Operating Range - Philips AVENT SCD535 Manual

ENGLISH
10
Note: When the parent unit is not in the charger, the battery pack gradually discharges, even when the
parent unit is switched off.
1 Place the parent unit and the baby unit in the same room to test the connection (Fig. 10).
Make sure the baby unit is at least 1 metre/3.5 feet away from the parent unit.
2 Press and hold the on/off button 3on the baby unit until the green power-on light goes
on. (Fig. 11)
,
The display lights up and the battery symbol appears on the display (Fig. 12).
,
After 2 seconds the temperature and humidity values are shown on the display (Fig. 13).
,
3 Press and hold the on/off button 3on the parent unit until the sound level lights light up
The display goes on and the battery symbol appears on the display (Fig. 15).
,
,
, The LINK light on the parent unit turns green and lights up continuously when a connection
the display (Fig. 17).
,
are shown on the display. (Fig. 18)
,
,
1 Place the baby unit at least 1 metre/3.5 feet away from your baby (Fig. 21).
2
1 metre/3.5 feet away from the baby unit to avoid acoustic feedback (Fig. 10).
For more information on the operating range, see section 'Operating range' below.

Operating range

The operating range of the baby monitor is 330 metres/1000 feet in open air. Depending on the
surroundings and other factors that may cause interference, this range may be smaller. Indoors the
operating range is up to 50 metres/150 feet.
Note: If the ECO mode is switched on, the operating range of the baby monitor is also smaller. See
section 'ECO mode' in chapter 'Menu options'.
Dry materials
Wood, plaster, cardboard, glass
(without metal, wires or lead)
Brick, plywood
Reinforced concrete
Metal grilles or bars
< 30cm/12in
< 30cm/12in
< 30cm/12in
< 1cm /0.4in
Loss of range
0-10%
5-35%
30-100%
90-100%
