Summary of Contents for dallmeier SeMSy iPS 10000
- Page 1 REV. 1.0.0 | 2021-03-11 SERVICE SeMSy Recording Server ® iPS 10 000 SOFTWARE VERSIONS 10.7.X...
- Page 2 Third-party trademarks are named for information purposes only. Dallmeier respects the intellectual property of third parties and always attempts to ensure the complete identification of third-party trademarks and indication of the respective holder of rights. In case that protected rights are not indicated separately, this circumstance is no reason to assume that the respective trademark is unprotected.
-
Page 3: Table Of Contents
Chapter 6: UpDate Maintenance License Implementation Chapter 7: SYSteM paraMeterS Default Parameters Export Parameters Import Parameters Chapter 8: hDDS Identify 1.1.1 Information Dialog 1.1.2 Display Procedure Exchange IPS 10 000 – Firmware Versions 10.7.X| REV. 1.0.0 | © 2021 Dallmeier... - Page 4 Chapter 9: pOWer SUppLY MODULeS Identify 1.1.1 Information Dialog 1.1.2 Display 1.1.3 Status LED Deactivation Exchange Chapter 10: MaINteNaNCe IPS 10 000 – Firmware Versions 10.7.X| REV. 1.0.0 | © 2021 Dallmeier...
-
Page 5: Chapter 1: Introduction
1.3.1 this Document This “Service” document contains detailed information on how to maintain the appliance. The target audience of this document is trained video security system integrators. IPS 10 000 – Firmware Versions 10.7.X| REV. 1.0.0 | © 2021 Dallmeier... -
Page 6: Other Applicable Documents
(button, check box, drop-down list, menu item, etc.). Paragraphs in italics provide information on basic principles, special features and efficient procedures as well as general recommendations. IPS 10 000 – Firmware Versions 10.7.X| REV. 1.0.0 | © 2021 Dallmeier... -
Page 7: Chapter 2: Safety Instructions
If the units are brought from a cold to a warm environment, resulting condensation water may cause malfunctions and damages. In this case, wait (up to 8 hours) until the units have reached room temperature before commissioning. IPS 10 000 – Firmware Versions 10.7.X| REV. 1.0.0 | © 2021 Dallmeier... - Page 8 Do not dispose waste electrical and electronic equipment into the household trash. Disconnect the units from the power supply. Remove all connected devices. Return the units to your respective sales partner. IPS 10 000 – Firmware Versions 10.7.X| REV. 1.0.0 | © 2021 Dallmeier...
-
Page 9: Chapter 3: General Notes
Dispose of used batteries according to the present instructions ▶ apprOVaLS/CertIFICatIONS At the time of the generation of this document, the device was certified als follows: • • • • IPS 10 000 – Firmware Versions 10.7.X| REV. 1.0.0 | © 2021 Dallmeier... -
Page 10: Chapter 4: Login
Move the mouse pointer to the bottom of the screen. ▶ Login button is displayed. Fig. 2-1 Click Login. ▶ The virtual keyboard is displayed. Enter the password. ▶ Confirm with OK. ▶ IPS 10 000 – Firmware Versions 10.7.X| REV. 1.0.0 | © 2021 Dallmeier... -
Page 11: Remote Login
▶ Scan the network. ▶ Select the required appliance. ▶ Open the context menu with a right-click. ▶ Click NetConfig3. ▶ The connection is established. Fig. 2-3 IPS 10 000 – Firmware Versions 10.7.X| REV. 1.0.0 | © 2021 Dallmeier... - Page 12 Click Login. ▶ The configuration interface is displayed. Fig. 2-4 Make the required settings (see below). ▶ Click Close in order to exit the configuration interface. ▶ IPS 10 000 – Firmware Versions 10.7.X| REV. 1.0.0 | © 2021 Dallmeier...
-
Page 13: Chapter 5: Licenses
Make sure that the feature or function is selected as active. ▶ Check the functionality of the feature or function. ▶ Note that more settings are required under certain circumstances. ▶ IPS 10 000 – Firmware Versions 10.7.X| REV. 1.0.0 | © 2021 Dallmeier... -
Page 14: Chapter 6: Update
The duration of the maintenance license is displayed in the software‘s info dialog and can be accessed via the network (PService3). Open the SW-Maintenance dialog via System > Info > Service. ▶ Fig. 4-1 IPS 10 000 – Firmware Versions 10.7.X| REV. 1.0.0 | © 2021 Dallmeier... -
Page 15: Implementation
While the update is performed, no settings or adjustments should be made. The storage medium should be removed only after the full completion of the update (restart). IPS 10 000 – Firmware Versions 10.7.X| REV. 1.0.0 | © 2021 Dallmeier... -
Page 16: Chapter 7: System Parameters
Open the System parameters dialog via System > System parameters > Default. ▶ Fig. 5-1 Click OK. ▶ The default system parameters will be restored. IPS 10 000 – Firmware Versions 10.7.X| REV. 1.0.0 | © 2021 Dallmeier... -
Page 17: Export Parameters
System parameters > Save Configuration. ▶ Fig. 5-2 Click Search..▶ Select the appropriate storage directory as target. ▶ Click OK. ▶ The system parameters will be exported. IPS 10 000 – Firmware Versions 10.7.X| REV. 1.0.0 | © 2021 Dallmeier... -
Page 18: Import Parameters
Select the required storage medium as a Source. ▶ Select the relevant import option. ▶ Finally, click in order to start the import. ▶ The saved system parameters will be restored. IPS 10 000 – Firmware Versions 10.7.X| REV. 1.0.0 | © 2021 Dallmeier... -
Page 19: Chapter 8: Hdds
HDD is not active and OK (RAID spare HDD) orange HDD is in recovery process (RAID) Check the status of the hard disk drives. ▶ Identify the defective hard disk drive. ▶ IPS 10 000 – Firmware Versions 10.7.X| REV. 1.0.0 | © 2021 Dallmeier... -
Page 20: Display
The capacity of a new HDD must be the same as the capacity of the replaced HDD (or larger). NOTICE possibility of data loss! Always replace a defective HDD with a HDD from the same production series with ▶ identical firmware. IPS 10 000 – Firmware Versions 10.7.X| REV. 1.0.0 | © 2021 Dallmeier... -
Page 21: Exchange
In order to exchange a defective hard disk drive, proceed as follows: NOTICE Data loss! In order to prevent data loss and damage to property observe the procedure described above. IPS 10 000 – Firmware Versions 10.7.X| REV. 1.0.0 | © 2021 Dallmeier... - Page 22 Remove the cover plate mounted in the HDD drawer unit. CAUTION risk of injury from sharp edges Use care when installing the HDD drawer unit ▶ Fig. 6-7 Remove the 4 screws. ▶ IPS 10 000 – Firmware Versions 10.7.X| REV. 1.0.0 | © 2021 Dallmeier...
- Page 23 Make sure the HDD drawer unit and the housing are flush. ▶ Lock the HDD drawer unit with the key. ▶ The new hard disk drive is initialized as described above. IPS 10 000 – Firmware Versions 10.7.X| REV. 1.0.0 | © 2021 Dallmeier...
-
Page 24: Chapter 9: Power Supply Modules
Select the power Supply tab. ▶ Fig. 7-1 grey Power supply unit is not mounted green Power supply is active and okay Power supply is defective/switched off IPS 10 000 – Firmware Versions 10.7.X| REV. 1.0.0 | © 2021 Dallmeier... -
Page 25: Display
The status of the power supply modules is also indicated by the green LED on the front of the module. Fig. 7-3 Green LED lights up Power supply module switched on and OK Green LED not lit Power supply module switched off or defective IPS 10 000 – Firmware Versions 10.7.X| REV. 1.0.0 | © 2021 Dallmeier... -
Page 26: Deactivation
Turn off the defective power supply module with the appropriate power switch. ▶ Remove the power cable. ▶ Fig. 7-5 Loose the screws at the top of the power supply module. ▶ IPS 10 000 – Firmware Versions 10.7.X| REV. 1.0.0 | © 2021 Dallmeier... - Page 27 Serious danger by electric shock Do not grip to the open shaft of the power supply module. ▶ Insert no tools in the open shaft of the power supply module. ▶ IPS 10 000 – Firmware Versions 10.7.X| REV. 1.0.0 | © 2021 Dallmeier...
- Page 28 Turn on the new power supply module with the appropriate power switch. ▶ The power supply module is put into operation automatically. The device is powered from the redundant power supply modules with equal parts of tension. IPS 10 000 – Firmware Versions 10.7.X| REV. 1.0.0 | © 2021 Dallmeier...
-
Page 29: Chapter 10: Maintenance
Damage to the surface of the device Clean the housing (outside) with a soft, dry and antistatic cloth. ▶ Do not use detergents. ▶ Do not use microfiber cleaning cloths. ▶ IPS 10 000 – Firmware Versions 10.7.X| REV. 1.0.0 | © 2021 Dallmeier... - Page 30 HEAD & ACCOUNTS OFFICE Dallmeier electronic GmbH & Co.KG Bahnhofstr. 16 93047 Regensburg Germany +49 941 8700 0 +49 941 8700 180 mail info@dallmeier.com www.dallmeier.com...
