- Page 1 ASSEMBLY INSTRUCTION CONWAY DAYBED WITH TRUNDLE 74371 1020mm 2140mm 1120mm Imported by JWA Furniture Pty Ltd, Qld, Brisbane Australia. For any assistance with assembly or for missing parts please refer to your receipt...
- Page 2 PRE-ASSEMBLY PREPARATION Before you start: 1.Choose a clean, level, spacious assembly area. Avoid hard surfaces that may damage the product 2.Take care when lifting. Product should be assembled as near as possible to the point of 3.Ensure that you have all required contents for complete assembly 4.Always read the assembly instructions carefully before beginning assembly.
- Page 3 PARTS LIST...
- Page 4 STEP 1: • Prepare a protected surface with a blanket or cardboard. • Attach the 4x Threaded rod(D) to the armrest left(2) and armrest right(3), as shown below. And tighten halfway. • Attach the 4x feet(11) to the armrest left(2) and armrest right(3). Secure with wood screw(I).
- Page 5 STEP 3: • Attach 2x end cap(7) onto every slat(6). • Attach the slat to the bed as shown below. Push the caps into the holes. STEP 4: • Attach trundle cross rail (10) with 3x bolt (A),washer(E) tighten with allen key(G) to trundle front side rail (8) and with 2x bolt to trundle side rail back (9) as shown below.
- Page 6 STEP 5: • Attach 2x end cap(7) onto every slat(6). • Attach the slat to the bed as shown below. Push the caps into the holes. STEP 6: • Slot in the trundle bed and fixing is complete. Assembly Is Complete...
- Page 7 PRODUCT CARE: FURNITURE / BED 1. When assembling your furniture / bed please ensure that you have checked the contents for all relevant parts. 2. When tightening bolts make sure that they are fully tightened but not forced. 3. When moving your fully assembled bed you must first remove the mattress and lift the frame into position, take care when lifting and always have two people handling the bed.
