- Page 1 ASSEMBLY INSTRUCTION CHAMBORD SINGLE BED 74319 980mm 2140mm 1120mm Imported by JWA Furniture Pty Ltd, Qld, Brisbane Australia. For any assistance with assembly or for missing parts please refer to your receipt...
- Page 2 PRE-ASSEMBLY PREPARATION Before you start: 1.Choose a clean, level, spacious assembly area. Avoid hard surfaces that may damage the product 2.Take care when lifting. Product should be assembled as near as possible to the point of 3.Ensure that you have all required contents for complete assembly 4.Always read the assembly instructions carefully before beginning assembly.
- Page 3 PARTS LIST...
- Page 4 STEP 1: • Prepare a protected surface with a blanket or cardboard. • Attach the 4x Threaded rod(C) to the armrest left(2) and armrest right(3), as shown below. And tighten halfway. • Attach the 4x feet(8) to the armrest left(2) and armrest right(3). And tighten clockwise.
- Page 5 STEP 3: • Attach the centre cross rail(5) to the side rail and headboard as shown below. Thread 1x bolt(B),2x washer(E) per side from the top and below, and lock with Hex nut(D) • Repeat for the other side rail. STEP 4: •...
- Page 6 PRODUCT CARE: FURNITURE / BED 1. When assembling your furniture / bed please ensure that you have checked the contents for all relevant parts. 2. When tightening bolts make sure that they are fully tightened but not forced. 3. When moving your fully assembled bed you must first remove the mattress and lift the frame into position, take care when lifting and always have two people handling the bed.
