Quooker Scale Control Plus Installation Manual page 11

5
7
A
Scale Control Plus
cartridge
Reduces limescale
Step 1 When alarm sounds, 0% blinks.
Step 2 Unscrew the old cartridge (counter
automatically.
Step 3 Screw in the new cartridge
(clockwise).
Step 4
The Scale Control meter is 100%.
Step 5 Run boiling water for 20 seconds.
Step 6 Check for leaks.
6
8
B
A
A
B
5. Mounting the inlet combination
Insert the inlet combination into the
bracket. Turn the screw on the top of the
bracket clockwise using the supplied Allen
key until the inlet combination is securely
attached.
6. Connecting the tube
Mount the provided push fit connection
using the insert on the T-piece. Then
connect plastic tube A to the push-fit.
7. Connecting the Scale Control Plus
Now connect plastic tube (A) to the head
of the Scale Control Plus. Make sure that
this is done in the right direction (see
the arrow on the head). Now connect the
second plastic tube (B) to the other side
of the head.
8. Flushing out the cartridge
Open the isolation valve or mains water
supply. Ventilate the system by activating
the boiling water tap and run for
20 seconds. Check for leaks. Now activate
the boiling function again and let the
water run for about 5 minutes, until the
water is once again clear. Turn on the tank
using the Q button. Once the water has
heated up again, the Quooker system is
ready to use (continue to section E).
