105cm
Imported by Amart Furniture Pty Ltd, Qld, Brisbane Australia.
For any assistance with assembly or for missing parts please phone
Amart Furniture, Customer Service Free call 1800 351 084
ASSEMBLY INSTRUCTION
HERCULES 3 SEATER
ITEM CODE 66097
Imported by Amart Furniture Pty Ltd, Qld, Brisbane Australia.
For any assistance with assembly or for missing parts please phone
Amart Furniture, Customer Service Free call 1800 351 084
218cm
Depth: 98cm
1
66097
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Amart Furniture HERCULES 66097
Summary of Contents for Amart Furniture HERCULES 66097
- Page 1 HERCULES 3 SEATER ITEM CODE 66097 Imported by Amart Furniture Pty Ltd, Qld, Brisbane Australia. For any assistance with assembly or for missing parts please phone Amart Furniture, Customer Service Free call 1800 351 084 218cm 105cm Depth: 98cm Imported by Amart Furniture Pty Ltd, Qld, Brisbane Australia. For any assistance with assembly or for missing parts please phone Amart Furniture, Customer Service Free call 1800 351 084 66097...
- Page 2 PRE‐ASSEMBLY PREPARATION Before you start: Choose a clean, level, spacious assembly area. Avoid hard surfaces that may damage the product Take care when lifting. Product should be assembled as near as possible to the point of use Ensure that you have all required contents for complete assembly Always read the assembly instructions carefully before beginning assembly.
- Page 3 Step1: Keep back rest in upright position, then slide receivers into steel mechanism posts at the seat of furniture, and press both sides of the back firmly into place to ensure fully locked. Receiver at bottom of back rest Mechanism post at rear of seat slide receiver into post Step2: Connect the cords “A” and “B” on both ends of 3‐seater to connect power for recliners. One cord comes from the seater back rest and the other from the seater seat. 66097...
- Page 4 Step3: Unravel the cord ‘C’ with a power plug on the end of it. The cord is from the middle back rest and can then be plugged into a wall socket to connect power for charge station on the console. Cord ‘C ’of charge station plugged into wall socket Step4: Plug the cord ‘D’ with a power plug on the end of it, into socket at back panel of arm. Cord ‘C ’of charge station Cord ‘D ’of reading light plugged into wall socket plugged into wall socket 66097...
- Page 5 Step5: Plug electric cord into socket at back panel of arm. Cord ‘C ’of charge station Cord ‘D ’of reading light electric cord plugged into wall socket plugged into wall socket ASSEMBLY IS COMPLETE SAFETY NOTE: PLEASE ENSURE THAT ALL ELECTRICAL CORDS AND CABLES ARE CLEAR OF THE FRAME AND MECHANISM. A FAILURE TO DO SO MAY SEVER YOUR POWER CORD RESULTING IN SERIOUS INJURY OR DEATH. 66097...
- Page 6 Instruction On Wireless Charging Point At Charge Station Of Drop‐ Down Console • Only one cell phone can be charged at a time. • Here are the model numbers of applicable cell phone. Wireless Charging Point 66097...
- Page 7 READ THESE INSTRUCTIONS THOROUGHLY BEFORE USE: DANGER: TO REDUCE THE RISK OF ELECTRIC SHOCK: Always unplug from electric outlet before cleaning. WARNING: RISK OF INJURY Keep children away from extended footrest and any moving parts. CAUTION: Do not allow children to play on this electric recliner or operate the powered mechanism.
- Page 8 66097...
