II. The DB-RC4 v2 Hardware

2.1 Unpacking and inspection

Your packing box should contain the following items:
Items
DigiBird DB-RC4 v2 enclosure
DB-RC4 v2 AC/DC Switching Power Adapter
Standard Computer Power Cord, 10A, 18AWG (NEMA 5-15P to IEC-320-C13), 6-ft. (American
Standard) or 1× CEE7/7 Male Plug to 2 Way IEC 60320 C13 Connector 6 Feet 10a/250v power cord
(European Standard)
USB 2.0 Cable Type A Male to Type B Male 5 feet, Black
DigiBird CD containing Software Installation File and User Guide (PDF version)
Warranty Card
User guide and Software are also available on www.digibirdtech.com.
Before connecting any inputs or outputs, it is advised to power on the unit. Should you encounter any
problems powering on the unit, immediately contact your local distributor or dealer.
The DB-RC4 v2 enclosure will arrive boxed with internal foam for protection during shipping.
You are encouraged to retain the box and all packing material so the unit can be returned in the
unlikely event that repairs should ever become necessary.

2.2 Hardware Overview

2.2.1 Technical Specification

Connectors
Indicators
Outputs
Input Resolution
Input Clock Rate
Input Bandwidth
Arbitrary Upscaling
Operating Humidity
Operating Temperature
Power
8
All rights reserved by DigiBird
(1) Single-Link or Dual-Link DVI-I female for input
(4) DVI-I female for output
(1) power connector female
(1) USB-B female
(1) Power LED, (1) Input LED, (1) Status LED
4 x Single-Link DVI or analog RGB outputs, up to 1920×1200@60Hz
Up to 4K×4K
330MHz
9.9Gbps
Unlimited upscaling for original cropped area
90% non-condensing
32º to 104ºF (0º to 40ºC)
Input: 100-240 VAC, 1.4 Amps
Output: 12 VDC, 5 Amps
Consumption: 40 Watts
®
Quantity
1x
1x
1x
1x
1x
1x
