Assembly Instructions

Sun Lounger

Caution: You must read this before you proceed

CAUTION: This Sun Lounger is NOT a TOY.

Keep your child / children at bay during the assembly process.

Whenever lifting / moving the Sun Lounger and to prevent damage to the Sun

Lounger,two adults are needed to execute these actions.

Noble House Home Furn i shings LLC

1/6

Page 1 CAUTION: This Sun Lounger is NOT a TOY. Keep your child / children at bay during the assembly process. Whenever lifting / moving the Sun Lounger and to prevent damage to the Sun Lounger,two adults are needed to execute these actions.
Page 2: Parts List
Parts List Picture Description Seat Panel with Foldable Legs Foldable Seat Cushion Hardware Picture Description Allen Key Bolt (M8*35mm) Washer (M8*2mm) Noble House Home Furn i shings LLC...
Page 3: Assembly Preparation
Foldable Seat Cushion (B) This Sun Lounger has multiple parts and may require up to 30 minutes to assemble. To give you anoverview of the Sun Lounger parts, the above picture is to help you put the various parts intoperspective.
Page 4 Unpack and place all parts on a clean, non-marring surface. Step 2 2.1) Place the Seat with Foldable Legs(A) facedown, on to a clean, non-marring surface. Lift Legs upwards and outwards until they lock into the Braces, as shown above. 2.2) Affix the Leg to the Brace using Bolt( ) and Washers( ) on both sides,...
Page 5 Step 3 Place Foldable Seat Cushion(B) onto the Sun Lounger. Lay the Sun Lounger down and tie the velcro straps of the Cushion(B) to the Seat Panel(A) as show above. Your Sun Lounger is ready for use. This Sun Lounger can only be used on a flat, level surface.
