WATCH BBQ ASSEMBLY
REGISTER THE BBQ FOR
ON VIDEO HERE:
EXTENDED WARRANTY:
MANUAL
Installation, use, maintenance and safety
FCC-G-22320-20 / BG06-200A
!
OUTDOOR USE ONLY
READ THE MANUAL, FOLLOW THE
ASSEMBLY INSTRUCTIONS STEP BY
STEP. GET TO KNOW YOUR GRILL
AND THE SAFETY INSTRUCTIONS
BEFORE USING THE APPLIANCE!
Advertisement
Table of Contents
Related Manuals for FCC BBQ TITAN 2.0
Summary of Contents for FCC BBQ TITAN 2.0
- Page 1 WATCH BBQ ASSEMBLY REGISTER THE BBQ FOR ON VIDEO HERE: EXTENDED WARRANTY: MANUAL Installation, use, maintenance and safety FCC-G-22320-20 / BG06-200A OUTDOOR USE ONLY READ THE MANUAL, FOLLOW THE ASSEMBLY INSTRUCTIONS STEP BY STEP. GET TO KNOW YOUR GRILL AND THE SAFETY INSTRUCTIONS BEFORE USING THE APPLIANCE!
-
Page 2: Table Of Contents
Contents Warnings ............................3 Technical Data ..........................4 Read before assembly ......................5 Inside the box ..........................6 Exploded Drawing with parts list ..................7 Hardware ............................7 Assembly instructions ......................8 Connecting gas ........................16 Gas leak test - To be done before using the grill .............17 Last check ............................18 Lighting instructions ........................19 Maintenance ..........................20... -
Page 3: Warnings
WARNINGS! WARNINGS! ● ACCESSIBLE PARTS OF THE GRILL BECOME VERY HOT DURING USE. KEEP CHILDREN AND OTHERS WHO NEED SUPERVISION AT A SAFE DISTANCE. ● THE GRILL IS INTENDED FOR OUTDOOR USE ONLY IN WELL- VENTILATED AREAS. ● LEAK TESTS (SEE PAGE ) MUST ALWAYS BE CARRIED OUT BEFORE THE GRILL IS USED AND WHEN REPLACING THE GAS CONTAINER. -
Page 4: Technical Data
Technical Data Tekniske data Total Heat input: 4.5 kW (2.25kW x 2 burners) Gas consumption: 327 gram/hour Gascylinder (not included): Use standard cylinder approved for use in the Nordic Region. Even though butane and propane gas can be used, we recommend propane for use in the Nordic Region. -
Page 5: Read Before Assembly
Transport damage to parts, varnish or enamel must be reported to the dealer or FCC BBQ before mounting and using the grill. If damage is reported after, there is a possibility that damage may have occurred during assembly. -
Page 6: Inside The Box
Inside the box CODE DESCRIPTION FIREBOX ASSY BACK HANDLE FOR CART WITH BELT FRONT HANDLE FOR CART CART HANDLE WHEEL SUPPORT WHEEL CODE DESCRIPTION FIGURE M6x10 SCREW SCREW FOR WHEELS LOCK SCREW FOR CART LOCK STOPPLE M6x3 STEPS SCREW M6x12 STEPS SCREW... -
Page 7: Exploded Drawing With Parts List
Exploded drawing and parts list CODE DESCRIPTION CODE DESCRIPTION KNOB THERMOMETER OIL DRIP PAN SUPPORT THERMOMETER BASE OIL DRIP PAN STOPPER CAST IRON COOKING GRATE STOPPLE LEFT FIRE TAMPER STOPPLE RIGHT LEFT BURNER ASSY BACK SUPPORT FOR CART RIGHT BURNER ASSY FRONT SUPPORT FOR CART FIRE GUIDE GROOVE STOVE BODY SUPPORT ASSY... -
Page 8: Assembly Instructions
Assembly Fix the supporting cart tube (2) and cart handle assembly (3) with M6*10 screws (A) Then,fix screw for wheels lock on (B) wheel support (4) and wheels assembly (5) - Page 9 Assembly Fix the supporting cart and cart handle withe the screw for cart lock (C), then seal the hole with the stopple (D). Take out the accessories from the stove body, the turn the foam from the package upside down and place the stove bodydownwards on the foam. fccbbq.com...
- Page 10 Assembly Install the assembled frame on the stove body (1) then tighten it with M6x3 screw (E)
- Page 11 Assembly Place the installed product upright and place it on a leveled ground Carefully step on the handle with your foot to keep it still and lift the right side table and put the BBQ upright. fccbbq.com...
- Page 12 Assembly Stand the BBQ and make sure that the wheel support is set into the slot. Lift the left and the right side table lightly.and fix the M6x12 screw (F) to the screw hole.
- Page 13 Assembly Product fully assembled Turn down the left and right side table product unfolded and ready to be used. fccbbq.com...
- Page 14 Assembly When folding the side table, pull the left side out, then lift up the side table. Step on the handle and lift up the right side table and put the bbq down slowly.
- Page 15 The Flying Culinary Circus Turn down the right side table for the frame to be automatically locked. Now the bbq is fully folded. Product folded and standing. When unfolding , place the BBQ on a level surface and step on the handle. Pull the right side table out to unlock the side table, then follow step 8.
-
Page 16: Connecting Gas
Connecting gas FOLLOW THESE INSTRUCTIONS CAREFULLY TO AVOID SERIOUS DAMAGE TO YOUR BBQ AND CAUSE PERSONAL INJURY. HOSE • Connect the gas hose to the gas inlet on the grill. Tighten well. • Install the regulator and hose. Follow the installation instructions that came with the controller set. -
Page 17: Gas Leak Test - To Be Done Before Using The Grill
YOUR BARBECUE. 7. If detected leakage cannot be rectified, do not attempt to cure leakage but consult your dealer or FCC BBQ Products support at support@fccbbq.com for help in solving the problem. ● LEAK TEST MUST BE DONE REGULARLY AND EVERY TIME THE GAS CONTAINER, REGULATOR OR HOSE IS REPLACED. -
Page 18: Last Check
Last Check PLACEMENT OF THE BBQ • Ensure that the BBQ is placed at least 150cm in all directions from house walls, trees, plants and other flammable materials or liquids when in use. • Do not place the BBQ under a roof or overhang. •... -
Page 19: Lighting Instructions
Lighting Instructions LIGHTING INSTRUCTIONS Open the lid. The lid must always be open when the grill is lit. Check that all controls are in the "OFF" position. Open valve control on gas container. Push and turn the control knob slowly to the left to ”MAX”... -
Page 20: Maintenance
Maintenance KEEP THE FIREBOX, FLAME TAMERS, COOKING GRATE AND ACCESSORIES CLEAN TO AVOID GREASE FIRES. IF A GREASE FIRE OCCUR MAINTENANCE OF THE BARBECUE In case of grease fire, if possible close the gas • Check regularly that the burners are supply on the regulator / barbecue and burning correctly. - Page 21 Maintenance layer of acid-free oil once or twice a year. CLEANING For barbecues that are placed in coastal All cleaning and maintenance must be areas, we recommend that you treat the grill performed when the barbecue is cold. Make more often. sure that the gas upply is switched OFF and the regulator is disconnected from the gas COOKING GRATE OG FLAME TAMERS...
-
Page 22: Advice, Tips And Safety
• We recommend the use of FCC BBQ original covers for the best possible protection against rain, pollen and pollution. Remember that the grill must be completely dry and cold before applying the coating. -
Page 23: Troubleshooting
Troubleshooting PROBLEM POSSIBLE CAUSE SOLUTION Gas cylinder is empty Replace gas cylinder Damaged regulator Check/replace the regulator Burner is blocked Clean the burner Gas supply is blocked Clean gas ventury or hose BURNER WILL NOT LIGHT Electrode is broken or dirty Clean the electrode Ignition knob is broken Contact your dealer... -
Page 24: Consumer Contact
Consumer Contact This product is covered by a warranty in accordance with consumer legislation. It has undergone strict quality controls and testing at the factory. If there are any parts missing or the product has been damaged, please contact your dealer or the consumer contact below for help. In the event of damage to the product, we ask for pictures of the damage and damage to the product’s packaging is attached to the complaint.
