Machine description – quick overview
Rear view / side view from left
Item Symbol
1
2
3
4
5
6
7
8
9
10
11
12
18
Description 0
Power source welding current connector plug
Welding current connection between power source and wire feeder
Connection thread - G¼"
Shielding gas connection (inlet)
7-pole connection socket (digital)
• Control lead for wire feed unit
Quick connect coupling (red)
coolant return
Quick connect coupling (blue)
coolant supply
Wire spool protective cap
Wire spool holder
Wire feed unit
Lighting, inside
Push-button gas test / rinse hose package > see 5.2.1 chapter
Wire inching push-button
For potential- and gas-free inching of the wire electrode through the hose package to
the welding torch.
Protective cap, wire feed mechanism
On the inside of the protective cap the welding task lists (JOB-List) for the relevant
welding machine series can be found.
