EMS fireCell FC-179-002 Installation Manual

Wireless Sounder Weather Resistant Kit
Installation Guide
1 Supplied parts
Ensure that you have all of the required parts as detailed
below.
8
4
5
2
ITEM NO QTY
3 1/2 PAN POZI SCREW
1
2 1 PERSPEX MOUNTING PLATE
3 3 FLAT WASHER
4 1 WIRELESS MODULE (SOLD SEPARATELY)
5 1 LARGE O-RING (120 MM DIAMETER)
6 1 SMALL O-RING (90 MM DIAMETER)
1
7 RUBBER PLUG
8 1 SOUNDER VISUAL INDICATOR (SOLD SEPARATELY)
4 Fit the small o-ring
Fit the small o-ring (item 6) to the sounder / visual indicator.
Ensure the o-ring is spaced evenly around the lip of the
sounder / visual indicator.
©2022 EMS Ltd. All rights reserved.
7
6
PART DESCRIPTION
Part no
FC-179-002
2 Remove the sounder
Remove the sounder / visual indicator from the wireless
module by turning it anti-clockwise.
3 Fit the rubber plug
Fit the rubber plug (item 7) into the cavity on the sounder /
visual indicator.
3
1
5 Attach the sounder
Re-attach the sounder / visual indicator to the wireless
module.
Page 1 of 2
Product description
Wireless Sounder Weather Resistant Kit
TSD076-99 Iss 9 21/01/2022 AJM
