Installation
150
Connecting Cables
The system lies fully assembled in the box.To protect the camera lens while installing, it is
recommended to keep the camera lens cap on.
In the accessories box you find: - LAN cable
- Power adapter and power cable
4
5
3
2
1
Ethernet
PC
1. LAN 1: Connect LAN 1 to PC.
2. LAN 2: Connect LAN 2 to ethernet. The PC gets ethernet connection through the TANDBERG 150.
3. Power: Power on the system with the power cable.
4. Plug for handset: Optional feature, see www.tandberg.net for more information.
5. Plug for headset: Optional feature, see www.tandberg.net for more information.
D13651.05 Page 1
Advertisement
Table of Contents
Related Manuals for TANDBERG 150 MXP
Summary of Contents for TANDBERG 150 MXP
- Page 1 Ethernet 1. LAN 1: Connect LAN 1 to PC. 2. LAN 2: Connect LAN 2 to ethernet. The PC gets ethernet connection through the TANDBERG 150. 3. Power: Power on the system with the power cable. 4. Plug for handset: Optional feature, see www.tandberg.net for more information.
- Page 2 System Configuration 1. Open the General Settings menu Press the Settings key on the keypad to open the Administrator Settings menu and select ‘General’. 2. General configuration Configure System Name, Autoanswer and Maximum Call Length (in minutes). Note that ‘0’ means that there is no maximum call length.
