Raven Scanner Compact Quick Start Manual

Quick Start Guide
Getting started with Raven Scanner
Claim Your FREE Product - visit Raven.com/freeproduct
1
What's in the box:
Scanner
2
Install the scanner:
2.1
Remove all protective tapes and wrapping from the inside and
outside the scanner.
2.2 If you plan to feed documents using the rear input tray (not
required), attach the rear input tray to the back slot of the scanner
as indicated. If not, only use the ADF and/or the front input tray.
2.3 Plug the small end of the power adaptor into the power jack of
your scanner. Insert the other end to an appropriate power outlet.
2.4
Press the Power button on the front panel and wait for the LED
indicator to stop flashing.
2.5 For USB connection, connect the micro-USB end of the USB cable
into the micro-USB port on your scanner. Plug the rectangle end to the
USB port at the rear side of your computer. For WiFi connection
(optional), proceed with Raven Desktop installation and follow steps
shown.
3
Installing Raven Desktop and Scanner Drivers:
3.1 Visit Raven.com/Desktop
download Raven Desktop and drivers to
your Mac or PC.
Download the user manual at
Our support team is available to answer any questions and take your feedback.
Call us at 1-800-713-9009
Rear Input Tray Replacement Pad Module
(optional)
to 3.2 Choose the Compact Scanner in the
installation wizard.
raven.com/user-manuals
or email support@raven.com
AC Power Adapter & Cable
(After 10,000 scans)
2.2
(Network Enabled)
2.1
(Optional)
2.3
3.3 Choose USB connection method to your
scanner, using the USB cable included in the
box, or Wireless to set up WiFi connection to
your scanner.
Micro USB Cable
2.4
2.5
