Related Publications
R P
ELATED UBLICATIONS
Listed below are related manuals and their publication numbers. Copies of these publications can be downloaded
from the ADC website at www.adc.com. To order a hard copy, please contact your sales representative.
Title
Soneplex HDSL Compatibility Quick Reference Guide
Soneplex Loop Extender Design, Description, and Application Manual (V5)
Soneplex System TL1 Interface Specification
Soneplex Loop Extender Operation and Maintenance Manual (V5)
Soneplex Broadband System Operation and Maintenance Manual (V5)
Soneplex Broadband System Design, Description, and Application Manual (V5)
Soneplex Shelf Controller Unit Operation and Maintenance Manual
Soneplex Shelf Controller Unit (SCU) System Description and Engineering Guide
Soneplex Shelf Controller Unit (V3.5) Operation and Maintenance Manual
Soneplex System Installation Manual (Broadband and Loop Extender Chassis)
H2TU-R-402 List 5A Remote Unit Quick Installation Guide
H4D-409 List 2 Doubler Unit Quick Installation Guide
LPS-H4TU-C-L5 Line Unit Quick Installation Guide
LPS-H4TU-C-L5 Line Unit User Manual for SCU v5.0 and higher
S W
AFETY ARNINGS AND
To avoid electric shock, be careful when working near HDSL4 loop connections or
telecommunications circuits. Be careful when working near power supplies. Soneplex
equipment uses -48 Vdc office power and some remote HDSL4 equipment uses -130 Vdc.
Coming in contact with high electrical potential will result in death or severe personal injury.
The chassis must be properly grounded to ensure human and equipment safety.
To prevent electrical shock, never install telephone equipment in a wet location or during a
lightning storm. When installing or modifying telephone lines, disconnect lines on the network
side before working with uninsulated lines or terminals.
Electronic components can be damaged by electrostatic discharge (ESD). Before handling
modules, wear an antistatic discharge wrist strap to prevent damage to electronic components.
Place components in antistatic packing material when transporting or storing. When working on
components, always place them on an approved antistatic mat that is electrically grounded.
iv
N
OTICES
December 3, 2003
LTPS-UM-8054-01
Catalog Number
ADCP-61-168
ADCP-61-317
ADCP-61-419
ADCP-61-467
ADCP-61-471
ADCP-61-472
ADCP-61-756
ADCP-61-758
ADCP-61-776
LTPS-UM-8010-xx
LTPH-QI-1154-xx
LTPH-QI-1120-xx
LTPS-QI-8053-xx
LTPS-UM-8068-xx
LPS-H4TU-C-L5
