The LPS-H4TU-C-L5 Central Office (CO) module is a low-power, plug-in unit that installs in a Soneplex
Broadband Chassis or Soneplex Loop Extender Chassis at the central office. Hereinafter referred to as the
H4LXC, this CO module provides DS1/HDSL4 signal conversion, and status and alarm reporting. The module is
only compatible with the H4TU-R-402-5A remote module.
The LPS-H4TU-C, when used in conjunction with an H4TU-R-402-5A remote unit (H4LXR), provides 1.544
Mbps full-duplex T1 transmission on two unconditioned copper pairs over the full Carrier Service Area (CSA)
range. The CSA includes loops of up to 16,000 feet on 24 AWG wire or 12,000 feet on 26 AWG wire, including
bridged taps.
The H4LXC functions and features described in this manual are supported by Shelf Controller
Unit (SCU) Software Version 3.5 through 4.1.1. For information about this card when running
under SCU v5.0 and higher, refer to LTPS-UM-8068-xx.
F
EATURES
•
Remote provisioning of the line through the H4LXR
•
Status Light Emitting Diodes (LEDs) for Digital Signal Level 1 (DS1) and HDSL4 interfaces
•
Lightning and power cross-protection on HDSL4 and DS1 interfaces
•
1.544 Mbps full-duplex transmission on one unconditioned copper pair
•
34 kft range with two H4D repeaters (using 26 AWG copper)
•
Ultra-low wander (0.26 UI)
•
Alternate Mark Inversion (AMI) or Bipolar with 8-Zero Substitution (B8ZS) line code
•
Unframed, Superframe (SF), or Extended Superframe (ESF) frame format
•
Dual (bi-directional) loopbacks (initiated from H4LXC front panel, H4LXR front panel, or SCU craft screen)
DS1 is used throughout this document to refer to either the remote unit's DS1 interface or the
line unit's DSX-1 interface.
