Degelman STRAWMASTER X Quick Start Manual

QUICK-START GUIDE
STRAWMASTER
for
* Refer to operators manual for complete safety and operation info.
A
Connect Hydraulics
B
Backing Into Field Position
Note: Ensure there is plenty of room behind
and to the sides of the Strawmaster
before backing into field position.
1) 1)
ENSURE jacks are raised prior to backing up.
2) 2)
REMOVE transport pins/bars and store.
1) 1)
6
2) 2)
3) 3)
SLIGHTLY open the transport wheels. (Only 20°)
1)
Raise hydraulic jack
6
2)
Remove the front Center Beam Transport Pins (2),
Cylinder Lock Bars (2), and Endwheel Transport Bars (2)
and place in storage locations.
Transport Pin Transport Pin
Store Store
Store Store
Cylinder Cylinder
Lock Lock
3)
Activate the steering cylinders to slightly angle open the
transport wheels, but no more than 20º.
4)
Back-up slowly. The wings will open up. Ensure there is lots of
room behind and to the sides. Back-up evenly so you don't
damage the transport wheels.
IMPORTANT: Be sure to back-up evenly to avoid
serious damage to the transport wheels.
*
X
WHEELS............................
1
TRANSPORT.....................
2
DISCS................................
3
TINE ANGLE.....................
4
LATCH & ENDWHEEL......
5
IMPORTANT: Before working in field, lock the function to avoid accidental operation.
JACK..................................
6
2) 2)
4) 4)
BACK-UP SLOWLY/EVENLY to avoid
5
3) 3)
serious damage to transport wheels.
5) 5)
FULLY ROTATE end wheels
BEFORE latching truss arm clamps.
after connecting to the tractor.
Store Store
Remove Remove
Remove Remove
5
REMEMBER! You must complete Product
Registration to be eligible for Warranty.
5) 5)
5
6) 6)
5
6) 6)
5
5
5)
As wings are almost fully opened, FULLY ROTATE the end
wheels into field position BEFORE completely open.
Transport Transport
Bar Bar
Remove Remove
6)
Activate the LATCH hydraulics to fully secure the truss arms
into place. Make sure truss arm LATCHES ARE FULLY
ENGAGED before lowering harrow sections into field position.
IMPORTANT: To prevent serious damage, ensure both
latches have fully engaged and then LOCK-OUT
the Latch & Endwheel circuit before operating.
7)
Ensure the TRAILER HEIGHT is raised to MAXIMUM
then lower the harrow sections into field position using the
Transport Cylinders.
8)
Lower the disc sections using the Disc Cylinders.
9)
Adjust Tine Angle, Trailer Height
and Disc settings.
WARRANTY
Wheel Height Cylinders
Transport Cylinders
Disc Cylinders
Harrow Section Cylinders
Latch/Steering Cylinders
Jack Cylinder
4
4
4
1
7) 7)
1
7) 7)
2
7) 7)
5) 5)
5
6) 6)
Make sure truss arm LATCHES
FULLY ENGAGED before lowering
harrow sections
7) 7)
When lowering harrow sections, keep
TRAILER HEIGHT
8) 8)
Lower disc sections.
Open Open
2
9) 9)
4
4
4
4
1
7) 7)
8) 8)
3
ARE
5
into field position.
2
AT MAXIMUM.
1
3
5
Closed Closed
5
and
1
3
143437 v0.1
