Amart Furniture VALERIE 66709 Assembly Instruction Manual

2 seater

Download this manual

Imported by Amart Furniture Pty Ltd,Qld, Brisbane Australia.

For any assistance with assembly or for missing parts please

phone Amart Furniture, Customer Service Free Call

1800 351 084

ASSEMBLY INSTRUCTION

VALERIE 2 SEATER

ITEM CODE 66709

Imported by Amart Pty Ltd, Qld, Brisbane Australia.

For any assistance with assembly or for missing parts please phone

Amart furniture, Customer Service Free call 1800 351 084

66709

Need help?

Do you have a question about the VALERIE 66709 and is the answer not in the manual?

Page 1 Imported by Amart Pty Ltd, Qld, Brisbane Australia. For any assistance with assembly or for missing parts please phone Amart furniture, Customer Service Free call 1800 351 084 Imported by Amart Furniture Pty Ltd,Qld, Brisbane Australia. For any assistance with assembly or for missing parts please...
Page 2: Pre-Assembly Preparation
PRE-ASSEMBLY PREPARATION Before you start: 1. Choose a clean, level, spacious assembly area. Avoid hard surfaces that may damage the product 2. Take care when lifting. Product should be assembled as near as possible to the point of use 3. Ensure that you have all required contents for complete assembly 4.
Page 3: Parts List
PARTS LIST A.1PC D.1PC B.2PCS C.4PCS E.1PC(M5*100) F.8PCS(M8) G.8PCS(M8*19) H.8PCS(M8*30) Seat Backrest Middle Leg Allen Key Flat Washer Spring Washer Bolt 66709...
Page 4 STEP 1 Attach leg(C) to base frame(A) ,using bolt(H) with flat washer(G) and spring washer(F),then fasten by allen key(E). Attach middle leg (D) by fastening to thread in centre of base. With 2 people carefully turn over STEP 2 66709...
Page 5 STEP 3 Lift Backrest Frame into upright position. Place the backrest(B) on the seat(A) and secure STEP 4 with Hook and Loop Tape. 66709...
Page 6 ASSEMBLY IS COMPLETE 66709...
