HOMCOM A90-286V70 User Manual page 11

Do not lubricate more than what you need to. Remember: regular and reasonable lubrica-
tion is to improve the lifespan of your treadmill.
Whether it is necessary to lubricate, make sure the machine is
switched off and unplug the electricity. Lift the running belt, observe
if there are any silicon remaining on the running board which is
under therunning belt. If it is dry, then you need to apply the lubricant.
a) The step to lubricate the running board is as follows: (see the above figure)
b) Stop the running belt and fold the treadmill.
c) Turn over the running belt at the back of the mainframe. Insert the lubricant pot as deep
as possible into the middle of the running belt. Apply the lubricant onto the inner side of the
running belt. Lubricate both sides of the running belt.
•
ALIGN AND TIGHTEN THE BELT OF THE TREADMILL
•
ALIGN THE BELT: Due to its use, the belt can move off center. If
the belt has moved to the left, start treadmill, and increase the
speed to 3MPH. Use the 5mm Wrench to turn the fixed left bolt
clockwise or turn the fixed right bolt counterclockwise. Do not tight-
en the belt too much in order to be able to walk. Repeat this proce-
dure until the belt is properly aligned.
If deviate to the left, then adjust the screw on the
left side clockwise or the screw on the right side
anticlockwise.
If deviate to the right, then adjust the screw on the
right side clockwise or the screw on the left side
anticlockwise.
11
