note: All variables are stored as 'Holding Registers' . MODBUS functions :
• 'Read Holding Registers' (function code 3),
• 'Write Single Register' (function code 6),
• and 'Write Multiple Registers' (function code 16) are supported .
note: All variables with multiple UOM's depend upon the value of 'Input Mode' to determine which to use .
note: Use 'District Steam Delay' when 'Operating Mode' is set to District Steam . Use 'System Setpoint',
'System Differential' and 'Thermal Lockout Enable' when 'Operation Mode' is set to Burner/valve .
note: Use 'Vari-Boost Adjustment' when 'Boost Mode' is set to Vari-Day or Vari+ESD . Use
'Manual Boost Time' when 'Vari-Boost Adjustment' is set to Manual Boost .
note: The MPC Platinum has a schedule, which is 7-days, 4 day/night pairs per day . For example: Register
38 is the first DAY schedule of Monday; Register 39 is the first NIGHT schedule of Monday; Register 46
is the first DAY schedule of Tuesday; Register 47 is the first NIGHT schedule of Tuesday and so on .
note: Use MPC Platinum Installation and Operation manual for supplementary information .

MPCQ PlaTInUM MODBUS VarIaBle lIST

MPCQ reg /
DeSCrIPTIOn
VarIaBle#
1 – 3 Model
4 – 13 Serial Number
14 Firmware Version
15 Vari-Boost Adjustment
16 Boost Mode
17 Manual Boost Time
18,19 Bypass Time
20 through 51 Boiler Status
52 Boiler Type See "MPCQ Platinum
Boiler Type Table" on page 12
53 Bypass Mode
54 Cycle Length
55 through 86 Extension Panel Stage
Communication Error
87 Day Heat Adjustment
88 Outdoor Day Cutoff
89 Day Light Saving
90 Sensor Fault Mode
91 Sensor Mode
92 Lead Boiler
93 through 124 Lockout Input
125 Logic Mode
126 Last Stage Hold
127 Min Runtime
128 through 159 Boiler Mode
160 Total Boilers
161 Night Heat Adjustment
MODBUS Installation and Operation Manual
♦1
MUlT
UOM
(if not 1)
100
10
Minutes
Minutes
(BTYPE=0)®
(BTYPE=1)®
(BTYPE=2)®
(BTYPE=3)®
Minutes
°C, °F
10 psi
Minutes
range / STaTeS / SPeCIal
ValUeS
6 Character string ♦3
20 Character string ♦3
0 .1 – 6 .4
0=Disabled, 1=Manual,
2=Vari, 3=Vari+ESD
0 – 120
0 – 2,147,483,647 ♦4
0=Off, 1=On0=Off, 1=Low,
2=High, 0=Off, 1=Low, 2=Med,
3=High, 0=Off, 1=Low,
2=MLow, 3=Mhigh, 4=High
0=On/Off, 1=2-Stage2=3-
Stage, 3=4-Stage
0=AUTO, 1=ON
10 – 240
0="", 1=C/E
0 – 15 = A – P
-6 - 38°C, 20 - 100°F
0=Enable, 1=Disable
0=OutputOn,1=OutputOff
0=°F, 1=°C
See "MPCQ Platinum Boiler
Type Table" on page 12
0=(inactive), 1=L/O
0-PID, 1-OSS
0 .0 – 5 .0
1 – 60
0=Auto, 1=Standby, 2=Off, 3=On
1 – 32/(BTYPE+1)
0 – 15 = A – P
reaD
Only
X
X
X
X
X
X
X
11
