INSTALLATION MANUAL
MX Steam Room Series
1800/2000/2200
30 Day Technical Support:
Call 01908 317512 and request technical support for aiding
your installation.
Replacements Parts:
Inside of your warranty period visit:
https://www.insigniashowers.com, click support and make a
warranty claim.
Spares/Replacements Parts:
Outside of your warranty period
visit
https://www.insigniashowers.com/replacement-parts.html
ATTENTION INSTALLERS:
These instructions must be
left with the customer
CHECK ALL CONTENTS BEFORE BUILD COMMENCES. NO RETURNS CAN BE MADE
ONCE THE BUILD HAS STARTED AS IT IS DEEMED ACCEPTANCE OF PRODUCT!

Advertisement

loading
Need help?

Need help?

Do you have a question about the MX Series and is the answer not in the manual?

Questions and answers

Related Manuals for Insignia MX Series

Summary of Contents for Insignia MX Series

  • Page 1 www.insigniashowers.com Last Modified: 08/12/2021 INSTALLATION MANUAL MX Steam Room Series 1800/2000/2200 30 Day Technical Support: Call 01908 317512 and request technical support for aiding your installation. Replacements Parts: Inside of your warranty period visit: https://www.insigniashowers.com, click support and make a warranty claim.

  • Page 2: Table Of Contents

    www.insigniashowers.com Last Modified: 08/12/2021 Contents Thank you for your purchase Steam Generator Install 17 Tips for Installation Control Panel Instructions 18 Braided Hose Requirements Sauna Room Safety Guide 20 Electrical, Water & Tool requirements WEEE Compliance Statement 21 Box contents Column and Right Back Panel Install Right Side Panel Install Left Back Panel Install 10...
  • Page 3 Last Modified: 08/12/2021 Thank you for your recent purchase of an Insignia shower. Please read this booklet with great care to ensure you get the best out of your build and have a shower that will last for many years to come! Like everything, in order to obtain a first class product that will serve you well for many years, the effort and correctness put into the assembly will reflect in the quality of your finish.
  • Page 4 TIP 4—Sealing When using Insignia’s RubberGum, please ensure the product does not come in contact with your silicone as this will cause the RubberGum to fail and will not adhere as intended. Rubbergum is immediately waterproof and will gain additional strength over time.
  • Page 5 www.insigniashowers.com Last Modified: 08/12/2021...
  • Page 6 www.insigniashowers.com Last Modified: 08/12/2021 Electrics Pressure/Water Requirements Tools Required All connections MUST be carried out by an approved part P We recommend a BAR pressure between 2.5 and 3.4 BAR. You will require: electrician and a minor works certificate must be issued upon If you have a combi boiler system no problem should be •...

  • Page 7: Right Side Panel Install

    Right Side Panel Roof Marble Bench VERY IMPORTANT Have you got everything? If not please contact the Insignia directly on 01908 317 512. Remember NEVER book your tradesman until everything has arrived, been checked and is present. No replacement/missing parts can be obtained free of charge during or after the build.
  • Page 8 www.insigniashowers.com Last Modified: 08/12/2021 Step 1 — Connecting the column and right back panel Slot the panel bracket over the screw fixings and push down to secure in place.
  • Page 9 www.insigniashowers.com Last Modified: 08/12/2021 Step 2 — Connecting the right side panel Lift the right side panel, slot the screw fixings into the brackets and push down to secure into position...
  • Page 10 www.insigniashowers.com Last Modified: 08/12/2021 Step 3 — Connecting the left back panel Lift the left back panel, slot the brackets on to the screw fixings and push down to secure into position...
  • Page 11 www.insigniashowers.com Last Modified: 08/12/2021 Step 4 — Connecting the left side panel Lift the left side panel, slot the screw fixings into the brackets and push down to secure into position...
  • Page 12 www.insigniashowers.com Last Modified: 08/12/2021 Step 5 — Placing the benches in position Push the marble benches into position, tight into each corner of the steam room...
  • Page 13 www.insigniashowers.com Last Modified: 08/12/2021 Step 6 — Connecting the front CAUTION: Very Heavy—3 Person Lift Lift the front and slot the fixing screws into the brackets on either side panel and push down to secure into position...
  • Page 14 www.insigniashowers.com Last Modified: 08/12/2021 Step 7 — Installing the door handle Unscrew the door handle knobs, place the screw through the door and reconnect...
  • Page 15 www.insigniashowers.com Last Modified: 08/12/2021 Step 7 — Installing the roof Lift the roof and slot into position...

  • Page 16: Control Panel And Electrical Connections

    www.insigniashowers.com Last Modified: 08/12/2021 Step 8 — Control panel and electrical connections All connections MUST be carried out by an approved part P electrician and a minor works certificate must be issued upon completion. This product is NOT designed for DIY install and improper installation could be fatal. Please use correct size and type to meet electrical codes.

  • Page 17: Steam Generator Install

    Last Modified: 08/12/2021 Step 8 — Steam Generator Install The Insignia steam generator can be hung on a wall or sit on a base. The best Wall Mounting: mounting location will satisfy all or most of the following: 1. Note the location of the mounting holes on the back of the generator. The screws must set directly into studs or equivalent supports.

  • Page 18: Control Panel Instructions

    Press once to turn on the panel. Simply press again to turn it off. When powering down the 03 will automatically start and last for approximately 10 minutes. After this the screen will power off. To see our tutorial videos for operating Insignia control panel’s, please search for “Insignia Showers” on YouTube and find our “Insignia Control Panel”...
  • Page 19 www.insigniashowers.com Last Modified: 08/12/2021 Control Panel Instructions Connecting to Bluetooth Step 2 Step 1 Then simply go on your device and pair To connect a device via up with the shower which should be Bluetooth, press the music shown as “INS”. Once this is complete function button twice (which you will hear a beep to signify you’re looks like a musical note) the...
  • Page 20 www.insigniashowers.com Last Modified: 08/12/2021 Sealing your shower NOTE: Seal all the joints on the shower unit, as well as sealing the panels to the floor creating a clean watertight finish. The roof joins do not require sealing, however it can be should you wish.
  • Page 21 www.insigniashowers.com Last Modified: 08/12/2021 Steam Room & Shower Safety Guide Never leave children unattended in the shower or bath. Never bath children (under 12) using whirlpool function if fitted. Regulate the temperature of water before showering. Never allow children to use the steam function. This function is for ADULTS ONLY. Always be aware of the steam outlet position.

  • Page 22: Weee Compliance Statement

    (EEE) have to fulfil certain obligations. Under the WEEE directive Insignia is considered the producer of certain products we supply and in line with the demands of the legislation we are pleased to offer the op- portunity to return these products to us for treatment and recycling.
