OneSpace is a Trademark of Comfort Products, Inc.
ASSEMBLY INSTRUCTIONS
MODEL 50-JN1301
SUPPLIER CODE: JNFF
ULTRAMODERN GLASS COMPUTER DESK WITH DRAWERS
CUSTOMER SERVICE
For fastest service on claims, requests for replacement parts,
or questions, please visit our website at:
www.comfortproducts.net/support
e-mail: customerservice@comfortproducts.net
Keep your sales receipt as documentation of your ownership.
7
Advertisement
Related Manuals for Onespace 50-JN1301
Summary of Contents for Onespace 50-JN1301
- Page 1 ™ OneSpace is a Trademark of Comfort Products, Inc. ASSEMBLY INSTRUCTIONS MODEL 50-JN1301 SUPPLIER CODE: JNFF ULTRAMODERN GLASS COMPUTER DESK WITH DRAWERS CUSTOMER SERVICE For fastest service on claims, requests for replacement parts, or questions, please visit our website at: www.comfortproducts.net/support...
- Page 2 ASSEMBLY OVERVIEW (50-JN1301) # DESCRIPTION SIDE 1 SIDE 2 STOCK # QTY. weight capacity = 66lbs weight capacity s b l 2 of 13...
- Page 3 PARTS LIST 1 OF 2 (50-JN1301) # DESCRIPTION SIDE 1 SIDE 2 STOCK # QTY. ITEMS ARE NOT SHOWN TO SCALE. DESCRIPTION STOCK # QTY. 51-JN1301LG 51-JN1301FT Foot Support Board 51-JN1301SB Left Board 51-JN1301LB Right Board 51-JN1301RB Middle Board 51-JN1301MB...
- Page 4 PARTS LIST 2 OF 2 (50-JN1301) # DESCRIPTION SIDE 1 SIDE 2 STOCK # QTY. ITEMS ARE NOT SHOWN TO SCALE. DESCRIPTION STOCK # QTY. Desktop 51-JN1301DT 51-JN1301SP Glass Side Panel Drawer Back 51-JN1301DB Drawer Left 51-JN1301DL Panel Drawer Right...
- Page 5 HARDWARE LIST (50-JN1301) EXTRA HARDWARE INCLUDED FOR YOUR CONVENIENCE. ITEMS ARE NOT SHOWN TO SCALE. HARDWARE KIT STOCK # 51-JN1301HA PART DESCRIPTION QTY. - READ THE INSTRUCTION MANUAL BEFORE ASSEMBLING. M6 X 70MM - REMOVE ALL PIECES BEFORE BEGINNING INSTALLATION.
- Page 6 ASSEMBLY INSTRUCTIONS (50-JN1301) STEP 1 Attach the feet (2) to the bottom of the legs (1). STEP 2 Attach the legs to the support board (3) with four screws (A), tightening with the Allen wrench (N). A x 4 6 of 13...
- Page 7 ASSEMBLY INSTRUCTIONS (50-JN1301) STEP 3 Screw six Mini x Bolts (C) into the corner holes of the Bottom Board (7) and insert the six Dowels (B) into the middle holes. B x 6 C x 6 STEP 4 Place six Cams (D) into the lower holes of the Left Board (4), Right Board (5), and Middle Board (6). Note the arrow on the face of each Cam.
- Page 8 ASSEMBLY INSTRUCTIONS (50-JN1301) STEP 5 Screw seven Mini x Bolts (C) into the Back Board (8). Place seven Cams (D) in the remaining holes of the boards assembled in Step 4. Attach the Back Board (8) by aligning the Mini x Bolts (B) with the holes. Tighten the Cams clockwise half a turn to lock the boards into place.
- Page 9 ASSEMBLY INSTRUCTIONS (50-JN1301) STEP 7 Attach two Left Outer Rollers (9a) to the Left Board (4) and Middle Board (6) using four screws (E). Refer to the used for the right roller. E x 4 9a LEFT STEP 8 Attach two Crossbars (10) to the Left, Middle, and Right Boards using four Screws (F) at the ends and two Screws (G) in the middle.
- Page 10 ASSEMBLY INSTRUCTIONS (50-JN1301) STEP 9 Attach the legs to the Bottom Board (7) using four Screws (F). F x 4 STEP 10 Attach the glass Desktop (11) to the Crossbars using four Screws (H). H x 4 10 of 13...
- Page 11 ASSEMBLY INSTRUCTIONS (50-JN1301) STEP 11 Attach the Glass Side Panels (12) to the desk using four Screws (I) with the Caps and Washers (J). I x 4 J x 4 STEP 12 STEP 13 Attach the Drawer Back (13) to the Drawer Left Attach four Bolts (C) to the Drawer Front (16).
- Page 12 ASSEMBLY INSTRUCTIONS (50-JN1301) STEP 14 Insert four Cams (D) into the holes of the Drawer Left Panel (14) and Right Panel (15). Attach the Drawer Front (16) to the Left and Right Panels, making sure the groove is aligned with the Drawer Bottom (17). Tighten the Cams clockwise half a turn.
- Page 13 66 pounds and the weight capacity of the drawers is 22 pounds. For claims or questions concerning this warranty, please visit: www.comfortproducts.net or email us at: customerservice@comfortproducts.net MODEL: 50-JN1301 Comfort Products, Inc. P.O. Box 999 Memphis, TN 38101 www.comfortproducts.net customerservice@comfortproducts.net ™ OneSpace is a Trademark of Comfort Products, Inc. 13 OF 13...
