User Menu USER MENU To set a function and its parameters, enter into USER MENU by pressing MENU key on the Control Panel. The 'USER MENU' screen is shown in exact at the right side. Press UP / DOWN key to move from one menu item to the next followed by START/ENTER key on the right side of the Control panel to confirm the selection.
2. COUNTING SPEED From the USER MENU, operator can select the piece counting “SPEED” by pressing numeric 2 key or UP / DOWN key. The machine offers five counting speed: 800 / 900 / 1000 / 1200 / 1500 NPM (Notes per Minute). In sub menu, press corresponding numeric key or UP / DOWN key to select your desire speed confirmed by START/ENTER key.
1. LOCK MENU To prevent accidental MODE switch, operator can disable the MODE key function under LOCK MENU as MODE LOCK While MODE LOCK is (ON), the MODE key (ON). becomes inactive. If operator wishes to change counting MODE, it will first require deactivating the MODE LOCK function to (OFF).
4. AUTO START When the AUTO function is turned ON, the machine automatically feeds and counts banknotes on the hopper, whereas in MANUAL mode, pressing START/ENTER key is required to start counting operation after banknotes are placed into the hopper. Note that machine is defaulted as "AUTO"...
8. DUAL USER SET DUAL-USER is a feature that allows one MiB-9 machine to be shared by two operators as User1 and User2. This feature is disable from factory by default, therefore if operator requires to activate this feature, enter into this Menu item from USER MENU and make your selection as "DUAL USER ON"...
START/ENTER key and exit from the menu by pressing [C]. 2. DOUBLE LEVEL: MIB-9 is equipped with a double detection sensor to prevent 2 banknotes to pass through as one. Appropriate Double sensitivity level as 10 [00-20] has been adjusted from factory, however, if it is necessary to trouble shoot double note error, trained operator or service-provide able to make slight adjustment of this level around default value.
UP() or DOWN() key. START/ENTER key must be pressed to confirm operator’s input and selection. 6. STATION ID SET Station ID represents a given No. for each MiB-9 machine and would appear on each print report. Select “6. STATION ID SET” to enter into this sub-menu and use numeric keys (1-9) to input your Station ID. Use () () key to scroll and START/ENTER key to confirm your input and save.
SERVICE MENU 1 There are ‘Service Menu1’ and ‘Service Menu2.’ ‘Service Menu1’ includes mainly the menu for adjusting Parameter of Sensors. How to enter ‘SERVICE MENU 1’ 7-1. Press: 9→MODE→ ***** To exit from the current function, press ‘9(menu)’ key and to move ‘SERVICE MENU2’, press ‘DISPLAY’...
1. ERROR STOP CTRL. ERROR STOP CTRL. Sometimes there is need to prevent from ERROR STOP ON ERROR STOP OFF stopping the machine even though some error is occurred when you test the machine. If you want to do this, select “ERROR STOP OFF”. But after the test, it must be restored to “ERROR STOP ON”...
3. SYSTEM REPORT Counting Report SYSTEM REPORT COUNTING REPORT In this mode, you can see the total S/W VERSION number of the counted notes and the rejected notes. S/W version You can check the version of S/W and Currency. 4.SET A/S CALL No. After the machine is turned on, A/S call no.
What is CALIBRATION CALIBRATION is to make a full swing reference waveform to read the full level of a signal. If the machine rejects too many notes, the system might not analyze the input of waveform. It is possible to make a standard waveform for the system. For more detail information, please refer to the “9_CALIBRATION”...
Page 15
If you activate ‘ machine will start REAL-TIME S/N PRINTING’ on, printing during the machine on the counting SAVE BMP TO USB SAVE BMP TO USB You can download banknote image data using USB drive. 1. SAVE BMP ON For more detail information, please refer to the 2.
SERVICE MENU 2 There are ‘Service Menu1’ and ‘Service Men2’ in Service Menu. ‘Service Menu2’ includes the menu to have a test for development or for repair. How to enter ‘SERVICE MENU 2’: 8-1. Press: 9(MENU)→MODE→ ***** →DISPLAY To exit from the current function, press ‘9(menu)’...
SENSOR TEST SENSOR TEST 1) LED TEST LED TEST Turn ON/OFF LED. HOPPER TEST IR sensors such as JP, SP, Hopper, Reject and Stacker SENSOR LOGIC TEST sensors are invisible using human eyes. You can check these DOUBLE LOGIC TEST lights using Phone camera.
Reject sensor is LEFT RIGHT covered FRONT 0 REAR REJECT F STACKER Stacker sensor is LEFT RIGHT covered FRONT 0 REAR REJECT F STACKER 4) DOUBLE LOGIC TEST With this menu, you can check the double level. DOUBLE TEST Before you select this mode, you need to check below: CH LEFT : Clean inside of the double sensors and the path of note.
SELECTOR TEST 1) Selector Stacker SELECTOR TEST RED LED light (on the right of Front OPE) should be 1. SELECTOR STACKER turned on and the Guide Selector should move to 2. SELECTOR REJECTOR lower pocket (stacker) direction. 2) Selector Rejecter RED LED light (on the right of Front OPE) should be turned off and the Guide Selector should move to upper pocket(Rejector) direction.
CALIBRATION What is Calibration? Calibration is to make a full swing reference waveform to read the full CALIBRATION level of a signal. If the machine rejects too many notes in Mixed Mode or in CF Detection Mode, the system might not analyze the input of waveform.
Page 21
CODE [*****] 9 MENU MODE SERVICE MENU1 CALIBRATION 1.ERROR STOP CTRL. REJECT DETAIL ON/OFF SYSTEM REPORT SET A/S CALL NO. MR & DOUBLE SET MACHINE S/N HOPPER 6. CALIBRATION SOLENOID 7. SENSOR SELECT 8. SYSTEM SETTING Check if ‘OK’ is displayed. Please wait approximately 5 seconds.
145 mm 62 mm 70 mm This side faces upward This side faces downward Shading sheet provided from AMROTEC should be used Prepare to have IR CALIBRATION WHITE Place IR SHADING SHEET Open Front Cover and Close Front Cover in the middle of Hopper brush the dust.
Page 23
CODE [ ***** ] 9 MENU MODE CALIBRATION SERVICE MENU1 1.ERROR STOP CTRL. REJECT DETAIL ON/OFF SYSTEM REPORT SET A/S CALL NO. MR & DOUBLE SET MACHINE S/N HOPPER 6. CALIBRATION SOLENOID 7. SENSOR SELECT 8. SYSTEM SETTING Wait. IR SHADING IR SHADING AVG UNI WAIT .
<UV CALIBRATION SHEET : UV CALIBRATION V1.0> 165 mm 75 mm Shading sheet provided from AMROTEC should be used. Before UV Calibration, put UV Calibration sheet inside Front cover as the below image. Open Front Cover and brush the dust.
Page 25
CODE [ ***** ] 9 MENU MODE CALIBRATION SERVICE MENU1 1.ERROR STOP CTRL. REJECT DETAIL ON/OFF SYSTEM REPORT SET A/S CALL NO. MR & DOUBLE SET MACHINE S/N HOPPER 6. CALIBRATION SOLENOID 7. SENSOR SELECT 8. SYSTEM SETTING Shading sheet is pushed out. Wait.
9-4. MR & DOUBLE CALIBRATION <Use US$ 1 Real Banknote> Needed Good quality of 1~5 notes. (Don’t use Tapped note or damaged notes) CODE [*****] 9 MENU MODE SERVICE MENU1 CALIBRATION 1.ERROR STOP CTRL. REJECT DETAIL ON/OFF SYSTEM REPORT SET A/S CALL NO. MR &...
Page 27
Place 1~5 pcs of Sheet on the Hopper. Place the sheets in the middle of the Hopper like the picture. MR CALIBRATION PLACE CALIBRATION PAPER ON HOPPER Check The note is sent to Stacker. if ‘OK’ is displayed. MR SHADING Norm: 1.50 Noise: Level: 294(High) (5)
9-5. HOPPER CODE [*****] 9 MENU MODE SERVICE MENU1 CALIBRATION 1.ERROR STOP CTRL. REJECT DETAIL ON/OFF SYSTEM REPORT SET A/S CALL NO. MR & DOUBLE SET MACHINE S/N HOPPER 6. CALIBRATION SOLENOID 7. SENSOR SELECT 8. SYSTEM SETTING Without any sheet on the hopper sensor, machine will display as below.
