Wireless Sounder Weather Resistant Kit
Installation Guide
1 Supplied Parts
Ensure that you have all of the required parts as detailed
below.
8
4
5
2
ITEM NO QTY
1
3
1/2 PAN POZI SCREW
2
1
PERSPEX MOUNTING PLATE
3
3
FLAT WASHER
4
1
WIRELESS MODULE (SOLD SEPARATELY)
LARGE O-RING
5
1
SMALL O-RING
6
1
7
1
RUBBER PLUG
8
1
SOUNDER VISUAL INDICATOR (SOLD SEPARATELY)
4 Fit Small O-Ring
Fit the Small O-Ring (Item 6) to the top of the Wireless
Module.
©2015 EMS Security Group Ltd All rights reserved
7
6
PART DESCRIPTION
Part No
FC-179-002
2 Remove Sounder
Remove the Sounder / Visual Indicator from the Wireless
Module by turning it anticlockwise.
3 Fit Rubber Plug
Fit the Rubber Plug (item 7) into the cavity on the Sounder /
Visual Indicator.
3
1
5 Attach Sounder
Re-attach the Sounder / Visual Indicator to the Wireless
Module
Page 1 of 2
Product Description
Wireless Sounder Weather Resistant Kit
TSD076 Iss 7 10/02/2016 AJM
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for EMS FireCell FC-179-002
Summary of Contents for EMS FireCell FC-179-002
- Page 1 Fit the Small O-Ring (Item 6) to the top of the Wireless Re-attach the Sounder / Visual Indicator to the Wireless Module. Module ©2015 EMS Security Group Ltd All rights reserved Page 1 of 2 TSD076 Iss 7 10/02/2016 AJM...
- Page 2 Specification Regulatory Information Compatibility For use with FireCell Wireless Sounder and Manufacturer EMS Security Group Ltd. Technology House, Visual Indicator Variants. Herne Bay, Kent, CT6 8JZ, United Kingdom IP Rating IP55 Complies With BS EN 60529:2000 Dimensions 155mm (Ø) 12mm (D)
