Summary of Contents for Elektro-Automatik EA-PUB 10010-1000 4U

  • Page 1 MANUAL EA-PUB 10000 4U Programmable bidirectional DC Power Supplies © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 2: Table Of Contents

    Packaging 3.5.3 Switching the DC output on or off 2.1.3 Storage Remote control Unpacking and visual check 3.6.1 General Installation 3.6.2 Remote control via digital interface © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 3 Attention! The part of this document that deals with the handling of features on the control panel is only valid for devices with firmwares “KE: 3.06”, “HMI: 3.04” and “DR: 1.0.2.20” or higher. © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 4 © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 5: General

    Symbol for general notices Warranty EA Elektro-Automatik guarantees the functional competence of the applied technology and the stated performance param- eters. The warranty period begins with the delivery of free from defects equipment. Terms of guarantee are included in the general terms and conditions (TOS) of EA Elektro-Automatik.
  • Page 6: Disposal Of Equipment

    Maximum current of the device in Ampere Maximum voltage of the device in Volt (“10080” = 80 V) Series: 10 = Series 10000 Type identification: PSB = Power Unit Bidirectional © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 7: Intended Usage

    Read and understand the operat- ing guide before using this device. Non-adherence of the instructions in the operating guide can result in serious injury or death. © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 8: Safety

    It’s not allowed to run the device on AC sources such as generators or UPS equipment. It must only be • connected to a power grid! © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 9: Responsibility Of The Operator

    • before starting work must have read and understood the operating manual • © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 10: Alarm Signals

    Only if the current and voltage are supplied by the device as adjustable in the range of 0-100% FS, the device can be consid- ered as correctly operational. © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 11: Technical Data

    1.8.2 General technical data Display: 6 LED with different colors Controls: 1 pushbutton © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 12: Specific Technical Data

    0 - 10 V: ≤0.2%, 0 - 5 V: ≤0.4% Device confi guration Parallel operation Up to 64 units of any power class in series 10000 start from 5 kW, with Master-Slave-Bus and Share-Bus © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 13 Dimensions (W x H x D) Enclosure: 19“ x 4U x 668 mm (26.3 in) Weight 50 kg (110 lb) Weight with water cooling 56 kg (126 lb) © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 14 +2000 V DC Article numbers Standard 01123006 01123007 01123008 01123009 01123010 Standard + Water Cooling 01543006 01543007 01543008 01543009 01543010 *1 At 100% power and 100% output voltage © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 15: Views

    1.8.4 Views 1.8.4.1 Technical drawings PUB 10000 4U ≤200 V Side view of the air-cooled version shown © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 16 6. AC input connector 7. Grounding connection screw (PE) 8. Connector (DB15 female) for isolated analog programming, monitoring and other functions 9. USB interface 10. Ethernet interface © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 17 1.8.4.4 Technical drawings PUB 10000 4U ≥360 V Side view of the air-cooled version shown © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 18 6. AC input connector 7. Grounding connection screw (PE) 8. Connector (DB15 female) for isolated analog programming, monitoring and other functions 9. USB interface 10. Ethernet interface © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 19 7. AC input connector 8. Grounding connection screw (PE) 9. Connector (DB15 female) for isolated analog programming, monitoring and other functions 10. USB interface 11. Ethernet interface © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 20: Control Elements

    For quick and easy access to the most important DC output related values when the device isn’t in master-slave mode. This port has reduced functionality compared to the rear port. Status indicators (LED) These six color LEDs show the device status. © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 21: Construction And Function

    There are digital, microprocessor controlled components (KE, DR, HMI), which can be target of firmware updates. Share & Sense Power blocks Controller (DR) ≈ ≈ Commu- Commu- nication nication PUB 10000 (KE) (KE) Block diagram © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 22: Scope Of Delivery

    As a side effect, this type of cooling also reduces audible noise. © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 23: The Control Panel (Hmi)

    LED “Error” lighting up, indicated an MSP alarm (see section «3.7 Alarms and monitoring» for more informa- tion about this alarm) which is normal for not yet initialized slave. © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 24: Usb Port (Rear Side)

    0-5 V and 0-10 V, in each case corresponding to 0-100%. Figure 4- Analog interface © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 25: Share Bus" Connector

    The termination is done via digital switches that can be activated by remote control via SCPI or ModBus command, as well as in the Settings app of EA Power Control. Figure 7 - Master slave bus ports © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 26: Ethernet Port

    The water taps are located on the rear side of the device, also see the rear view drawing in section 1.8.4 . Details about the connection, requirements and use of the water cooling can be found in section 2.3.4 . © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 27: Installation & Commissioning

    © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 28: Preparation

    Continuous operation at the approved limit generates heat which must be removed, as well as voltage • loss which depends on cable length and heating. To compensate for these the cable cross section should be increased and the cable length reduced. © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 29 When running a higher number of recovering, i. e. energy backfeeding units on the same leg of the installation, the total cur- rents per phase increases accordingly. © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 30: Installing The Device

    The unacceptable positions, as shown below, are also valid for the vertical mount of the device onto a wall (room or inside a cabinet). The required air flow would be insufficient. Acceptable and unacceptable installation positions (air or water cooled, air cooled shown): Standing surface © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 31: Connection To Water Supply (Wc Models)

    23.3 24.22 26°C 13.15 14.84 16.26 17.67 18.9 20.09 21.29 22.32 23.32 24.31 25.16 27°C 14.08 15.68 17.24 18.57 19.83 21.11 22.23 23.31 24.32 25.22 26.1 © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 32 118.3 120.2 2.3.4.4 Notes The water flow should be started prior to powering the device, but at least prior to switching the DC terminal on • © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 33: Connection To Ac Supply

    Stripping length without cable end sleeve: 18-20 mm (0.75 in) • Valid for both, the ground conductor in the AC cable and the separate PE line for enclosure grounding © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 34 AC supply cable. Figure 13 - Grounding point © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 35: Connection To Dc Loads Or Dc Sources

    M10 bolt on a metal rail M6 bolt on a metal rail Recommendation: ring lug with a 11 mm hole Recommendation: ring lug with a 6.5 mm hole © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 36: Grounding Of The Dc Terminal

    In case any DC pole is grounded, the operator of the device must reinstate the basic protection for human safety by installing appropriate external means, for instance a cover, everywhere the potential of the DC terminal is connected to. © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 37: Connection Of Remote Sensing

    Dangerous voltage on the sense connectors! The sense cover must always be installed. Figure 14 - Example for remote sensing wiring (DC terminal and Sense terminal covers left way for illustrative purposes) Allowed connection schemes: © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 38: Installation Of An Interface Module

    On the bottom side of the module are two plas- tic nibs which must click into the green board (PCB) so that the module is properly aligned on the rear wall of the device. © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 39: Connection Of The Analog Interface

    Refer to «2.3.13 Initial commission» . Only after successful checking of the device as listed may it be operated as usual. © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 40: Terms

    Setting Slow will result in a higher transient time and higher voltage drop, but less overshooting, while Fast is vice versa. Also see «3.3.7 Dynamic characteristics and stability criteria» . © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 41: Current Regulation / Constant Current / Current Limiting

    1-2% of the rated voltage (on top of the voltage setting), while the duration mainly depends on the charging state of the capacities on the DC output and also the capacity value. © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 42: Power Regulation / Constant Power / Power Limiting

    With resistance mode being activated the function generator will be unavailable and the actual power value provided by the device does not include the simulated power dissipation of Ri. © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 43: Resistance Regulation / Constant Resistance (Sink Mode)

    We recommend: 10/60/80 V models: 1000uF..4700uF 750/920/1000 V models: 22uF...100uF 200/360 V models: 100uF...470uF 1500/2000 V models: 4.7uF...22uF 500 V models: 47uF...150uF © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 44: Alarm Conditions

    This function serves to protect the connected load application (source mode) or the external source (sink mode) so it’s not overloaded and possibly damaged due to an excessive power. © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 45: Safety Ovp

    1 master and x slaves are in the system and all have identical firmware versions installed. In case the system is initialized only later on, the slave will signal SF. © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 46: Manual Operation

    DC output related parameters via the front USB port. The button can also be used to acknowledge device alarms signaled by LED “Error”. Configuration of parameters via one of the USB ports is considered as remote control and is thus described in 3.6 . © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 47: Remote Control

    OUTPut[:STATe] [SOURce:]CURRent:LIMit:HIGH? OUTPut[:STATe]? [SOURce:]CURRent:LIMit:LOW SINK:CURRent [SOURce:]CURRent:LIMit:LOW? SINK:CURRent? [SOURce:]CURRent:PROTection[:LEVel] SINK:CURRent:LIMit:HIGH [SOURce:]CURRent:PROTection[:LEVel]? SINK:CURRent:LIMit:HIGH? [SOURce:]POWer SINK:CURRent:LIMit:LOW [SOURce:]POWer? SINK:CURRent:LIMit:LOW? [SOURce:]POWer:LIMit:HIGH SINK:CURRent:PROTection[:LEVel] [SOURce:]POWer:LIMit:HIGH? SINK:CURRent:PROTection[:LEVel]? [SOURce:]POWer:PROTection[:LEVel] SINK:POWer [SOURce:]POWer:PROTection[:LEVel]? SINK:POWer? [SOURce:]RESistance SINK:POWer:LIMit:HIGH [SOURce:]RESistance? © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 48 Programming details about the communication protocols etc. are to be found in the documentation “Programming Guide ModBus & SCPI“ which is supplied on the included USB stick or is available as download from the manufacturer’s website. © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 49: Interface Monitoring

    The timeout of the monitoring can be changed anytime via remote control; the new value would only be valid after the current timeout has elapsed • The interface monitoring doesn’t deactivate the Ethernet connection timeout, so these two timeouts can overlap © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 50: Remote Control Via The Analog Interface

    PF and OVP being signaled at the same time, so it would require to select the alarm indication on pin 6 to at least signal PF and for pin 14 to signal OVP in any of the combinations. © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 51 10 V range. In the 5 V range this resolution halves. Due to tolerances, the truly achievable resolu- tion can be slightly lower. © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 52 -> REM-SB level” being set to “Normal”, it requests to switch the DC output on. So when activat- ing remote control, the DC output will instantly switch on. © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 53 Reading actual values The AI provides the DC terminal values as current and voltage monitor. These can be read using a standard multimeter or similar. © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 54 DC current is flowing in any of both directions, one of the pins will indicate with a level > 0 V. © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 55: Alarms And Monitoring

    Triggers an alarm as soon as the output or input pow- LED, analog & digi- Protection er reaches the defined threshold. The DC terminal will be 0 W...1.1*P tal interfaces switched off. © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 56 These events shall not be confused with alarms such as OT and OVP which are for device protection. User defined events can, however, if set to action “Alarm”, switch off the DC terminal and thus protect the load, like a sensitive electronic application. © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 57: Other Applications

    © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 58 (* x (* x (* PSBE x (* x (* x (* x (* (* Requires at least firmware KE 3.06 on all involved units © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 59 DC outputs to switch off and can only reinstate the on/off condition automatically after PF or OT alarms, where the reaction to the alarms is configurable, action from an operator or a remote control software may become necessary in such a situation. © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 60 OCP alarm though the global OCP limit of the MS system was not reached. The same can occur with the OPP alarm. © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 61: Series Connection

    SEMI F47 it’s delayed for at least 2 seconds or will never occur. In this case, the device wouldn’t show any reaction to the sag, nor register the occurrence in any form. © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 62: Service And Maintenance

    Newly implemented features may require an updated documentation (user manual and/or programming guide, as well as • LabVIEW VIs), which is often delivered only later, sometimes significantly later © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 63: Trouble-Shooting Device Problems

    As an additional measure include fuses in line with the DC cables which could attenuate or even prevent damage to the device. © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 64: Contact And Support

    Telephone EA Elektro-Automatik GmbH Technical support: Switchboard: +49 2162 / 37850 Helmholtzstr. 31-37 support@elektroautomatik.com Support: +49 2162 / 378566 41747 Viersen All other topics: Germany ea1974@elektroautomatik.com © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
  • Page 66 7926 Convoy Court 41747 Viersen CA, 92111, San Diego Phone: +49 (2162) 3785 - 0 Phone: +1 (858) 836 1300 Fax: +49 (2162) 16230 ea1974@elektroautomatik.com sales@elektroautomatik.com www.elektroautomatik.com www.eapowered.com © EA Elektro-Automatik in 2023, this information is subject to change without notice 01123000_manual_pub_10000_4u_30kw_en_01...
