unsynchronized) SAMPle:ARRay:MODulation[:PERRor]:EPSK[:CURRent]? SAMPle:ARRay:MODulation[:PERRor]:EPSK:AVERage? SAMPle:ARRay:MODulation[:PERRor]:EPSK:MMAXimum? ⇒ RUN Read measurement results (synchronized) Returned values Description of parameters Def.

  • Page 401: Modulation:merror

    CMU-K20/21/22/23/24 Common: MODulation:MERRor MODulation:MERRor The subsystem MODulation:MERRor measures the magnitude error as well as general scalar modula- tion parameters. The subsystem corresponds to the measurement menu Modulation, application Magn. Error 8PSK, and the associated popup menu Modulation Configuration. Control of Measurement – Subsystem MODulation:MERRor The subsystem MODulation:MERRor controls the modulation measurement.

  • Page 402: Test Configuration

    Common: MODulation:MERRor CMU-K20/21/22/23/24 Test Configuration The commands of the following subsystems configure the Modulation measurement. They correspond to the sections in the Modulation Configuration menu that are related to the Magnitude Error application. Subsystem MODulation:MERRor:EPSK:CONTrol The subsystem MODulation:MERRor:EPSK:CONTrol configures the modulation measurement. It corre- sponds to the Control tab in the popup menu Modulation Configuration.

  • Page 403: Tolerance Values - Subsystem Modulation:oemp:epsk:limit

    CMU-K20/21/22/23/24 Common: MODulation:MERRor CONFigure:MODulation:MERRor:EPSK:CONTrol:DEFault <Enable> Default Settings <Enable> Description of parameters Def. value Def. unit FW vers. ON | The parameters are set to their default values – V2.15 Some or all parameters differ from the default values Description of command If used as a setting command with the parameter ON this command sets all parameters of the subsystem to their default values (the setting OFF causes an error message).

  • Page 404: Subsystem Subarrays:modulation

    Common: MODulation:MERRor CMU-K20/21/22/23/24 Subsystem SUBarrays:MODulation The subsystem SUBarrays:MODulation defines the measurement range and the type of output values. CONFigure:SUBarrays:MODulation:MERRor:EPSK <Mode>,<Start>,<Samples>{,<Start>,<Samples>} Definition of Subarrays <Mode> Description of parameters Def. value Def. unit ALL | Return all measurement values – ARIThmetical | Return arithm.
  • Page 405 CMU-K20/21/22/23/24 Common: MODulation:MERRor Scalar Results: READ[:SCALar]:MODulation:MERRor:EPSK? Start single shot meas. and return results FETCh[:SCALar]:MODulation:MERRor:EPSK? Read out meas. results (unsynchronized) SAMPle[:SCALar]:MODulation:MERRor:EPSK? Read out measurement results (synchronized) Returned values Value range Def. value Def. unit FW vers. 95thPercentileMErr 0.0 % to 100.0 % V2.15 MErrPeak (x3), 0.0 % to 100.0 %...
  • Page 406 Common: MODulation:MERRor CMU-K20/21/22/23/24 READ:ARRay:MODulation:MERRor:EPSK[:CURRent]? Phase Error in Burst READ:ARRay:MODulation:MERRor:EPSK:AVERage? READ:ARRay:MODulation:MERRor:EPSK:MMAXimum? ⇒ RUN Start single shot measurement and return results FETCh:ARRay:MODulation:MERRor:EPSK[:CURRent]? FETCh:ARRay:MODulation:MERRor:EPSK:AVERage? FETCh:ARRay:MODulation:MERRor:EPSK:MMAXimum? ⇒ RUN Read measurement results (unsynchronized) SAMPle:ARRay:MODulation:MERRor:EPSK[:CURRent]? SAMPle:ARRay:MODulation:MERRor:EPSK:AVERage? SAMPle:ARRay:MODulation:MERRor:EPSK:MMAXimum? ⇒ RUN Read measurement results (synchronized) Returned values Description of parameters Def.

  • Page 407: Spectrum:modulation

    CMU-K20/21/22/23/24 Common: SPECtrum:MODulation SPECtrum:MODulation The subsystem SPECtrum:MODulation[:GMSK] measures the off-carrier power due to the modulation of the GSM signal. The subsystem corresponds to the measurement menu Spectrum, application due to Modulation, and the associated configuration popups. Note: GMSK and 8PSK modulation The keywords [:GMSK] and :EPSK in the remote control commands denote GMSK and 8PSK modulation, respectively.

  • Page 408: Subsystem Spectrum:modulation:control

    Common: SPECtrum:MODulation CMU-K20/21/22/23/24 FETCh:SPECtrum:MODulation[:GMSK]:STATus? FETCh:SPECtrum:MODulation:EPSK:STATus? Measurement Status Returned values Description of parameters Def. value Def. unit FW vers. OFF | Measurement in the OFF state (*RST or ABORt) – V1.20 RUN | Running (after INITiate, CONTinue or READ) STOP | Stopped (STOP) ERR | OFF (could not be started)
  • Page 409 CMU-K20/21/22/23/24 Common: SPECtrum:MODulation CONFigure:SPECtrum:MODulation[:GMSK]:CONTrol:REPetition Test cycles CONFigure:SPECtrum:MODulation:EPSK:CONTrol:REPetition <Repetition>,<StopCondition>,<Stepmode> <Repetition> Description of parameters Def. value Def. unit CONTinuous | Continuous measurement (until STOP or ABORT) SING – SINGleshot | Single shot measurement (until Status = RDY) 1 to 10000 Multiple measurement (counting, until Status = STEP | RDY) <StopCondition>...

  • Page 410: Test Configuration

    Common: SPECtrum:MODulation CMU-K20/21/22/23/24 CONFigure:SPECtrum:MODulation[:GMSK]:CONTrol:DEFault <Enable> CONFigure:SPECtrum:MODulation:EPSK:CONTrol:DEFault <Enable> Default Settings <Enable> Description of parameters Def. value Def. unit FW vers. ON | All the parameters of the subsystem are set to default values – V2.00 At least one parameter of the subsystem differs from its default value Description of command If used as a setting command with the parameter ON, this command sets all the parameters of the subsystem to...
  • Page 411 CMU-K20/21/22/23/24 Common: SPECtrum:MODulation The limits are defined at up to 11 fixed frequencies numbered by the numeric suffix <nr> and as a function of the output power level. Outside interpolation range defined CONFig- fixed relative power limits ure:SPECtrum:MODulation:LIMit:LINE :REFPower[:UPPer], <MinPwLevelRel> and <MaxPwLevelRel> apply. Inside this range, the limits are derived from these values by linear interpolation.

  • Page 412: Subsystem Subarrays:spectrum:modulation

    Common: SPECtrum:MODulation CMU-K20/21/22/23/24 CONFigure:SPECtrum:MODulation[:GMSK]:LIMit:LINE:MODE[:UPPer] <Mode> CONFigure:SPECtrum:MODulation:EPSK:LIMit:LINE:MODE[:UPPer] <Mode> Limits on/off <Mode> Description of parameters Def. value Def. unit FW vers. ON | Switch on limit lines – V1.20 Switch off limit lines Description of command This command switches all limit lines for the spectrum due to modulation measurement on or off. CONFigure:SPECtrum:MODulation[:GMSK]:LIMit:LINE:DEFault <Enable>...

  • Page 413: Measured Values

    CMU-K20/21/22/23/24 Common: SPECtrum:MODulation For <Mode> = IVAL, the <Samples> parameter is ignored and the CMU returns a single measurement value corresponding to the abscissa value <Start>. If <Start> is located beween two test points with valid results then the result is calculated from the results at these two adjacent test points by linear interpolation. The subranges may overlap but must be within the total range of the spectrum due to modulation measurement.
  • Page 414 Common: CMU-K20/21/22/23/24 The reference power is the absolute carrier power measured as specified in the GSM standard. The following messages may be output for the value Matching: invalid MATC matching NMAT not matching out of range no trigger NRAM not ramping (burst not found) OFLW overflow UFLW...

  • Page 415: Spectrum:switching

    CMU-K20/21/22/23/24 Common: SPECtrum:SWITching SPECtrum:SWITching The subsystem SPECtrum:SWITching measures the off-carrier power due to the bursty nature of the GSM signal. The subsystem corresponds to the measurement menu Spectrum, application due to Switching, and the associated configuration popups. Control of Measurement – Subsystem SPECtrum:SWITching The subsystem SPECtrum:SWITching controls the spectrum due to switching measurement.

  • Page 416: Subsystem Spectrum:switching:control

    Common: SPECtrum:SWITching CMU-K20/21/22/23/24 FETCh:SPECtrum:SWITching[:GMSK]:STATus? FETCh:SPECtrum:SWITching:EPSK:STATus? Measurement Status Returned values Description of parameters Def. value Def. unit FW vers. OFF | Measurement in the OFF state (*RST or ABORt) – V1.20 RUN | Running (after INITiate, CONTinue or READ) STOP | Stopped (STOP) ERR | OFF (could not be started)
  • Page 417 CMU-K20/21/22/23/24 Common: SPECtrum:SWITching CONFigure:SPECtrum:SWITching[:GMSK]:CONTrol <Mode>,<Statistics> CONFigure:SPECtrum:SWITching:EPSK:CONTrol <Mode>,<Statistics> Scope of Measurement <Mode> Description of parameters Def. value Def. unit SCALar | Only scalar measured values ARRay – ARRay Scalar measured values and arrays <Statistics> Description of parameters Def. value Def. unit FW vers.

  • Page 418: Test Configuration

    Common: SPECtrum:SWITching CMU-K20/21/22/23/24 CONFigure:SPECtrum:SWITching[:GMSK]:CONTrol:MPOint<nr>:ENABle <Enable> CONFigure:SPECtrum:SWITching:EPSK:CONTrol:MPOint<nr>:ENABle <Enable> Enable/Disable Measurement Points <Enable> Description of parameters Def. value Def. unit FW vers. ON | Switch on measurement point <nr> – V1.20 Switch off measurement point <nr> Description of command This command switches the measurement at the individual frequency points no. 1 to 4 (numbered by the numeric suffix <nr>) on or off.
  • Page 419 CMU-K20/21/22/23/24 Common: SPECtrum:SWITching Limits CONFigure:SPECtrum:SWITching[:GMSK]:LIMit:LINE[:ASYMmetrical]:UPPer<nr>:ENABle CONFigure:SPECtrum:SWITching:EPSK:LIMit:LINE[:ASYMmetrical]:UPPer<nr>:ENABle <Enable> CONFigure:SPECtrum:SWITching[:GMSK]:LIMit:LINE[:ASYMmetrical]:UPPer<nr> CONFigure:SPECtrum:SWITching:EPSK:LIMit:LINE[:ASYMmetrical]:UPPer<nr> <Power level>, <Limit at 0.4 MHz>, <Limit at 0.6 MHz>, <Limit at 1.2 MHz>, <Limit at 1.8 MHz>,<Enable> Numeric Suffix Value range Description of parameters Def. value <nr> 1 to10 Power level no. Parameters Value range Description of parameters...
  • Page 420 Common: SPECtrum:SWITching CMU-K20/21/22/23/24 Default values for GSM1800 (both modulation schemes): Level <nr> Level / [dBm] 0.4 MHz / [dBc] 0.6 MHz / [dBc] 1.2 MHz / [dBc] 1.8 MHz / [dBc] ≥ 36.0 –16.0 –21.0 –21.0 –24.0 34.0 –18.0 –21.0 –21.0 –24.0 32.0...

  • Page 421: Subsystem Subarrays:spectrum:switching

    CMU-K20/21/22/23/24 Common: SPECtrum:SWITching Subsystem SUBarrays:SPECtrum:SWITching The subsystem SUBarrays:SPECtrum:SWITching defines the measurement range and the type of out- put values. CONFigure:SUBarrays:SPECtrum:SWITching[:GMSK] CONFigure:SUBarrays:SPECtrum:SWITching:EPSK <Mode>,<Start>,<Samples>{,<Start>,<Samples>} Definition of Subarrays <Mode> Description of parameters Def. value Def. unit ALL | Return all measurement values – ARIThmetical | Return arithm.

  • Page 422: Subsystem Spectrum:switching

    Common: SPECtrum:SWITching CMU-K20/21/22/23/24 Subsystem SPECtrum:SWITching The subsystem SPECtrum:SWITching measures and returns the frequency spectum (due to switching) and compares it with tolerance values. The subsystem corresponds to the graphical measurement menu Spectrum. READ[:SCALar]:SPECtrum:SWITching[:GMSK]? Scalar Results READ[:SCALar]:SPECtrum:SWITching:EPSK? Start single shot measurement and return results FETCh[:SCALar]:SPECtrum:SWITching[:GMSK]? FETCh[:SCALar]:SPECtrum:SWITching:EPSK? Read measurement results (unsynchronized)
  • Page 423 CMU-K20/21/22/23/24 Common: SPECtrum:SWITching READ:SUBarrays:SPECtrum:SWITching[:GMSK]? Subarray Results ⇒ RUN READ:SUBarrays:SPECtrum:SWITching:EPSK? Start meas. and return results FETCh:SUBarrays:SPECtrum:SWITching[:GMSK]? ⇒ RUN FETCh:SUBarrays:SPECtrum:SWITching:EPSK? Read meas. results (unsynchronized) SAMPle:SUBarrays:SPECtrum:SWITching[:GMSK]? ⇒ RUN SAMPle:SUBarrays:SPECtrum:SWITching:EPSK? Read results (synchronized) Ret. values per subrange Description of parameters Def. value Def. unit FW vers.

  • Page 424: Measurement Groups (Signalling Only)

    Signalling: POWer[:NORMal] CMU-K20/21/22/23/24 Measurement Groups (Signalling only) The measurement groups in this section are either provided in Signalling mode only or implemented with major differences in the two test modes. POWer[:NORMal] The subsystem POWer[:NORMal] measures the MS transmitter output power versus time for normal bursts.
  • Page 425 CMU-K20/21/22/23/24 Signalling: POWer[:NORMal] CONFigure:POWer[:NORMal][:GMSK]:EREPorting <Mode> Event Reporting CONFigure:POWer[:NORMal]:EPSK:EREPorting <Mode> <Mode> Description of parameters Def. value Def. unit FW vers. SRQ | Service request – V1.15 SOPC | Single operation complete SRSQ | SRQ and SOPC No reporting Description of command This command defines the events generated when the measurement is terminated or stopped (event reporting, see chapter 5 of CMU manual).

  • Page 426: Test Configuration

    Signalling: POWer[:NORMal] CMU-K20/21/22/23/24 Test Configuration The commands of the following subsystems configure the power measurement. They correspond to the sections in the Power Configuration popup menu that are related to the normal burst power measurement. For a detailed explanation of the power tolerance template defined in the GSM standard see chapter 4.
  • Page 427 CMU-K20/21/22/23/24 Signalling: POWer[:NORMal] DISPlay:POWer[:NORMal][:GMSK]:CONTrol:GRID <Enable> Grid DISPlay:POWer[:NORMal]:EPSK:CONTrol:GRID <Enable> <Enable> Description of parameters Def. value Def. unit FW vers. ON | Switch on grid lines – V1.15 Switch off grid lines Description of command This command switches the grid lines in the test diagrams on or off. CONFigure:POWer[:NORMal]:EPSK:CONTrol:RPMode <Mode>...

  • Page 428: Subsystem Power[:Normal]

    Signalling: POWer[:NORMal] CMU-K20/21/22/23/24 Subsystem POWer[:NORMal]...:LIMit:LINE The subsystem POWer[:NORMal]...:LIMit:LINE defines the limit lines and thus the tolerance values for the normal burst power measurement. The subsystem corresponds to the tab Limit Lines in the popup menu Power Configuration. CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE:UPPer<nr>[:STATic]:ENABle <Enable> CONFigure:POWer[:NORMal]:EPSK:LIMit:LINE:UPPer<nr>[:STATic]:ENABle <Enable> CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE:UPPer<nr>[:STATic] CONFigure:POWer[:NORMal]:EPSK:LIMit:LINE:UPPer<nr>[:STATic] Upper Limit Line...
  • Page 429 CMU-K20/21/22/23/24 Signalling: POWer[:NORMal] The default settings for 8MSK modulation (EDGE channels, keyword :EPSK) are given in the table below: for Enable forTable Start Stop Start Stop Start Stop Suffix Enable Time Time rel.Level rel.Level abs.Level abs.Level Visibility –10.0 symb –7 ¼ symb –59.0 –59.0 –36.0...
  • Page 430 Signalling: POWer[:NORMal] CMU-K20/21/22/23/24 The default settings for 8MSK modulation (EDGE channels, keyword :EPSK) are given in the table below: for Enable for Table Start Stop Start Stop Start Stop Suffix Enable Time Time rel.Level rel.Level abs.Level abs.Level Visibility –10.0 symb ½...
  • Page 431 CMU-K20/21/22/23/24 Signalling: POWer[:NORMal] CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE:UPPer<AreaNr>:ALL:DYNamic:ENABle CONFigure:POWer[:NORMal]:EPSK:LIMit:LINE:UPPer<AreaNr>:ALL:DYNamic:ENABle <Enable> Dynamic Correction on/off <Enable> Description of parameters Def. value Def. unit FW vers. ON | OFF Switch dynamic correction on or off – V2.00 Description of command This command switches the dynamic correction of the upper limit area <nr> for all ten PCL ranges on or off. CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE:UPPer:ALL:DYNamic:ENABle <Enable>...
  • Page 432 Signalling: POWer[:NORMal] CMU-K20/21/22/23/24 CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE:LOWer<AreaNr>:ALL:DYNamic:ENABle CONFigure:POWer[:NORMal]:EPSK:LIMit:LINE:LOWer<AreaNr>:ALL:DYNamic:ENABle <Enable> Dynamic Correction on/off <Enable> Description of parameters Def. value Def. unit FW vers. ON | OFF Switch dynamic correction on or off – VV2.00 Description of command This command switches the dynamic correction of the lower limit area <nr> for all ten PCL ranges on or off. The query returns 160 Boolean values corresponding to the limit check in PCL ranges 1 to 10 (inner loop) in each of the areas 1 to 16 (outer loop).

  • Page 433: Subsystem Power[:Normal]

    CMU-K20/21/22/23/24 Signalling: POWer[:NORMal] Subsystem POWer[:NORMal]...:LIMIt:ABPower The subsystem POWer[:NORMal]...:LIMit:ABPower defines the limit values for the average normal burst power. The subsystem corresponds to the tab Limits in the popup menu Power Configuration. CONFigure:POWer[:NORMal][:GMSK]:LIMit:ABPower<nr> Average Burst Power <StartPCL>, <StopPCL>, <LowerLimit>, <UpperLimit> CONFigure:POWer[:NORMal][:GMSK]:LIMit:ABPower<nr>:ENABle <Enable> Parameter Value range Description of parameters...

  • Page 434: Subsystem Subarrays:power

    Signalling: POWer[:NORMal] CMU-K20/21/22/23/24 Subsystem SUBarrays:POWer The subsystem SUBarrays:POWer defines the measurement range and the type of output values. CONFigure:SUBarrays:POWer[:NORMal][:GMSK] Definition of Subarrays CONFigure:SUBarrays:POWer[:NORMal]:EPSK <Mode>,<Start>,<Samples>{,<Start>,<Samples>} <Mode> Description of parameters Def. value Def. unit ALL | Return all measurement values – ARIThmetical | Return arithm.
  • Page 435 CMU-K20/21/22/23/24 Signalling: POWer[:NORMal] READ[:SCALar]:POWer[:NORMal][:GMSK]? Scalar results: READ[:SCALar]:POWer[:NORMal]:EPSK? Start single shot measurement and return results FETCh[:SCALar]:POWer[:NORMal][:GMSK]? FETCh[:SCALar]:POWer[:NORMal]:EPSK? Read out measurement results (unsynchronized) SAMPle[:SCALar]:POWer[:NORMal][:GMSK]? SAMPle[:SCALar]:POWer[:NORMal]:EPSK? Read out measurement results (synchronized) Returned values Value range Def. value Def. unit FW vers. AvgBurstPwCurr, –137 dBm to +53 dBm V1.15 PeakBurstPwCurr, –137 dBm to +53 dBm...
  • Page 436 Signalling: POWer[:NORMal] CMU-K20/21/22/23/24 CALCulate:POWer[:NORMal][:GMSK]:LIMit:MATChing? CALCulate:POWer[:NORMal]:EPSK:LIMit:MATChing? Limit Matching Returned values Value range Def. value Def. unit FW vers. – V1.15 AvgBurstPwCurr, NMAU | NMAL | INV | OK PeakBurstPwCurr, NMAU | NMAL | INV | OK – TimingAdvError, OK (no limit check) –...
  • Page 437 CMU-K20/21/22/23/24 Signalling: POWer[:NORMal] READ:ARRay:POWer[:NORMal][:GMSK][:CURRent]? READ:ARRay:POWer[:NORMal]:EPSK[:CURRent]? Burst Power READ:ARRay:POWer[:NORMal][:GMSK]:AVERage? READ:ARRay:POWer[:NORMal]:EPSK:AVERage? READ:ARRay:POWer[:NORMal][:GMSK]:MAXimum? READ:ARRay:POWer[:NORMal]:EPSK:MAXimum? READ:ARRay:POWer[:NORMal][:GMSK]:MINimum? READ:ARRay:POWer[:NORMal]:EPSK:MINimum? ⇒ RUN Start single shot measurement and return results FETCh:ARRay:POWer[:NORMal][:GMSK][:CURRent]? FETCh:ARRay:POWer[:NORMal]:EPSK[:CURRent]? FETCh:ARRay:POWer[:NORMal][:GMSK]:AVERage? FETCh:ARRay:POWer[:NORMal]:EPSK:AVERage? FETCh:ARRay:POWer[:NORMal][:GMSK]:MAXimum? FETCh:ARRay:POWer[:NORMal]:EPSK:MAXimum? FETCh:ARRay:POWer[:NORMal][:GMSK]:MINimum? FETCh:ARRay:POWer[:NORMal]:EPSK:MINimum? ⇒ RUN Read meas. results (unsynchronized) SAMPle:ARRay:POWer[:NORMal][:GMSK][:CURRent]? SAMPle:ARRay:POWer[:NORMal]:EPSK[:CURRent]? SAMPle:ARRay:POWer[:NORMal][:GMSK]:AVERage? SAMPle:ARRay:POWer[:NORMal]:EPSK:AVERage? SAMPle:ARRay:POWer[:NORMal][:GMSK]:MAXimum? SAMPle:ARRay:POWer[:NORMal]:EPSK:MAXimum? SAMPle:ARRay:POWer[:NORMal][:GMSK]:MINimum?
  • Page 438 Signalling: POWer[:NORMal] CMU-K20/21/22/23/24 READ:SUBarrays:POWer[:NORMal][:GMSK][:CURRent]? Subarray Results READ:SUBarrays:POWer[:NORMal]:EPSK[:CURRent]? READ:SUBarrays:POWer[:NORMal][:GMSK]:AVERage? READ:SUBarrays:POWer[:NORMal]:EPSK:AVERage? READ:SUBarrays:POWer[:NORMal][:GMSK]:MAXimum? READ:SUBarrays:POWer[:NORMal]:EPSK:MAXimum? READ:SUBarrays:POWer[:NORMal][:GMSK]:MINimum? READ:SUBarrays:POWer[:NORMal]:EPSK:MINimum? ⇒ RUN Start single shot measurement and return results FETCh:SUBarrays:POWer[:NORMal][:GMSK][:CURRent]? FETCh:SUBarrays:POWer[:NORMal]:EPSK[:CURRent]? FETCh:SUBarrays:POWer[:NORMal][:GMSK]:AVERage? FETCh:SUBarrays:POWer[:NORMal]:EPSK:AVERage? FETCh:SUBarrays:POWer[:NORMal][:GMSK]:MAXimum? FETCh:SUBarrays:POWer[:NORMal]:EPSK:MAXimum? FETCh:SUBarrays:POWer[:NORMal][:GMSK]:MINimum? FETCh:SUBarrays:POWer[:NORMal]:EPSK:MINimum? ⇒ RUN Read meas. results (unsynchronized) SAMPle:SUBarrays:POWer[:NORMal][:GMSK][:CURRent]? SAMPle:SUBarrays:POWer[:NORMal]:EPSK[:CURRent]? SAMPle:SUBarrays:POWer[:NORMal][:GMSK]:AVERage? SAMPle:SUBarrays:POWer[:NORMal]:EPSK:AVERage? SAMPle:SUBarrays:POWer[:NORMal][:GMSK]:MAXimum? SAMPle:SUBarrays:POWer[:NORMal]:EPSK:MAXimum? SAMPle:SUBarrays:POWer[:NORMal][:GMSK]:MINimum?
  • Page 439 CMU-K20/21/22/23/24 Signalling: POWer[:NORMal] CALCulate:ARRay:POWer[:NORMal][:GMSK]:LIMit:MATChing[:CURRent]? CALCulate:ARRay:POWer[:NORMal]:EPSK:LIMit:MATChing[:CURRent]? CALCulate:ARRay:POWer[:NORMal][:GMSK]:LIMit:MATChing:AVERage? CALCulate:ARRay:POWer[:NORMal]:EPSK:LIMit:MATChing:AVERage? CALCulate:ARRay:POWer[:NORMal][:GMSK]:LIMit:MATChing:MAXimum? CALCulate:ARRay:POWer[:NORMal]:EPSK:LIMit:MATChing:MAXimum? CALCulate:ARRay:POWer[:NORMal][:GMSK]:LIMit:MATChing:MINimum? CALCulate:ARRay:POWer[:NORMal]:EPSK:LIMit:MATChing:MINimum? Burst Matching Returned values Value range Def. value Def. unit FW vers. Matching MATC | NMAT | INV | NTSC | OUT – V1.15 Description of command This command is always a query. It indicates whether and in which way tolerances for the burst power (see command above) have been exceeded.

  • Page 440: Power:aburst

    Signalling: POWer:ABURst CMU-K20/21/22/23/24 POWer:ABURst The subsystem POWer:ABURst measures the MS output carrier power versus time for access bursts. The subsystem corresponds to the measurement menu Power, application P/t Access..., and the associated popup menu Power Configuration. It contains all commands for measurement control and for the output of measurement results.

  • Page 441: Test Configuration

    CMU-K20/21/22/23/24 Signalling: POWer:ABURst FETCh:POWer:ABURst[:GMSK]:STATus? Measurement Status Returned values Description of parameters Def. value Def. unit FW vers. – V3.0 OFF | Measurement in the OFF state (*RST or ABORt) RUN | Running (after INITiate, CONTinue or READ) STOP | Stopped (STOP) ERR | OFF (could not be started) STEP |...

  • Page 442: Subsystem Power:aburst

    Signalling: POWer:ABURst CMU-K20/21/22/23/24 Subsystem SUBarrays:POWer The subsystem SUBarrays:POWer defines the measurement range and the type of output values. CONFigure:SUBarrays:POWer:ABURst[:GMSK] Definition of Subarrays <Mode>,<Start>,<Samples>{,<Start>,<Samples>} <Mode> Description of parameters Def. value Def. unit ALL | Return all measurement values – ARIThmetical | Return arithm.
  • Page 443 CMU-K20/21/22/23/24 Signalling: POWer:ABURst READ[:SCALar]:POWer:ABURst[:GMSK]? Scalar results Start single shot measurement and return results FETCh[:SCALar]:POWer:ABURst[:GMSK]? Read out measurement results (unsynchronized) SAMPle[:SCALar]:POWer:ABURst[:GMSK]? Read out measurement results (synchronized) Value range Def. value Def. unit FW vers. Returned values Avg. Burst Pw. (Curr), See data sheet V3.0 Time of Arrival, –100.0 bit to +100.0 bit...
  • Page 444 Signalling: POWer:ABURst CMU-K20/21/22/23/24 CALCulate:POWer:ABURst[:GMSK]:LIMit:MATChing? Limit Matching Returned values Value range Def. value Def. unit FW vers. Avg. Burst Pw. (Curr), NMAU | NMAL | INV | OK – V3.0 – BurstMatching INV | MATC | NMAT | OUT | NTR | NRAM | OFLW | UFLW | NTSC | OFF Description of command This command is always a query.
  • Page 445 CMU-K20/21/22/23/24 Signalling: POWer:ABURst Subarray Results ⇒ RUN READ:SUBarrays:POWer:ABURst[:GMSK]? Start single shot meas. and return results ⇒ RUN FETCh:SUBarrays:POWer:ABURst[:GMSK]? Read meas. results (unsynchronized) ⇒ RUN SAMPle:SUBarrays:POWer:ABURst[:GMSK]? Read results (synchronized) Description of parameters Def. value Def. unit FW vers. Ret. values per subrange –100.0 dB to + 20.0 dB BurstPower[1], 1 value for burst power...

  • Page 446: Power:pcl

    Signalling: POWer:PCL CMU-K20/21/22/23/24 POWer:PCL The subsystem POWer:PCL controls the power vs PCL measurement. It corresponds to the measurement menu Power with the application P/PCL: ⇒ INITiate:POWer:PCL Start new measurement ⇒ ABORt:POWer:PCL Abort running measurement and switch off ⇒ STOP:POWer:PCL Stop measurement after current stat. cycle STOP ⇒...

  • Page 447: Subsystem Power:pcl:control

    CMU-K20/21/22/23/24 Signalling: POWer:PCL Subsystem POWer:PCL:CONTrol CONFigure:POWer:PCL:CONTrol:REPetition <Repetition>,<StopCondition>,<Stepmode> Test Cycles <Repetition> Description of parameters Def. value Def. unit CONTinuous | Continuous measurement SING – (continuous, until STOP or ABORT) SINGleshot | Single measurement (single shot, until Status = RDY) 1 to 10000 Multiple measurement (counting, until Status = STEP | RDY) <StopCond>...

  • Page 448: Subsystem Power:pcl

    Signalling: POWer:PCL CMU-K20/21/22/23/24 Description of command This command defines the GSM channel numbers for the P/PCL measurement. The total number n of channels measured is either 3 or 7, depending on the CONFigure:POWer:PCL:CCOunt setting. If 7 channels are measured, the following default values apply: GSM400 259, 265, 270, 276, 282, 287, 293 GSM850...
  • Page 449 CMU-K20/21/22/23/24 Signalling: POWer:PCL Scalar Results READ[:SCALar]:POWer:PCL:PCLPower<PCL>? Start single shot measurement and return results FETCh[:SCALar]:POWer:PCL:PCLPower<PCL>? Read out measurement results (unsynchronized) SAMPle[:SCALar]:POWer:PCL:PCLPower<PCL>? Read out measurement results (synchronized) Value range Def. value Def. unit FW vers. Returned Value PCh1, ... , P1Chn See previous command V2.15 Description of command These commands are always queries.

  • Page 450: Power:mpr

    Signalling: POWer:MPR CMU-K20/21/22/23/24 POWer:MPR The subsystem POWer:MPR combines the POWer and MODulation systems, i.e. it measures the signal power vs. time and the scalar modulation parameters simultaneously. The subsystem contains all commands for measurement control and for the output of measurement results; configurations such as limit lines must be defined separately in the POWer and MODulation systems.

  • Page 451: Subsystem Power:mpr:control

    CMU-K20/21/22/23/24 Signalling: POWer:MPR Subsystem POWer:MPR:CONTrol The subsystem POWer:MPR:CONTrol defines the repetition mode, statistic count, and stop condition of the measurement. CONFigure:POWer[:NORMal][:GMSK]:MPR:CONTrol <Mode>, <Statistics> Scope of Measurement <Mode> Desciption of parameters Def. value Def. unit SCALar | Scalar values only (incl. ramp matching) ARRay –...

  • Page 452: Test Configuration

    Signalling: POWer:MPR CMU-K20/21/22/23/24 Test Configuration The commands of the following subsystems configure the combined power and modulation measurement. Note that configurations such as limit lines must be defined separately in the POWer and MODulation systems. Subsystem SUBarrays:POWer:MPR The subsystem SUBarrays:POWer:MPR defines the measurement range and the type of output values. CONFigure:SUBarrays:POWer[:NORMal][:GMSK]:MPR Definition of Subarrays <Mode>,<Start>,<Samples>{,<Start>,<Samples>}...

  • Page 453: Measured Values - Subsystem Power:mpr

    CMU-K20/21/22/23/24 Signalling: POWer:MPR Measured Values – Subsystem POWer:MPR The subsystem POWer:MPR determines and outputs the results of the combined power and modulation measurement. Scalar Results READ[:SCALar]:POWer[:NORMal][:GMSK]:MPR? Start single shot measurement and return results FETCh[:SCALar]:POWer[:NORMal][:GMSK]:MPR? Read out meas. results (unsynchronized) SAMPle[:SCALar]:POWer[:NORMal][:GMSK]:MPR? Read out measurement results (synchronized) Returned values Value range...
  • Page 454 Signalling: POWer:MPR CMU-K20/21/22/23/24 Returned values Description of parameters Def. value Def. unit FW vers. –100.0 dB to + 20.0 dB BurstPower[1], 1 value for burst power V2.00 –100.0 dB to + 20.0 dB BurstPower[x], xth value for burst power Description of command These commands are always queries.
  • Page 455 CMU-K20/21/22/23/24 Signalling: POWer:MPR CALCulate:POWer[:NORMal][:GMSK]:MPR:LIMit:MATChing? Limit Matching Returned values Value range Def. value Def. unit FW vers. AvgBurstPwCurr, NMAU | NMAL | INV | OK – V2.00 – PeakBurstPwCurr, NMAU | NMAL | INV | OK BurstMatching, INV | MATC | NMAT | OUT | NTR | NRAM | –...

  • Page 456: Receiver Quality

    Signalling: Receiver Quality CMU-K20/21/22/23/24 Receiver Quality The subsystem RXQuality comprises the commands for all receiver quality measurements. The subsystem corresponds to the main menu Receiver Quality and the associated popup menu Receiver Quality Configuration. Important Note: Receiver Quality Measurements with MCS-5 to MCS-9 Receiver Quality measurements on circuit-switched channels using the modulation and coding schemes MCS-5 to MCS-9 (see CONFigure:NETWork[:CSWitched]:SMODe:TRAFfic command)

  • Page 457: Confidence Ber - Subsystem Rxquality:control:confidence

    CMU-K20/21/22/23/24 Signalling: Receiver Quality CONFigure:RXQuality:CONTrol:DEFault <Enable> Default Settings <Enable> Description of parameters Def. value Def. unit FW vers. ON | The parameters are set to default values – V2.00 Some or all parameters differ from the default value Description of command As a setting command with the setting ON this command sets all parameters of the subsystem to default values (the setting OFF causes an error message).

  • Page 458: Receiver Quality - Single Shot

    Signalling: Receiver Quality CMU-K20/21/22/23/24 Receiver Quality – Single Shot The subsystem RXQuality:BER contains the commands for receiver quality measurements in the single shot repetition mode. The subsystem corresponds to the main menu Receiver Quality, application BER, and the corresponding sections of the associated popup menu Receiver Quality Configuration. Control of Measurement –...

  • Page 459: Subsystem Rxquality:ber:control

    CMU-K20/21/22/23/24 Signalling: Receiver Quality FETCh:RXQuality:BER:STATus? Measurement Status Return Description of parameters Def. value Def. unit FW vers. – V2.00 OFF | Measurement in the OFF state (*RST or ABORt) RUN | Running (after INITiate, CONTinue or READ) STOP | Stopped (STOP) ERR | OFF (could not be started) STEP |...
  • Page 460 Signalling: Receiver Quality CMU-K20/21/22/23/24 CONFigure:RXQuality:BER<nr>:CONTrol:REPetition Test Cycles <StopCondition>,<Stepmode> <StopCondition> Description of parameters Def. value Def. unit ALIMits | Measurement aborted when all limits are exceeded – FLIMit | Aborted when first limit value is exceeded below CLEVel | Statistical BER test switched on NONE Not aborted, measurement over all frames <Stepmode>...
  • Page 461 CMU-K20/21/22/23/24 Signalling: Receiver Quality Reference Level, Multislot CONFigure:RXQuality:BER<nr>:CONTrol[:CSWitched][:TCH]:MSLot:RLEVel <Level> CONFigure:RXQuality:BER<nr>:CONTrol:PDATa:[:TCH]:MSLot:RLEVel <Level> <Level> Description of parameters Def. value Def. unit FW vers. 137 dBm to –27 dBm Reference level for RF1 See below V3.05 – –137 dBm to –10 dBm Reference level for RF2 See below –90 dBm to +13 dBm Reference level for RF3 OUT...
  • Page 462 Signalling: Receiver Quality CMU-K20/21/22/23/24 Slot Configuration: Individual (Single-Slot, Circuit Switched) CONFigure:RXQuality:BER<nr>:CONTrol[:CSWitched][:TCH]:LEVel[:SLOT]:ZERO <Level> CONFigure:RXQuality:BER<nr>:CONTrol[:CSWitched][:TCH]:LEVel[:SLOT]:ONE <Level> CONFigure:RXQuality:BER<nr>:CONTrol[:CSWitched][:TCH]:LEVel[:SLOT]:TWO <Level> CONFigure:RXQuality:BER<nr>:CONTrol[:CSWitched][:TCH]:LEVel[:SLOT]:THRee <Level> CONFigure:RXQuality:BER<nr>:CONTrol[:CSWitched][:TCH]:LEVel[:SLOT]:FOUR <Level> CONFigure:RXQuality:BER<nr>:CONTrol[:CSWitched][:TCH]:LEVel[:SLOT]:FIVE <Level> CONFigure:RXQuality:BER<nr>:CONTrol[:CSWitched][:TCH]:LEVel[:SLOT]:SIX <Level> CONFigure:RXQuality:BER<nr>:CONTrol[:CSWitched][:TCH]:LEVel[:SLOT]:SEVen <Level> <Level> Description of parameters Def. value Def. unit FW vers. –127 dB to +127 dB Power of CMU in timeslot no.

  • Page 463: Subsystem Rxquality:ber:limit

    CMU-K20/21/22/23/24 Signalling: Receiver Quality Subsystem RXQuality:BER:LIMit The subsystem RXQuality:BER:LIMit defines tolerance values for the single shot receiver quality measurements. The subsystem corresponds to the tab Limits in the popup menu Receiver Quality Configuration. CONFigure:RXQuality:BER<nr>:LIMit:CLII <ClassIIBER> Class II Bits <ClassIIBER> Description of parameters Def.

  • Page 464: Measured Values - Subsystem Rxquality:ber

    Signalling: Receiver Quality CMU-K20/21/22/23/24 CONFigure:RXQuality:BER<nr>:LIMit:DEFault <Enable> Default Settings <Enable> Description of parameters Def. value Def. unit FW vers. ON | All parameters are set to their default values – V2.00 Some or all parameters differ from the default values Description of command As a setting command with the setting ON this command sets all parameters of the subsystem to default values (the setting OFF causes an error message).
  • Page 465 CMU-K20/21/22/23/24 Signalling: Receiver Quality Returned values for BDBL Value range Def. value Def. unit FW vers. ProgressTime, 0.0% to 100.0% V2.00 BER, 0.000% to 100.000% USFBLER 0.000% to 100.000% DBLER 0.000% to 100.000% CRCErrors, 0 to 50000 – Status INV | PASS | FAIL | TLOW | IMP –...
  • Page 466 Signalling: Receiver Quality CMU-K20/21/22/23/24 CALCulate:RXQuality:BER:LIMit:MATChing? Limit Matching Returned values for RFER Value range Def. value Def. unit Total, PASS | FAIL | INV | TLOW | IMP – – ClassIIBits, NMAU | INV | OK ClassIbBits, NMAU | INV | OK –...

  • Page 467: Receiver Quality - Continuous

    CMU-K20/21/22/23/24 Signalling: Receiver Quality Receiver Quality – Continuous The subsystem RXQuality:BAVerage contains the commands for receiver quality measurement with continuous repetition. The subsystem corresponds to the main menu Receiver Quality, application BER Average and the corresponding parts of the associated popup menu Receiver Quality Configuration. Control of Measurement –...

  • Page 468: Subsystem Rxquality:baverage:control

    Signalling: Receiver Quality CMU-K20/21/22/23/24 Subsystem RXQuality:BAVerage:CONTrol The subsystem RXQuality:BAVerage:CONTrol sets the parameters for the continuous receiver quality measurement. The subsystem corresponds to the tab Control in the popup menu Receiver Quality Configuration. Meas. Mode, Average CONFigure:RXQuality:BAVerage:CONTrol[:CSWitched] <Mode>, <FramesToAverage> CONFigure:RXQuality:BAVerage:CONTrol:PDATa <Mode>, <FramesToAverage> <Mode>...
  • Page 469 CMU-K20/21/22/23/24 Signalling: Receiver Quality CONFigure:RXQuality:BAVerage:CONTrol[:TCH]:LEVel:UNTimeslot <Level> TCH BER Level, Unused Timeslot <Level> Description of parameters Def. value Def. unit FW vers. –127 dB to +127 dB Level in unused timeslot –18.0 V2.00 Description of command This command defines the relative level of the traffic channel (TCH) in the unused timeslot for the continuous application.

  • Page 470: Subsystem Rxquality:baverage:limit

    Signalling: Receiver Quality CMU-K20/21/22/23/24 CONFigure:RXQuality:BAVerage:CONTrol:DEFault <Enable> Default Settings <Enable> Description of parameters Def. value Def. unit FW vers. ON | The parameters are set to default values – V2.00 Some or all parameters differ from the default value Description of command As a setting command with the setting ON this command sets all parameters of the subsystem to default values (the setting OFF causes an error message).

  • Page 471: Measured Values - Subsystem Rxquality:baverage

    CMU-K20/21/22/23/24 Signalling: Receiver Quality CONFigure:RXQuality:BAVerage:LIMit:USFBler <USF_BLER> USF Block Error Rate <USF_BLER> Description of parameters Def. value Def. unit FW vers. 0 % to 100 % Upper limit for USF block error rate 10.0 V3.05 Description of command This command defines an upper limit for the USF BLER. CONFigure:RXQuality:BAVerage:LIMit:DEFault <Enable>...
  • Page 472 Signalling: Receiver Quality CMU-K20/21/22/23/24 Returned values for BDBL Value range Def. value Def. unit FW vers. ProgressTime, 0.0% to 100.0% V2.00 BER, 0.000% to 100.000% USFBLER 0.000% to 100.000% DBLER 0.000% to 100.000% CRCErrors, 0 to 500 – – Status INV | PASS | FAIL | TLOW | IMP Description of command These commands are always queries.
  • Page 473 CMU-K20/21/22/23/24 Signalling: Receiver Quality CALCulate:RXQuality:BAVerage:LIMit:MATChing? Limit Matching Returned values for RFER Value range Def. value Def. unit Total, PASS | FAIL | INV | TLOW | IMP – – ClassIIBits, NMAU | INV | OK ClassIbBits, NMAU | INV | OK –...

  • Page 474: Receiver Quality - Block Error Ratio

    Signalling: Receiver Quality CMU-K20/21/22/23/24 Receiver Quality – Block Error Ratio The subsystem RXQuality:BLER contains the commands for the Block Error Ratio (BLER) measurement. The subsystem corresponds to the main menu Receiver Quality, application BLER and the corresponding parts of the associated popup menu Receiver Quality Configuration. Control of Measurement –...

  • Page 475: Subsystem Rxquality:bler:control

    CMU-K20/21/22/23/24 Signalling: Receiver Quality Subsystem RXQuality:BLER:CONTrol The subsystem RXQuality:BLER:CONTrol defines parameters controlling the scope of the BLER measurement. The subsystem corresponds to the Control tab in the popup menu Receiver Quality Configuration. CONFigure:RXQuality:BLER:CONTrol:REPetition <Repetition> ,<Stepmode> Stop Condition <Repetition> Description of parameters Def.

  • Page 476: Measured Values - Subsystem Rxquality:bler

    Signalling: Receiver Quality CMU-K20/21/22/23/24 Description of command This command defines the levels in all 8 timeslots of the downlink (BS) TCH signal relative to the Reference Level set via CONFigure:RXQuality:BLER:CONTrol:PDATa[:TCH]:MSLot:RLEVel and the corresponding packet data command. The levels are valid for BLER tests if the MS is set to multislot operation. The level range quoted above is restricted by the condition that the absolute level (calculated from the reference level and the relative individual levels) must not exceed the level ranges of the RF connectors.

  • Page 477: Symbolic Status Event Register Evaluation

    CMU-K20/21/22/23/24 Signalling: Symbolic Status Event Register Evaluation Symbolic Status Event Register Evaluation The following commands are used to retrieve the events reported in function groups GSM400/850/900/1800/1900-MS Signalling; see section Symbolic Status Event Register Evaluation in Chapter 5 of the CMU operating manual. STATus:OPERation:SYMBolic:ENABle <Event>{,<Event>} Symbolic status evaluation Parameter description...

  • Page 478: Connection Control (Signalling Only)

    Connection Control (Signalling only) CMU-K20/21/22/23/24 Connection Control (Signalling only) In the Signalling mode, the CMU is able to generate BCCH and TCH signals and to set up a connection to the mobile. A broad range of signalling parameters can be configured and measurements may be performed with a connection established.

  • Page 479: Subsystem Trigger (Trigger Mode)

    CMU-K20/21/22/23/24 Connection Control (Signalling only) Attenuation [SENSe:]LEVel:ATTenuation <Mode> Description of parameters Def. value Def. unit FW vers. <Mode> Mixer level in normal range LNOise – V1.15 NORMal | Low noise (mixer level 10 dB higher than in normal LNOise | setting) Low distortion (mixer level 10 dB lower than in LDIStortion...
  • Page 480 Connection Control (Signalling only) CMU-K20/21/22/23/24 Level – IF Power TRIGger[:SEQuence]:THReshold:IFPower <Threshold> Parameter description Def. value Default unit FW vers. <Threshold> IF power threshold –26 V3.10 –47 dB to 0 dB Command description This command sets the IF signal level at which the measurement is triggered. The IF power threshold is defined relative to the maximum RF input level;...

  • Page 481: Subsystem Signalling (Connection Setup And Cleardown)

    CMU-K20/21/22/23/24 Connection Control (Signalling only) Trigger Default Settings TRIGger[:SEQuence]:DEFault <Enable> Description of parameters Def. value Def. unit FW vers. <Enable> All parameters are set to their default values – V2.00 ON | All or some parameters differ from the default values Description of command If used as a setting command with the parameter ON this command sets all parameters of the subsystem to their default values (the setting OFF causes an error message).

  • Page 482: Fig. 6-1 Signalling States Of The Cmu And Transitions Including Handover

    Connection Control (Signalling only) CMU-K20/21/22/23/24 Default SOFF (origin) SOFF (dest.) SOFF SON (origin) MS Synch SOFF (automatic) SOFF SOFF HANDoff (destination) CPEN (dest.) SYNC (origin) Signal CRELease MS MOC ALER (origin) HANDoff CREL (origin) ease Transitory (automatic, when call is State accepted/mobile is picked up) CED (dest.)
  • Page 483 CMU-K20/21/22/23/24 Connection Control (Signalling only) DAI Acoustic Dev. PROCedure:SIGNalling[:CSWitched]:DAI <Interface> Description of parameters Def. value Def. unit FW vers. <Interface> Default setting active during call setup NORM – V3.0 NORMal | Test of speech decoder / DTX functions (downlink) DECoder | Test of speech encoder / DTX functions (uplink) ENCoder | Test of acoustic devices and A/D &...
  • Page 484 Connection Control (Signalling only) CMU-K20/21/22/23/24 Combined Channel/TS/PCL Change PROCedure:SIGNalling[:CSWitched][:TCH][:SSLot]:CHCCombined <ChannelNumber>, <Timeslot>, <PCL> Description of parameters Def. value Def. unit <ChannelNumber> Number of traffic channel, GSM400 – 259 to 293 | 306 to 340 Number of traffic channel, GSM850 – 128 to 251 Number of traffic channel, GSM900 –...
  • Page 485 CMU-K20/21/22/23/24 Connection Control (Signalling only) PROCedure:SIGNalling[:CSWitched][:TCH][:SSLot]:MS:PCL <PCL> Description of parameters Def. value Def. unit FW vers. <PCL> Power of mobile phone in PCL units, GSM400/850/900 – 0 to 19 GSM1800 – 0 to 31 GSM1900 V1.15 0 to 31 Description of command Sig.
  • Page 486 Connection Control (Signalling only) CMU-K20/21/22/23/24 Loop PROCedure:SIGNalling[:CSWitched][:TCH][:SSLot]:LOOP <Loop> PROCedure:SIGNalling[:CSWitched][:TCH]:MSLot:LOOP <Loop> Description of parameters Def. value Def. unit FW vers. <Loop> No test loop set A (single – V3.10 OFF | TCH loop including signalling of erased frames slot) Speech TCH loop without signalling of erased frames TCH burst-by-burst loop H (multi- Multi-slot TCH burst-by-burst loop...

  • Page 487: Subsystem Handover

    CMU-K20/21/22/23/24 Connection Control (Signalling only) Subsystem HANDover The subsystem HANDover sets the target for a forced handover of the mobile phone. The corresponding softkeys are located in the Handover tab in the popup menu Connect. Control. Destination List STATus:HANDover:TARGet:LIST? Description of parameters Def.

  • Page 488: Subsystem Mssignal (Signal Of Mobile Station)

    Connection Control (Signalling only) CMU-K20/21/22/23/24 Default Settings MCONTrol:DEFault <Enable> Description of parameters Def. value Def. unit FW vers. <Enable> All parameters are set to their default values – V3.10 ON | All or some parameters differ from the default values Description of command If used as a setting command with the parameter ON this command sets all parameters of the subsystem to their default values (the setting OFF causes an error message).
  • Page 489 CMU-K20/21/22/23/24 Connection Control (Signalling only) Timing Advance CONFigure:MSSignal[:CSWitched][:TCH]:TADVance <Bit > Description of parameters Def. value Def. unit FW vers. <Bit> Timing advance for GSM850/900/1800/1900 V3.05 0 bit to 63 bit Timing advance for GSM400 0 bit to 219 bit Description of command Sig.

  • Page 490: Subsystem Bssignal (Signal Of Base Station/Cmu)

    Connection Control (Signalling only) CMU-K20/21/22/23/24 Subsystem BSSignal (Signal of Base Station/CMU) The subsystem BSSignal configures the operating mode and the RF control and traffic channels that the CMU transmits to communicate with the MS under test. It corresponds to the tab BS Signal in the popup menu Connect.
  • Page 491 CMU-K20/21/22/23/24 Connection Control (Signalling only) BCCH Level CONFigure:BSSignal:CCH[:TX]:LEVel[:ABSolute] <Level> Description of parameters Def. value Def. unit FW vers. <Level> Absol. level of control channel, RF1 –85 V1.15 –137 dBm to –27 dBm Absol. level of control channel, RF2 –85 –137 dBm to –10 dBm Absol.
  • Page 492 Connection Control (Signalling only) CMU-K20/21/22/23/24 Unused Timeslot Level CONFigure:BSSignal[:CSWitched][:TCH]:LEVel:UNTimeslot <Level> PROCedure:BSSignal[:CSWitched][:TCH]:LEVel:UNTimeslot <Level> Description of parameters Def. value Def. unit FW vers. <Level> Level in unused timeslot see below V1.15 –127 dB to +127 dB Description of command Sig. State This command determines the (relative) level in the unused timeslots. The level range quoted above is restricted by the condition that the absolute level (calculated from the used timeslot level and the relative level in the unused timeslots) must not exceed the level ranges of the RF connectors.
  • Page 493 CMU-K20/21/22/23/24 Connection Control (Signalling only) For GSM850, the following four default sequences are available: 130, 134, 138, 143, 145, 149, 153, 157, 163, 167, 171, 176, 181, 185, 189, 193, 198, 202, 205, 209, 211, Sequence A: 215, 217, 219, 221, 227, 231, 234, 238, 242, 246, 250, OFF, ... OFF 132, 135, 139, 142, 144, 148, 151, 156, 161, 164, 166, 173, 177, 179, 182, 186, OFF,...OFF Sequence B: 195, 203, 206, 210, 213, 216, 220, 223, 226, 229, 232, 235, 239, 243, 245, 249, OFF, ...
  • Page 494 Connection Control (Signalling only) CMU-K20/21/22/23/24 Main Timeslot CONFigure:BSSignal[:CSWitched][:TCH]:MSLot:MTIMeslot <Slot_No> Description of parameters Def. value Def. unit FW vers. <Slot_No> Main timeslot, used for signalling – V3.05 0 to 7 Description of command Sig. State ≠CEST, This command defines the timeslot that the MS and the BS/CMU use for signalling (default value). Changing main timeslot...

  • Page 495: Subsystem Bssignal:cch:auxtx (Aux Tx Signal)

    CMU-K20/21/22/23/24 Connection Control (Signalling only) Slot Configuration Individual CONFigure:BSSignal[:CSWitched][:TCH]:MSLot:SCONfig:INDividual <Enable_0>,<Enable_1>, ..., <Enable_7>, <Level_0>, ..., <Level_7> Description of parameters Def. value Def. unit <Enable_n> Enable or disable downlink timeslot no. n see below – ON | OFF (the MS is instructed to listen to this TS) Description of parameters Def.

  • Page 496: Subsystem Network

    Connection Control (Signalling only) CMU-K20/21/22/23/24 Aux TX – RF Channel CONFigure:BSSignal:CCH:AUXTx:CHANnel <Channel> Description of parameters Def. value Def. unit FW vers. <Channel> Number of Aux TX channel, GSM400 – V3.40 259 to 293 | 306 to 340 Number of Aux TX channel, GSM850 –...
  • Page 497 CMU-K20/21/22/23/24 Connection Control (Signalling only) Advice of Charge CONFigure:NETWork[:CSWitched]:AOCHarge:ENABle <Enable> CONFigure:NETWork[:CSWitched]:AOCHarge <Value1>, <Value2> ... , <Value7> Description of parameters Def. value Def. unit <Enable> Switch on or off data for advice of charge – ON | OFF Description of parameters Def.

  • Page 498: Subsystem Network:system (System Parameters)

    Connection Control (Signalling only) CMU-K20/21/22/23/24 CONFigure:NETWork:IDENtity:MCC <Code> Description of parameters Def. value Def. unit FW vers. <Code> Mobile Country Code – V1.15 0 to 999 Description of command Sig. State This command defines the Mobile Country Code. SOFF, Q: all CONFigure:NETWork:IDENtity:MNC <Code>...
  • Page 499 CMU-K20/21/22/23/24 Connection Control (Signalling only) Cell Access CONFigure:NETWork:SYSTem:CACCess <Mode> Description of parameters Def. value Def. unit FW vers. Mode> Radio cell disabled for all mobiles NBARred – V1.15 BARRed | Radio cell accessible NBARred Description of command Sig. State This command enables or disables the radio cell for mobiles. SOFF, Q: all CONFigure:NETWork:SYSTem:BINDicator <Band>...

  • Page 500: Subsystem Network[:Cswitched]:Smode (Type Of Signalling)

    Connection Control (Signalling only) CMU-K20/21/22/23/24 Access Class CONFigure:NETWork:SYSTem:ACLass <Code> Description of parameters Def. value Def. unit FW vers. <Code> Access classes (0 to 15) barred from network access – V3.05 0 to 2 –1 (16 bit value) Description of command Sig.
  • Page 501 CMU-K20/21/22/23/24 Connection Control (Signalling only) Traffic Mode CONFigure:NETWork[:CSWitched]:SMODe:TRAFfic <Mode> Description of parameters Def. value Def. unit FW vers. <Mode> Full-rate coding, Full Rate Version 1 FRV1 – V1.15 FRV1 | Full Rate Version 2 (Enhanced Full Rate) FRV2 | Half-rate coding, Half Rate Version 1 HRV1 | Full Rate Data 4800 Baud FD48 |...

  • Page 502: Subsystem Network[:Cswitched]:Request (Requested Mobile Data)

    Connection Control (Signalling only) CMU-K20/21/22/23/24 Loop Command CONFigure:NETWork[:CSWitched]:SMODe:LCOMmand <Mode> Description of parameters Def. value Def. unit FW vers. <Mode> The CMU sends “Close Loop“ every time a connection – V1.15 ENABle | is established The CMU never sends „Close Loop“ DISable | ! Mobile never sends back Loop is closed for BER measurements only...

  • Page 503: Subsystem Network[:Cswitched]:Amr (Amr Codec Test)

    CMU-K20/21/22/23/24 Connection Control (Signalling only) IMSI Request CONFigure:NETWork[:CSWitched]:REQuest:IMSI <Mode> Description of parameters Def. value Def. unit FW vers. <Mode> IMSI requested – V1.15 ON | No request Description of command Sig. State ≠CEST, This command determines whether the international mobile subscriber identity of the connected mobile phone is requested during location update, call to mobile, call from mobile, or SMS transfer.
  • Page 504 Connection Control (Signalling only) CMU-K20/21/22/23/24 Codec Mode DL, Half Rate CONFigure:NETWork[:CSWitched]:AMR:HRATe:DLCMode <Mode> PROCedure:NETWork[:CSWitched]:AMR:HRATe:DLCMode <Mode> Description of parameters Def. value Def. unit FW vers. <Mode> DL codec mode 1, 2, 3, 4 – V3.40 CM1 | CM2 | CM3 | CM4 Description of command Sig.
  • Page 505 CMU-K20/21/22/23/24 Connection Control (Signalling only) AMR Rate Set, Half Rate CONFigure:NETWork[:CSWitched]:AMR:HRATe:RSETting <CM4>, <CM3>, CM2>, <CM1>, <ThrDown4>, <ThrUp3>, <ThrDown3>, <ThrUp2>, <ThrDown2>, <ThrUp1> Description of parameters Def. value Def. unit FW vers. <CM4>, <CM3>, <CM2>, CM1> User bit rate for codec modes 4 to 1. C0795, –...

  • Page 506: Subsystem Network[:Cswitched]:Timeout

    Connection Control (Signalling only) CMU-K20/21/22/23/24 AMR Rate Set, Full Rate CONFigure:NETWork[:CSWitched]:AMR:FRATe:RSETting <CM4>, <CM3>, CM2>, <CM1>, <ThrDown4>, <ThrUp3>, <ThrDown3>, <ThrUp2>, <ThrDown2>, <ThrUp1> Description of parameters Def. value Def. unit <CM4>, <CM3>, <CM2>, CM1> User bit rate for codec modes 4 to 1. The C1220, –...

  • Page 507: Connector Subsystems (External Attenuation At The Connectors)

    CMU-K20/21/22/23/24 Connection Control (Signalling only) Radiolink Timeout Mobile CONFigure:NETWork[:CSWitched]:TIMeout:RLINk[:MOBile] <Time> Description of parameters Def. value Def. unit FW vers. <Time> Number of missing SACCH blocks (the step size is 4) – V1.15 4 to 64 Description of command Sig. State ≠CEST, This command defines the maximum number of SACCH blocks which may be missing before a mobile phone considers the radio link to be interrupted (radio link timeout)
  • Page 508 Connection Control (Signalling only) CMU-K20/21/22/23/24 RF Output OUTPut[:STATe] <State> Description of parameters Def. value Def. unit FW vers. <State> Connector RF1 used as output – V1.15 Connector RF2 used as output Connector RF3 OUT used as output Description of command Sig.

  • Page 509: Subsystem Dm:clock (Synchronization)

    CMU-K20/21/22/23/24 Connection Control (Signalling only) Subsystem DM:CLOCk (Synchronization) The subsystem DM:CLOCk sets a system clock specific to the network. This frequency is set in the tab Synch. in the popup menu Connect. Control. REF OUT 2 on/off SOURce:DM:CLOCk:STATe <Mode> Description of parameters Def.
  • Page 510 Connection Control (Signalling only) CMU-K20/21/22/23/24 Reported PCL [SENSe:]RREPorts:RPCL? Description of parameters Def. value Def. unit FW vers. Return Reported power of mobile phone in PCL units, GSM400/850/900 – 0 to 19 GSM1800 – 0 to 31 GSM1900 V3.05 0 to 31 Description of command Sig.

  • Page 511: Mssinfo (Signalling Information Of Mobile Phone)

    CMU-K20/21/22/23/24 Connection Control (Signalling only) MSSinfo (Signalling Information of Mobile Phone) The subsystem MSSinfo contains the commands for querying the parameters of the mobile. The subsystem corresponds to the Signalling Info output table in the main menu GSMxxx-MS Overview. The mobile parameters do not actually represent a measured value, they are provided by the mobile phone during location update.
  • Page 512 Connection Control (Signalling only) CMU-K20/21/22/23/24 Dialled Number [SENSe:]MSSinfo:DNUMber? Description of parameters Def. value Def. unit FW vers. Returned values Dialed number – V1.15 "Max. 20-digit" Description of command Sig. State This command is always a query and returns the number dialed at the mobile. CEST Traffic Mode [SENSe:]MSSinfo:TRAFfic?
  • Page 513 CMU-K20/21/22/23/24 Connection Control (Signalling only) Codec Mode DL, requested by MS (Half Rate) [SENSe:]MSSinfo:AMR:HRATe:DLCMode? Description of parameters Def. value Def. unit FW vers. <Mode> DL codec mode 1, 2, 3, 4 – V3.40 CM1 | CM2 | CM3 | CM4 Description of command Sig.

  • Page 514: File Management - System Mmemory

    File Management – System MMEMory CMU-K20/21/22/23/24 File Management – System MMEMory The MMEMory system provides mass storage capabilities for the CMU. The functionality of this system is included in the Data menu; see CMU200/300 operating manual. The mass storage of the CMU may be internal or external. The internal mass storage device is a section on the internal hard disk that is reserved for mass storage (directory c:\temp).
  • Page 515 CMU-K20/21/22/23/24 File Management – System MMEMory Save to File MMEMory:L3MSg:SAVE [<FileName>] [,<msus>] Parameter description Def. value Def. unit FW vers. Parameters Name of the file to be saved see description – – "<FileName>", Storage device of the file to be saved INTernal –...

  • Page 516: Options And Extensions

    Options and Extensions CMU-K20/21/22/23/24 Options and Extensions The features described in this section require the installation of additional software options; for a complete list of deliverable options refer to the data sheet. GPRS and EGPRS Signalling (with Options R&S CMU-K42 and R&S CMU-K43) The remote-control commands presented in this section control the setup and release of a TBF connection, configure the MS and BS Signals and define the network parameters for packet data services.

  • Page 517: Fig. 6-2 Gprs Signalling States Of The Cmu And Transitions

    CMU-K20/21/22/23/24 Options and Extensions GPRS Signalling Control PROCedure:SIGNalling:PDATa:ACTion <Action> Description of parameters Def. value Def. unit FW vers. <Action> Switch off BCCH signal (signal off) – – V3.05 SOFF | Switch on BCCH signal (signal on) SON | Connect Test Mode A CTMA | Connect Test Mode B CTMB |...
  • Page 518 Options and Extensions CMU-K20/21/22/23/24 See command [SENSe:]SIGNalling:PDATa:STATe? below. Signalling states: Actions: initiated from the CMU: initiated from the mobile phone: See description of command MS Attach MS initiates GPRS-attach MS Detach MS initiates GPRS-detach PROC:SIGN:PDAT:ACT Further transitions between the signalling states (not shown in Fig. 6-2) may occur, e.g. in case of errors. Handover transitions can be performed in analogy to the circuit-switched case;...
  • Page 519 CMU-K20/21/22/23/24 Options and Extensions Slot Configuration: Uplink/Downlink PROCedure:SIGNalling:PDATa[:TCH]:MSLot:SCONfig <Main_TS>,<DL_Enable_0>,..., <DL_Enable_7>, <DL_Power_0>, ..., <DL_Power_7> <UL_Enable_0>,..., <UL_Enable_7>, <UL_Gamma_0>, ..., <UL_Gamma_7> Description of parameters Def. value Def. unit FW vers. <Main_TS> Main timeslot used for signalling – V3.10 0 to 7 Description of parameters Def.

  • Page 520: Subsystem Mssignal:pdata (Rf Signal Of Ms Under Test)

    Options and Extensions CMU-K20/21/22/23/24 Enable Frequency Hopping PROCedure:SIGNalling:PDATa[:TCH]:MSLot:FHOPping:ENABle <Enable> Description of parameters Def. value Def. unit FW vers. <Sequence> Enable or disable frequency hopping – V3.40 ON | OFF Description of command Sig. State This command enables or disables frequency hopping in the downlink traffic channel.. The hopping CEST sequences are defined via Q: all...
  • Page 521 CMU-K20/21/22/23/24 Options and Extensions RF Channel CONFigure:BSSignal:PDATa[:TCH]:MSLot:CHANnel <Number> Description of parameters Def. value Def. unit FW vers. <Number> Number of traffic channel, GSM400 – – 259 to 293 | 306 to 340 Number of traffic channel, GSM850 – – 128 to 251 Number of traffic channel, GSM900 –...

  • Page 522: Subsystem Network

    Options and Extensions CMU-K20/21/22/23/24 Downlink Slot Configuration CONFigure:BSSignal:PDATa[:TCH]:MSLot:SCONfig <Enable_0>,..., <Enable_7>, <Level_0>,... <Level_7> Description of parameters Def. value Def. unit <Enable_n> Enable or disable downlink timeslot no. n see below – ON | OFF (the MS is instructed to listen to this TS) Description of parameters Def.

  • Page 523: Subsystem Network:identity

    CMU-K20/21/22/23/24 Options and Extensions Subsystem NETWork:IDENtity The subsystem NETWork:IDENtity defines the identity of the mobile radio network. The subsystem corresponds to the table section Network Identity in the Network tab. The following commands are related to packet data transfer: Routing Area Code CONFigure:NETWork:IDENtity:RAC <Code>...
  • Page 524 Options and Extensions CMU-K20/21/22/23/24 Puncturing Scheme CONFigure:NETWork:PDATa:EGPRs:PSCHeme <PS_1>, ... <PS_12> PROCedure:NETWork:PDATa:EGPRs:PSCHeme <PS_1>, ... <PS_12> Description of parameters Def. value Def. unit FW vers. <Coding_Scheme> – V3.40 Puncturing scheme for MCS-1 P1 | P2, Puncturing scheme for MCS-2 P1 | P2, Puncturing scheme for MCS-3 P1 | P2 | P3, Puncturing scheme for MCS-4...
  • Page 525 CMU-K20/21/22/23/24 Options and Extensions USF Duty Cycle CONFigure:NETWork:PDATa:USDCycle <Code> Description of parameters Def. value Def. unit FW vers. <Code> 100 % assigned A100 – V3.40 A100 | 0 % assigned, 100 % random A000 | 12.5 % assigned, 87.5 % random A012 Description of command Sig.

  • Page 526: Mssinfo

    Options and Extensions CMU-K20/21/22/23/24 RLC Mode (Testmode B) CONFigure:NETWork:PDATa:RLCMode <Mode> Description of parameters Def. value Def. unit FW vers. <Mode> Acknowledged mode (for special applications) UNAC – V3.10 ACKN | Unacknowledged mode UNAC Description of command Sig. State This command defines the downlink RLC mode for a packet data connection in test mode B. SOFF, According to standard GSM 04.14, test mode B corresponds to Unacknowledged operation where the IDLE,...

  • Page 527: Adaptive Multi-Rate (Amr) Speech Codec

    CMU-K20/21/22/23/24 Options and Extensions Adaptive Multi-Rate (AMR) Speech Codec (Option R&S CMU-K45) With option R&S CMU-K45, the CMU provides the functionality for AMR speech codec tests. The additional commands belong the the NETWork[:CSWitched]… and MSSinfo subsystems. Subsystem NETWork[:CSWitched]:AMR (AMR Codec Test) The subsystem NETWork[:CSWitched]:AMR comprises the commands to configure and test the AMR speech codec.
  • Page 528 Options and Extensions CMU-K20/21/22/23/24 Codec Mode UL, Half Rate CONFigure:NETWork[:CSWitched]:AMR:HRATe:ULCMode <Mode> PROCedure:NETWork[:CSWitched]:AMR:HRATe:ULCMode <Mode> Description of parameters Def. value Def. unit FW vers. <Mode> UL codec mode 1, 2, 3, 4 – V3.40 CM1 | CM2 | CM3 | CM4 Description of command Sig.
  • Page 529 CMU-K20/21/22/23/24 Options and Extensions AMR Rate Set, Half Rate CONFigure:NETWork[:CSWitched]:AMR:HRATe:RSETting <CM4>, <CM3>, CM2>, <CM1>, <ThrDown4>, <ThrUp3>, <ThrDown3>, <ThrUp2>, <ThrDown2>, <ThrUp1> Description of parameters Def. value Def. unit FW vers. <CM4>, <CM3>, <CM2>, CM1> User bit rate for codec modes 4 to 1. C0795, –...
  • Page 530 Options and Extensions CMU-K20/21/22/23/24 AMR Rate Set, Full Rate CONFigure:NETWork[:CSWitched]:AMR:FRATe:RSETting <CM4>, <CM3>, CM2>, <CM1>, <ThrDown4>, <ThrUp3>, <ThrDown3>, <ThrUp2>, <ThrDown2>, <ThrUp1> Description of parameters Def. value Def. unit <CM4>, <CM3>, <CM2>, CM1> User bit rate for codec modes 4 to 1. The C1220, –...

  • Page 531: Mssinfo (Amr Codec Modes)

    CMU-K20/21/22/23/24 Options and Extensions MSSinfo (AMR Codec Modes) The subsystem MSSinfo contains the commands to query the AMR codec modes used and requested by the mobile. The information is provided in the Network tab of the Connection Control menu. Codec Mode DL, requested by MS (Half Rate) [SENSe:]MSSinfo:AMR:HRATe:DLCMode? Description of parameters Def.

  • Page 532: Table 6-1 Remote Control Commands: Non Signalling

    List of Commands CMU-K20/21/22/23/24 List of Commands In the following, all remote control commands of the function group GSM900/1800/1900-MS are listed with their parameters and page numbers. They are arranged alphabetically according to the second keyword of the command so that related commands belong to the same group. The commands for the two test modes Non Signalling and Signalling are listed separately.
  • Page 533 CMU-K20/21/22/23/24 List of Commands Command, Non Signalling Parameter Remark Page CONTinue:MODulation:EVMagnitude:EPSK – no query 6.85 CONFigure:SUBarrays:MODulation:EVMagnitude:EPSK ALL | ARIThmetical | MINimum | with query 6.88 MAXimum IVAL,<Start>,<Samples>{,<Start>, <Samples>} READ:ARRay:MODulation:EVMagnitude:EPSK:AVERage? –100.0 dB to +100.0 dB query only 6.90 FETCh:ARRay:MODulation:EVMagnitude:EPSK:AVERage? –100.0 dB to +100.0 dB query only 6.90 SAMPle:ARRay:MODulation:EVMagnitude:EPSK:AVERage?
  • Page 534 List of Commands CMU-K20/21/22/23/24 Command, Non Signalling Parameter Remark Page FETCh:ARRay:MODulation:EVMagnitude:EPSK[:CURRent]? –100.0 dB to +100.0 dB query only 6.90 SAMPle:ARRay:MODulation:EVMagnitude:EPSK[:CURRent]? –100.0 dB to +100.0 dB query only 6.90 READ:SUBarrays:MODulation:EVMagnitude:EPSK[:CURRent]? –100.0 dB to +20.0 dB query only 6.90 FETCh:SUBarrays:MODulation:EVMagnitude:EPSK –100.0 dB to +20.0 dB query only 6.90 [:CURRent]?
  • Page 535 CMU-K20/21/22/23/24 List of Commands Command, Non Signalling Parameter Remark Page FETCh:SUBarrays:MODulation:MERRor:EPSK:MMAXimum? –100.0 dB to +20.0 dB query only 6.102 SAMPle:SUBarrays:MODulation:MERRor:EPSK:MMAXimum? –100.0 dB to +20.0 dB query only 6.102 FETCh:MODulation:MERRor:EPSK:STATus? OFF | RUN | STOP | ERR | STEP | query only 6.97 RDY, 1 to 10000 | NONE , 1 to 1000 | NONE...
  • Page 536 List of Commands CMU-K20/21/22/23/24 Command, Non Signalling Parameter Remark Page CONFigure:MODulation:OVERview:EPSK:CONTrol:DEFault ON | OFF with query 6.82 CONFigure:MODulation:OVERview:EPSK:CONTrol:REPetition CONTinuous | SINGleshot | 1 to with query 6.81 10000, SONerror | NONE, STEP | NONE CONFigure:MODulation:OVERview:EPSK:EREPorting SRQ | SOPC | SRSQ | OFF with query 6.80 CALCulate:MODulation:OVERview:EPSK:LIMit:MATChing?
  • Page 537 CMU-K20/21/22/23/24 List of Commands Command, Non Signalling Parameter Remark Page READ:ARRay:MODulation[:PERRor]:EPSK:MMAXimum? –100.0 dB to +100.0 dB query only 6.96 FETCh:ARRay:MODulation[:PERRor]:EPSK:MMAXimum? –100.0 dB to +100.0 dB query only 6.96 SAMPle:ARRay:MODulation[:PERRor]:EPSK:MMAXimum? –100.0 dB to +100.0 dB query only 6.96 READ:SUBarrays:MODulation[:PERRor]:EPSK:MMAXimum? –100.0 dB to +20.0 dB query only 6.96 FETCh:SUBarrays:MODulation[:PERRor]:EPSK:MMAXimum?
  • Page 538 List of Commands CMU-K20/21/22/23/24 Command, Non Signalling Parameter Remark Page SAMPle:SUBarrays:MODulation[:PERRor][:GMSK]:AVERage? –100.0 dB to +20.0 dB query only 6.71 CONFigure:MODulation[:PERRor][:GMSK]:CONTrol SCALar | ARRay, 1 to 1000 | with query 6.65 NONE CONFigure:MODulation[:PERRor][:GMSK]:CONTrol:DEFault ON | OFF with query 6.66 CONFigure:MODulation[:PERRor][:GMSK]:CONTrol:REPetition CONTinuous | SINGleshot | 1 to with query 6.66 10000, SONerror | NONE, STEP |...
  • Page 539 CMU-K20/21/22/23/24 List of Commands Command, Non Signalling Parameter Remark Page SAMPle:ARRay:MODulation[:PERRor][:GMSK][:CURRent]? –100.0 dB to +100.0 dB query only 6.70 READ:SUBarrays:MODulation[:PERRor][:GMSK][:CURRent]? –100.0 dB to +20.0 dB query only 6.71 FETCh:SUBarrays:MODulation[:PERRor][:GMSK][:CURRent]? –100.0 dB to +20.0 dB query only 6.71 SAMPle:SUBarrays:MODulation[:PERRor][:GMSK][:CURRent]? –100.0 dB to +20.0 dB query only 6.71 Modulation measurement: GMSK Modulation, Extended Phase Error...
  • Page 540 List of Commands CMU-K20/21/22/23/24 Command, Non Signalling Parameter Remark Page CONFigure:MODulation:XPERror[:GMSK]:LIMit[:CURRent] 0.0 deg to 50.0 deg, 0.0 deg to with query 6.74 50.0 deg, –100 dB to 0 dB, –100 dB to 0 dB, 0 Hz to 999 Hz READ:ARRay:MODulation:XPERror[:GMSK]:MMAXimum? –100.0 dB to +100.0 dB query only 6.78...
  • Page 541 CMU-K20/21/22/23/24 List of Commands Command, Non Signalling Parameter Remark Page CONFigure:NPOWer:CONTrol:STATistics 1 to 1000 | NONE with query 6.39 CONFigure:NPOWer:EREPorting SRQ | SOPC | SRSQ | OFF with query 6.38 FETCh:NPOWer:STATus? OFF | RUN | STOP | ERR | STEP | query only 6.38 RDY, 1 to 10000 | NONE, 1 to...
  • Page 542 List of Commands CMU-K20/21/22/23/24 Command, Non Signalling Parameter Remark Page READ:SUBarrays:POWer:FRAMe? <Result> query only 6.53 FETCh:SUBarrays:POWer:FRAMe? <Result> query only 6.53 SAMPle:SUBarrays:POWer:FRAMe? <Result> query only 6.53 POWer:MSLot measurement INITiate:POWer:MSLot – no query 6.54 ABORt:POWer:MSLot – no query 6.54 STOP:POWer:MSLot – no query 6.54 CONTinue:POWer:MSLot –...
  • Page 543 CMU-K20/21/22/23/24 List of Commands Command, Non Signalling Parameter Remark Page DISPlay:POWer:MSLot:CONTrol:GRID ON | OFF with query 6.55 CONFigure:POWer:MSLot:CONTrol:REPetition CONTinuous | SINGleshot | 1 to with query 6.55 10000, SONerror | NONE,STEP | NONE CONFigure:POWer:MSLot:EREPorting SRQ | SOPC | SRSQ | OFF with query 6.54 CONFigure:POWer:MSLot:FILTer...
  • Page 544 List of Commands CMU-K20/21/22/23/24 Command, Non Signalling Parameter Remark Page SAMPle[:SCALar]:POWer:MSLot? <Result> query only 6.59 READ:ARRay:POWer:MSLot[:CURRent]? –100.0 dB to +20.0 dB query only 6.60 FETCh:ARRay:POWer:MSLot[:CURRent]? –100.0 dB to +20.0 dB query only 6.60 SAMPle:ARRay:POWer:MSLot[:CURRent]? –100.0 dB to +20.0 dB query only 6.60 READ:SUBarrays:POWer:MSLot[:CURRent]? –100.0 dB to +20.0 dB...
  • Page 545 CMU-K20/21/22/23/24 List of Commands Command, Non Signalling Parameter Remark Page POWer:XSLOT measurement INITiate:POWer:XSLot – no query 6.45 ABORt:POWer:XSLot – no query 6.45 STOP:POWer:XSLot – no query 6.45 CONTinue:POWer:XSLot – no query 6.45 CONFigure:SUBarrays:POWer:XSLot ALL | ARIThmetical | MINimum | with query 6.48 MAXimum IVAL,<Start>,<Samples>{,<Start>,...
  • Page 546 List of Commands CMU-K20/21/22/23/24 Command, Non Signalling Parameter Remark Page CONFigure:SUBarrays:POWer[:NORMal]:EPSK ALL | ARIThmetical | MINimum | with query 6.21 MAXimum IVAL,<Start>,<Samples>{,<Start>, <Samples>} CALCulate:ARRay:POWer[:NORMal]:EPSK:AREA:LIMit:MATCh <Matching> query only 6.25 ing:AVERage? CALCulate:ARRay:POWer[:NORMal]:EPSK:AREA:LIMit: <Matching> query only 6.25 MATChing:MAXimum? CALCulate:ARRay:POWer[:NORMal]:EPSK:AREA:LIMit: <Matching> query only 6.25 MATChing:MINimum? CALCulate:ARRay:POWer[:NORMal]:EPSK:AREA:LIMit: <Matching>...
  • Page 547 CMU-K20/21/22/23/24 List of Commands Command, Non Signalling Parameter Remark Page <Visibility> CONFigure:POWer[:NORMal]:EPSK:LIMit:LINE: ON | OFF with query 6.16 LOWer<nr>[:STATic]:ENABle CONFigure:POWer[:NORMal]:EPSK:LIMit:LINE: ON | OFF with query 6.18 UPPer:ALL:DYNamic:ENABle CONFigure:POWer[:NORMal]:EPSK:LIMit:LINE: ON | OFF with query 6.17 UPPer<nr>:ALL:DYNamic:ENABle CONFigure:POWer[:NORMal]:EPSK:LIMit:LINE: <fromTPCL>, <toTPCL>, with query 6.17 UPPer<nr>:DYNamic<nr>...
  • Page 548 List of Commands CMU-K20/21/22/23/24 Command, Non Signalling Parameter Remark Page FETCh:SUBarrays:POWer[:NORMal]:EPSK:MINimum? –100.0 dB to +20.0 dB query only 6.24 SAMPle:SUBarrays:POWer[:NORMal]:EPSK:MINimum? –100.0 dB to +20.0 dB query only 6.24 FETCh:POWer[:NORMal]:EPSK:STATus? OFF | RUN | STOP | ERR | STEP | query only 6.12 RDY, 1 to 10000 | NONE , 1 to 1000 | NONE...
  • Page 549 CMU-K20/21/22/23/24 List of Commands Command, Non Signalling Parameter Remark Page SAMPle:ARRay:POWer[:NORMal][:GMSK]:AVERage? –100.0 dB to +20.0 dB query only 6.23 READ:SUBarrays:POWer[:NORMal][:GMSK]:AVERage? –100.0 dB to +20.0 dB query only 6.24 FETCh:SUBarrays:POWer[:NORMal][:GMSK]:AVERage? –100.0 dB to +20.0 dB query only 6.24 SAMPle:SUBarrays:POWer[:NORMal][:GMSK]:AVERage? –100.0 dB to +20.0 dB query only 6.24 CONFigure:POWer[:NORMal][:GMSK]:CONTrol...
  • Page 550 List of Commands CMU-K20/21/22/23/24 Command, Non Signalling Parameter Remark Page UPPer<nr>[:STATic] <StartRelLevel>, <EndRelLevel>, <StartAbsLevel>, <EndAbsLevel>, <Visibility> CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE: ON | OFF with query 6.14 UPPer<nr>[:STATic]:ENABle CALCulate:ARRay:POWer[:NORMal][:GMSK]:LIMit: MATC | NMAT | INV | NTSC | OUT query only 6.25 MATChing:AVERage? CALCulate:ARRay:POWer[:NORMal][:GMSK]:LIMit: MATC | NMAT | INV | NTSC | OUT query only 6.25 MATChing:MAXimum?
  • Page 551 CMU-K20/21/22/23/24 List of Commands Command, Non Signalling Parameter Remark Page FETCh:ARRay:POWer[:NORMal][:GMSK][:CURRent]? –100.0 dB to +20.0 dB query only 6.23 SAMPle:ARRay:POWer[:NORMal][:GMSK][:CURRent]? –100.0 dB to +20.0 dB query only 6.23 READ:SUBarrays:POWer[:NORMal][:GMSK][:CURRent]? –100.0 dB to +20.0 dB query only 6.24 FETCh:SUBarrays:POWer[:NORMal][:GMSK][:CURRent]? –100.0 dB to +20.0 dB query only 6.24 SAMPle:SUBarrays:POWer[:NORMal][:GMSK][:CURRent]?
  • Page 552 List of Commands CMU-K20/21/22/23/24 Command, Non Signalling Parameter Remark Page SAMPle:SUBarrays:POWer[:NORMal][:GMSK]:MPR: –100.0 dB to +20.0 dB query only 6.30 MAXimum? READ:ARRay:POWer[:NORMal][:GMSK]:MPR:MINimum? –100.0 dB to +20.0 dB query only 6.29 FETCh:ARRay:POWer[:NORMal][:GMSK]:MPR:MINimum? –100.0 dB to +20.0 dB query only 6.29 SAMPle:ARRay:POWer[:NORMal][:GMSK]:MPR:MINimum? –100.0 dB to +20.0 dB query only 6.29 READ:SUBarrays:POWer[:NORMal][:GMSK]:MPR:MINimum?
  • Page 553 CMU-K20/21/22/23/24 List of Commands Command, Non Signalling Parameter Remark Page [SENSe:]RFANalyzer:TSEQuence OFF | GSM0 to GSM7 | DUMMy with query RF Signal generated INITiate:RFGenerator – no query ABORt:RFGenerator – no query SOURce:RFGenerator:FM:DEViation –10 kHz to 10 kHz with query SOURce:RFGenerator:FREQuency[:CHANnel] 0.2 MHz to 2700 MHz with query SOURce:RFGenerator:LEVel:UNTimeslot...
  • Page 554 List of Commands CMU-K20/21/22/23/24 Command, Non Signalling Parameter Remark Page MODE[:UPPer] CONFigure:SPECtrum:MODulation:EPSK:LIMit:LINE: <Minimum>, <Maximum> with query 6.107 REFPower[:UPPer] CONFigure:SPECtrum:MODulation:EPSK:LIMit: <MinLevel>,<MaxLevel>,<AbsLeve with query 6.106 LINE[:ASYMmetrical]:UPPer<nr> l>,<Enable> CONFigure:SPECtrum:MODulation:EPSK:LIMit: ON | OFF with query 6.106 LINE[:ASYMmetrical]:UPPer<nr>:ENABle FETCh:SPECtrum:MODulation:EPSK:STATus? OFF | RUN | STOP | ERR | STEP | only query 6.104 RDY, 1 to 10000 | NONE , 1 to...
  • Page 555 CMU-K20/21/22/23/24 List of Commands Command, Non Signalling Parameter Remark Page REPetition 10000, SONerror | NONE, STEP | NONE CONFigure:SPECtrum:MODulation[:GMSK]:EREPorting SRQ | SOPC | SRSQ | OFF with query 6.103 CONFigure:SPECtrum:MODulation[:GMSK]:LIMit:LINE:DEFault ON | OFF with query 6.108 CONFigure:SPECtrum:MODulation[:GMSK]:LIMit:LINE: ON | OFF with query 6.108 MODE[:UPPer]...
  • Page 556 List of Commands CMU-K20/21/22/23/24 Command, Non Signalling Parameter Remark Page CONFigure:SPECtrum:SWITching:EPSK:CONTrol: <F1>, <F2> with query 6.114 AMPoints:FREQuency CONFigure:SPECtrum:SWITching:EPSK:CONTrol:DEFault ON | OFF with query 6.114 DISPlay:SPECtrum:SWITching:EPSK:CONTrol:GRID ON | OFF with query 6.113 CONFigure:SPECtrum:SWITching:EPSK:CONTrol: ON | OFF with query 6.114 MPOint<nr>:ENABle CONFigure:SPECtrum:SWITching:EPSK:CONTrol:REPetition CONTinuous | SINGleshot | 1 to with query 6.113...
  • Page 557 CMU-K20/21/22/23/24 List of Commands Command, Non Signalling Parameter Remark Page INITiate:SPECtrum:SWITching[:GMSK] – no query 6.111 ABORt:SPECtrum:SWITching[:GMSK] – no query 6.111 STOP:SPECtrum:SWITching[:GMSK] – no query 6.111 CONTinue:SPECtrum:SWITching[:GMSK] – no query 6.111 CONFigure:SUBarrays:SPECtrum:SWITching[:GMSK] ALL | ARIThmetical | MINimum | with query 6.117 MAXimum IVAL,<Start>,<Samples>{,<Start>, <Samples>}...
  • Page 558 List of Commands CMU-K20/21/22/23/24 Command, Non Signalling Parameter Remark Page FETCh:ARRay:SPECtrum:SWITching[:GMSK]? –100.0 dB to +100.0 dBm only query 6.118 SAMPle:ARRay:SPECtrum:SWITching[:GMSK]? –100.0 dB to +100.0 dBm only query 6.118 READ:SUBarrays:SPECtrum:SWITching[:GMSK]? –100.0 dB to +100.0 dBm query only 6.119 FETCh:SUBarrays:SPECtrum:SWITching[:GMSK]? –100.0 dB to +100.0 dBm query only 6.119 SAMPle:SUBarrays:SPECtrum:SWITching[:GMSK]?
  • Page 559 CMU-K20/21/22/23/24 List of Commands Command, Non Signalling Parameter Remark Page READ[:SCALar]:WPOWer? –30 dBm to +30 dBm query only 6.37 FETCh[:SCALar]:WPOWer? –30 dBm to +30 dBm query only 6.37 SAMPle[:SCALar]:WPOWer? –30 dBm to +30 dBm query only 6.37 1115.6088.12 6.255 E-12...

  • Page 560: Table 6-2 Remote Control Commands: Signalling Mode

    List of Commands CMU-K20/21/22/23/24 Commands for GSM Mobile Tests Table 6-2 Remote control commands: Signalling mode Command, Signalling Parameter Remark Page RF generator signal of CMU CONFigure:BSSignal:CCH:AUXTx:CHANnel <Channel> with query 6.192 CONFigure:BSSignal:CCH:AUXTx:CHTYpe OFF | BCCH with query 6.191 CONFigure:BSSignal:CCH:AUXTx:LEVel[:ABSolute] <Level> with query 6.192 CONFigure:BSSignal:CCH[:TX]:CHANnel...
  • Page 561 CMU-K20/21/22/23/24 List of Commands Command, Signalling Parameter Remark Page <PCL_7> CONFigure:BSSignal[:CSWitched][:TCH]:MSLot:SCONfig:UUNused <Enable_0>,<Enable_1>, ..., with query 6.190 <Enable_7> CONFigure:BSSignal[:CSWitched][:TCH][:SSLot]:FHOPping:A <Channel>{,<Channel>} with query 6.188 CONFigure:BSSignal[:CSWitched][:TCH][:SSLot]:FHOPping:B Channel>{,<Channel>} with query 6.188 CONFigure:BSSignal[:CSWitched][:TCH][:SSLot]:FHOPping:C Channel>{,<Channel>} with query 6.188 CONFigure:BSSignal[:CSWitched][:TCH][:SSLot]:FHOPping:D Channel>{,<Channel>} with query 6.188 CONFigure:BSSignal[:CSWitched][:TCH][:SSLot]:TIMeslot 2 to 6 | 0 to 7 with query 6.188 Inputs and Outputs...
  • Page 562 List of Commands CMU-K20/21/22/23/24 Command, Signalling Parameter Remark Page Configuration and Message File Management MMEMory:L3MSg:BEMPty ON | OFF query only 6.211 MMEMory:L3MSg:BWRiting ON | OFF with query 6.211 MMEMory:L3MSg:CDEStination <FileName> no query 6.210 MMEMory:L3MSg:SAVE [<FileName>] [,<msus>] no query 6.211 MMEMory:RECall:CURRent <FileName>...
  • Page 563 CMU-K20/21/22/23/24 List of Commands Command, Signalling Parameter Remark Page SAMPle:ARRay:MODulation:EVMagnitude:EPSK:MMAXimum? –100.0 dB to +100.0 dB query only 6.90 READ:SUBarrays:MODulation:EVMagnitude:EPSK:MMAXimum? –100.0 dB to +20.0 dB query only 6.90 FETCh:SUBarrays:MODulation:EVMagnitude:EPSK:MMAXimum? –100.0 dB to +20.0 dB query only 6.90 SAMPle:SUBarrays:MODulation:EVMagnitude:EPSK:MMAXimum? –100.0 dB to +20.0 dB query only 6.90 FETCh:MODulation:EVMagnitude:EPSK:STATus?
  • Page 564 List of Commands CMU-K20/21/22/23/24 Command, Signalling Parameter Remark Page CONFigure:MODulation:MERRor:EPSK:CONTrol:DEFault ON | OFF with query 6.99 CONFigure:MODulation:MERRor:EPSK:CONTrol:REPetition CONTinuous | SINGleshot | 1 with query 6.98 to 10000, SONerror | NONE, STEP | NONE CONFigure:MODulation:MERRor:EPSK:EREPorting SRQ | SOPC | SRSQ | OFF with query 6.97 CALCulate:MODulation:MERRor:EPSK:LIMit:MATChing?
  • Page 565 CMU-K20/21/22/23/24 List of Commands Command, Signalling Parameter Remark Page <MagnErrorRMS>,<EVMErro rPeak>, <EVMErrorRMS>, <OriginOffset>, <IQImbalance>, <FreqError> Modulation measurement: 8PSK Modulation, Overview INITiate:MODulation:OVERview:EPSK – no query 6.80 ABORt:MODulation:OVERview:EPSK – no query 6.80 STOP:MODulation:OVERview:EPSK – no query 6.80 CONTinue:MODulation:OVERview:EPSK – no query 6.80 CONFigure:MODulation:OVERview:EPSK:CONTrol SCALar | ARRay, 1 to 1000 | with query...
  • Page 566 List of Commands CMU-K20/21/22/23/24 Command, Signalling Parameter Remark Page FETCh:SUBarrays:MODulation[:PERRor]:EPSK:AVERage? –100.0 dB to +20.0 dB query only 6.96 SAMPle:SUBarrays:MODulation[:PERRor]:EPSK:AVERage? –100.0 dB to +20.0 dB query only 6.96 CONFigure:MODulation[:PERRor]:EPSK:CONTrol SCALar | ARRay, 1 to 1000 | with query 6.92 NONE CONFigure:MODulation[:PERRor]:EPSK:CONTrol:DEFault ON | OFF with query 6.93...
  • Page 567 CMU-K20/21/22/23/24 List of Commands Command, Signalling Parameter Remark Page CONTinue:MODulation[:PERRor][:GMSK] – no query 6.64 CONFigure:SUBarrays:MODulation[:PERRor][:GMSK] ARIThmetical with query 6.68 MINimum MAXimum IVAL,<Start>,<Samples>{,<St art>,<Samples>} READ:ARRay:MODulation[:PERRor][:GMSK]:AVERage? –100.0 dB to +100.0 dB query only 6.70 FETCh:ARRay:MODulation[:PERRor][:GMSK]:AVERage? –100.0 dB to +100.0 dB query only 6.70 SAMPle:ARRay:MODulation[:PERRor][:GMSK]:AVERage? –100.0 dB to +100.0 dB...
  • Page 568 List of Commands CMU-K20/21/22/23/24 Command, Signalling Parameter Remark Page STEP | RDY, 1 to 10000 | NONE, 1 to 1000 | NONE CONFigure:MODulation[:PERRor][:GMSK]:TIME:DECode STANdard | GTBits with query 6.68 READ[:SCALar]:MODulation[:PERRor][:GMSK]? <Result> query only 6.69 FETCh[:SCALar]:MODulation[:PERRor][:GMSK]? <Result> query only 6.69 SAMPle[:SCALar]:MODulation[:PERRor][:GMSK]? <Result>...
  • Page 569 CMU-K20/21/22/23/24 List of Commands Command, Signalling Parameter Remark Page CONFigure:MODulation:XPERror[:GMSK]:EREPorting SRQ | SOPC | SRSQ | OFF with query 6.72 CONFigure:MODulation:XPERror[:GMSK]:FILTer G500 | B600 with query 6.73 CONFigure:MODulation:XPERror[:GMSK]:LIMit:AVERage 0.0 deg to 50.0 deg, 0.0 deg with query 6.75 to 50.0 deg, –100 dB to 0 dB, –100 dB to 0 dB, 0 Hz to 999 CONFigure:MODulation:XPERror[:GMSK]:LIMit:DEFault ON | OFF...
  • Page 570 List of Commands CMU-K20/21/22/23/24 Command, Signalling Parameter Remark Page RF signal of the mobile phone CONFigure:MSSignal:CCH:PMAX <Level> with query 6.184 CONFigure:MSSignal:PDATa[:TCH]:MSLot:SCONfig <Enable_0>,..., <Enable_7>, with query 6.216 <Gamma_0>,... <Gamma_7> CONFigure:MSSignal[:CSWitched]:DTX ON | OFF with query 6.184 CONFigure:MSSignal[:CSWitched][:TCH]:MSLot:LOOP <Loop> with query 6.185 CONFigure:MSSignal[:CSWitched][:TCH]:MSLot:SCONfig <Enable_0>,<Enable_1>, ..., with query...
  • Page 571 CMU-K20/21/22/23/24 List of Commands Command, Signalling Parameter Remark Page [SENSe:]MSSinfo:MSCLass:PDATa:EGPRs? 1 to 29 query only 6.222 [SENSe:]MSSinfo:MSCLass:PDATa[:GPRS]? 1 to 29 query only 6.222 [SENSe:]MSSinfo:POWer:CLASs? 1 to 5 query only 6.208 [SENSe:]MSSinfo:REVision? PH1 | PH2 | PH2P query only 6.207 [SENSe:]MSSinfo:TRAFfic? FRV1 | FRV2 | HRV1 | FD48 | query only 6.208...
  • Page 572 List of Commands CMU-K20/21/22/23/24 Command, Signalling Parameter Remark Page CONFigure:NETWork:PDATa:TWACk ON | OFF with query 6.221 CONFigure:NETWork:PDATa:USDCycle A100 | A000 | A012 with query 6.221 CONFigure:NETWork:PDATa:USF 0 to 7 with query 6.220 CONFigure:NETWork:SYSTem:ACLass 0 to 2 –1 with query 6.196 CONFigure:NETWork:SYSTem:BINDicator G18 | G19 with query...
  • Page 573 CMU-K20/21/22/23/24 List of Commands Command, Signalling Parameter Remark Page <ThrUp1> CONFigure:NETWork[:CSWitched]:AMR:HRATe:RSETting <CM4>, <CM3>, CM2>, with query 6.225 <CM1>,<ThrDown4>, <ThrUp3>, <ThrDown3>, <ThrUp2>, <ThrDown2>, <ThrUp1> CONFigure:NETWork[:CSWitched]:AMR:HRATe:ULCMode ON | OFF with query 6.200 PROCedure:NETWork[:CSWitched]:AMR:HRATe:ULCMode ON | OFF with query 6.200 CONFigure:NETWork[:CSWitched]:AMR:HRATe:ULCMode ON | OFF with query 6.224 PROCedure:NETWork[:CSWitched]:AMR:HRATe:ULCMode...
  • Page 574 List of Commands CMU-K20/21/22/23/24 Command, Signalling Parameter Remark Page CONFigure:NETWork[:CSWitched]:SMODe:TRAFfic FRV1 | FRV2 | HRV1 | FD24 | with query 6.197 FD48 | FD96 | FD14 | HD24 | HD48 | C1TM |... | C4TM | MC1TM | ... | MC4TM | AMRH | AMRF CONFigure:NETWork[:CSWitched]:SOFFset –7 to 7...
  • Page 575 CMU-K20/21/22/23/24 List of Commands Command, Signalling Parameter Remark Page ABORt:POWer:ABURst[:GMSK] – no query 6.136 STOP:POWer:ABURst[:GMSK] – no query 6.136 CONTinue:POWer:ABURst[:GMSK] – no query 6.136 CONFigure:SUBarrays:POWer:ABURst[:GMSK] ALL | ARITHmetical | with query 6.138 MINimum | MAXimum,<Start>,<Samples >{,<Start>,<Samples>} CALCulate:ARRay:POWer:ABURst[:GMSK]:AREA:LIMit:MATChing <Matching> query only 6.141 CONFigure:POWer:ABURst[:GMSK]:EREPorting SRQ | SOPC | SRSQ | OFF...
  • Page 576 List of Commands CMU-K20/21/22/23/24 Command, Signalling Parameter Remark Page IVAL,<Start>,<Samples>{,<St art>,<Samples>} CONFigure:POWer:FRAMe:CONTrol:DEFault ON | OFF with query 6.51 CONFigure:POWer:FRAMe:CONTrol:REPetition CONTinuous | SINGleshot | 1 with query 6.51 to 10000, SONerror | NONE, STEP | NONE CONFigure:POWer:FRAMe:EREPorting SRQ | SOPC | SRSQ | OFF with query 6.50 CONFigure:POWer:FRAMe:FCOunt...
  • Page 577 CMU-K20/21/22/23/24 List of Commands Command, Signalling Parameter Remark Page CALCulate:ARRay:POWer:MSLot:AREA:LIMit:MATChing[:CURRent <Matching> query only 6.61 [SENSe:]ARRay:POWer:MSLot:AREA:LIMit:UPPer:INFO? <Result> query only 6.62 [SENSe:]ARRay:POWer:MSLot:AREA:LIMit:UPPer:LEVel? <Result> query only 6.62 [SENSe:]ARRay:POWer:MSLot:AREA:LIMit:UPPer:TIME? <Result> query only 6.62 READ:ARRay:POWer:MSLot:AVERage? –100.0 dB to +20.0 dB query only 6.60 FETCh:ARRay:POWer:MSLot:AVERage? –100.0 dB to +20.0 dB query only 6.60 SAMPle:ARRay:POWer:MSLot:AVERage?
  • Page 578 List of Commands CMU-K20/21/22/23/24 Command, Signalling Parameter Remark Page SAMPle:SUBarrays:POWer:MSLot:MAXimum? –100.0 dB to +20.0 dB query only 6.61 READ:ARRay:POWer:MSLot:MINimum? –100.0 dB to +20.0 dB query only 6.60 FETCh:ARRay:POWer:MSLot:MINimum? –100.0 dB to +20.0 dB query only 6.60 SAMPle:ARRay:POWer:MSLot:MINimum? –100.0 dB to +20.0 dB query only 6.60 READ:SUBarrays:POWer:MSLot:MINimum?
  • Page 579 CMU-K20/21/22/23/24 List of Commands Command, Signalling Parameter Remark Page CONFigure:POWer:PCL:CONTrol:REPetition CONTinuous | SINGleshot | 1 with query 6.143 to 10000, SONerror | NONE, STEP | NONE CONFigure:POWer:PCL:EREPorting SRQ | SOPC | SRSQ | OFF with query 6.142 READ[:SCALar]:POWer:PCL:PCLPower<PCL>? <Result> query only 6.145 FETCh[:SCALar]:POWer:PCL:PCLPower<PCL>? <Result>...
  • Page 580 List of Commands CMU-K20/21/22/23/24 Command, Signalling Parameter Remark Page FETCh:ARRay:POWer:SLOT? <Result> query only 6.44 SAMPle:ARRay:POWer:SLOT? <Result> query only 6.44 READ:SUBarrays:POWer:SLOT? <Result> query only 6.44 FETCh:SUBarrays:POWer:SLOT? <Result> query only 6.44 SAMPle:SUBarrays:POWer:SLOT? <Result> query only 6.44 POWer:XSLOT measurement INITiate:POWer:XSLot – no query 6.45 ABORt:POWer:XSLot –...
  • Page 581 CMU-K20/21/22/23/24 List of Commands Command, Signalling Parameter Remark Page Power vs. time (normal burst, 8PSK modulation) INITiate:POWer[:NORMal]:EPSK – no query 6.120 ABORt:POWer[:NORMal]:EPSK – no query 6.120 STOP:POWer[:NORMal]:EPSK – no query 6.120 CONTinue:POWer[:NORMal]:EPSK – no query 6.120 CONFigure:SUBarrays:POWer[:NORMal]:EPSK ALL | ARIThmetical | with query 6.130 MINimum | MAXimum |...
  • Page 582 List of Commands CMU-K20/21/22/23/24 Command, Signalling Parameter Remark Page CONFigure:POWer[:NORMal]:EPSK:LIMit:LINE:LOWer:ALL:DYNa ON | OFF with query 6.128 mic:ENABle CONFigure:POWer[:NORMal]:EPSK:LIMit:LINE:LOWer<AreaNr> ON | OFF with query 6.128 :ALL:DYNamic:ENABle CONFigure:POWer[:NORMal]:EPSK:LIMit:LINE:LOWer<nr> <fromTPCL>, <toTPCL>, with query 6.127 :DYNamic<RgNr> <Correction>, ON | OFF CONFigure:POWer[:NORMal]:EPSK:LIMit:LINE:LOWer<nr> <StartTime>, <EndTime>, with query 6.125 [:STATic] <StartRelLevel>,...
  • Page 583 CMU-K20/21/22/23/24 List of Commands Command, Signalling Parameter Remark Page READ:SUBarrays:POWer[:NORMal]:EPSK:MAXimum? –100.0 dB to +20.0 dB query only 6.134 FETCh:SUBarrays:POWer[:NORMal]:EPSK:MAXimum? –100.0 dB to +20.0 dB query only 6.134 SAMPle:SUBarrays:POWer[:NORMal]:EPSK:MAXimum? –100.0 dB dB to +20.0 dB query only 6.134 READ:ARRay:POWer[:NORMal]:EPSK:MINimum? –100.0 dB to +20.0 dB query only 6.133 FETCh:ARRay:POWer[:NORMal]:EPSK:MINimum?
  • Page 584 List of Commands CMU-K20/21/22/23/24 Command, Signalling Parameter Remark Page MATChing:AVERage? CALCulate:ARRay:POWer[:NORMal][:GMSK]:AREA:LIMit: <Matching> query only 6.135 MATChing:MAXimum? CALCulate:ARRay:POWer[:NORMal][:GMSK]:AREA:LIMit: <Matching> query only 6.135 MATChing:MINimum? CALCulate:ARRay:POWer[:NORMal][:GMSK]:AREA:LIMit: <Matching> query only 6.135 MATChing[:CURRent]? READ:ARRay:POWer[:NORMal][:GMSK]:AVERage? –100.0 dB to +20.0 dB query only 6.133 FETCh:ARRay:POWer[:NORMal][:GMSK]:AVERage? –100.0 dB to +20.0 dB query only 6.133 SAMPle:ARRay:POWer[:NORMal][:GMSK]:AVERage?
  • Page 585 CMU-K20/21/22/23/24 List of Commands Command, Signalling Parameter Remark Page LOWer<nr>[:STATic]:ENABle CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE: ON | OFF with query 6.127 UPPer:ALL:DYNamic:ENABle CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE: ON | OFF with query 6.127 UPPer<nr>:ALL:DYNamic:ENABle CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE: <fromTPCL>, <toTPCL>, with query 6.126 UPPer<nr>:DYNamic<nr> <Correction>, ON | OFF CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE: ON | OFF with query 6.126 UPPer<nr>:DYNamic<nr>:ENABle...
  • Page 586 List of Commands CMU-K20/21/22/23/24 Command, Signalling Parameter Remark Page FETCh:SUBarrays:POWer[:NORMal][:GMSK]:MINimum? –100.0 dB to +20.0 dB query only 6.134 SAMPle:SUBarrays:POWer[:NORMal][:GMSK]:MINimum? –100.0 dB to +20.0 dB query only 6.134 FETCh:POWer[:NORMal][:GMSK]:STATus? OFF | RUN | STOP | ERR | query only 6.121 STEP | RDY, 1 to 10000 | NONE , 1 to 1000 | NONE CONFigure:POWer[:NORMal][:GMSK]:TOFFset –4.00 to +4.00...
  • Page 587 CMU-K20/21/22/23/24 List of Commands Command, Signalling Parameter Remark Page CONFigure:POWer[:NORMal][:GMSK]:MPR:CONTrol:REPetition CONTinuous | SINGleshot | 1 with query 6.147 to 10000, SONerror | NONE,STEP | NONE CONFigure:POWer[:NORMal][:GMSK]:MPR:EREPorting SRQ | SOPC | SRSQ | OFF with query 6.146 CALCulate:POWer[:NORMal][:GMSK]:MPR:LIMit:MATChing? <Result> query only 6.151 READ:ARRay:POWer[:NORMal][:GMSK]:MPR:MAXimum? –100.0 to +20.0...
  • Page 588 List of Commands CMU-K20/21/22/23/24 Command, Signalling Parameter Remark Page MS Receiver Reports [SENSe:]RREPorts:COUNt? <Counts> query only 6.206 [SENSe:]RREPorts:DTX? ON | OFF query only 6.206 [SENSe:]RREPorts:NCELl? <Channel>, 0 to 63 | NAN query only 6.206 [SENSe:]RREPorts:RPCL? 0 to 31 query only 6.206 [SENSe:]RREPorts:RXLevel? 0 to 63 | NAN...
  • Page 589 CMU-K20/21/22/23/24 List of Commands Command, Signalling Parameter Remark Page CONFigure:RXQuality:BAVerage:LIMit:DBLer 0 % to 100 % with query 6.166 CALCulate:RXQuality:BAVerage:LIMit:MATChing? <Result> query only 6.169 CONFigure:RXQuality:BAVerage:LIMit:USFBler 0 % to 100 % with query 6.167 FETCh:RXQuality:BAVerage:STATus? OFF | RUN | STOP | ERR | query only 6.163 STEP | RDY, 1 to 500 |...
  • Page 590 List of Commands CMU-K20/21/22/23/24 Command, Signalling Parameter Remark Page CONFigure:RXQuality:BER<nr>:CONTrol:PDATa[:TCH] <Level> with query 6.158 :LEVel[:SLOT]:SEVen CONFigure:RXQuality:BER<nr>:CONTrol:PDATa[:TCH] <Level> with query 6.158 :LEVel[:SLOT]:SIX CONFigure:RXQuality:BER<nr>:CONTrol:PDATa[:TCH] <Level> with query 6.158 :LEVel[:SLOT]:THRee CONFigure:RXQuality:BER<nr>:CONTrol:PDATa[:TCH] <Level> with query 6.158 :LEVel[:SLOT]:TWO CONFigure:RXQuality:BER<nr>:CONTrol:PDATa[:TCH] <Level> with query 6.158 :LEVel[:SLOT]:ZERO CONFigure:RXQuality:BER<nr>:CONTrol:PDATa[:TCH]:MSLot <Level_0>, ..., <Level_7>...
  • Page 591 CMU-K20/21/22/23/24 List of Commands Command, Signalling Parameter Remark Page :MSLot:RLEVel CONFigure:RXQuality:BER<nr>:LIMit:CLIB 0 % to 100 % with query 6.159 CONFigure:RXQuality:BER<nr>:LIMit:CLII 0 % to 100 % with query 6.159 CONFigure:RXQuality:BER<nr>:LIMit:DBLer 0 % to 100 % with query 6.159 CONFigure:RXQuality:BER<nr>:LIMit:DEFault ON | OFF with query 6.160 CONFigure:RXQuality:BER<nr>:LIMit:FERRors...
  • Page 592 List of Commands CMU-K20/21/22/23/24 Command, Signalling Parameter Remark Page CONFigure:RXQuality:CONTrol:DEFault ON | OFF with query 6.153 CONFigure:RXQuality:CONTrol:HTIMe 0 s to 100 s, 0 s to 100 s with query 6.152 CONFigure:RXQuality:PDATa:BITStream PR9 | PR11 | PR15 | PR16 with query 6.152 CONFigure:RXQuality[:CSWitched]:BITStream PR9 | PR11 | PR15 | PR16...
  • Page 593 CMU-K20/21/22/23/24 List of Commands Command, Signalling Parameter Remark Page PROCedure:SIGNalling[:CSWitched][:TCH][:SSLot]:CHCCombined <ChannelNumber>, with query 6.180 <Timeslot>, <PCL> PROCedure:SIGNalling[:CSWitched][:TCH][:SSLot]:FHOPping:SEQ A | B | C | D | OFF with query 6.180 uence PROCedure:SIGNalling[:CSWitched][:TCH][:SSLot]:LOOP <Loop> with query 6.182 PROCedure:SIGNalling[:CSWitched][:TCH][:SSLot]:MS:PCL 0 to 31 with query 6.181 PROCedure:SIGNalling[:CSWitched][:TCH][:SSLot]:TIMeslot 2 to 6 | 0 to 7...
  • Page 594 List of Commands CMU-K20/21/22/23/24 Command, Signalling Parameter Remark Page CONFigure:SPECtrum:MODulation:EPSK:LIMit:LINE <MinLevel>,<MaxLevel>,<Ab with query 6.106 [:ASYMmetrical]:UPPer<nr> sLevel>,<Enable> CONFigure:SPECtrum:MODulation:EPSK:LIMit:LINE ON | OFF with query 6.106 [:ASYMmetrical]:UPPer<nr>:ENABle FETCh:SPECtrum:MODulation:EPSK:STATus? OFF | RUN | STOP | ERR | only query 6.104 STEP | RDY, 1 to 10000 | NONE , 1 to 1000 | NONE READ[:SCALar]:SPECtrum:MODulation:EPSK? <Result>...
  • Page 595 CMU-K20/21/22/23/24 List of Commands Command, Signalling Parameter Remark Page CONFigure:SPECtrum:MODulation[:GMSK]:LIMit:LINE:DEFault ON | OFF with query 6.108 CONFigure:SPECtrum:MODulation[:GMSK]:LIMit:LINE: ON | OFF with query 6.108 MODE[:UPPer] CONFigure:SPECtrum:MODulation[:GMSK]:LIMit:LINE: <Minimum>, <Maximum> with query 6.107 REFPower[:UPPer] CONFigure:SPECtrum:MODulation[:GMSK]:LIMit:LINE <MinLevel>,<MaxLevel>,<Ab with query 6.106 [:ASYMmetrical]:UPPer<nr> sLevel>,<Enable> CONFigure:SPECtrum:MODulation[:GMSK]:LIMit:LINE ON | OFF with query 6.106 [:ASYMmetrical]:UPPer<nr>:ENABle...
  • Page 596 List of Commands CMU-K20/21/22/23/24 Command, Signalling Parameter Remark Page DISPlay:SPECtrum:SWITching:EPSK:CONTrol:GRID ON | OFF with query 6.113 CONFigure:SPECtrum:SWITching:EPSK:CONTrol: ON | OFF with query 6.114 MPOint<nr>:ENABle CONFigure:SPECtrum:SWITching:EPSK:CONTrol:REPetition CONTinuous | SINGleshot | 1 with query 6.113 to 10000, SONerror | NONE, STEP | NONE CONFigure:SPECtrum:SWITching:EPSK:CSMODE PHOL | SCO with query...
  • Page 597 CMU-K20/21/22/23/24 List of Commands Command, Signalling Parameter Remark Page STOP:SPECtrum:SWITching[:GMSK] – no query 6.111 CONTinue:SPECtrum:SWITching[:GMSK] – no query 6.111 CONFigure:SUBarrays:SPECtrum:SWITching[:GMSK] ARIThmetical with query 6.117 MINimum MAXimum IVAL,<Start>,<Samples>{,<St art>,<Samples>} CONFigure:SPECtrum:SWITching[:GMSK]:CONTrol SCALar | ARRay, 1 to 1000 | with query 6.113 NONE CONFigure:SPECtrum:SWITching[:GMSK]:CONTrol:DEFault ON | OFF with query...
  • Page 598 List of Commands CMU-K20/21/22/23/24 Command, Signalling Parameter Remark Page FETCh:ARRay:SPECtrum:SWITching[:GMSK] –100.0 dB to +100.0 dBm query only 6.119 :AMPoints:POWer? READ:SUBarrays:SPECtrum:SWITching[:GMSK]? –100.0 dB to +100.0 dBm query only 6.119 FETCh:SUBarrays:SPECtrum:SWITching[:GMSK]? –100.0 dB to +100.0 dBm query only 6.119 SAMPle:SUBarrays:SPECtrum:SWITching[:GMSK]? –100.0 dB to +100.0 dBm query only 6.119 Symbolic Status Register Evaluation...
  • Page 599 CMU-K20/21/22/23/24 List of Commands Command, Signalling Parameter Remark Page SAMPle[:SCALar]:WPOWer? –30 dBm to +30 dBm query only 6.37 1115.6088.12 6.295 E-12...

  • Page 600: Table 6-3 Remote Control Commands: Non Signalling Mode

    List of Commands CMU-K20/21/22/23/24 Alphabetical Command Lists Table 6-3 Remote control commands: Non Signalling mode Command (Non Signalling, alphabetical) Page ABORt:MODulation:EVMagnitude:EPSK ............................ 6.85 ABORt:MODulation:MERRor:EPSK ............................6.97 ABORt:MODulation:OVERview:EPSK............................6.80 ABORt:MODulation:XPERror[:GMSK] ............................6.72 ABORt:MODulation[:PERRor]:EPSK ............................6.91 ABORt:MODulation[:PERRor][:GMSK] ............................6.64 ABORt:NPOWer ..................................6.38 ABORt:POWer:FRAMe................................
  • Page 601 CMU-K20/21/22/23/24 List of Commands Command (Non Signalling, alphabetical) Page CALCulate[:SCALar]:POWer[:NORMal][:GMSK]:MPR:LIMit:MATChing? ................... 6.31 CONFigure:IQIF:RXPath ................................6.34 CONFigure:IQIF:RXTXcombined..............................6.33 CONFigure:IQIF:TXPath................................6.34 CONFigure:MODulation:EVMagnitude:EPSK:CONTrol ......................6.86 CONFigure:MODulation:EVMagnitude:EPSK:CONTrol:DEFault ....................6.87 CONFigure:MODulation:EVMagnitude:EPSK:CONTrol:REPetition .................... 6.86 CONFigure:MODulation:EVMagnitude:EPSK:EREPorting......................6.85 CONFigure:MODulation:MERRor:EPSK:CONTrol ........................6.98 CONFigure:MODulation:MERRor:EPSK:CONTrol:DEFault ......................6.99 CONFigure:MODulation:MERRor:EPSK:CONTrol:REPetition ....................6.98 CONFigure:MODulation:MERRor:EPSK:EREPorting........................6.97 CONFigure:MODulation:OEMP:EPSK:LIMit:AVERage .......................
  • Page 602 List of Commands CMU-K20/21/22/23/24 Command (Non Signalling, alphabetical) Page CONFigure:POWer:FRAMe:FCOunt ............................6.50 CONFigure:POWer:MSLot:CONTrol ............................6.55 CONFigure:POWer:MSLot:CONTrol:DEFault ..........................6.56 CONFigure:POWer:MSLot:CONTrol:REPetition ......................... 6.55 CONFigure:POWer:MSLot:EREPorting............................6.54 CONFigure:POWer:MSLot:FILTer ............................... 6.57 CONFigure:POWer:MSLot:LIMit:LINE:GLEVel ........................... 6.57 CONFigure:POWer:MSLot:MVIew............................... 6.56 CONFigure:POWer:MSLot:SCOunt............................. 6.56 CONFigure:POWer:MSLot:TOFFset ............................6.56 CONFigure:POWer:SLOT:CONTrol:DEFault ..........................6.42 CONFigure:POWer:SLOT:CONTrol:REPetition .......................... 6.42 CONFigure:POWer:SLOT:EREPorting............................
  • Page 603 CMU-K20/21/22/23/24 List of Commands Command (Non Signalling, alphabetical) Page CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE:UPPer<nr>[:STATic] ..................6.14 CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE:UPPer<nr>[:STATic]:ENABle ..............6.14 CONFigure:POWer[:NORMal][:GMSK]:MPR:CONTrol ....................... 6.27 CONFigure:POWer[:NORMal][:GMSK]:MPR:CONTrol:REPetition ..................... 6.27 CONFigure:POWer[:NORMal][:GMSK]:MPR:EREPorting......................6.26 CONFigure:POWer[:NORMal][:GMSK]:TOFFset ........................6.12 CONFigure:RFANalyzer:MCONTrol:TSOFfset ..........................6.4 CONFigure:RFANalyzer:TPCL ..............................6.3 CONFigure:RFGenerator:MODulation:BIT:SELection........................6.6 CONFigure:RFGenerator:MODulation:TRANsmission ........................6.6 CONFigure:RFGenerator:MODulation:TSEQuence:SELection..................... 6.6 CONFigure:SPECtrum:MODulation:EPSK:CONTrol ......................... 6.104 CONFigure:SPECtrum:MODulation:EPSK:CONTrol:DEFault ....................
  • Page 604 List of Commands CMU-K20/21/22/23/24 Command (Non Signalling, alphabetical) Page CONFigure:SPECtrum:SWITching[:GMSK]:LIMit:LINE[:ASYMmetrical]:UPPer<nr>:ENABle ..........6.115 CONFigure:SPECtrum:SWITching[:GMSK]:SCOunt......................... 6.112 CONFigure:SUBarrays:MODulation:EVMagnitude:EPSK ......................6.88 CONFigure:SUBarrays:MODulation:MERRor:EPSK ......................... 6.100 CONFigure:SUBarrays:MODulation:XPERror[:GMSK]........................ 6.76 CONFigure:SUBarrays:MODulation[:PERRor]:EPSK........................6.94 CONFigure:SUBarrays:MODulation[:PERRor][:GMSK]....................... 6.68 CONFigure:SUBarrays:POWer:FRAMe ............................6.52 CONFigure:SUBarrays:POWer:MSLot ............................6.58 CONFigure:SUBarrays:POWer:SLOT ............................6.43 CONFigure:SUBarrays:POWer:XSLot............................6.48 CONFigure:SUBarrays:POWer[:NORMal]:EPSK ........................6.21 CONFigure:SUBarrays:POWer[:NORMal][:GMSK] ........................
  • Page 605 CMU-K20/21/22/23/24 List of Commands Command (Non Signalling, alphabetical) Page FETCh:ARRay:MODulation:XPERror[:GMSK]:MMAXimum? ..................... 6.78 FETCh:ARRay:MODulation:XPERror[:GMSK][:CURRent]? ....................... 6.78 FETCh:ARRay:MODulation[:PERRor]:EPSK:AVERage? ......................6.96 FETCh:ARRay:MODulation[:PERRor]:EPSK:MMAXimum? ....................... 6.96 FETCh:ARRay:MODulation[:PERRor]:EPSK[:CURRent]? ......................6.96 FETCh:ARRay:MODulation[:PERRor][:GMSK]:AVERage? ......................6.70 FETCh:ARRay:MODulation[:PERRor][:GMSK]:MMAXimum? ....................6.70 FETCh:ARRay:MODulation[:PERRor][:GMSK][:CURRent]? ...................... 6.70 FETCh:ARRay:POWer:FRAMe? ..............................6.53 FETCh:ARRay:POWer:MSLot:AVERage? ..........................6.60 FETCh:ARRay:POWer:MSLot:MAXimum? ..........................6.60 FETCh:ARRay:POWer:MSLot:MINimum? ..........................
  • Page 606 List of Commands CMU-K20/21/22/23/24 Command (Non Signalling, alphabetical) Page FETCh:SUBarrays:MODulation:EVMagnitude:EPSK:MMAXimum? ..................6.90 FETCh:SUBarrays:MODulation:EVMagnitude:EPSK[:CURRent]?....................6.90 FETCh:SUBarrays:MODulation:MERRor:EPSK:AVERage? ....................6.102 FETCh:SUBarrays:MODulation:MERRor:EPSK:MMAXimum? ....................6.102 FETCh:SUBarrays:MODulation:MERRor:EPSK[:CURRent]? ....................6.102 FETCh:SUBarrays:MODulation:XPERror[:GMSK]:AVERage? ....................6.79 FETCh:SUBarrays:MODulation:XPERror[:GMSK]:MMAXimum? ....................6.79 FETCh:SUBarrays:MODulation:XPERror[:GMSK][:CURRent]? ....................6.79 FETCh:SUBarrays:MODulation[:PERRor]:EPSK:AVERage? ....................6.96 FETCh:SUBarrays:MODulation[:PERRor]:EPSK:MMAXimum? ....................6.96 FETCh:SUBarrays:MODulation[:PERRor]:EPSK[:CURRent]? ....................6.96 FETCh:SUBarrays:MODulation[:PERRor][:GMSK]:AVERage? ....................
  • Page 607 CMU-K20/21/22/23/24 List of Commands Command (Non Signalling, alphabetical) Page FETCh[:SCALar]:SPECtrum:MODulation[:GMSK]? ......................... 6.109 FETCh[:SCALar]:SPECtrum:SWITching:EPSK?........................6.118 FETCh[:SCALar]:SPECtrum:SWITching[:GMSK]?........................6.118 FETCh[:SCALar]:WPOWer?................................ 6.37 INITiate:MODulation:EVMagnitude:EPSK ........................... 6.85 INITiate:MODulation:MERRor:EPSK ............................6.97 INITiate:MODulation:OVERview:EPSK ............................6.80 INITiate:MODulation:XPERror[:GMSK]............................6.72 INITiate:MODulation[:PERRor]:EPSK ............................6.91 INITiate:MODulation[:PERRor][:GMSK]............................6.64 INITiate:NPOWer..................................6.38 INITiate:POWer:FRAMe ................................6.50 INITiate:POWer:MSLot ................................6.54 INITiate:POWer:SLOT .................................
  • Page 608 List of Commands CMU-K20/21/22/23/24 Command (Non Signalling, alphabetical) Page READ:ARRay:POWer[:NORMal]:EPSK:MINimum? ........................6.23 READ:ARRay:POWer[:NORMal]:EPSK[:CURRent]?........................6.23 READ:ARRay:POWer[:NORMal][:GMSK]:AVERage? ........................ 6.23 READ:ARRay:POWer[:NORMal][:GMSK]:MAXimum?........................ 6.23 READ:ARRay:POWer[:NORMal][:GMSK]:MINimum? ......................... 6.23 READ:ARRay:POWer[:NORMal][:GMSK]:MPR:AVERage?......................6.29 READ:ARRay:POWer[:NORMal][:GMSK]:MPR:MAXimum?....................... 6.29 READ:ARRay:POWer[:NORMal][:GMSK]:MPR:MINimum? ......................6.29 READ:ARRay:POWer[:NORMal][:GMSK]:MPR[:CURRent]? ...................... 6.29 READ:ARRay:POWer[:NORMal][:GMSK][:CURRent]? ....................... 6.23 READ:ARRay:SPECtrum:MODulation:EPSK? .......................... 6.110 READ:ARRay:SPECtrum:MODulation[:GMSK]? ........................6.110 READ:ARRay:SPECtrum:SWITching:EPSK? ...........................
  • Page 609 CMU-K20/21/22/23/24 List of Commands Command (Non Signalling, alphabetical) Page READ[:SCALar]:MODulation:MERRor:EPSK? .......................... 6.101 READ[:SCALar]:MODulation:OVERview:EPSK? ........................6.83 READ[:SCALar]:MODulation:XPERror[:GMSK]?......................... 6.77 READ[:SCALar]:MODulation[:PERRor]:EPSK? .......................... 6.95 READ[:SCALar]:MODulation[:PERRor][:GMSK]?........................6.69 READ[:SCALar]:NPOWer?................................6.40 READ[:SCALar]:POWer:FRAMe:FPOWer<nr>?......................... 6.53 READ[:SCALar]:POWer:MSLot? ..............................6.59 READ[:SCALar]:POWer:SLOT:SPOWer<nr>? ........................... 6.44 READ[:SCALar]:POWer:XSLot:SPOWer<nr>? ........................... 6.49 READ[:SCALar]:POWer[:NORMal]:EPSK? ..........................6.21 READ[:SCALar]:POWer[:NORMal][:GMSK]:MPR? ........................6.29 READ[:SCALar]:POWer[:NORMal][:GMSK]? ..........................
  • Page 610 List of Commands CMU-K20/21/22/23/24 Command (Non Signalling, alphabetical) Page SAMPle:ARRay:SPECtrum:MODulation:EPSK? ........................6.110 SAMPle:ARRay:SPECtrum:MODulation[:GMSK]? ........................6.110 SAMPle:ARRay:SPECtrum:SWITching:EPSK? ........................6.118 SAMPle:ARRay:SPECtrum:SWITching[:GMSK]? ........................6.118 SAMPle:SUBarrays:MODulation:EVMagnitude:EPSK:AVERage? .................... 6.90 SAMPle:SUBarrays:MODulation:EVMagnitude:EPSK:MMAXimum? ..................6.90 SAMPle:SUBarrays:MODulation:EVMagnitude:EPSK[:CURRent]? ................... 6.90 SAMPle:SUBarrays:MODulation:MERRor:EPSK:AVERage? ....................6.102 SAMPle:SUBarrays:MODulation:MERRor:EPSK:MMAXimum? ....................6.102 SAMPle:SUBarrays:MODulation:MERRor:EPSK[:CURRent]? ....................6.102 SAMPle:SUBarrays:MODulation:XPERror[:GMSK]:AVERage? ....................6.79 SAMPle:SUBarrays:MODulation:XPERror[:GMSK]:MMAXimum? .....................
  • Page 611 CMU-K20/21/22/23/24 List of Commands Command (Non Signalling, alphabetical) Page SAMPle[:SCALar]:POWer[:NORMal]:EPSK? ..........................6.21 SAMPle[:SCALar]:POWer[:NORMal][:GMSK]:MPR? ......................... 6.29 SAMPle[:SCALar]:POWer[:NORMal][:GMSK]? .......................... 6.21 SAMPle[:SCALar]:SPECtrum:MODulation:EPSK? ........................6.109 SAMPle[:SCALar]:SPECtrum:MODulation[:GMSK]? ........................ 6.109 SAMPle[:SCALar]:SPECtrum:SWITching:EPSK? ........................6.118 SAMPle[:SCALar]:SPECtrum:SWITching[:GMSK]? ........................6.118 SAMPle[:SCALar]:WPOWer? ..............................6.37 [SENSe:]ARRay:POWer:MSLot:AREA:LIMit:INFO:STIMe?......................6.63 [SENSe:]ARRay:POWer:MSLot:AREA:LIMit:LOWer:INFO?....................... 6.62 [SENSe:]ARRay:POWer:MSLot:AREA:LIMit:LOWer:LEVel?...................... 6.62 [SENSe:]ARRay:POWer:MSLot:AREA:LIMit:LOWer:TIME?....................... 6.62 [SENSe:]ARRay:POWer:MSLot:AREA:LIMit:UPPer:INFO?......................
  • Page 612 List of Commands CMU-K20/21/22/23/24 Command (Non Signalling, alphabetical) Page STOP:WPOWer................................... 6.35 SYSTem:OPTions:INFO:CURRent?............................6.32 SYSTem:RESet:CURRent................................6.33 TRIGger[:SEQuence]:DEFault............................... 6.9 TRIGger[:SEQuence]:SLOPe ............................... 6.9 TRIGger[:SEQuence]:SOURce ..............................6.8 TRIGger[:SEQuence]:SOURce:EXTernal............................6.9 TRIGger[:SEQuence]:THReshold:IFPower ..........................6.9 TRIGger[:SEQuence]:THReshold:RFPower ..........................6.9 1115.6088.12 6.308 E-12...

  • Page 613: Table 6-4 Remote Control Commands: Signalling Mode

    CMU-K20/21/22/23/24 List of Commands Table 6-4 Remote control commands: Signalling mode Command (Signalling, alphabetical) Page ABORt:MODulation:EVMagnitude:EPSK ............................ 6.85 ABORt:MODulation:MERRor:EPSK ............................6.97 ABORt:MODulation:OVERview:EPSK............................6.80 ABORt:MODulation:XPERror[:GMSK] ............................6.72 ABORt:MODulation[:PERRor]:EPSK ............................6.91 ABORt:MODulation[:PERRor][:GMSK] ............................6.64 ABORt:NPOWer ..................................6.38 ABORt:POWer:ABURst[:GMSK] ............................... 6.136 ABORt:POWer:FRAMe................................6.50 ABORt:POWer:MSLot .................................
  • Page 614 List of Commands CMU-K20/21/22/23/24 Command (Signalling, alphabetical) Page CALCulate:MODulation[:PERRor][:GMSK]:LIMit:MATChing? ..................... 6.70 CALCulate:POWer:ABURst[:GMSK]:LIMit:MATChing? ......................6.140 CALCulate:POWer:MSLot:LIMit:MATChing? ..........................6.59 CALCulate:POWer:PCL[:CURRent]:LIMit:MATChing? ......................6.145 CALCulate:POWer[:NORMal]:EPSK:LIMit:MATChing? ......................6.132 CALCulate:POWer[:NORMal][:GMSK]:LIMit:MATChing?......................6.132 CALCulate:POWer[:NORMal][:GMSK]:MPR:LIMit:MATChing?....................6.151 CALCulate:RXQuality:BAVerage:LIMit:MATChing? ........................6.169 CALCulate:RXQuality:BER:LIMit:MATChing? ........................... 6.162 CONFigure:BSSignal:CCH:AUXTx:CHANnel..........................6.192 CONFigure:BSSignal:CCH:AUXTx:CHTYpe ..........................6.191 CONFigure:BSSignal:CCH:AUXTx:LEVel[:ABSolute] ....................... 6.192 CONFigure:BSSignal:CCH[:TX]:CHANnel ..........................
  • Page 615 CMU-K20/21/22/23/24 List of Commands Command (Signalling, alphabetical) Page CONFigure:MODulation:OVERview:EPSK:CONTrol:REPetition....................6.81 CONFigure:MODulation:OVERview:EPSK:EREPorting ......................6.80 CONFigure:MODulation:XPERror[:GMSK]:CONTrol........................6.73 CONFigure:MODulation:XPERror[:GMSK]:CONTrol:DEFault..................... 6.74 CONFigure:MODulation:XPERror[:GMSK]:CONTrol:REPetition....................6.74 CONFigure:MODulation:XPERror[:GMSK]:EREPorting ......................6.72 CONFigure:MODulation:XPERror[:GMSK]:FILTer ........................6.73 CONFigure:MODulation:XPERror[:GMSK]:LIMit:AVERage ......................6.75 CONFigure:MODulation:XPERror[:GMSK]:LIMit:DEFault ......................6.75 CONFigure:MODulation:XPERror[:GMSK]:LIMit:LOWer:MODE ....................6.75 CONFigure:MODulation:XPERror[:GMSK]:LIMit:UPPer:MODE....................6.75 CONFigure:MODulation:XPERror[:GMSK]:LIMit[:CURRent]....................... 6.74 CONFigure:MODulation:XPERror[:GMSK]:TIME:DECode......................6.73 CONFigure:MODulation[:PERRor]:EPSK:CONTrol........................
  • Page 616 List of Commands CMU-K20/21/22/23/24 Command (Signalling, alphabetical) Page CONFigure:NETWork:PDATa:TWACk ............................6.221 CONFigure:NETWork:PDATa:USDCycle..........................6.221 CONFigure:NETWork:PDATa:USF ............................6.220 CONFigure:NETWork:SYSTem:ACLass ........................... 6.196 CONFigure:NETWork:SYSTem:BINDicator ..........................6.195 CONFigure:NETWork:SYSTem:BSAGblksres .......................... 6.195 CONFigure:NETWork:SYSTem:BSPamfrms..........................6.195 CONFigure:NETWork:SYSTem:BSPReorganis ........................6.195 CONFigure:NETWork:SYSTem:CACCess ..........................6.195 CONFigure:NETWork:SYSTem:PLUPdate ..........................6.195 CONFigure:NETWork[:CSWitched]:AMR:FRATe:DLCMode ....................6.200 CONFigure:NETWork[:CSWitched]:AMR:FRATe:DLCMode ....................6.223 CONFigure:NETWork[:CSWitched]:AMR:FRATe:RSETting .....................
  • Page 617 CMU-K20/21/22/23/24 List of Commands Command (Signalling, alphabetical) Page CONFigure:POWer:FRAMe:EREPorting ............................. 6.50 CONFigure:POWer:FRAMe:FCOunt ............................6.50 CONFigure:POWer:MSLot:CONTrol ............................6.55 CONFigure:POWer:MSLot:CONTrol:DEFault ..........................6.56 CONFigure:POWer:MSLot:CONTrol:REPetition ......................... 6.55 CONFigure:POWer:MSLot:EREPorting............................6.54 CONFigure:POWer:MSLot:FILTer ............................... 6.57 CONFigure:POWer:MSLot:LIMit:LINE:GLEVel ........................... 6.57 CONFigure:POWer:MSLot:MVIew............................... 6.56 CONFigure:POWer:MSLot:SCOunt............................. 6.56 CONFigure:POWer:MSLot:TOFFset ............................6.56 CONFigure:POWer:PCL:CCOunt .............................. 6.143 CONFigure:POWer:PCL:CHANnel ............................
  • Page 618 List of Commands CMU-K20/21/22/23/24 Command (Signalling, alphabetical) Page CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE:LOWer<nr>[:STATic]:ENABle ..............6.125 CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE:UPPer:ALL:DYNamic:ENABle ..............6.127 CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE:UPPer<nr>:ALL:DYNamic:ENABle............6.127 CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE:UPPer<nr>:DYNamic<nr> ................. 6.126 CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE:UPPer<nr>:DYNamic<nr>:ENABle............6.126 CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE:UPPer<nr>[:STATic] .................. 6.124 CONFigure:POWer[:NORMal][:GMSK]:LIMit:LINE:UPPer<nr>[:STATic]:ENABle ..............6.124 CONFigure:POWer[:NORMal][:GMSK]:MPR:CONTrol ......................6.147 CONFigure:POWer[:NORMal][:GMSK]:MPR:CONTrol:REPetition ................... 6.147 CONFigure:POWer[:NORMal][:GMSK]:MPR:EREPorting......................6.146 CONFigure:POWer[:NORMal][:GMSK]:TOFFset ........................6.121 CONFigure:RXQuality:BAVerage:CONTrol:BAVerage......................6.164 CONFigure:RXQuality:BAVerage:CONTrol:DEFault .........................
  • Page 619 CMU-K20/21/22/23/24 List of Commands Command (Signalling, alphabetical) Page CONFigure:RXQuality:BER<nr>:CONTrol[:CSWitched][:TCH]:LEVel[:SLOT]:ZERO ............... 6.158 CONFigure:RXQuality:BER<nr>:CONTrol[:CSWitched][:TCH]:MSLot:LEVel:INDividual............6.157 CONFigure:RXQuality:BER<nr>:CONTrol[:CSWitched][:TCH]:MSLot:RLEVel ................ 6.157 CONFigure:RXQuality:BER<nr>:LIMit:CLIB ..........................6.159 CONFigure:RXQuality:BER<nr>:LIMit:CLII ..........................6.159 CONFigure:RXQuality:BER<nr>:LIMit:DBLer..........................6.159 CONFigure:RXQuality:BER<nr>:LIMit:DEFault ......................... 6.160 CONFigure:RXQuality:BER<nr>:LIMit:FERRors ........................6.159 CONFigure:RXQuality:BER<nr>:LIMit:USFBler ........................6.159 CONFigure:RXQuality:BLER:CONTrol:DEFault ........................6.172 CONFigure:RXQuality:BLER:CONTrol:PDATa[:TCH]:MSLot:LEVel:INDividual................ 6.171 CONFigure:RXQuality:BLER:CONTrol:PDATa[:TCH]:MSLot:RLEVel ..................6.171 CONFigure:RXQuality:BLER:CONTrol:REPetition ........................
  • Page 620 List of Commands CMU-K20/21/22/23/24 Command (Signalling, alphabetical) Page CONFigure:SPECtrum:SWITching:EPSK:LIMit:LINE[:ASYMmetrical]:UPPer<nr> ..............6.115 CONFigure:SPECtrum:SWITching:EPSK:LIMit:LINE[:ASYMmetrical]:UPPer<nr>:ENABle ............. 6.115 CONFigure:SPECtrum:SWITching:EPSK:SCOunt........................6.112 CONFigure:SPECtrum:SWITching[:GMSK]:CONTrol ....................... 6.113 CONFigure:SPECtrum:SWITching[:GMSK]:CONTrol:AMPoints:FREQuency ................6.114 CONFigure:SPECtrum:SWITching[:GMSK]:CONTrol:DEFault ....................6.114 CONFigure:SPECtrum:SWITching[:GMSK]:CONTrol:MPOint<nr>:ENABle ................6.114 CONFigure:SPECtrum:SWITching[:GMSK]:CONTrol:REPetition ..................... 6.113 CONFigure:SPECtrum:SWITching[:GMSK]:CSMODE......................6.112 CONFigure:SPECtrum:SWITching[:GMSK]:EREPorting......................6.111 CONFigure:SPECtrum:SWITching[:GMSK]:LIMit:LINE:DEFault....................6.116 CONFigure:SPECtrum:SWITching[:GMSK]:LIMit:LINE:MODE[:UPPer] ................... 6.116 CONFigure:SPECtrum:SWITching[:GMSK]:LIMit:LINE[:ASYMmetrical]:UPPer<nr>...
  • Page 621 CMU-K20/21/22/23/24 List of Commands Command (Signalling, alphabetical) Page CONTinue:SPECtrum:MODulation:EPSK ..........................6.103 CONTinue:SPECtrum:MODulation[:GMSK] ..........................6.103 CONTinue:SPECtrum:SWITching:EPSK........................... 6.111 CONTinue:SPECtrum:SWITching[:GMSK]..........................6.111 CONTinue:WPOWer..................................6.35 DISPlay:POWer:MSLot:CONTrol:GRID ............................6.55 DISPlay:POWer[:NORMal]:EPSK:CONTrol:GRID ........................6.123 DISPlay:POWer[:NORMal][:GMSK]:CONTrol:GRID........................6.123 DISPlay:SPECtrum:MODulation:EPSK:CONTrol:GRID ......................6.105 DISPlay:SPECtrum:MODulation[:GMSK]:CONTrol:GRID ......................6.105 DISPlay:SPECtrum:SWITching:EPSK:CONTrol:GRID ......................6.113 DISPlay:SPECtrum:SWITching[:GMSK]:CONTrol:GRID ......................6.113 FETCh:ARRay:MODulation:EVMagnitude:EPSK:AVERage? ....................
  • Page 622 List of Commands CMU-K20/21/22/23/24 Command (Signalling, alphabetical) Page FETCh:MODulation:EVMagnitude:EPSK:STATus? ........................6.85 FETCh:MODulation:MERRor:EPSK:STATus? ..........................6.97 FETCh:MODulation:OVERview:EPSK:STATus? ........................6.80 FETCh:MODulation:XPERror[:GMSK]:STATus?......................... 6.72 FETCh:MODulation[:PERRor]:EPSK:STATus?........................... 6.91 FETCh:MODulation[:PERRor][:GMSK]:STATus?........................6.65 FETCh:NPOWer:STATus? ................................6.38 FETCh:POWer:ABURst[:GMSK]:STATus? ..........................6.137 FETCh:POWer:FRAMe:STATus? ............................... 6.50 FETCh:POWer:MSLot:STATus? ..............................6.54 FETCh:POWer:PCL:STATus?..............................6.142 FETCh:POWer:SLOT:STATus? ..............................6.41 FETCh:POWer:XSLot:STATus?..............................
  • Page 623 CMU-K20/21/22/23/24 List of Commands Command (Signalling, alphabetical) Page FETCh:SUBarrays:POWer[:NORMal][:GMSK]:MPR:AVERage? ..................... 6.150 FETCh:SUBarrays:POWer[:NORMal][:GMSK]:MPR:MAXimum? .................... 6.150 FETCh:SUBarrays:POWer[:NORMal][:GMSK]:MPR:MINimum? ....................6.150 FETCh:SUBarrays:POWer[:NORMal][:GMSK]:MPR[:CURRent]?..................... 6.150 FETCh:SUBarrays:POWer[:NORMal][:GMSK][:CURRent]?...................... 6.134 FETCh:SUBarrays:SPECtrum:MODulation:EPSK?........................6.110 FETCh:SUBarrays:SPECtrum:MODulation[:GMSK]?........................ 6.110 FETCh:SUBarrays:SPECtrum:SWITching:EPSK?........................6.119 FETCh:SUBarrays:SPECtrum:SWITching[:GMSK]?......................... 6.119 FETCh:WPOWer:STATus? ................................. 6.36 FETCh[:SCALar]:MODulation:EVMagnitude:EPSK? ........................6.89 FETCh[:SCALar]:MODulation:MERRor:EPSK? ........................6.101 FETCh[:SCALar]:MODulation:OVERview:EPSK? ........................6.83 FETCh[:SCALar]:MODulation:XPERror[:GMSK]? ........................
  • Page 624 List of Commands CMU-K20/21/22/23/24 Command (Signalling, alphabetical) Page INITiate:RXQuality:BLER................................6.170 INITiate:SPECtrum:MODulation:EPSK............................6.103 INITiate:SPECtrum:MODulation[:GMSK]........................... 6.103 INITiate:SPECtrum:SWITching:EPSK ............................6.111 INITiate:SPECtrum:SWITching[:GMSK] ............................ 6.111 INITiate:WPOWer ..................................6.35 INPut[:STATe].................................... 6.203 IQIF:DEFault ....................................6.34 MCONTrol:DEFault..................................6.184 MMEMory:L3MSg:BEMPty ................................ 6.211 MMEMory:L3MSg:BWRiting ..............................6.211 MMEMory:L3MSg:CDEStination..............................6.210 MMEMory:L3MSg:SAVE................................6.211 MMEMory:RECall:CURRent ..............................
  • Page 625 CMU-K20/21/22/23/24 List of Commands Command (Signalling, alphabetical) Page READ:ARRay:MODulation:MERRor:EPSK:AVERage? ......................6.102 READ:ARRay:MODulation:MERRor:EPSK:MMAXimum? ......................6.102 READ:ARRay:MODulation:MERRor:EPSK[:CURRent]?......................6.102 READ:ARRay:MODulation:XPERror[:GMSK]:AVERage? ......................6.78 READ:ARRay:MODulation:XPERror[:GMSK]:MMAXimum? ...................... 6.78 READ:ARRay:MODulation:XPERror[:GMSK][:CURRent]? ......................6.78 READ:ARRay:MODulation[:PERRor]:EPSK:AVERage? ......................6.96 READ:ARRay:MODulation[:PERRor]:EPSK:MMAXimum? ......................6.96 READ:ARRay:MODulation[:PERRor]:EPSK[:CURRent]? ......................6.96 READ:ARRay:MODulation[:PERRor][:GMSK]:AVERage? ......................6.70 READ:ARRay:MODulation[:PERRor][:GMSK]:MMAXimum? ..................... 6.70 READ:ARRay:MODulation[:PERRor][:GMSK][:CURRent]? ......................
  • Page 626 List of Commands CMU-K20/21/22/23/24 Command (Signalling, alphabetical) Page READ:SUBarrays:POWer:MSLot:AVERage? ..........................6.61 READ:SUBarrays:POWer:MSLot:MAXimum?..........................6.61 READ:SUBarrays:POWer:MSLot:MINimum? ..........................6.61 READ:SUBarrays:POWer:MSLot[:CURRent]?..........................6.61 READ:SUBarrays:POWer:SLOT? ............................... 6.44 READ:SUBarrays:POWer:XSLot?............................... 6.49 READ:SUBarrays:POWer[:NORMal]:EPSK:AVERage? ......................6.134 READ:SUBarrays:POWer[:NORMal]:EPSK:MAXimum?......................6.134 READ:SUBarrays:POWer[:NORMal]:EPSK:MINimum? ......................6.134 READ:SUBarrays:POWer[:NORMal]:EPSK[:CURRent]?......................6.134 READ:SUBarrays:POWer[:NORMal][:GMSK]:AVERage? ......................6.134 READ:SUBarrays:POWer[:NORMal][:GMSK]:MAXimum?......................6.134 READ:SUBarrays:POWer[:NORMal][:GMSK]:MINimum? ......................6.134 READ:SUBarrays:POWer[:NORMal][:GMSK]:MPR:AVERage?....................
  • Page 627 CMU-K20/21/22/23/24 List of Commands Command (Signalling, alphabetical) Page SAMPle:ARRay:MODulation:MERRor:EPSK[:CURRent]? ....................... 6.102 SAMPle:ARRay:MODulation:XPERror[:GMSK]:AVERage? ....................... 6.78 SAMPle:ARRay:MODulation:XPERror[:GMSK]:MMAXimum? ....................6.78 SAMPle:ARRay:MODulation:XPERror[:GMSK][:CURRent]? ..................... 6.78 SAMPle:ARRay:MODulation[:PERRor]:EPSK:AVERage? ......................6.96 SAMPle:ARRay:MODulation[:PERRor]:EPSK:MMAXimum? ..................... 6.96 SAMPle:ARRay:MODulation[:PERRor]:EPSK[:CURRent]? ....................... 6.96 SAMPle:ARRay:MODulation[:PERRor][:GMSK]:AVERage? ...................... 6.70 SAMPle:ARRay:MODulation[:PERRor][:GMSK]:MMAXimum? ....................6.70 SAMPle:ARRay:MODulation[:PERRor][:GMSK][:CURRent]? ....................6.70 SAMPle:ARRay:POWer:ABURst[:GMSK]? ..........................6.140 SAMPle:ARRay:POWer:FRAMe? ..............................
  • Page 628 List of Commands CMU-K20/21/22/23/24 Command (Signalling, alphabetical) Page SAMPle:SUBarrays:POWer:MSLot:MINimum? ........................... 6.61 SAMPle:SUBarrays:POWer:MSLot[:CURRent]? ........................6.61 SAMPle:SUBarrays:POWer:SLOT? ............................6.44 SAMPle:SUBarrays:POWer:XSLot? ............................6.49 SAMPle:SUBarrays:POWer[:NORMal]:EPSK:AVERage? ....................... 6.134 SAMPle:SUBarrays:POWer[:NORMal]:EPSK:MAXimum? ....................... 6.134 SAMPle:SUBarrays:POWer[:NORMal]:EPSK:MINimum? ......................6.134 SAMPle:SUBarrays:POWer[:NORMal]:EPSK[:CURRent]? ...................... 6.134 SAMPle:SUBarrays:POWer[:NORMal][:GMSK]:AVERage? ....................6.134 SAMPle:SUBarrays:POWer[:NORMal][:GMSK]:MAXimum? ....................6.134 SAMPle:SUBarrays:POWer[:NORMal][:GMSK]:MINimum? ...................... 6.134 SAMPle:SUBarrays:POWer[:NORMal][:GMSK]:MPR:AVERage? ....................
  • Page 629 CMU-K20/21/22/23/24 List of Commands Command (Signalling, alphabetical) Page [SENSe:]CORRection:LOSS:INPut<nr>[:MAGNitude] ......................6.204 [SENSe:]CORRection:LOSS:OUTPut<nr>[:MAGNitude] ......................6.204 [SENSe:]LEVel:ATTenuation..............................6.175 [SENSe:]LEVel:DEFault ................................6.175 [SENSe:]LEVel:MAXimum................................. 6.174 [SENSe:]LEVel:MODE................................6.174 [SENSe:]MSSinfo:AMR:FRATe:DLCMode? ..........................6.209 [SENSe:]MSSinfo:AMR:FRATe:DLCMode? ..........................6.227 [SENSe:]MSSinfo:AMR:FRATe:ULCMode? ..........................6.209 [SENSe:]MSSinfo:AMR:FRATe:ULCMode? ..........................6.227 [SENSe:]MSSinfo:AMR:HRATe:DLCMode?..........................6.209 [SENSe:]MSSinfo:AMR:HRATe:DLCMode?..........................6.227 [SENSe:]MSSinfo:AMR:HRATe:ULCMode?..........................6.209 [SENSe:]MSSinfo:AMR:HRATe:ULCMode?..........................
  • Page 630 List of Commands CMU-K20/21/22/23/24 Command (Signalling, alphabetical) Page STOP:POWer:ABURst[:GMSK]..............................6.136 STOP:POWer:FRAMe ................................. 6.50 STOP:POWer:MSLot................................... 6.54 STOP:POWer:PCL ..................................6.142 STOP:POWer:SLOT..................................6.41 STOP:POWer:XSLot ................................... 6.45 STOP:POWer[:NORMal]:EPSK..............................6.120 STOP:POWer[:NORMal][:GMSK] .............................. 6.120 STOP:POWer[:NORMal][:GMSK]:MPR ............................. 6.146 STOP:RXQuality:BAVerage ..............................6.163 STOP:RXQuality:BER ................................6.154 STOP:RXQuality:BLER ................................6.170 STOP:SPECtrum:MODulation:EPSK............................
  • Page 631 CMU-K20/-K21/-K22/-K23/-K24 Contents of Chapter 7 Contents 7 Remote Control – Program Examples ............... 7.1 GSM Non Signalling Measurements....................7.1 GSM Signalling Measurements.......................7.3 Call Setup to the Mobile Phone, Simple RX/TX Measurements..........7.3 Handover..........................7.5 1115.6088.12 I-7.1...
  • Page 633 CMU-K20/-K21/-K22/-K23/-K24 GSM-MS Non Signalling Measurements 7 Remote Control – Program Examples The following program examples illustrate how to solve typical measurement tasks in the Non Signalling and in the Signalling mode. To keep the syntax as short and simple as possible, the programs were written with the aid of Winbatch, a batch job tool organizing and simplifying the transfer of commands and data between the controller and the instrument.
  • Page 634 GSM-MS Non Signalling Measurements CMU-K20/-K21/-K22/-K23/-K24 FPRINT ................Define input connector RF4 CMUGSMNS: INP:STAT RF4 Define output connector RF3 CMUGSMNS: OUTP:STAT RF3 Make sure that external attenuations are set CMUGSMNS: SENS:CORR:LOSS:INP2 0.0 to zero CMUGSMNS: SENS:CORR:LOSS:OUTP2 0.0 FPRINT ................FPRINT GENERATOR SETTINGS FPRINT ................
  • Page 635 CMU-K20/-K21/-K22/-K23/-K24 GSM Signalling Measurements GSM Signalling Measurements A GSM mobile phone is connected to the bidirectional connector RF2 as described in chapter 2 and tested. We assume that the mobile phone is capable of operating in the GSM900 band; in the example involving a GSM900/1800 handover, an appropriate dual-band mobile must be used.
  • Page 636 GSM Signalling Measurements CMU-K20/-K21/-K22/-K23/-K24 Switch IMSI request off CMUGSM: CONF:NETW:REQ:IMSI OFF Switch IMEI request off CMUGSM: CONF:NETW:REQ:IMEI OFF Switch authentication request off CMUGSM: CONF:NETW:REQ:AUTH OFF Switch handover request off CMUGSM: CONF:NETW:REQ:HAND OFF Signalling via FACCH CMUGSM: CONF:NETW:SMOD:SCH FACC Fast power change (over FACCH) CMUGSM: CONF:NETW:SMOD:PCH FAST FPRINT ................
  • Page 637 CMU-K20/-K21/-K22/-K23/-K24 GSM Signalling Measurements FPRINT ................Absolute power of TCH BS signal, used TS CMUGSM: PROC:BSS:LEV:UTIM -102;*OPC? FPRINT ................FPRINT START THE SINGLE SHOT BER (RXQ:BER) AND THE POWER/MODULATION MEASUREMENT FPRINT THE TX MEASUREMENTS ARE FASTER AND WILL BE FINISHED FIRST FPRINT WHILE THE RXQ:BER MEAS.
  • Page 638 GSM Signalling Measurements CMU-K20/-K21/-K22/-K23/-K24 ! Generate the BCCH signal and set up the call as shown in the previous section. This means that the mobile operates on the GSM900 band while the signalling procedures are carried out. ! As soon as the call is established RXQuality and other measurements can be performed in the GSM900 band.
  • Page 639 CMU-K20/-K21/-K22/-K23/-K24 Index Index Chan................ 4.104 B52 Mode ............4.174, 6.193 2.17 BA List ............ , 4.179, 6.192 Bad DUT...............4.139 Band Indicator ...........4.178, 6.195 8PSK modulation ............4.33 Bar graph (Spectrum) Due to Modulation.........4.59, 1.110 Due to Switching ...........4.60, 1.118 BCC..............4.174, 6.194 BCCH Level............4.163, 6.187 percentile ............
  • Page 640 Index CMU-K20/-K21/-K22/-K23/-K24 Channel Count..........4.103, 6.143 Discontinuous Transmission (DTX)......4.161 Channel Type Display Area (Power, NS) ..........4.16 Aux TX............4.168, 6.191 Display line..............4.15 Circuit Switched – Traffic Channel....... 4.158 Display mode.............3.6, 3.7 Class Ib Bits........... 4.143, 6.159, 6.166 Display Mode Class II Bits..........4.143, 6.159, 6.166 Modulation (NS) ............4.51 Closed loop (power control).........
  • Page 641 CMU-K20/-K21/-K22/-K23/-K24 Index from other network ..........4.163, 4.168 Individual Levels BER ..........4.142 Full Rate ..............4.170 Info .................1.32 Function group..............5.1 Info box GSM400/850/900/1800/1900-MS Non Signaling ..4.2 Power (NS) .............4.21, 4.23 GSM400/850/900/1800/1900-MS Signalling ... 4.89 Power (Sig) ..........4.105, 4.109 Spectrum..............4.59 Info Box ..............4.19, 4.32 Input level...
  • Page 642 Index CMU-K20/-K21/-K22/-K23/-K24 Power (NS) .............. 6.16 remote control ..........6.184, 6.216 Power (Sig)............6.125 MSIN ..............4.150, 6.207 Multislot NS ................4.17 Multislot class ............6.208, 6.222 Multislot Guard ............4.37, 1.57 Magnitude Error 8PSK ........... 4.46 Main Service ............4.91, 6.218 Main Timeslot ..4.104, 4.159, 4.166, 4.196, 6.190, 6.217 Receiver Quality ............
  • Page 643 CMU-K20/-K21/-K22/-K23/-K24 Index Power (NS) ............. 4.11, 4.99 Power Control...............4.195 remote control ............1.54 Power control level ............4.112 Sig ................. 4.102 Power measurement (control) P/t Multislot (control) Non Signalling............4.28 remote control ............1.54 remote control (NS)..........6.27 P/t Norm. 8PSK ............. 4.17 remote control (Sig) ..........6.147 P/t Norm.
  • Page 644 Index CMU-K20/-K21/-K22/-K23/-K24 commands ..............6.1 GPRS..............6.212 notation..............5.8 RXQuality Program examples ............ 7.1 remote control ..........6.163, 6.170 Repetition Modulation............1.66, 1.81 Power ............. 4.11, 1.55 Power (NS) .............. 4.29 Samples ...............4.118 Spectrum ............ 1.105, 1.113 Sampling rate ..............4.38 Repetition mode............3.6, 5.5 Save Requested Mobile Data ..........
  • Page 645 CMU-K20/-K21/-K22/-K23/-K24 Index Signalling............... 4.116 TCH Level BLER ............4.131 Spectrum measurement (control) Template PCL ..........4.13, 4.75, 6.3 Non Signalling ............4.61 Test mode ................3.1 remote control ......... 1.103, 1.111, 1.112 Test mode ................2.6 Speech coding ............. 4.118 Test Setup ..............6.154 Speech Decoder ..........4.180, 6.204 BER................4.140 Speech Encoder ..........
  • Page 646 Index CMU-K20/-K21/-K22/-K23/-K24 USF Block Error Rate ..........4.119 USF Duty Cycle ..........4.200, 6.220 Wideband power remote control ............1.35 Wideband Power Voice activity detection ..........4.161 Non Signalling............4.73 Signalling ..............4.92 Winbatch ................7.1 1115.6088.12 E-12...

This manual is also suitable for:

Gsm850-msGsm900-msGsm1800-msGsm1900-msCmu-k20Cmu-k21 ... Show all

Table of Contents
