Quick-Setup Glass
and Metal TV Stand
NS-MG1158
Before using your new product, please read these instructions to prevent any damage.
PACKAGE CONTENTS: PARTS.....................................3
PACKAGE CONTENTS: HARDWARE..........................4
ASSEMBLY INSTRUCTIONS.........................................5
CARE AND MAINTENANCE...................................... 11
USER GUIDE
Advertisement
Related Manuals for Insignia NS-MG1158
Summary of Contents for Insignia NS-MG1158
-
Page 1: Table Of Contents
USER GUIDE Quick-Setup Glass and Metal TV Stand NS-MG1158 SAFETY INFORMATION AND SPECIFICATIONS..2 PACKAGE CONTENTS: PARTS........3 PACKAGE CONTENTS: HARDWARE......4 ASSEMBLY INSTRUCTIONS.........5 CARE AND MAINTENANCE........11 Before using your new product, please read these instructions to prevent any damage. -
Page 2: Safety Information And Specifications
Keep these items away from young 48.75 × 10 × 18" (123.82 × 24.5 × 45.72 cm) children! Bottom shelf (W × H × D): Model #: NS-MG1158 42.75 × 10.13 × 17.13" (108.58 × 25.73 × 43.51 cm) 20" (50.8 cm) 38" (96.52 cm) 58"... -
Page 3: Package Contents: Parts
QUICK-SETUP GLASS AND METAL TV STAND PACKAGE CONTENTS: PARTS A Stand body(1) C Middle glass shelf (1) D Bottom glass shelf (1) B Top glass shelf (1) Rear support bar (1) www.insigniaproducts.com... -
Page 4: Package Contents: Hardware
QUICK-SETUP GLASS AND METAL TV STAND PACKAGE CONTENTS: HARDWARE Note: You may receive extra hardware. Make sure you have all the hardware necessary to assemble your new TV stand: Label Hardware Qty. Label Hardware Qty. Large thumbscrew T-shaped shelf lock Medium thumbscrew Locking peg... -
Page 5: Assembly Instructions
QUICK-SETUP GLASS AND METAL TV STAND ASSEMBLY INSTRUCTIONS Step 1: Unfolding the stand body. • Unfold the stand body (A), then insert and tighten two large thumbscrews (E) into the right side of the rear panel. You’ll need: www.insigniaproducts.com... - Page 6 QUICK-SETUP GLASS AND METAL TV STAND Step 2: Attach the rear support bar 1 Attach the rear support bar (J) to the top metal frame with the medium thumbscrew (K). 2 Insert the two locking pegs (F) into the bottom side of the top glass shelf (B). You’ll need: K (1) F (2)
- Page 7 QUICK-SETUP GLASS AND METAL TV STAND Step 3: Mounting the top shelf • Turn the top shelf over and align the locking pegs with the holes in the top of the back support frame and align the metal pegs with holes in the side of the frame. Lock the locking pegs in place by rotating the peg heads to face the back.
- Page 8 QUICK-SETUP GLASS AND METAL TV STAND Step 4: Securing the top shelf 1 Secure the top shelf to the steel frame with the small thumbscrews (G) and attach two rubber shelf pads (H). 2 Insert two large suction cups (L) and three small suction cups (M). You’ll need: G (2) H (2)
- Page 9 QUICK-SETUP GLASS AND METAL TV STAND Step 5: Installing the middle and bottom shelves • Install the remaining shelves (C and D). Lock the middle shelf (C) into place with the T-shaped shelf lock (I). You’ll need: I (1) www.insigniaproducts.com...
- Page 10 QUICK-SETUP GLASS AND METAL TV STAND Step 6: Installing the optional tipping restraint • Install the tipping restraint hardware by removing the top thumbscrew, placing the loop on the tipping restraint over the thumbnail screw hole, then replacing the thumbscrew. You’ll need: Phillips screwdriver Drill...
-
Page 11: Care And Maintenance
QUICK-SETUP GLASS AND METAL TV STAND CARE AND MAINTENANCE Glass • Use a commercial liquid glass cleaner and a soft cloth. • Do not use harsh powders or any other abrasive substances as they will scratch the glass. WARNING Please use your stand correctly and safely. Improper use can cause safety hazards or damage to your furniture or household items. Carefully read the following chart. - Page 12 QUICK-SETUP GLASS AND METAL TV STAND www.insigniaproducts.com...
- Page 13 FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN Insignia and are not returned to you. If service of Products or DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE AND parts are required after the Warranty Period expires, you must NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, WILL APPLY pay all labor and parts charges.
- Page 14 4. Date of Manufacture: _______________ Lot number: 1-877-467-4289 (U.S. and Canada) or 01-800-926-3000 (Mexico) www.insigniaproducts.com INSIGNIA is a trademark of Best Buy and its affiliated companies. Registered in some countries. Distributed by Best Buy Purchasing, LLC 7601 Penn Ave South, Richfield, MN 55423 U.S.A.
