Ventev Terrawave Manual

2.4/5 GHz 6 dBi Wi-Fi Directional Antenna with 4 RPSMA
SPECIFICATIONS
274556
SKU:
M6060060P1D43602C
Model Number:
2.4/5 GHz
Frequency Range:
6 dBi
Gain:
60°/70°
Vertical Beamwidth:
Vertical
Polarization:
≤2.0
VSWR:
≥20dB
Isolation:
20W
Maximum Input Power:
4
# of Ports:
RPSMA Male
Connector Type:
36"
Antenna Cable:
10 x 5.6 x 1.4"
Dimensions:
1.2 lbs.
Weight:
-40°F to 158°F
Operating Temperature:
60 mph
Wind Rating:
www.ventev.com/infra
Male Connectors
Ventev's 2.4/5 GHz 6 dBi High Density Multiple-Input and
Multiple-Output (MIMO) Directional Wi-Fi Antenna is
designed to operate with any manufacturer's latest 802.11ac
Waves I & II WLAN access points. The antenna's gain and
directional beam delivers on the modern user demand for
high-capacity connectivity. Four dual-band leads ensure
exceptional performance while simplifying connection to the
access point. An articulating mount enables the antenna to
be positioned precisely where coverage is needed and
comes with mounting hardware to support mast and/or wall
mounting.
Every Ventev antenna is RoHS compliant and covered by
Ventev's two-year TerraNet warranty program.
For more information or to purchase, contact Ventev:
800.851.4965 or sales@ventev.com.
RADIATION PATTERNS
