SCU and H4LXR Craft Port Interface

SCU
AND
C
ONNECTING A
The SCU and H4LXR craft interfaces are accessed through the Craft Port on their respective front panels. For
initial setup of the line unit, connect a PC running a terminal emulation program (such as Hyperterminal or
ProComm) or a VT100-compatible terminal to the SCU Craft port
DB9 connector. The procedure for connecting to an H4LXR Craft port is the same.
Connect a maintenance terminal to the SCU Craft port using a shielded cable with a maximum
length of approximately 50 feet (at 9600 baud, 8 bits, no parity, and 1 stop bit as specified for
RS-232 protocol).
Use a straight-through cable for connecting the SCU DCE port to DTE equipment. Use a
cross-over cable for connecting the SCU DCE port to DCE equipment
1
Connect one end of the interface cable to the serial COM port of a PC, maintenance terminal, or to other
networking equipment.
2
Connect the other end of the interface cable to the SCU Craft port (see
8
H4LXR C
RAFT
M
T
AINTENANCE
SCU
craft port
Interface cable
Figure 3. Connect SCU Craft Port to Maintenance Terminal
Table 4. SCU Craft Port Pinouts
Pin
Name
2
Transmitted Data (TD)
3
Received Data (RD)
5
Frame Ground (FG)
7
Request to Send (RTS)
(a) Standard references for EIA/RS232 pinouts.
December 3, 2003
P
ORT
ERMINAL TO THE
(Table
3). The SCU Craft port is a DCE RS-232
S0073-A
chassis
Circuit
Source
CCITT
DTE
103
DCE
104
101
102
LTPS-UM-8054-01
I
NTERFACE
C
P
RAFT
ORT
Maintenance terminal
Serial COM port
Figure 4
for pinouts).
Circuit
EIA/RS
(a)
BA
(a)
BB
(a)
AA
(a)
AB
LPS-H4TU-C-L5
