83cm
Imported by Amart Furniture Pty Ltd, Qld, Brisbane Australia.
For any assistance with assembly or for missing parts please phone
Amart Furniture, Customer Service Free call 1800 351 084
ASSEMBLY INSTRUCTION
GRANDVUE 3 SEATER
ITEM CODE 66707
Imported by Amart Furniture Pty Ltd, Qld, Brisbane Australia.
For any assistance with assembly or for missing parts please phone
Amart Furniture, Customer Service Free call 1800 351 084
261cm
Depth: 99cm
1
66707
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Amart Furniture GRANDVUE 66707
Summary of Contents for Amart Furniture GRANDVUE 66707
- Page 1 ASSEMBLY INSTRUCTION GRANDVUE 3 SEATER ITEM CODE 66707 Imported by Amart Furniture Pty Ltd, Qld, Brisbane Australia. For any assistance with assembly or for missing parts please phone Amart Furniture, Customer Service Free call 1800 351 084 261cm 83cm Depth: 99cm Imported by Amart Furniture Pty Ltd, Qld, Brisbane Australia. For any assistance with assembly or for missing parts please phone Amart Furniture, Customer Service Free call 1800 351 084 66707...
-
Page 2: Pre-Assembly Preparation
PRE‐ASSEMBLY PREPARATION Before you start: Choose a clean, level, spacious assembly area. Avoid hard surfaces that may damage the product Take care when lifting. Product should be assembled as near as possible to the point of use Ensure that you have all required contents for complete assembly Always read the assembly instructions carefully before beginning assembly. - Page 3 STEP 1: Locate package of sofa legs and package of table lid that are placed into the zipper pocket underneath. With 2 people carefully turn onto back on piece of cardboard or carpet to protect covering flat washer Ȼ10*1.5 hexagon wrench 17mm hexagon nut M10 spring washer Ȼ10 4pcs 4pcs 1pcs 4pcs side leg middle leg table lid 4pcs 2pcs 1pcs STEP 2: Make the screw of side leg go into hole at corner of bottom frame, then place flat washer, spring washer and hexagon nut on the screw in turn, finally use hexagon wrench to fasten hexagon nut tightly. flat washer leg screw clockwise turning of wrench for tighten of nuts 66707...
- Page 4 STEP 3: Screw two middle legs into holes in the central area of the bottom. clockwise turning for tighten of middle leg with screw STEP 4: Take out the bracket of arm table with fittings from separate package dispatched together with every piece of sofa. a. 3*Bolt M6X20 triangular end for assembly at bottom of sofa b. 3*Bolt M6X50 fanned end for assembly of table lid c. 1*Allen Key M5 66707...
- Page 5 STEP 5: Use Allen key to fix table lid onto fanned end of bracket with three bolts M6X20. clockwise turning of Allen key for tighten of bolts STEP 6: Use Allen key to fix the bracket to timber block at bottom of sofa with three bolts M6X50. Note: The timber block has been fitted to both the left and right side so that the table may be attached to either side, as required. clockwise turning of Allen key for tighten of bolts 66707...
- Page 6 ASSEMBLY IS COMPLETE 66707...
- Page 7 66707...
