- Page 1 DMS 2400 (MK3) COMMISSIONING 008496 | REV 1.0.0 | 2022-01-24...
- Page 2 All trademarks identified by ® are registered trademarks of Dallmeier. Third-party trademarks are named for information purposes only. Dallmeier respects the intellectual property of third parties and always attempts to ensure the complete identification of third- party trademarks and indication of the respective holder of rights.
-
Page 3: Table Of Contents
9 HDD Mounting 10 Connections and Status 11 Commissioning and Local Login Commissioning Local Login 12 Commissioning and Remote Login Commissioning Remote Login 13 Specifications 14 Maintenance COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier... -
Page 4: Validity
Keep all documents in legible condition and in a suitable location for future reference. Regularly check the website www.dallmeier.com for the latest updates to the product documentation. COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier... -
Page 5: This Document
Service The “Service” document contains detailed information on how to maintain the appliance. The target audience of this document is trained video security system inte- grators. COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier... -
Page 6: Typographical Conventions
(buttons, menu items). Paragraphs in italics provide information on basic principles, special features and efficient procedures as well as general recommendations. COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier... -
Page 7: Safety Instructions
Do not make any modifications to the hardware or software that have not been tested and approved by Dallmeier. Inappropriate modifications may cause malfunctions, damages and data loss and may result in the loss of warranty. COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier... - Page 8 DIN, VDE and ISO standards and which provide for a standard-compliant lightning protection equipotential bonding, are mandatory and must be fulfilled by all means. COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
- Page 9 Do not dispose waste electrical and electronic equipment into the household trash. Disconnect the device from the power supply. Remove all connected devices. Return the device to your respective sales partner. COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
-
Page 10: General Notes
The device should only be shipped in the original packaging. If the original packaging is no longer available, ensure that the used packaging sufficiently protects the device against damage, moisture, heat and cold. COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier... -
Page 11: Warranty
The following approvals/certifications were valid for the device at the time of this document’s compilation: • CE / UKCA • • DIN EN 50130-4 Visit www.dallmeier.com for possible updates. COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier... -
Page 12: Requirements
US fire protection regulation “Standard for Protection of Electronic Computer/Data Processing Equipment, ANSI/NFPA 75”. Secured room Risk of manipulation and sabotage. A stand-alone installation should only be operated in secured rooms with restricted access. COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier... - Page 13 Socket outlet The used socket outlet has to be installed near the DMS 2400 MK3 appli- ance. It has to be easily accessible. Secure Earthing ➡ Ensure a proper grounding at all times, preferably by grounding the rack directly. Power Supply ➡...
-
Page 14: Dimensions
➡ Ensure that sufficient air circulation is provided at the place of installation for proper cooling of the DMS 2400 (MK3) appliance. ➡ Put the DMS 2400 (MK3) appliance top-down on a stable, nonslip sur- face. COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier... -
Page 15: Hdd Mounting
➡ Only replace HDDs for service purposes. ➡ Start with the mounting of the hard drive in the HDD bay 1 (back side, left bay). ➡ Mount the hard drives in a sequentially. COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier... - Page 16 HDD tray. ➡ Ensure that HDD and HDD tray are flush at the rear side. ➡ Mount the HDD tray on the HDD with 4 screws. COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
- Page 17 Depending on the number and properties of the mounted hard disk drives, various messages and dialogs are displayed during the first start and the initialization COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
- Page 18 ➡ Confirm the messages if required. ➡ Observe the instructions given in the dialogs. ➡ Note the appropriate “Configuration” documentation. ➡ Load the “Default System Parameters” as first step of the configuration. COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
-
Page 19: Connections And Status
LED Al. (Alarm) Orange The device is in Alarm Mode LED St. (Record) Green The device is recording LED Po. (Power) Blue The device is in operation COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier... - Page 20 USB 3.0, Type A Contact IN - Relay Out Weidmüller Socket, 16 Pins HDDs Up to two 3.5“ HDD Power Supply 115-230 V AC ±5%, 50/60 Hz COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
- Page 21 (galvanic isolation, max. 12 V DC / 24 V AC / 0.5 A, 150 mOhm as NC or N) Function Relay 1 Relay 2 9/11 Relay 3 13/15 Relay 4 COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
-
Page 22: Commissioning And Local Login
The definition of passwords and network parameters is necessary for remote access with Dallmeier Client Software. ➡ Drag the mouse pointer to the lower screen edge. The task bar with the Login button is displayed. COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier... - Page 23 ➡ Click the Login button. ➡ Click Later to login without changing a password. The configuration interface is displayed. ➡ Refer to the corresponding “Configuration” document. COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
-
Page 24: Commissioning And Remote Login
➡ Observe the “Operation” documentation for Dallmeier Device Manager. ➡ Select the device from the scanner list. ➡ Start the NetConfig3 function over the context menu. The connection is established and device information is displayed. COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier... - Page 25 ➡ Confirm with Login. The configuration interface is compressed for narrowband connections before transmission if the Slow Network check-box is activated. ➡ Refer to the corresponding “Configuration” documentation. COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
-
Page 26: Specifications
HTTPS encryption, SSL/TLS 1.2 (AES), network access control according to IEEE 802.1X Electrical Data Voltage supply 115-230 V AC ±5%, 50/60 Hz Power consumption Max. 50W Thermal output Approx. 171 BTU/h COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier... - Page 27 Dust-free Approvals and Certifications Type CE, UKCA, FCC, DIN EN 50130-4 Detailed technical data and possible updates can be found in the current „Specification“ document at www.dallmeier.com. COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
-
Page 28: Maintenance
If it becomes necessary to clean the device, observe the following notes: NOTICE Damage to the surface of the device ➡ Clean the housing (outside) with a soft, dry and anti static cloth. ➡ Do not use detergents. COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier... - Page 29 Notes COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
- Page 30 Notes COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
- Page 31 Notes COMMISSIONING – DMS 2400 (MK 3) | REV 1.0.0 | © 2022 Dallmeier...
- Page 32 HEADQUARTERS Dallmeier electronic GmbH & Co.KG Bahnhofstr. 16 93047 Regensburg Germany +49 941 8700-0 +49 941 8700-180 mail info@dallmeier.com www.dallmeier.com...
