Parameter
DS1 Interface
Input/Output Signals
DS1 Line Rate
DS1 Equalization
DS1 Line Format
DS1 Frame Format
DS1 Pulse Output
HDSL4 Interface
Output Signal Level
Loop Type
Impedance
Line Rate
Loop Power Output
Loop Loss
Loop Wander
Power Requirements
Input Voltage
Maximum Power Consumption
Heat Dissipation
Electrical Protection
Environmental
Operating Temperature
Storage Temperature
Humidity
Physical
Dimensions (H x W x D)
LPS-H4TU-C-L5
A - S
PECIFICATIONS
Table 14. LPS-H4TU-C Specifications
Specification
Per ANSI T1-403
1.544 Mbps
0 to 655 feet
Alternate Mark Inversion (AMI) or
Bipolar with 8-Zero Substitution (B8ZS) or
AUTO (line format transmitted matches
line format received)
Extended Superframe (ESF), Superframe
(SF), Ft Only (Terminal Framing), or AUTO
(detects/adapts to frame format)
6V peak-to-peak
+14.1 dBm ± 0.5 dBm
Single or mixed gauges
135 ohms nominal
784 Kbps 16-TC
-190 ± 8 Vdc
47 dB @ 196 kHz
0.26 UI maximum
-48 Vdc (nominal)
32 W for two H4D units, 12 W without
units
5.9 W for no doubler units
6.5 W for one doubler unit
7.8 W for two doubler units
Secondary surge and power
cross-protection on all HDSL4 ports
(requires external primary protection)
-40°F to 149°F (-40°C to 65°C)
-40°F to 158°F (-40°C to 70°C)
5% to 95%, operating and storage
4.6 inches x 0.7 inches x 9.5 inches
(11.7 cm x 1.7 cm x 24.1 cm)
Remarks
±200 ppm
In 133 foot increments
135Ω termination
With or without bridged taps
Balanced
Overlapped Pulse Amplitude
Modulation (PAM)
135Ω termination
Non-condensing
