Measurlogic DTS 310 Quick Start Manual

Kwh meter with pulse output
Hide thumbs Also See for DTS 310:
1
2
3
4

Advertisement

Table of Contents

DTS 310 kWh meter with pulse output
This Quick Start Guide is designed to familiarize the user with the connection and configuration
of the DTS 310 DIN rail mounted single / 3 phase power & energy meter with kWh pulse output.
DTS 310 Model #
DTS 310-34-NN-P-4
DTS 310-36-NN-P-3
DTS 310-36-NN-P-6
If you do not see your specific meter model number above please contact
Measurlogic Inc. at 303-805-5252 or info@measurlogic.com.
©Measurlogic
MQ0012-22A
Applicable DTS 310 Models
Measurlogic Part #
D310-0056
D310-0136
D310-0180
For more information please use the DTS 310
installation guide
https://www.measurlogic.com/product/dts-310/
Page 1 of 4
•
208V-480V 3ph 3 or 4 wire
•
333mV / Rogowski CTs
•
Self-powered
•
kWh pulse output
•
208V-600V 3ph 3 or 4 wire
•
333mV / Rogowski CTs
•
24Vdc auxiliary powered
•
kWh pulse output
•
208V-600V 3ph 4 wire
•
333mV / Rogowski CTs
•
Self-powered
•
kWh pulse output
ATTENTION
Description
7268 S. Tucson Way, Centennial CO 80112
Tel: 877-777-6567 Fax: 425-799-4780
e-mail: info@measurlogic.com
web: www.measurlogic.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DTS 310 and is the answer not in the manual?

Questions and answers

Related Manuals for Measurlogic DTS 310

Summary of Contents for Measurlogic DTS 310

  • Page 1 DTS 310 kWh meter with pulse output This Quick Start Guide is designed to familiarize the user with the connection and configuration of the DTS 310 DIN rail mounted single / 3 phase power & energy meter with kWh pulse output. Applicable DTS 310 Models...
  • Page 2 The DTS 310 operates normally when power is applied to Phase A, Phase B and/or Neutral depending on model number so no additional auxiliary power supply is needed. To provide added flexibility to the DTS 310 meter it can be powered from a DC auxiliary supply (model dependant) in the following ranges.
  • Page 3 Wiring the Digital Pulse Output When ordered as an kWh energy pulse meter, the DTS 310 has a single digital output that functions as a pulse corresponding to measured kWh. Digital Inputs (Marked 1, 2) • Unused – do not connect.
  • Page 4 Rogowski Coil 70mV per 1000A @ 60Hz Used at nominal 800A The Maximum Current for this Rogowski Coil is 5000A 7268 S. Tucson Way, Centennial CO 80112 ©Measurlogic Page 4 of 4 Tel: 877-777-6567 Fax: 425-799-4780 MQ0012-22A e-mail: info@measurlogic.com web: www.measurlogic.com...
