Replacing the cartridge

• The cartridge must be replaced before it becomes completely saturated.
• The 'Q' on the top of the tank is the on / off switch.
• When installed with a Meter: If it is not possible to replace the cartridge when the alarm
sounds, you can temporarily snooze it (for 72 hours) by pressing the wheel on the Scale
Control Plus Meter.
1
3
2
4
Scale Control Plus
cartridge
Reduces limescale
Step 1 When alarm sounds, 0% blinks.
Step 2 Unscrew the old cartridge (counter
automatically.
Step 3 Screw in the new cartridge
(clockwise).
Step 4
The Scale Control meter is 100%.
Step 5 Run boiling water for 20 seconds.
Step 6 Check for leaks.
Operational data
Life span: 550L @ 15 dH
Max pressure: 8.6 bar
Temperature range: 2-38°C
Service and order: www.quooker.com
• Only to be connected to drinking water.
•
cartridge prior to use.
• Please dispose this cartridge with your
general waste.
1. Releasing the pressure
Turn off the tank using the Q button.
Activate boiling and cold water together
in order to release the pressure from the
system and then close it once again when
the water runs cold. Turn off the mains
water supply, or in case of a type B tank,
close the inlet combination isolation valve.
2. Replacing the cartridge
Detach the saturated cartridge by twisting
it out of the head and replace it with
a new one.
3. Flushing out the system
Turn on the mains water supply, or in
case of a type B tank, open the inlet
combination isolation valve. Ventilate the
system by activating the boiling water tap
and run for 20 seconds. Check for leaks.
Now activate the boiling function again and
let the water run for about 5 minutes, until
the water is once again clear. Turn on the
tank using the Q button. Once the water
has heated up again, the Quooker system
is ready to use.
4. When installed with a Meter: resetting
the Meter
Turn on the Meter by pressing the wheel
once. Turn the wheel to 'reset' and press
the wheel to confirm.
