ASSEMBLY INSTRUCTIONS
ASSEMBLY INSTRUCTIONS
MODEL 50-LD01CHSHLF
SUPPLIER CODE: JNFF
Essential Book Case, Cherry
CUSTOMER SERVICE
For fastest service on claims, requests for replacment parts,
or questions, please visit our website at:
www.comfortproducts.net/support
- e
m
l i a
c :
s u
o t
m
e
s r
r e
i v
e c
@
o c
m
f
r o
p t
o r
d
c u
s t
n .
t e
Keep your sales receipt as documentation of your ownership.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Onespace 50-LD01CHSHLF
Summary of Contents for Onespace 50-LD01CHSHLF
- Page 1 ™ OneSpace is a Trademark of Comfort Products, Inc. ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS MODEL 50-LD01CHSHLF SUPPLIER CODE: JNFF Essential Book Case, Cherry CUSTOMER SERVICE For fastest service on claims, requests for replacment parts, or questions, please visit our website at: www.comfortproducts.net/support...
- Page 2 Overview...
-
Page 3: Parts List
Parts List ITEM DESCRIPTION STOCK# 51-LD01CHSHLFA Front Trim 51-LD01CHSHLFB Left Wall 51-LD01CHSHLFC Right Wall 51-LD01CHSHLFD Back Trim 51-LD01CHSHLFE Bracing Shelf 51-LD01CHSHLFF Bottom Shelf 51-LD01CHSHLFG Bottom Trim 51-LD01CHSHLFH Back Panel (x5) 51-LD01CHSHLFI Shelf (x3) 51-LD01CHSHLFJ... -
Page 4: Hardware Kit
HARDWARE KIT 51-LD01CHSHLFHA ITEM# DESCRIPTION Calm Bolt Cam Lock Dowel Feet Tacs Backing Tape... - Page 5 STEP Turn nine Cam Bolts (1) into the Left Wall and Right Wall each (C and D). Insert six Pegs (3) into each wall. Insert Feet Tacs (5) into the bottom of each wall.
- Page 6 STEP Inset four Dowels (3) into the ends of the Top, Bottom Shelf, and Bracing Shelf (A, G, F). Turn four Cam Bolts (1) into the Top (A) and two Cam Bolts into the Bottom Shelf (G).
- Page 7 STEP Push two Cam Locks (2) into the Front Trim, Back Trim, and Bottom Trim (B, E, and H). Place the Front and Back Trim (B and E) onto the Cam Bolts onto the Top (A). Place the Bottom Trim (H) onto the Bottom Shelf (G). Tighten cams by turning the Cam Lock 180 degrees using a screw driver.
- Page 8 STEP Push Cam Locks (2) into one end of the Top, Bracing Shelf, and Bottom Shelf each, and into the attached Trim Pieces as shown. Then place onto the Cam Bolts in the Right Wall (D) as shown, and tighten. CAUTION: Do not overtighten cams.
- Page 9 STEP Insert the Back Panels (I) into the provided slots, as shown.
- Page 10 STEP Push Cam Locks (2) into the remaining holes as shown, then set the Left Wall (C) onto the shelf and tighten the Cam Locks. Next, apply the four strips of Backing Tape (5) where the Back Panels meet, to secure them together.
- Page 11 STEP Mount the Drawer Sides (J and I) onto the Drawer Front (G) by first inserting two Cam Locks (3) each, and then sliding the Drawer Sides onto the Cam Bolts on the Drawer Front.
- Page 13 FINISHED...
- Page 14 United States. All warranties are limited to the original purchaser for normal use. The weight capacity is defined as 44 pounds for the desktop and 44 lbs for each shelf. For claims or questions concerning this warranty, please visit: www.comfortproducts.net or email us at: customerservice@comfortproducts.net MODEL: # 50-LD01CHSHLF Comfort Products, Inc. 122 Gayoso Avenue Memphis, TN 38103 www.comfortproducts.net...
