- Page 1 MANUAL EA-PS 10000 4U Programmable DC Power Supplies © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
-
Page 2: Table Of Contents
3.5.2 Control locations Installation 3.5.3 Remote control via a digital interface 2.3.1 Safety procedures before installation and use 29 3.5.4 Remote control via the analog interface © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... - Page 3 Attention! The part of this document that deals with the handling of features on the control panel is only valid for devices with firmwares “KE: 3.02”, “HMI: 3.02” and “DR: 1.0.2.20” or higher. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
-
Page 4: General
Symbol for general notices Warranty EA Elektro-Automatik guarantees the functional competence of the applied technology and the stated performance param- eters. The warranty period begins with the delivery of free from defects equipment. Terms of guarantee are included in the general terms and conditions (TOS) of EA Elektro-Automatik. -
Page 5: Disposal Of Equipment
Maximum current of the device in Ampere Maximum voltage of the device in Volt („10080“ = 80 Volt) Series: 10 = Series 10000 Type identification: PS = Power Supply © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 6: Intended Usage
In order to keep the touch current below the limit defined in the safety standard, it’s ATTENTION Separate protective earth (PE) required to ground the enclosure with a separate ground line. See “2.3.5.5. Grounding must be connected. the enclosure“ © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 7: Safety
(also see “3.4. Manual operation“ and “3.4.3. Configuration via the menu“ ) © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 8: Responsibility Of The Operator
• Furthermore, anyone working with the equipment is responsible for ensuring that the device is at all times technically fit for use. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 9: Alarm Signals
Only if the current and voltage are supplied by the device as adjustable in the range of 0-100% FS, the device can be consid- ered as correctly operational. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 10: Technical Data
1.8.2 General technical data Display: Color TFT touch screen with gorilla glass, 5”, 800pt x 480pt, capacitive Controls: 2 rotary knobs with pushbutton function, 1 pushbutton © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 11: Specific Technical Data
0 - 10 V ≤0.2%, 0 - 5 V ≤0.4% Device configuration Parallel operation Up to 64 units of any power class in series 10000, with Master-Slave-Bus and Share-Bus © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... - Page 12 Dimensions (W x H x D) 19“ x 4U x 668 mm (Enclosure only, not over all) Weight 50.0 kg (110 Lb) Weight with water cooling 56.0 kg (126 Lb) © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
- Page 13 +2000 V DC +2000 V DC Article number Article number Standard 06230904 06230905 06230909 06230906 Article number Water cooling *1 At 100% Power and 100% Output voltage © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
- Page 14 Positive DC pole <-> PE +2000 V DC +2000 V DC Article number Article number Standard 06230907 06230908 Article number Water cooling *1 At 100% Power and 100% Output voltage © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
-
Page 15: Views
1.8.4 Views 1.8.4.1 Technical Drawing PS 10000 4U ≤200 V © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... - Page 16 6. Mains input terminal 7. Grounding connection screw (PE) 8. Connector (DB15 female) for isolated analog programming, monitoring and other functions 9. USB interface 10. Ethernet interface © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
- Page 17 1.8.4.4 Technical Drawing PS 10000 4U >360 V © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
- Page 18 6. Mains input terminal 7. Grounding connection screw (PE) 8. Connector (DB15 female) for isolated analog programming, monitoring and other functions 9. USB interface 10. Ethernet interface © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
- Page 19 7. Mains input terminal 8. Grounding connection screw (PE) 9. Connector (DB15 Female) for isolated analog programming, monitoring and other functions 10. USB interface 11. Ethernet interface © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
-
Page 20: Control Elements
Port for USB sticks For the connection of standard USB sticks. See section “1.9.6.5. USB port (front side)“ for more details. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 21: Construction And Function
There are digital, microprocessor controlled components (KE, DR, HMI), which can be target of firmware updates. Share & Sense Power blocks Controller (DR) ≈ ≈ Commu- Commu- nication nication PS/PSI 10000 (KE) (KE) Block diagram © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 22: Scope Of Delivery
Water cooling the environment due to exhausted heat caused by a certain power dissipation. As a side effect, this type of cooling also reduces audible noise. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 23: The Control Panel (Hmi)
Protection settings ditto 0-110% nom OVP, OCP etc., related to the physical values The lower limit for resistance set value varies. See tables in section 1.8.3 © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... - Page 24 Pushbutton function of the knobs The rotary knobs also have a pushbutton function which is used in all value adjustment to move the cursor by rotation as shown: © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
-
Page 25: Usb Port (Rear Side)
(see below) or the analog interface and can, therefore, only be used alternatively to these. However, monitoring is always available. Figure 2 - USB port © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 26: Interface Module Slot
For a PS 10000 series device, different or identical PS 10000 series models can be used as slave units. A PS 10000 device can furthermore be the slave of PSI 10000 series devices. Figure 5 - Share bus © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 27: Sense" Connector (Remote Sensing)
If remote control is in operation the Ethernet port has no priority over any other interface and can, therefore, only be used alternatively to these. However, monitoring is always available. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 28: Water Cooling
The water taps are located on the rear side of the device, also see the rear view drawing in section 1.8.4 . Details about the connection, requirements and use of the water cooling can be found in section 2.3.4 . © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 29: Installation & Commissioning
Continuous operation at the approved limit generates heat which must be removed, as well as voltage • loss which depends on cable length and heating. To compensate for these the cable cross section should be increased and the cable length reduced. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 30: Installing The Device
The required air flow would be insufficient. This wouldn’t actually apply to water cooled models, but the construction of the entire device isn’t made for operation in this position. Acceptable and unacceptable installation positions (air or water cooled, air cooled shown): Standing surface © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 31: Installing The Water Cooling
24.31 25.16 27°C 14.08 15.68 17.24 18.57 19.83 21.11 22.23 23.31 24.32 25.22 26.1 28°C 14.96 16.61 18.14 19.38 20.86 22.07 23.18 24.28 25.25 26.2 27.18 © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... - Page 32 118.3 120.2 2.3.4.4 Notes • The water flow should be started prior to powering the device, but at least prior to switching the DC terminal on © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
-
Page 33: Connection To Ac Supply
Stripping length without cable end sleeve: 18-20 mm (0.75 in) • Valid for both, the ground conductor in the AC cable and the separate PE line for enclosure grounding © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... - Page 34 (cabinet), it’s recommended to only pull the plug and dismount the bracket. Figure 10 - Mounting position of the bracket Figure 11 - Fully installed strain relief © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
- Page 35 AC supply cable. Figure 12 - Grounding point © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
-
Page 36: Connection To Dc Loads
M10 bolt on a metal rail M6 bolt on a metal rail Recommendation: ring lug with a 11 mm hole Recommendation: ring lug with a 6.5 mm hole © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... - Page 37 • 90° up or down space saving in depth • no bending radius • horizontal lead • space saving in height • • large bending radius © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
-
Page 38: Connection Of Remote Sense
Dangerous voltage on the sense terminals! The sense cover must always be installed. Figure 13 - Example for remote sensing wiring (DC terminal and Sense terminal covers left way for illustrative purposes) Allowed connection schemes: © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 39: Grounding Of The Dc Output
On the bottom side of the module are two plastic nibs which must click into the green board (PCB) so that the module is properly aligned on the rear wall of the device. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 40: Connecting The Analog Interface
Refer to “2.3.13. Initial commission“ . Only after successful checking of the device as listed may it be operated as usual. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 41: Operation And Application
= transient time to below the adjusted value for a short time. t = transient time settle the output voltage. to settle the output voltage. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 42: Current Regulation / Constant Current / Current Limiting
ARM controller, being only a little slower than other controllers inside the control circuit. Clarification: = (U ) * I © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 43: Alarm Conditions
DC output reaches the adjusted OPP limit. • This function serves to protect the connected load application so that this isn’t overloaded and possibly damaged due to an excessive power consumption. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 44: Safety Ovp
This alarm has to be acknowledged after the cause has been removed. Should the device neither be master nor slave, the Share bus cable should be removed for unimpeded operation. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 45: Manual Operation
Many settings are self-explanatory, others are not. Those will be explained on the pages following. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... - Page 46 = Levels and function as described in the table in 3.5.4.3 • Inverted = Levels and function will be inverted • Also see “3.5.4.7. Application examples“ . © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
- Page 47 Determines the condition of the DC output after leaving remote control either manually or by command: = Default, DC output will always be off after leaving remote control • • Auto = DC output will keep the last state © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
- Page 48 = Logging starts and stops with every change of state on the DC output, no matter if • caused by the user, software or a device alarm. Attention: Every next start will create a new log file. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
- Page 49 = Baud rate and node address are assigned by the bus master Fixed baud rates: kbps, kbps, kbps, kbps, kbps, kbps, kbps, kbps, 1Mbps Node Address Selection of the CANopen node address in the range 1...127 © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
- Page 50 String input box for a user-definable text which describes the Profibus slave. Max. length: 54 characters Station Name String input box for a user-definable text which describes the Profinet station name. Max. length: 200 characters © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
- Page 51 The baud rate is selectable, other serial settings can’t be changed and are defined like this: 8 data bits, 1 stop bit, parity = none Baud rates: 2400Bd, 4800Bd, 9600Bd, 19200Bd, 38400Bd, 57600Bd, 115200Bd © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
- Page 52 Furthermore, the backlight intensity can be adjusted here. Lock See “3.8. Locking the adjustment limits and user profiles“ and “3.9. Loading and saving user profiles“ © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
-
Page 53: Adjustment Limits
The actual operating mode, which is only indicated while the DC output is switched on, solely depends on the set values. For more information see section “3.2. Operating modes“. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 54: Manual Adjustment Of Set Values
The display then switches back to the main page and the set values take effect. When entering a value which would exceed the upper/lower adjustment limit it would be rejected with an appropriate message. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 55: Switching The Dc Output On Or Off
USB stick is full or removed, it will be indicated by another symbol ( ). After every manual stop or switching the DC output off the logging is stopped and the log file closed. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 56: The Quick Menu
The device offers a quick menu which allows for the quick access to often used features and modes being switched on or off in the Settings menu. It can be opened by swiping up from the bottom screen edge or tapping the bar: Overview: © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 57: The Graph
• Swiping on the three scales (Y axis) moves them up or down Tapping the menu touch area ( ) exits the graph screen anytime • © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 58: Remote Control
Programming details for the interfaces, the communication protocols etc. are to be found in the documentation “Programming Guide ModBus & SCPI“ which is supplied on the included USB stick or which is available as download from the manufacturer’s website. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... - Page 59 The timeout of the monitoring can be changed anytime via remote control; the new value would only be valid after the • current timeout has elapsed The interface monitoring doesn’t deactivate the Ethernet connection timeout (see 3.4.3.5 ), so these two timeouts can overlap • © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
-
Page 60: Remote Control Via The Analog Interface
PF and OVP being signaled at the same time, so it would require to select the alarm indication on pin 6 to at least signal PF and for pin 14 to signal OVP in any of the combinations. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... - Page 61 The resolution is the same for set values (VSEL etc.) and actual values (VMON/CMON) and is 26214 when working with the 10 V range. In the 5 V range this resolution halves. Due to tolerances, the truly achievable resolution can be slightly lower. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
- Page 62 -> REM-SB level” being set to “Normal”, it requests to switch the DC output on. So when activating remote control, the DC output will instantly switch on. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
- Page 63 The AI provides the actual values on the DC output as current and voltage monitor. These can be read using a standard multimeter or an analog input of a PLC etc. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
-
Page 64: Device Alarm Handling
Fail connectors is wired to another device while the device reporting the isn’t (yet) con- figured for master-slave operation. For details also see 3.3.7 . © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... - Page 65 Swipe with your finger up from the bottom edge of the screen or directly tap on the bottom bar: The quick menu will open. Tap on to activate the alarm sound, or on to deactivate it. Leave the quick menu. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
-
Page 66: Locking The Control Panel (Hmi)
In the group tap on Unlock limits and profiles. You will be requested to enter the 4-digit PIN. Deactivate the lock by entering the correct PIN. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 67: Loading And Saving User Profiles
Loading a user profile works the same way, but in the requester you would then tap Load under Load profile?. Alternatively, you may import the profile or export it as file to an USB stick with Import/Export. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 68: Other Applications
The same applies when building several blocks of devices, i. e. a block of power supplies and a block of elec- tronic load, to later connect then in two-quadrant operation. The blocks should be placed as close as possible to each other. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... - Page 69 Settings matrix for the units on the MS bus: BIAS Device position Termination setting(s) Master (at end) BIAS + TERM Master (central) BIAS Slave (at end) TERM Slave (central) © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
- Page 70 As long as MS mode remains activated, the initialization process of the master-slave system will be re- peated each time the master unit is powered. The initialization can also be repeated manually anytime via the Settings menu, in group “Master-Slave”. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
- Page 71 OCP alarm though the global OCP limit of the MS system was not reached. The same can occur with the OPP alarm. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
-
Page 72: Series Connection
SEMI F47 it’s delayed for at least 2 seconds or will never occur. In this case, the device wouldn’t show any reaction to the sag, nor register the occurrence in any form. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 73: Service And Maintenance
Newly implemented features may require an updated documentation (user manual and/or programming guide, as well as LabView VIs), which is often delivered only later, sometimes significantly later © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 74: Trouble-Shooting Device Problems
As an additional measure include fuses in line with the DC cables which could attenuate or even prevent damage to the device. © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... -
Page 75: Contact And Support
Telephone EA Elektro-Automatik GmbH Technical support: Switchboard: +49 2162 / 37850 Helmholtzstr. 31-37 support@elektroautomatik.com Support: +49 2162 / 378566 41747 Viersen All other issues: Germany ea1974@elektroautomatik.com © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01... - Page 76 EA Elektro-Automatik GmbH & Co. KG Helmholtzstr. 31-37 41747 Viersen Phone +49 2162 3785 - 0 Fax +49 2162 1623 - 0 ea1974@elektroautomatik.com www.elektroautomatik.com © EA Elektro-Automatik in 2022, this information is subject to change without notice 06230900_manual_ps_10000_4u_30kw_en_01...
