Summary of Contents for Iceco JP60P
- Page 1 JP60P official@icecofreezer.com Any questions please contact us: official@icecofreezer.com...
-
Page 3: Table Of Contents
Catalogue - - - - - - - - - - - - - - - - - Supply Details - - - - - - - - - - - - - - - - - - - - - Operation - - - - - - - - Cleaning And Maintenance... -
Page 4: Supply Details
Supply Details JP60P refrigerator x1 Basket x1 DC CONNECTION 80W AC ADAPTER CABLE x1 (FOR HOME USE) MODEL JP60P Series External dimensions 28.9*19.3*18.8(inch) (LxWxH) 735 x 490 x 477(mm) Net weight 51.9lbs/23.5kg Installed power Supply voltage DC 12V/24V Supply current 7.0A/3.5A... -
Page 5: Operation
Operation (Using in Vehicles) Power ON / OFF Button Function Button (MAX mode & ECO mode) Temperature Down Button (Changing setting temperature down) Temperature UP Button (change setting temperature up) - Page 6 2.1 MAX & MIN Mode With power on (long press A)→ press B (MAX/ECO light turns on) Tip: Press the C or D button to adjust the temperature according to your needs. In order to save energy, the compressor will stop running automatically after reaching the setting temperature, and restart again when the inside temperature goes up...
- Page 7 2.2 Switch Between °C to °F In the standby mode, long press B and D at 3S, → press C or D to switch °C or °F. TIP: When the temperature is adjusted, the screen will show the temperature inside the refrigerator.
- Page 8 2.3 Triple Battery Protection Operation In the standby status(connecting the power without pressing A), long press A and B at the same time for 3S to enter the battery protection setting menu. Press D and C to adjust the level. Display : “- - -”...
-
Page 9: Cleaning And Maintenance
Cleaning And Maintenance 3.1 Cleaning Cleaning the freezer with a wet cloth and warm water mixed with gentle non-abrasive detergents. 3.2 Maintenance Don't forget to power off and disconnect the plug before cleaing the unit. Don't use pointed objects or abrasive detergents. -
Page 10: Error Codes & Solutions
Error Codes & Solutions Error Code Battery protection cut-out ※ The voltage can not reach the cut-out value, the battery protection is activated. Fan over-current cut-out ※ The fan overloads with more than 1 A current. Motor start error ※ The motor of compressor is blocked or the pressure difference in the refrigeration system is too high. - Page 11 Solutions 1. If error codes appears on the screen If error codes appear when the fridge is powered by 12v source, plz confirm whether the current voltage is stable. Because the voltage of the car battery is unstable during driving, which will activate the battery protection function and error codes will display.
-
Page 12: Warranty & Return Policy
Warranty & Return Policy 30-day money back guaranty upon receiving goods. 5 year warranty compressor. 1 year warranty for refrigerator accessories. For returns or exchanges, please fill out the following return and exchange registration form in the package as a proof of return. All materials must be returned in the original condition and packaging. -
Page 13: Troubleshooting (Q & A)
ICECO refrigerators can operate normally at an ambient temperature of 55 ℃(131 ℉). Waterproof ICECO refrigerators can be used in light rain, but please be careful not to put water into the vent, and do not place it on the wet ground. - Page 14 2. Why did it change back to the original temperature after setting the temperature? Because when setting the temperature, the refrigerator will display the original temperature. It takes time to reach the setting temperature. 3. What should I do if the refrigerator is upside down when it is delivered? To ensure the maximum performance of the refrigerator, we suggest to allow the refrigerator...
- Page 15 4. What is the function of triple battery protection? How do they work? 3-stage battery protection helps you prevent dead car battery or the refrigerator drain your power supply. VOLTAGE DISPLAY PROTECTION OFF(V) IN(V) OFF(V) IN(V) POSITION 10.9 21.3 22.6 MIDDLE 10.4 11.7...
- Page 16 Because of the structure of the refrigerator, the temperature will be displayed differently when you test in the different point. ICECO measured the inside temperature in the center of the box and it would closer to the temperature you see in the display.
- Page 17 The temperature of different positions is different. where the temperature is measured. The temperature of upper, middle and lower of the refrigerator are different. Under normal circumstances, the bottom of the refrigerator and the place near the wall of the refrigerator are closer to the setting temperature.
-
Page 18: Safety Instructions
9. What is the specification of the fuse of the refrigerator? The supply line is protected by a 15A fuse located in the refrigerator. Safety Instruction SAFETY INSTRUCTIONS Please read the user manual and safety instructions carefully before using the appliance. - Page 19 Do not use the refrigerator in uncovered, ！ outdoor areas exposed to the elements. Do not use this appliance near direct heat ！ sources, for example, a cooker, radiator or exposing it to direct sunlight. Do not place ice or liquids which are not ！...
- Page 20 WARNING! Keep ventilation openings, in the ！ appliance enclosure or in the built-in structure, clear of obstruction. Do not use mechanical devices or other means to accelerate the defrosting ！ process, other than those recommended by the manufacturer. ！ Do not damage the refrigerant circuit. Do not use electrical appliances inside the food storage compartments of the ！...
- Page 21 Do not touch the compressor or the ！ con-denser. They are hot. When positioning the appliance, ensure ！ the supply cord is not trapped or damaged. Do not locate multiple portable ！ socket-outlets or portable power supplies at the rear of the appliance. Further information is provided on the technical data label inside the product.
- Page 22 3. This appliance is intended to be used in household and similar applications such as staff kitchen areas in shops, offices and other working environments; farm houses and by clients in hotels, motels and other residential type environments; bed and breakfast type environments; catering and similar non-retail applications.
- Page 24 Cooler Than A Cooler...
