1. Hardware

1.1. Overview

VWC2-ROC is a compact video wall controller which delivers 4k/60 visual experiences. Up to 4x
input sources can be displayed simultaneously to LCD wall or LED wall with any size and at any
position.
With capabilities to support embedded audio, VWC2-ROC offers higher flexibility for versatile
applications, such as meeting rooms, small control rooms and digital signage.

1.2. Hardware Interface

VWC2-ROC series have 3x types of chassis.
1.2.1. 1U-0404
Front View
Support modify IP address via push button
1.2.2. 1U-0408
Front View
Support modify IP address via push button
1.2.3. 1U-0412
Front View
Rear View
4x HDMI input, 4x HDMI output, 1x Lan for control, 1x
Lan for preview
Rear View
4x HDMI input, 8x HDMI output, 1x Lan for control, 1x
Lan for preview
Rear View
