Joab EcoDrive Manual

There is a serious risk of injury or death when operating or working on a vehicle with a snow plough. This is
particularity important to bare in mind when the Automatic plough up function is activated. The ploughs are
automatically retracted when the vehicle is put into reverse gear. Make sure there are no persons near the ploughs
when operating the vehicle or ploughs.

Operate the Plough

1. Turn the PTO off.
2. Press the right arrow directional button on the CBW
controller to open the snow plough page
NOTE: if it is not possible to select the snow plough
page, as described above, see section 5 below.
3. Push the control-stick forward to lower the front snow
plough. To lower the side plough, press the top button
on the top of the control-stick.
4. Operate the ploughs, as required, in accordance with
Table 1 below.
Table 1: Control stick functions
Side plough
OUT
Side plough
DOWN
Front plough
DOWN
Quick Reference Guide | EcoDrive - Snow Plough Operation | 1021128 Edition 1 | 2021-04-28
EcoDrive - Snow Plough Operation
.
Side plough
IN
Side plough
UP
Front plough
UP
Front plough
LEFT

Plough Icon Definitions

The following table lists the icons available in the snow
plough page setup.
Table 2: Plough Icon Definitions
Icon Description
Slush flap*
Float mode - Plough
Automatic Plough UP
on reverse
* Option
Slush Flaps - If installed, this activates a set of rubber
flaps that are lowered below the bottom edge of the snow
plough blade and are used to scrape slush from the road.
Float Mode - see float mode below.
Automatic Plough UP on reverse - when activated, the
front and the side plough are retracted whenever the
vehicle is put into reverse gear.
Plough work lights - when activated, the right lower work
lighting on the vehicle is lit.
Salt Spreader - see salt spreader below.

Float Mode

Float mode allows the front plough to follow undulations in
the road surface. The plough can move up and down.
Front plough
RIGHT
Icon Description
Plough work lights*
Salt spreader - fixed*
Salt spreader - LS*
Page 1 of 2
