INSTALLATION GUIDE

Fixed-Position Wall Mount
for TVs 19–39 in.
NS-HTVMFAB
Before using your new product, please read these instructions to prevent any damage.

Advertisement

Table of Contents
loading

Related Manuals for Insignia NS-HTVMFAB

Summary of Contents for Insignia NS-HTVMFAB

  • Page 1: Installation Guide

    INSTALLATION GUIDE Fixed-Position Wall Mount for TVs 19–39 in. NS-HTVMFAB Before using your new product, please read these instructions to prevent any damage.

  • Page 2: Safety Information And Specifications

    Customer Service or call a qualified contractor. Insignia is not responsible for damage or injury caused by incorrect installation or use. CAUTION: Do not exceed the maximum weight indicated. This mounting system is intended for use only with the maximum weights indicated.

  • Page 3: Tools Needed

    FIXED-POSITION WALL MOUNT FOR TVs 19-39 in. Tools needed You will need the following tools to assemble your new TV wall mount: ardware Pencil Edge-to-edge Socket wrench with 1/2 in. stud finder (13 mm) socket or adjustable wrench 7/32 in. (5.5 mm) wood drill bit (for wood stud wall) Phillips screwdriver 3/8 in.

  • Page 4: Tv Hardware Bag

    TV Hardware Bag Label Hardware Qty. Label Hardware Qty. M4 × 12 mm screw M4 washer M6 × 12 mm screw M6/M8 washer M8 × 20 mm screw Spacers M4 × 35 mm screw Lag bolt washer M6 × 35 mm screw 5/16 in.

  • Page 5: Installation Instructions

    FIXED-POSITION WALL MOUNT FOR TVs 19-39 in. Installation instructions STEP 1 - Determining whether your TV has a flat back or an irregular or obstructed back Carefully place your TV screen face-down on a cushioned, clean surface to protect the screen from damages and scratches.
  • Page 6 STEP 2 - Select screws, washers, and spacers Select the hardware for your TV (screws, washers, and spacers). A limited number of TVs come with mounting hardware included. (If there are screws that came with the TV, they are almost always in the holes on the back of the TV.) If you don't know the correct length of the mounting screws your TV requires, test various sizes by hand threading the screws.
  • Page 7 FIXED-POSITION WALL MOUNT FOR TVs 19-39 in. STEP 3 - Option 1: Attaching the mounting hardware to TVs with a flat back Align the left and right TV brackets (01) with the screw holes on the back of the TV. Make sure that the brackets are level.
  • Page 8 STEP 3 - Option 2: Attaching the mounting hardware to TVs with irregular or obstructed backs Place spacers (09) over the screw holes on the back of the TV. Align the left and right TV brackets (01) with the screw holes on the back of the TV. Make sure that the brackets are level.
  • Page 9 FIXED-POSITION WALL MOUNT FOR TVs 19-39 in. STEP 4 - Determine wall-mount location Note: • For more detailed information on determining where to drill your holes, visit our online height-finder at: http://mf1.bestbuy.selectionassistant.com/index.php/heightfinder • Your TV should be high enough so your eyes are level with the middle of the screen. This is normally 40 to 60 in.
  • Page 10 STEP 5 - Option 1: Installing on a wood stud* wall Note: Any drywall covering the wall must not exceed 5/8 in. (16 mm). Locate the stud. Verify the center of the stud with an edge-to-edge stud finder. Align the center of the wall plate template (R) at the height (a + b) you determined in the previous step, make sure that it is level, then tape it to the wall.
  • Page 11 FIXED-POSITION WALL MOUNT FOR TVs 19-39 in. STEP 5 - Option 2: Installing on a solid concrete or concrete block wall (requires Concrete Installation Kit CMK1) CAUTION: To prevent property damage or personal injury, never drill into the mortar between the blocks.
  • Page 12 STEP 6 - Mounting the TV to the wall plate If the locking screws (S) cover the bottom holes of the TV brackets (01), unscrew them until the holes are clear. Holding the TV with the top of the screen tilted toward the wall, slide the upper notches of the right and left TV brackets (01) over the upper lip of the wall plate (10).
  • Page 13 FIXED-POSITION WALL MOUNT FOR TVs 19-39 in. Securing the TV to the wall plate • Tighten the locking screws (S) with a Phillips screwdriver until they contact the wall plate (10). To remove the TV from the wall plate, unscrew the locking screws, then pull the bottom away from the wall and lift the assembly off the wall bracket.

  • Page 14: One-Year Limited Warranty

    Insignia and are not returned to you. If service of Products or parts are required after the Warranty Period expires, you must pay all labor and parts charges. This warranty lasts as long as you own your Insignia Product during the Warranty Period.

  • Page 15: What Does The Warranty Not Cover

    REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS YOUR EXCLUSIVE REMEDY FOR BREACH OF WARRANTY. INSIGNIA SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR THE BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT, INCLUDING, BUT NOT LIMITED TO, LOST DATA, LOSS OF USE OF YOUR PRODUCT, LOST BUSINESS OR LOST PROFITS.
  • Page 16 Part Number: 6907-302035 www.insigniaproducts.com 1-877-467-4289 (U.S. and Canada) or 01-800-926-3000 (Mexico) INSIGNIA is a trademark of Best Buy and its affiliated companies. Distributed by Best Buy Purchasing, LLC 7601 Penn Ave. South, Richfield, MN 55423 U.S.A. ©2020 Best Buy. All rights reserved.
