Upgrade Firmware - Mega System Tech iCAMView iCV-01a User Manual

WARNING:
Do not lose this password. If the password is lost, you can not access the device
to make changes.
To remove the password, you must first enter a valid "Input Device Password",
go to "Device Password" and delete the entries, click "OK".
ii. Management Protocol
The administrator can determine the parameter settings when providing access
via HTTP (web) to iCAMView. For security reasons, the administrator can
choose to use either an open or advanced port setting to control these access.
The default values are set to port number 80 for HTTP.
Once the HTTP port number is set to another port (other than 80), the full IP
Address must be entered in order to access the Website.
For example:
If a value of 61 is set as the HTTP port number, then http://192.168.0.177:61
must be entered as the web address in order to access iCAMView website.
Uncheck to disable this function.

2.4 Upgrade Firmware

iCAMView Utility offers a convenient method to upgrade iCAMView firmware.
1. Click "Upgrade Firmware" to bring up the Wizard.
iCAMView user manual
Chapter 4: Using iCAMView Utility to Setup IP & Update Firmware
-17-
