  • Page 1 DMS 2400 (MK3) Service EN REV 1.0.0 | 2022-02-23...
  • Page 2 All trademarks identified by ® are registered trademarks of Dallmeier. Third-party trademarks are named for information purposes only. Dallmeier respects the intellectual property of third parties and always attempts to ensure the complete identification of third- party trademarks and indication of the respective holder of rights.

  • Page 3: Table Of Contents

    Mainboard Battery 6 Commissioning and Local Login Local Login Remote Login 7 Licenses 8 Updates 9 System Parameters 10 HDDs Identify Replace 11 Cleaning 12 Filter Mat SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...

  • Page 4: Validity

    Keep all documents in legible condition and in a suitable location for future reference. Regularly check the website www.dallmeier.com for the latest updates to the product documentation. SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...

  • Page 5: This Document

    The document “Commissioning” contains detailed descriptions on installa- tion, connection and commissioning of the device as well as safety instruc- tions and general notes. The target audience of this document is trained system integrators. SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...

  • Page 6: Typographical Conventions

    (buttons, menu items). Paragraphs in italics provide information on basic principles, special features and efficient procedures as well as general recommendations. SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...

  • Page 7: Safety Instructions

    Do not make any modifications to the hardware or software that have not been tested and approved by Dallmeier. Inappropriate modifications may cause malfunctions, damages and data loss and may result in the loss of warranty. SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
  • Page 8 DIN, VDE and ISO standards and which provide for a standard-compliant lightning protection equipotential bonding, are mandatory and must be fulfilled by all means. SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
  • Page 9 Do not dispose waste electrical and electronic equipment into the household trash. Disconnect the device from the power supply. Remove all connected devices. Return the device to your respective sales partner. SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...

  • Page 10: General Notes

    24 high-resolution video streams at a frame rate of 30 fps. This makes the appliance ideally suited for video security systems in stores, gas stations or private homes that require the highest recording quality in a small foot- print. SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...

  • Page 11: Approvals/Certifications

    Injury due to explosion hazard! ➡ Replace the battery on the main board always by a battery of the same type. ➡ Dispose of used batteries according to the present instructions. SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...

  • Page 12: Commissioning And Local Login

    The definition of passwords and network parameters is necessary for remote access with Dallmeier Client Software. ➡ Drag the mouse pointer to the lower screen edge. The task bar with the Login button is displayed. SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
  • Page 13 ➡ Click the Login button. ➡ Click Later to login without changing a password. The configuration interface is displayed. ➡ Refer to the corresponding “Configuration” document. SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...

  • Page 14: Remote Login

    ➡ Start the NetConfig3 function over the context menu. The connection is established and device information is displayed. ➡ Enter the serial number (e.g. DAV8-12345678) as the Password. ➡ Confirm with Login. SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
  • Page 15 If the Slow Network check-box is activated, the configuration interface is compressed for narrowband connections before transmission, . ➡ Refer to the corresponding “Configuration” documentation. SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...

  • Page 16: Licenses

    After the activation of features and functions, a restart of the appliance is recommended. ➡ Open the Licenses dialog via Setup > System > Info > Licenses. SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
  • Page 17 ➡ Make sure that the feature or function is selected as active. ➡ Check the functionality of the feature or function. More settings might be required under certain circumstances. SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...

  • Page 18: Updates

    An appliance with maintenance licenses for the first two years can also be updated in the third year when the update was released before the expirati- on of the license for the second year. SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
  • Page 19 ➡ Make sure that the appliance is not switched off during the perfor- mance of the update or restart. Note that a reboot of the appliance can be triggered by an unstable SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
  • Page 20 While the update is performed, no settings or adjustments should be made. The storage medium should be removed only after the full completion of the update (restart). SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...

  • Page 21: System Parameters

    ➡ Open the System Parameters dialog via System > System Parameters > Default. ➡ Click OK. The default system parameters will be restored. Export Parameters The system parameters can be exported. After export they can be archived SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
  • Page 22 ➡ Inappropriate or incorrectly modified system parameters can lead to the loss of recordings and a permanent system fault. ➡ Open the Restore Configuration dialog via System > System Parameters > Restore Configuration. SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
  • Page 23 ➡ Select the required storage medium as a Source. ➡ Select the relevant import option. ➡ Finally, click OK in order to start the import. The saved system parameters will be restored. SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...

  • Page 24: 10 Hdds

    10 HDDs The SMAVIA appliance DMS 2400 (MK3) can be operated with 2 hard disks. Proceed as described below in order to replace a defective hard disk drive. NOTICE No Hot-Plug or Hot-Swap! ➡ Only replace HDDs in a service case.
  • Page 25 ➡ Identify the defective hard disk drive. Display Status messages of the hard disk drives are also displayed on the screen at the front of the appliance: SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
  • Page 26 After replacing the hard disk drive, all tracks have to be initialized and in this process all recordings will be lost. The settings of the device are completely preserved. SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
  • Page 27 During the initialization of the tracks all recordings are deleted. ➡ Log on to the configuration interface as described above. ➡ Open the hard disk Management dialog via Setup > Recording > HDD Management. SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
  • Page 28 Rec column. The initialization of the hard disk drives and the construction of the tracks will start automatically. It must be made no further adjustments. SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...

  • Page 29: Replace

    No Hot-Plug/Hot-Swap possible: Risk of damage and loss of data ➡ Only replace HDDs for service purposes. ➡ Identify the defective hard disk drive as described above. ➡ Unlock the HDD drawer unit with the key. SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
  • Page 30 ➡ Remove the cover panel mounted on the HDD drawer unit. CAUTION Risk of injury from sharp edges! ➡ Use care when installing the HDD drawer unit. ➡ Remove the 4 screws. SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
  • Page 31 ➡ Insert the HDD drawer unit into the guide rail. ➡ Slide the HDD drawer unit carefully and completely into the housing. ➡ Make sure not to cant. ➡ Do not use any force. SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
  • Page 32 ➡ Make sure the HDD drawer unit and the housing are flush. ➡ Lock the HDD drawer unit with the key. The new hard disk drive is initialized as described above. SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...

  • Page 33: Cleaning

    ➡ Clean the housing (outside) with a soft, dry and anti-static dust cloth. ➡ Remove dust deposits on the vent openings by gentle suction if required. SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...

  • Page 34: 12 Filter Mat

    A system message displays at the time of the change of the filter mat. Replacing the filter mat ➡ Open the front cover of the appliance. ➡ Remove the old filter mat. ➡ Insert the new filter mat. SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
  • Page 35 Open the configuration interface of the appliance as described above. Open the Service Settings dialog via Setup > System > Service > Settings. ➡ Click Changed Filter Mat. ➡ Close the dialog with OK. SERVICE – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
