Summary of Contents for S&T TPMS1209T02-ER

  • Page 1 TPMS1209T02-ER USER MANUAL Suzhou Sate Auto Electronic Co., Ltd www.sate.com.cn Page 1 of 28...
  • Page 2: Table Of Contents

    Table of Contents I. TPMS1209T02-ER, Full-time Direct TPMS -----------------------------------3 II. Parts of TPMS1209T02-ER --------------------------------------------------------3 III. Installation and Programming of TPMS1209T02-ER Monitor ---------4 1. Installation of Monitor -----------------------------------------------------------4 2. Programming of Monitor -------------------------------------------------------5 2.1Programming of Transmitter ID -----------------------------------------7 2.2 Standard Pressure Programming ----------------------------------------7 2.3 System Time Programming...
  • Page 3: Tpms1209T02-Er, Full-Time Direct Tpms

    Through TPMS1209T02-ER, the driver can keep the tire running under a proper pressure so as to avoid excess gasoline consumption and keep the vehicle in an easily controlled state.
  • Page 4: Installation And Programming Of Tpms1209T02-Er Monitor

    Alarm Lamp Transmitter Security Lock Wrench Pedestal III. Installation and Programming of TPMS1209T02-ER 1. Installation of Monitor 1.1 Insert the pedestal to the back of the monitor as shown in below picture. Install Pedestal 1.2 Choose a suitable location to install the Monitor onto the dashboard.
  • Page 5: Programming Of Monitor

    3M Dual Lock 1.3 The monitor power wire consists of 3 different colors of wires. The Black wire should be connected to the ground. The Red wire should be connected to the vehicle’s continuous power supply. The Blue wire should be connected to ignition switch, when switched to “ON”, the blue wire is connected with 12V power.
  • Page 6: Programming Of Transmitter

    2.1 Programming of Transmitter ID When the monitor is powered for the first time, the screen shows “NSP”, which means there is no transmitter programmed into it. If the user wants to program a new transmitter into the monitor, the operation should be finished in programming mode.
  • Page 7: Standard Pressure Programming

    then press up or down arrow key to adjust the value. 4. Once finish programming of the first digit, press to start → programming the second digit which flashes. Press up or down arrow key to adjust the value. 5. Press → again to program the third digit which flashes. Press up or down arrow key to adjust the value.
  • Page 8 programming mode. 2. Then press any of the four arrow keys to choose the desired tire position. 3. Then press S for 3 seconds to set the first digit which flashes. Press up or down arrow key to adjust the value to 1. 4.
  • Page 9: System Time Programming

    Note: The default standard pressure is set to 100 psi in factory. 2.3 System Time Programming Function: The system clock was preset in the factory. It is the base of the alarm record, user can check the current date and time as follows: 1.
  • Page 10 3. Press the ↓ key to access the third interface, 312 stands for 12th day as shown below: 4. Press the ↓ key to access the fourth interface, 416 stands for 16 O’clock as shown below: 5. Press the ↓ key to access the fifth interface, 533 stands for 33 mins. As shown below: Under any interface of system time inquiry, press S for 3 seconds to start programming.
  • Page 11 next interface for programming. 2.4 Programming of Temperature and Pressure Unit 1. After program the system time, press P to access interface for programming temperature and pressure unit. The first interface displays the temperature unit. As shown below: At this time, press up or down arrow key to switch to the pressure unit interface.
  • Page 12: Deletion Of Transmitter

    Note: After programming, press P key for 3 seconds to return to normal mode. IV. Installation of TPMS1209T02-ER Transmitter Before install the transmitter, make sure the transmitter has been programmed into the monitor and monitor is under normal mode. If no...
  • Page 13: Installation Of Transmitter

    program, the screen will display “NSP”. When the transmitter is screwed onto the valve according to the programmed position, the monitor can receive the signals and then display the transmitter location icon, pressure, temperature information on the screen. When all of information were received by the monitor and the information are all normal, the screen display “ON”.
  • Page 14: Installation Of Security Lock

    Transmitter. If the user chooses to use the lock, please refer to the below part of lock installation. Security Lock and Transmitter should be installed at same time. 3. Screw the transmitter onto the tire valve. 4. Check the connection of Transmitter and valve with the soap solution to confirm whether the transmitter is firmly screwed onto the valve or not, check whether there is air leakage caused by the installation or the seal of the Transmitters or not.
  • Page 15 Transmitter Security Lock Wrench The function of the Lock is to connect the Transmitter and the Lock by connecting the meshing part of them, and then fasten the Lock firmly by the three bolts in the sockets, thus the Transmitter with the Lock can be firmly screwed onto the valve and cannot be screwed off by a sudden force.
  • Page 16: System Function Of Tpms1209T02

    Note: Install the lock or not will not influence the functions of the Transmitter. V. System Function of TPMS1209T02-ER 1. Full-time Monitoring Function: TPMS1209T02-ER can monitor the tire pressure and temperature whether the vehicle is running or parked. Therefore to keep the driver informed of the tire state and realize full-time monitoring.
  • Page 17: Low Pressure Level 1 Alarm

    Function: the system will issue the high pressure alarm when the tire pressure is 25% higher than the standard. Alarm mode: the alarm lamp flashes, high pressure warning iron, tire position icon and the audible alarm turn on together. Treatment: press any key to stop the audible alarm. The red alarm lamp remains on and the display reverts to the normal mode.
  • Page 18: Low Pressure Level 2 Alarm

    when the tire pressure returns to normal level. 4. Low pressure level 2 alarm Display mode: Function: the system will issue level 2 low pressure alarm when the tire pressure is 25% lower than the standard. Alarm mode: the alarm lamp flashes, low pressure level 2 alarm iron, tire position icon and the audible alarm turn on together.
  • Page 19: High Temperature Alarm

    Alarm mode: the alarm lamp flashes, low pressure level 3 alarm iron, tire position icon and the audible alarm turn on together. Treatment: press any key to stop the audible alarm. The red alarm lamp remains on and the display reverts to the normal mode. The user should slow down the vehicle and replace the tire with the spare tire.
  • Page 20: Transmitter Trouble Alarm

    Display mode: Function: the system will issue a quick leaking alarm when the pressure drops more than 2.8 psi within 12 seconds. Alarm mode: the alarm lamp flashes and the audible alarm turns on, the tire position icon flashes. Treatment: press any key to stop the audible alarm and the system reverts to normal mode.
  • Page 21: Tpms1209T02-Er Auxiliary Functions In Normal Mode

    Note: The red alarm lamp goes off automatically when the communication between the transmitter and monitor returns back to normal mode. VI. TPMS1209T02-ER Auxiliary Functions in Normal Mode Alarm Record Inquiry 1. Under normal mode or pressure inquiry interface, press P and S at the same time for 3 seconds to access the alarm record inquiry interface.
  • Page 22 Time (year) Time (month) Time (date) Time (hour) Time (minute) Then it will display the next alarm record in the same way as above. Page 22 of 28...
  • Page 23 3. Press P and S at the same time to return to pressure inquiry interface. Page 23 of 28...
  • Page 24: Specifications

    Specifications VII. Monitor Modulation Type: FSK Mid-frequency: 434.1 MHz Receiving Sensitivity: -105 dBm Input Voltage: 12V / 24V Current: < 60mA Operating Temperature: -30℃~70℃ Storage Temperature: -30℃~75℃ Transmitter Modulation Type: FSK Mid-frequency: 434.1 MHz Transmitting Power: 0 dBm Input Voltage: 3.6V (Battery) Static Current: <...
  • Page 25: Frequently Asked Questions

    VIII. Frequently Asked Questions 1. Why do I need to check the tires periodically with the TPMS system installed? Periodic check of the tire can keep the driver aware of the tires conditions and ensure driving safety. 2. Pressure alarm frequently occurs. The user can check if the standard pressure is suitable or not.
  • Page 26 When vehicle runs the temperature around the transmitter will rise. When there is high temperature alarm, please check if the tire is under abnormal condition which causes the wheel rim becomes very hot. 6. The monitor displays nothing or abnormal code. Please check the power supply state and contact us at +86-21-50792951 if necessary.
  • Page 27: Warranty Term

    IX. Warranty Terms Valid Warranty Card 1. The Warranty Card must be filled completely, signed by and sealed by the authorized distributors of Sate. 2. The Warranty Card is valid in the countries or regions where the purchase occurs. 3. The Warranty Service requires user to offer the Warranty Card and the original invoice.
  • Page 28: Important Notes

    3. The warranty responsibility is subject to the conditions and limitations specified in the User Manual. 4. TPMS1209T02-ER monitor should be connected with the continuous power supply and installed by the professional. S&T is not responsible for the vehicle circuit damage or accident caused by wrong installation or improper use of the system.
