Noble House Home Furnishings SUN LOUNGER Assembly Instructions Manual

Hide thumbs Also See for SUN LOUNGER:

Caution: You must read this before you proceed

Please look on the Seat Panel for hardware packs

SUN LOUNGER

CAUTION: This Sun Lounger is NOT a TOY.

Keep your child / children at bay during the assembly process.

For moving the Sun Lounger and to prevent damage to the Sun Lounger, two adults may be

needed to execute this action.

Noble House Home Furnishings LLC

Table of Contents

Need help?

Do you have a question about the SUN LOUNGER and is the answer not in the manual?

Page 1 CAUTION: This Sun Lounger is NOT a TOY. Keep your child / children at bay during the assembly process. For moving the Sun Lounger and to prevent damage to the Sun Lounger, two adults may be needed to execute this action.
Page 2 Label Picture Description Seat Panel Leg Panel Cross Bar Cushion Label Picture Description ① Bolt (M8 x 40mm) ② Bolt (M6 x 45mm) ③ Washer ④ Allen Wrench Noble House Home Furnishings LLC...
Page 3 Before Beginning Assembly: Noble House Home Furnishings LLC...
Page 4 Seat Panel (A) This Sun Lounger has multiple parts and may require up to some 30 minutes to assemble. To give you an overview of the Sun Lounger parts, the above picture is to help you put the various parts into perspective. Please read through the instructions below to familiarise youself with the parts and steps before assembly.
Page 5 With the assistance from your adult partner, attach the Cross Bar (C) to the Seat Panel (A) and the Leg Panel (B) of the assembled part in Step 2 by using Bolt (②), Washer (③) and Allen Wrench (④) as shown above. Do not fully tighten the Bolts Noble House Home Furnishings LLC...
Page 6 Step 5 With assistance from your partner, stand the assembled part in Step 4 up. Place the Cushion (D) onto the Sun Lounger, then attach all 6 velcros of the Cushion (D) to the Seat Panel (A) as shown above.
Page 7 Noble House Home Furnishings LLC...
