MiB-9
File Name: FAQ_20191210_MIB09
Date: December 10, 2019
How to capture Banknote image data using MiB-9 Machine
Please be noted that banknote image sampling is required time to time for us to improve banknote recognition
software or counterfeit detection software and require sampling from our customers. This process only be
performed by connecting both Machine and PC to LAN Port (RJ45 connector). You can purchase this type of
cable from any hardware store or Amazon.
For this process, you would require our software "VolX" which you would find in our Dealer Login Section
under MiB-9 product section. Password to enter into this section is [55757]. Once you have downloaded this
software onto your PC (desktop or a known folder), please perform the steps below to connect the software with
MiB-9 machine.
First, you need to connect your MiB-9 with your PC using RJ45 connector (LAN Port). Please follow the
steps below:
1. Enter into network connectionsÎ
Î Ethernet on your PC as illustrated belowÎ
Î Î
2 Pocket Discriminator
Product Support
Î
Î Î
Advertisement
Table of Contents
Related Manuals for Amrotec MiB-9
Summary of Contents for Amrotec MiB-9
- Page 1 PC (desktop or a known folder), please perform the steps below to connect the software with MiB-9 machine. First, you need to connect your MiB-9 with your PC using RJ45 connector (LAN Port). Please follow the steps below: 1.
- Page 2 2. Right click “Ethernet: Unidentified network” and click on “Properties”Î Î Î Î 3. Find and click “Internet protocol Version 4 (TCP/IPv4)” then click PropertiesÎ Î Î Î...
- Page 3 Î Step #1: [Selection of Proper settings on MiB-9] 1) First, make sure that MiB-9 machine is connected to the PC using RJ45 connector (LAN Port) as described in above steps 1-6. 2) Once properly connected through proper cable, please select correct image settings options on the machine in order for capturing correct images required for banknote data sampling.
- Page 4 4) Once you are on this 1. Image Down Setting sub-menu item, press START/ENTER key to reach to next sub-menu item for type of selection. You need to choose any of the option below according to the requirement of sampling whether to capture data for genuine rejected banknotes or suspect banknotes. The below are the choices and explanation for each of the selections to choose from ÎÎÎ...
- Page 5 1-3. IMAGE DOWN ALL => This menu item is for downloading both No.1 and No.2 above at the same time. 1-4. STACKER MODE => This menu item is used when developing of newly released / issue banknotes denominations or developing a new currency software.
- Page 6 VolX 1.9 Software For IP selection matching with MiB-9 IP address shown on the MiB-9 3. Once IP address is selected on the Volx 1.9 Version software and machine is connected to the software, then, follow below steps: a) Create a folder in advanced on your desktop or C: where you can easily locate it after.
- Page 7 Please zip the folder and email us the zip file for our data processing and software improvement or development. Please contact "AMROTEC" service dept as below if you need assistance on how to connect your MiB-9 to your PC and perform sampling of banknotes image data for software improvement (if needed).
