Noble House Home Furnishings SOFA Assembly Instructions Manual
Hide thumbs
Also See for SOFA:
- Assembly instructions manual (10 pages) ,
- Assembly instructions manual (14 pages) ,
- Assembly instructions manual (11 pages)
Related Manuals for Noble House Home Furnishings SOFA
Summary of Contents for Noble House Home Furnishings SOFA
- Page 1 Assembly Instructions Caution: You must read this before you proceed SOFA Noble House Home Furnishings LLC Page 1 OF 10...
-
Page 2: Part List
Part List Label Picture Description Backrest Left Armrest Right Armrest Seat Left Seat Cushion Right Seat Cushion Back Cushion Iron Leg Middle Leg Noble House Home Furnishings LLC Page 2 OF 10... -
Page 3: Hardware List
Hardware List Label Picture Description Plastic Washer ① Bolt(M8*55) ② Flat Washer Ring ③ Spring Washer Ring ④ Bolt(M8*25) ⑤ Allen Wrench ⑥ Assembly Preparation Before Beginning Assembly: Noble House Home Furnishings LLC Page 3 OF 10... -
Page 4: Assembly Steps
FRONT FACING This Sofa has multiple parts and may require up to 60 minutes to assemble. To give you an overview of the Sofa parts, the above picture is to help you put the various parts into perspective. Please read through the instructions below to familiarise yourself with the parts and steps before assembly. - Page 5 Step 2 Seat(D) Left Armrest(B) Right Armrest(C) ③ ② ④ ⑥ Attach the Left Armrest(B) & Right Armrest(C) using Bolts(②),Spring Washer Rings(④),Flat Washer Rings(③) with the Allen Wrench(⑥), turning clockwise until tight. Noble House Home Furnishings LLC Page 5 OF 10...
- Page 6 Install the Iron Legs(H) to Left Armrest(B) using Bolts(⑤),Spring Washer Rings(④),Flat Washer Rings(③) with the Allen Wrench(⑥), turning clockwise until tight. Repeat the same process with the Right Armrest(C). Step 4 Seat(D) Middle Leg(I) ① Noble House Home Furnishings LLC Page 6 OF 10...
- Page 7 Seat(D) Stick the fabric to the Right Armrest Stick the fabric of the Seat(D) to the Right Armrest(C) and Left Armrest(B) as shown above. Step 6 Right Armrest(C) Left Armrest(B) Backrest(A) Noble House Home Furnishings LLC Page 7 OF 10...
- Page 8 Caution: Ensure that your fingers do not get caught or pinched in the assembly process. Step 7 Left Seat Cushion(E) Right Seat Cushion(F) Put the Left Seat Cushion(E) and the Right Seat Cushion(F) on the sofa. Step 8 Back Cushion(G) Noble House Home Furnishings LLC...
- Page 9 Place the Back Cushions(G) on the sofa. Step 9 Your Sofa is ready for use. This Sofa can only be used on a flat, level surface. Noble House Home Furnishings LLC Page 9 OF 10...
- Page 10 Noble House Home Furnishings LLC Page 10 OF 10...
