OneSpace is a Trademark of Comfort Products, Inc.
ASSEMBLY INSTRUCTIONS
MODEL 50-LD01ESHSHLF
SUPPLIER CODE: JNFF
Essential Book Case, Espresso
CUSTOMER SERVICE
For fastest service on claims, requests for replacment parts,
or questions, please visit our website at:
www.comfortproducts.net/support
- e
m
l i a
c :
s u
o t
m
e
s r
r e
i v
e c
@
o c
m
f
r o
p t
o r
d
c u
s t
n .
t e
Keep your sales receipt as documentation of your ownership.
Advertisement
Related Manuals for Onespace 50-LD01ESHSHLF
Summary of Contents for Onespace 50-LD01ESHSHLF
- Page 1 ™ OneSpace is a Trademark of Comfort Products, Inc. ASSEMBLY INSTRUCTIONS MODEL 50-LD01ESHSHLF SUPPLIER CODE: JNFF Essential Book Case, Espresso CUSTOMER SERVICE For fastest service on claims, requests for replacment parts, or questions, please visit our website at: www.comfortproducts.net/support l i a...
- Page 2 Overview...
-
Page 3: Parts List
Parts List ITEM DESCRIPTION STOCK# 51-LD01ESSHLFA Front Trim 51-LD01ESSHLFB Left Wall 51-LD01ESSHLFC Right Wall 51-LD01ESSHLFD Back Trim 51-LD01ESSHLFE Bracing Shelf 51-LD01ESSHLFF Bottom Shelf 51-LD01ESSHLFG Bottom Trim 51-LD01ESSHLFH Back Panel (x5) 51-LD01ESSHLFI Shelf (x3) 51-LD01ESSHLFJ... -
Page 4: Hardware Kit
HARDWARE KIT 51-LD01ESSHLFHA ITEM# DESCRIPTION Calm Bolt Cam Lock Dowel Feet Tacs Backing Tape... - Page 5 STEP Turn nine Cam Bolts (1) into the Left Wall and Right Wall each (C and D). Insert six Pegs (3) into each wall. Insert Feet Tacs (5) into the bottom of each wall.
- Page 6 STEP Inset four Dowels (3) into the ends of the Top, Bottom Shelf, and Bracing Shelf (A, G, F). Turn four Cam Bolts (1) into the Top (A) and two Cam Bolts into the Bottom Shelf (G).
- Page 7 STEP Push two Cam Locks (2) into the Front Trim, Back Trim, and Bottom Trim (B, E, and H). Place the Front and Back Trim (B and E) onto the Cam Bolts onto the Top (A). Place the Bottom Trim (H) onto the Bottom Shelf (G). Tighten cams by turning the Cam Lock 180 degrees using a screw driver.
- Page 8 STEP Push Cam Locks (2) into one end of the Top, Bracing Shelf, and Bottom Shelf each, and into the attached Trim Pieces as shown. Then place onto the Cam Bolts in the Right Wall (D) as shown, and tighten. CAUTION: Do not overtighten cams.
- Page 9 STEP Insert the Back Panels (I) into the provided slots, as shown.
- Page 10 STEP Push Cam Locks (2) into the remaining holes as shown, then set the Left Wall (C) onto the shelf and tighten the Cam Locks. Next, apply the four strips of Backing Tape (5) where the Back Panels meet, to secure them together.
- Page 11 STEP Mount the Drawer Sides (J and I) onto the Drawer Front (G) by first inserting two Cam Locks (3) each, and then sliding the Drawer Sides onto the Cam Bolts on the Drawer Front.
- Page 13 FINISHED...
- Page 14 • DO NOT stand on the desk. Do not use the desk as a stepladder. • • Every 6 months, check all bolts and screws to ensure they are tight. • This product is California 93120 Compliant for Formaldehyde. PLEASE VISIT WWW.COMFORTPRODUCTS.NET FOR WARRANTY INFORMATION Comfort Products warrants this product to be free from defects in material and workmanship for one (1) year.
